IFM ANT513 Manuel utilisateur

Operating instructions

RF-identification system

ANT513

Read/write head

11458694 / 0005 / 2022

ANT513

Contents

1 Preliminary note ............................................................. 3

1.1 Symbols used.......................................................... 3

1.2 Warnings used ......................................................... 3

1.3 Legal and copyright information ............................................ 3

2 Safety instructions............................................................ 4

3 Intended use................................................................ 5

4 Items supplied............................................................... 6

5 Function ................................................................... 7

5.1 ID tags ............................................................... 7

5.2 Device overview........................................................ 7

6 Installation.................................................................. 8

6.1 Notes on the unit installation............................................... 8

6.2 Avoiding interference .................................................... 8

6.3 Mechanical design ...................................................... 8

6.4 Alignment of the sensing face.............................................. 9

6.5 Install device........................................................... 9

6.6 Mounting distances...................................................... 10

6.7 Positioning of the ID tag .................................................. 10

7 Electrical connection.......................................................... 12

7.1 Wiring................................................................ 12

8 Operating and display elements................................................. 13

9 Maintenance, repair and disposal................................................ 14

10 Approvals/standards.......................................................... 15

Glossary................................................................... 16

ANT513

1 Preliminary note

You will find instructions, technical data, approvals and further information using the QR code on the

unit / packaging or at www.ifm.com.

1.1 Symbols used

Requirement

Instructions

Reaction, result

[...] Designation of keys, buttons or indications

Cross-reference

Important note

Non-compliance may result in malfunction or interference.

Information

Supplementary note

1.2 Warnings used

ATTENTION

Warning of damage to property

1.3 Legal and copyright information

used without the consent of ifm electronic gmbh.

All product names, pictures, companies or other brands used on our pages are the property of the

respective rights owners.

ANT513

2 Safety instructions

General

• The unit described is a subcomponent for integration into a system.

– The system architect is responsible for the safety of the system.

– The system architect undertakes to perform a risk assessment and to create documentation in

accordance with legal and normative requirements to be provided to the operator and user of

the system. This documentation must contain all necessary information and safety instructions

for the operator, the user and, if applicable, for any service personnel authorised by the

architect of the system.

• Read this document before setting up the product and keep it during the entire service life.

• The product must be suitable for the corresponding applications and environmental conditions

without any restrictions.

• Only use the product for its intended purpose (Ò → Intended use).

• If the operating instructions or the technical data are not adhered to, personal injury and/or damage

to property may occur.

• The manufacturer assumes no liability or warranty for any consequences caused by tampering with

the product or incorrect use by the operator.

• Installation, electrical connection, set-up, operation and maintenance of the product must be

carried out by qualified personnel authorised by the machine operator.

• Protect units and cables against damage.

Radio equipment

In general, radio equipment must not be used in the vicinity of petrol stations, fuel depots, chemical

plants or blasting operations.

uDo not transport and store any flammable gases, liquids or explosive substances near the unit.

Interference of electronic and medical devices

Operation can affect the function of electronic devices that are not correctly shielded.

uDisconnect the device in the vicinity of medical equipment.

uContact the manufacturer of the corresponding device in case of any interference.

ANT513

3 Intended use

The read/write head reads and writes ID tags without contact. For use, the read/write head must be

connected to the DTE10x evaluation unit.

The data is converted into digitally coded values and provided to the evaluation unit.

ANT513

4 Items supplied

• Read/write head

• 2x hexagonal nut

The device is supplied without installation and connection accessories.

Available accessories: www.ifm.com.

The optimum function is not ensured when using components from other manufacturers.

ANT513

5 Function

5.1 ID tags

The ID tags are passively operated without a battery. The energy required for operation is provided by

the read/write head.

The energy is provided via an inductive coupling. The integrated antenna coil in the read/write head

generates a magnetic field which partly penetrates the antenna coil of the ID tag. A voltage is

generated by induction that supplies the data carrier with energy.

The device supports ID tags according to ISO 15693.

5.2 Device overview

Article number: ANT513

Function: Read/write head

Type designation: DTRHF MCRWIDUS03

Type: rectangular

ANT513

6 Installation

6.1 Notes on the unit installation

When mounting several RFID units adhere to the minimum distances between the systems.

Flush mounting of a read/write head in metal reduces the read/write distance.

Device performance can be affected if positioned in the immediate vicinity of powerful HF

emission sources such as welding transformers or converters.

6.2 Avoiding interference

The device generates a modulated electrical field with a frequency of 13.56 MHz.

Avoid interference with data communication:

uDo not operate any devices in the vicinity that use the same frequency band.

wSuch devices are for example frequency converters and switched-mode power supplies.

If there are other devices in the same frequency band in the vicinity:

uThe mounting distances between the devices should be as large as possible.

uUse the devices in alternating operation.

uSwitch the HF field of the device on/off.

6.3 Mechanical design

On delivery the sensing face is facing the front.

Fig.1: Factory setting

ANT513

Fig.2: Antenna head separated from the fixing element

1 Sensing face 2 Adjustable antenna head

3 Fixing element

6.4 Alignment of the sensing face

uLoosen the screw.

uRemove the antenna head from the fixing element and

turn it.

uAttach the fixing element to the antenna head.

uTighten the screw.

6.5 Install device

uFix the device with 2 M5 screws and nuts.

ANT513

Fig.3: Non-flush mounting

Fig.4: Flush mounting

6.6 Mounting distances

Operating mode Distance side (A) Distance front (B)

For reading and writing ≥ 300 mm ≥ 250 mm

6.7 Positioning of the ID tag

For installation in or on metal use the ID tags provided for this purpose.

uAlign the ID tag on the central axis of the antenna of the device.
