4
1. OLED Display
The OLED display shows current playback mode, format, sample rate, and the IP address of the
NEO Stream when available.
Tip: OLED screen should be on the left-hand side when NEO Stream is positioned horizontally, and at the top when positioned vertically.
2. Multi-function Knob
Turn for volume control, if enabled.
Turn to select the function to adjust after short-pressing button 4.
- Volume control and Mute (turn the knob/Short press)
- Screen brightness is also selected with a long press of the knob.
- SYSTEM STATUS - displays IP addresses and system version
- Advanced/Simple OLED display
- Audio Output Port Selection – Analogue, Digital, or USB
- System Mode Selector - AIO, DLNA, Tidal Connect, ROON, or NAA
- Hotspot ON/OFF
- Digital Filters
Tip: Turn to select the function to adjust after short-pressing button 4. Short press once to enter the selection, turn knob to make changes,
short press again to conrm change.
I) Volume control and Mute
Turn the knob to change the volume. Short press to mute/unmute the sound.
Tip: To enable or disable the volume control, adjust the Playback Options in Settings on http://i.local/
