OPERATING AND MAINTENANCE
INSTRUCTIONS
MODEL S251-2KWP
WIDE BAND SOLID STATE AMPLIFIER
DOCUMENT NUMBER
S251-2KWPMNL V1.0
Page
2
TABLE OF CONTENTS
SECTION DESCRIPTION PAGE
1.0 INTRODUCTION ..........................................................................................4
2.0 GENERAL DESCRIPTION...........................................................................5
2.1 AC Connection and Set-Up ................................................................5
3.0 WARRANTY INFORMATION.....................................................................6
4.0 GENERAL INFORMATION
4.1 Scope Of This Manual........................................................................7
4.2 General Specifications........................................................................7
4.3 Protection Circuits ..............................................................................8
4.4 Status Indicators, Controls and Connectors......................................10
4.5 Operating Instructions.......................................................................13
4.6 Data Sheets .......................................................................................17
5.0 PRINCIPALS OF OPERATION
5.1 Proper Usage And Warnings ............................................................18
5.2 Features Of The Amplifier...............................................................19
5.3 Level Control Board .........................................................................20
5.4 Optional Features..............................................................................20
6.0 AUTOMATIC LEVELING CONTROL (ALC )
6.1 ALC Features....................................................................................21
6.2 Leveling Using The "INT' Mode......................................................22
` 6.3 Leveling Using The 'EXT' Mode......................................................23
7.0 IEEE-488 INTERFACE OPTION
7.1 Introduction.......................................................................................26
7.2 Remote Initialization.........................................................................26
7.3 GPIB Address ...................................................................................27
7.4 Status Commands..............................................................................28
7.5 RS-232 Instructions ..........................................................................30
8.0 MAINTENANCE AND SERVICING
8.1 Periodic Maintenance .......................................................................31
8.2 Servicing The Amplifier...................................................................31
8.3 Equipment Return Procedure............................................................32
Page
3
LIST OF FIGURES
FIGURE DESCRIPTION PAGE
1.0 S251-2KWP ILLUSTRATION ......................................................................4
2.0 S251-2KWP REAR PANEL ILLUSTRATION...........................................10
3.0 FRONT PANEL DISPLAY START-UP MENU.........................................13
4.0 GPIB ADDRESS MENU .............................................................................14
5.0 MAIN MENU STATUS DISPLAY.............................................................15
6.0 TURNING ON THE AMPLIFIER...............................................................16
7.0 S251-2KWP SCHEMATIC DIAGRAM......................................................19
LIST OF APPENDICES
SECTION APPENDIX DESCRIPTION PAGE
9.0 A AMPLIFIER DATA SHEETS..........................................................33
10.0 B DRAWINGS PACKAGE.................................................................34
Page
4
SECTION 1.0
INTRODUCTION
Congratulations on the purchase of your new Wide Band Amplifier from Instruments For Industry,
Inc. Your new Wide Band Amplifier incorporates the finest advancements in state of the art solid-
state electronics technology available in a compact, portable and versatile package. Your Wide Band
Amplifier's quality, performance and trouble free operation depends on you thoroughly reading
through this manual and familiarizing yourself with its proper operation and usage.
Your Wide Band Amplifier comes with the following accessories, be sure to check your packaging
for the items listed below before disposing of the packaging.
CONTENTS
(For a typical Wide Band Amplifier )
Quantity Description
1 High Power Wide Band Amplifier, Model S251-2KWP
1 AC power line cord
1 Operation and Instruction Manual, Doc. No. S251-2KWP
1 Amplifier Data Sheets (Included with Unit)
FIGURE 1.0
S251-2KWP ILLUSTRATION
Page
5
SECTION 2.0
GENERAL DESCRIPTION
The Instruments for Industry, Inc. (IFI) manufactured S251-2KWP Wide Band Amplifier is a Bench
Top or rack mount amplifier providing 2000 Watts of RF power from 1000 MHz to 2500 MHz.
The Amplifier features a Color Touchscreen that displays continuous forward and reflected power in
three-digit metering. The display also scrolls to provide the operator with operating status and self-
diagnostic fault indications.
The Amplifier is unconditionally stable and incorporates protection circuits that monitor and control
the VSWR input and outputs so the amplifier cannot be damaged by any mismatched load.
The Amplifier may be equipped with an IEEE-488 BUS & RS232 interfaces, which allows the
amplifier to be remotely controlled using as computer.
To operate the Amplifier, connect the single-phase power line cord to the IEC connector on the rear
panel.
Page
6
SECTION 3.0
WARRANTY INFORMATION
Instruments For Industry, Inc. (IFI) warrants each product of its manufacture to be free from any
defect in material and workmanship for a period of three years from shipment to the original
purchaser. All warranty returns, however, must first be authorized by our factory office
representative. Refer to the Service Section for information on how to return items for warranty
repair.
Warranty liability shall be limited to repair or replacement of, or part thereof, which proves to be
defective after inspection by IFI. This warranty shall not apply to any IFI product that has been
disassembled, modified, physically or electrically damaged or any product that has been subjected to
conditions exceeding the applicable specifications or ratings.
IFI shall not be liable for any direct or consequential injury, loss or damage incurred through the use,
or the inability to use, any IFI product.
IFI reserves the right to make design changes to any IFI product without incurring any obligation to
make the same changes to previously purchased units.
This warranty is the full extent of obligation and liability assumed by IFI with respect to any and all
IFI products. IFI neither makes, nor authorizes any person to make, any other guarantee or warranty
concerning IFI Products.
Page
7
SECTION 4.0
GENERAL INFORMATION
4.1 SCOPE OF THIS MANUAL
This manual is intended to inform a qualified transmitter operator or technician of the normal
operating and maintenance procedures for the S251-2KWP. It is not intended to be a course of
instruction for unqualified personnel.
4.2 GENERAL SPECIFICATIONS
The specifications listed below represent the minimum performance characteristics at the time of
delivery. SPECIFICATIONS
Frequency Response: 1000 - 2500 MHz
Power Output: Minimum 2000 Watts
AC Source: 100~230VAC, 50/60, Single Phase
Power Gain: 63 dB
Input Impedance: Nominal 50 Ohms unbalanced
Output Impedance: Nominal 50 Ohms unbalanced
Input Signal Levels: < 0 dBm ( 1.0 mW ) See data sheet for specific input drive levels
Duty Cycle: 10 %
Spurious: -50dBc
Page
8
4.3 PROTECTION CIRCUITS
The S251-2KWP is designed with a variety of protection circuits to provide safeguards for the
amplifier should any adverse electrical conditions occur or if the amplifier accidentally experiences
operator deviation of the design application. Listed below are the safeguards built into the S251-
2KWP.
4.3.1 Over Heat Protection
The S251-2KWP critical components are mounted to heat sinks, which are, in turn, air cooled by four
fans. Should an over heating condition occur, either through component failure or by a restricted
airflow, the S251-2KWP contains heat sensors that will shut down the system. As a result, the air
inlet and outlet openings should be free of obstructions for proper cooling of the amplifier. Operation
is restored after Fault Reset when the amplifier cools to normal temperature levels.
4.3.2 Input Protection
The S251-2KWP is designed to operate with less than a 0 dBm (1.0 mW) input signal however, to
prevent overdriving the amplifier, the Input Protection circuit will activate if the input signal exceeds
3 dBm (2.0 mW) and will automatically compensate for the increased input signal by reducing the
gain of the preamplifier. Even though the amplifier has an Input Protection Circuit, overdriving the
amplifier is not recommended; refer to paragraph 5.1.2 for more details.
4.3.3 Output Protection
The S251-2KWP incorporates a microprocessor controlled Output Protection Circuit which monitors
the Forward Power Meter indication and limits the output power. This feature protects the amplifier
from being over driven and causing damage to the power transistors.
It is important to note that this feature only operates when the Forward and Reverse Sample Ports on
the amplifier have 50 Ohm Terminations installed.
IMPORTANT NOTE:
The S251-2KWP Sample RF Output connector must be terminated with the supplied 50 Ohm
load if the output is not being used. Should the S251-2KWP be operated without a
termination on the Sample RF Output connection will jeopardize the accuracy of the metering
and output protection; which are based on the Forward Power Readings, which may result in
damaging the amplifier and voiding the unit’s warranty.
Page
9
4.3.4 Power Supply Faults
The Power Supply Fault circuit monitors the 55 VDC, ± 12 VDC and 5 VDC power supplies and
produces a fault indication should any voltage level deviate from normal operating parameters. Each
power supply voltage output is monitored and displayed to indicate the power supplies are operating
within design parameters. Some units may have Green Status LED Indicators in addition to the
Controller Display. Should any power supply voltage deviate from the design parameters, the
corresponding power supply fault will be displayed
4.3.5 Mismatch Protection
The S251-2KWP is designed to operate with a tuned 50 Ohm load and should any mismatching of
the 50 Ohm load occur, the Reverse Power, also called Reflective Power, will increase producing a
high VSWR. The S251-2KWP microprocessor monitors the Reverse Power levels by utilizing a
Dual Directional Coupler and begins to turn down the gain of the preamplifier when the Reflected
Power exceeds 40%. The Reverse Power is also displayed on the LCD Display for operator
monitoring for any mismatched load.
4.3.6 Short Circuit Protection
The S251-2KWP utilizes three different power supply voltages, + 55 VDC, ± 12 VDC and the
+ 5 VDC, each of the power supplies are designed with a short circuit and overload protection
device.
Page
10
4.4 STATUS INDICATORS, CONTROLS AND CONNECTORS
The S251-2KWP has various controls and status indicators, which are identified below and can be
visually located on Figure 1.0, S251-2KWP Illustration and Figure 2.0, S251-2KWP Rear Panel
Illustration. A narrative description for the function and purpose of each control and status indicator
is provided within paragraphs 4.4.1 and 4.4.2.
S251-2KWP RF AMPLIFIER
Front Panel: Rear Panel:
Local/Remote Switch AC PWR, IEC Power Connector
Amp ON / OFF Switch ALC INPUT, BNC Type
Operate / Standby Switch INTERLOCK, BNC Type
Fault/Reset Switch IEEE-488, Connector
Color Touchscreen Display
RF Output, N Type, Female
RF Input, N Type, Female
FWD Sample Port,’N’ Type Female
FIGURE 2.0
S251-2KWP REAR PANEL ILLUSTRATION
