IEM
INDUSTRIAL EQUIPMENT AND MACHINERY GMBH
Tel. +49(0)6131/914694 • Fax +49(0)6131/963109
E
-Mail: [email protected] • Web Shop: http://www.waterpilot.de • internet: www.iemgmbh.de
1P 2P 3P Time of change filter
10001000 Min.
21002000 Min.
30103000 Min.
41105000 Min.
500110000 Min.
610115000 Min.
7 (Umwelt 3) 01120000 Min.
8 (EisCafe) 11112000 Min.
[1] 1P /2P /3P :Set changing filter (refer to left table)
[2] 4P: timing filter/count(flow meter)switch (OFF=>timing, ON)
=>counting (flow meter)
[3] 5P: ON=>Reach time of changing filter, it will display and
stop output.
OFF=>Reach time of changing filter, it will not display and
continue output.
[4] 6P: Setting by supplier OFF (Don’t touch!)
0=>OFF
1=>ON
(1) Power / PUMP/ plug of auto flushing
(2) Low pressure/ High pressure/ Leaking detector/ plug of water detector
(3) Mode setting switch (total 6 option):
(4)The switch of re-timing for changing filter: Set counting numeral “zero” for changing filter. (When operate, please press the switch
continuously, and it will complete when the alarm stop.
(5)Reset switch: Restart the circuit board system.
(6)Adjust water detector sensitivity: Rotate anticlockwise (increase sensitivity), rotate clockwise (decrease sensitivity).
(7) Buzzer: It will alarm when running abnormal.
(8) Plug of flow meter: It can calculate and display the life of filter by way of flow meter.
(9) Plug of LCD display board.
Security Advices
The RO Unit is constructed for a Water Pipe Pressure of 3 –5 bar. In case of a lower Pressure, the Quantity
and Quality of the Product Water will degrade. In Order to counter this, you should plump for an RO Unit with an
included Booster Pump.
At a higher Pressure, the Membrane can be damaged. In this case you should install an additional Pressure
Reducer.
Do not keep the Unit out of Action for a longer Time, since otherwise there is the risk of Bacterial Contamination.
Concerniong the Choice of the Location, please keep the following in mind:
Position the Unit, where it doesn´t displace and can be maintained.
The Unit should be positioned near the WaterSupply, to avoid Pressure Drops through short Pipes.
The Location of the Unit should necessarily have a Bottom Outlet, since possible Leakages can cause Water
Damages. Because of this please obviate an Installation in Conjunction with Furniture.
Please check the Unit regularly for bacteriological and microbiological Contaminations.
If you don´t use the Unit for any Length of Time, please shut down the Current Entry and close the Feed Water
Supply. In this case you should disinfect the Unit before Reconnection.
Besides Rodents (Mice,...) can erode the Tubes.
