IEI Technology prox.pad Plus Instructions de montage
prox.pad PlusTM
IR Access System
Installer Guide
This equipment is designed to be installed and serviced by security and lock industry professionals.
Please refer to the table of contents and list of illustrations on page 3.
Access system programming: This access system possesses serial communications capability and can be managed as part of an
overall access control system with Hub Manager ProfessionalTM software. See the inside cover for system requirements.
Optional Keypad Programming: The pro .pad Plus IR unit can be programmed manually using the keypad on each unit and
without the use of a personal computer (PC) and software. This manual contains the optional keypad programming instructions.
Keypad programming can be helpful to get a door or doors up and running prior to having the availability of the host computer. In all
cases, the personal computer programming options supersede the keypad programming options.
Page 1 of 32 ocument # 6105681, Rev 1.1, 2a
Service Company, Put Contact Information Here:
Company Name: __________________________________________
Service Num er: __________________________________________
15.21 Information to User
Any changes or modifications not e pressly
approved by the party responsible for compliance
could void the user's authority to operate the
equipment.
prox.pad Plus IR Access System Installer Guide
Access system programming - System Requirements
●Hub Manager ProfessionalTM access control software version 7.2 or higher (part number HUBSWR includes software
installation instructions)
●LS Link PDA Software or DTD (Data Transfer Device)
PC Hardware Requirements
●IBM-compatible Pentium-class computer
●30MB available hard disk space
●VGA monitor or better, 800 600 resolution recommended
●CD-ROM or DVD-ROM drive
●Mouse
Operating System List
●Windows 98
●Windows 2000
●Windows XP
Refer to our we site at www.ieib.com for any changes to these specifications.
Technical Support
Service Company: To contact IEI’s Technical Support department, call 1- 800-343-9502. Questions can also be submitted through
our website at www.ieib.com. You can also download an electronic version of this manual from this site.
End User: Please contact your service company.
Page 2 of 32 ocument # 6105681, Rev 1.1, 2a
prox.pad Plus IR Access System Installer Guide
Table of Contents
Description.............................................................................................................................................................................4
prox.pad Plus IR Specifications.............................................................................................................................................6
prox.pad Plus IR Default Settings..........................................................................................................................................7
Daylight Sa ing Time.............................................................................................................................................................7
prox.pad Plus IR LED Indicators/Sounder Operations...........................................................................................................8
prox.pad Plus IR Component O er iew.................................................................................................................................9
prox.pad Plus IR Control Board O er iew...........................................................................................................................10
Communication Board O er iew.........................................................................................................................................11
Performing a Wall Mounted Installation...............................................................................................................................12
Pre enting Possible Water Problems..................................................................................................................................13
Performing a Glass Mounted Installation.............................................................................................................................14
Performing a Secure Installation..........................................................................................................................................15
Installing a Tamper Switch...................................................................................................................................................17
Mounting o er a metal or plastic single gang J-Box.......................................................................................................17
Wall mounting.................................................................................................................................................................17
Remo ing/Inserting Circuit Boards......................................................................................................................................18
Connecting the Communication Board to the Main Control Board......................................................................................19
Wiring the Main Relay to Fail Secure Lock..........................................................................................................................20
Wiring the Main Relay to Fail Safe Lock..............................................................................................................................21
Wiring the Aux Relay For Alarm Shunt................................................................................................................................22
Wiring the Aux Relay For Propped or Forced Door.............................................................................................................23
Wiring the Door Contact Input.............................................................................................................................................24
Wiring an External REX Switch (Request to Exit)................................................................................................................25
Programming.......................................................................................................................................................................26
Entering Program Mode......................................................................................................................................................26
Changing the Master Code..................................................................................................................................................26
Programming a Super isor Code........................................................................................................................................26
prox.pad Plus IR User Types...............................................................................................................................................27
Programming Options Chart................................................................................................................................................28
List of Illustrations
Figure 1: prox.pad Plus IR Component O er iew..................................................................................................................9
Figure 2: Identifying Pin Connectors (Main Control Board)..................................................................................................10
Figure 3: Identifying Pin Connectors (Communication Board).............................................................................................11
Figure 4: Performing a Wall Mounted Installation................................................................................................................12
Figure 5: Gasket Installation for Exterior Applications.........................................................................................................13
Figure 6: Performing a Glass Mounted Installation..............................................................................................................14
Figure 7: Performing a Secure Installation...........................................................................................................................16
Figure 8: Tamper Switch Locations.....................................................................................................................................17
Figure 9: Remo ing/Inserting Printed Circuit Board.............................................................................................................18
Figure 10: Connecting the Communication Board to the Main Control Board.....................................................................19
Figure 11: Electric Strike (Fail Secure) Wiring Diagram......................................................................................................20
Figure 12: Maglock (Fail Safe) Wiring Diagram...................................................................................................................21
Figure 13: Wiring the Aux Relay for Alarm Shunt................................................................................................................22
Figure 14: Wiring the Aux Relay for Forced or Propped Door.............................................................................................23
Figure 15: Wiring the Door Contact Input............................................................................................................................24
Figure 16: Wiring the REX Switch.......................................................................................................................................25
ocument # 6105681, Rev 1.1, 2a Page 3 of 32
prox.pad Plus IR Access System Installer Guide
escription
The pro .pad Plus IR unit is a single door access system that is programmed and managed from a personal computer using Hub
Manager Professional software (version 7.2 or higher). The pro .pad Plus IR unit is equipped with IR communications which is used
to communicate with LS Link PDA software. In addition, you can program the unit via the keypad.
The pro .pad Plus IR unit is unique in that no separate controller is needed and there is no need to run cables from a reader to a
control. The unit is self-contained and includes built in HID pro imity and keypad.
Important features include:
●Managed with Hub Manager™ Professional access software
●IR Communication with PDA via LS Link PDA Software or DTD (Data Transfer Device)
●No separate control to install
●Eliminate costly reader wiring
●2000 users per door
●2000 event audit trail
●Integrated-HID pro imity
●Card, code, card and/or code
●Locate pro imity 10 ft from control
●Indoor and outdoor
●Glass mount kit
●Door monitor
●Main relay for lock
●Programmable au iliary relay
●Local sounder for alerts
●Option for keypad programming
Page 4 of 32 ocument # 6105681, Rev 1.1, 2a
prox.pad Plus IR Access System Installer Guide
Table 1: IEI-Supplied Parts/Optional Items
Quantity escription
1 Keypad/control unit assembly, with Prox Sensor, Backplate, hex socket screw
1 Communication Board
1 Filler Piece/REX Button
1 Press to Exit Label
4 Wall Anchors
4 Keypad Mounting Screws
5 Communication Board Mounting Screws
1 Antenna Backplate for remote mounting
1 Silicone Rubber “dogbone”
4 Self-Adhering Pads (for glass mounting)
1 Installer Guide
4 Cable Assemblies
1 Tamper Screw
1 Hex Wrench
Optional Items
1 Hub ManagerTM Professional PC Software ( ersion 7.2 or higher required)
1 PDA using LS Link PDA Software
1 DTD (Data Transfer De ice
1 prox.pad Plus IR Replacement Battery: Panasonic BR1225, Renata CR1225 or Varta
CR1225; Refer to caution below.
lots of 25 only ProxKey KeyFobs (IEI Part Number: 0297301)
lots of 25 only ProxCard II Cards (IEI Part Number: 0297401)
ocument # 6105681, Rev 1.1, 2a Page 5 of 32
Caution: Replace battery with types listed above only. Use of
another battery may present risk of fire or e plosion. Battery may
e plode if mistreated. Do not recharge, disassemble or dispose of
battery in fire.
prox.pad Plus IR Access System Installer Guide
prox.pad Plus IR Specifications
Table 2: prox.pad Plus IR Specifications
Electrical
Power Supply/Current Requirements 12-24 VDC, linear filtered and regulated power supply; 150mA
Wiring
Remote Antenna Cable (if installing in a
secured configuration) [ALPHA 1294C (22AWG) 4-conductor, stranded and shielded]
Power Supply Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
Door Lock Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
Door Monitor Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
REX Cable [ALPHA 2421C 18 AWG or ALPHA 1292C 22 AWG, 2-conductor,
stranded and shielded] (if using remote switch)
Mechanical
Height 5.25 in (13.3 cm)
Width 2.75 in (7 cm)
Depth 1.625 in (4.13 cm)
Relay Outputs
Main Relay Form C (switches up to 2A)
Program for either timed (1-99 sec) or toggle
Aux Relay Form C (switches up to 1A)
One of three functions can be programmed: Alarm Shunt Relay,
Forced Door Relay, or Propped Door Relay
Monitor Inputs
Door Position Switch Normally Closed, Dry Contact
Other Outputs
Infrared Output For communicating to the LS Link PDA Software for programming
Sounder 4000 Hz, defeatable
Bi-Color LED Red/Green
Yellow LED
Compatible Proximity Cards (All HI cards up to 40 bits, including the following)
Prox Card II, IsoProx II, DuoProx II, Proxkey FOB
Unit Capacity
Users 2000 Maximum (each user can ha e a card, PIN or both)
Transactions 2000 Maximum (includes e ent number, time, date, and user
number if applicable)
Environmental
Operating En ironment Indoor or Outdoor
Operating Temperature -31° to 150° F (-35° to 66° C)
Operating Humidity 5% to 95% relati e humidity, non-condensing
Page 6 of 32 ocument # 6105681, Rev 1.1, 2a
prox.pad Plus IR Access System Installer Guide
prox.pad Plus IR efault Settings
The table below lists the default settings for the pro .pad Plus IR unit as shipped from the factory. Subsequent sections in this chapter
e plain how to change these default settings or program additional functions.
Table 3: prox.pad Plus IR efault Settings
Option efault Setting Option efault Setting
Master Code 1234 Lock Output Time 5 Seconds
Audio Keypress Feedback Enabled Visual Keypress Feedback Enabled
Auxiliary Relay Alarm Shunt Auto-Entry Disabled
Card/PIN Program Mode Disabled User Lockout Enabled
Internal REX Switch Disabled Timezones Disabled
Auto-Unlock Disabled First-In Auto-Unlock Disabled
DST Time/Date Format US Daylight Sa ing Time Enabled
Anti-Passback Enabled Anti-Passback Timer 1 second
Audio Alert 1 Forced Door Audio Alert Audio Alert 2 Propped Door Audio Alert
Forced Door Time 10 Seconds Propped Door Time 30 Seconds
In alid PIN Lockout Count 3 Attempts In alid PIN Lockout Time 10 Seconds
Extended Unlock Time 10 Seconds 26-Bit Facility Code 11
aylight Saving Time
The pro .pad Plus IR supports the following Daylight Saving Time formats:
United States (US):
Begins: Second Sunday in March at 2:00 AM
Ends: First Sunday in November at 2:00 AM
European (EU):
Begins: Last Sunday in March at 2:00 AM
Ends: Last Sunday in October at 2:00 AM
ocument # 6105681, Rev 1.1, 2a Page 7 of 32
prox.pad Plus IR Access System Installer Guide
prox.pad Plus IR LE Indicators/Sounder Operations
The table below describes the various LED and Sounder indications used in the pro .pad Plus IR.
Table 4: prox.pad Plus IR LE Indicators/Sounder Operations
LE /Sounder Visual/Audible Condition escription
Yellow LE
Slow blink Unit is in Program mode
Rapid blink Verify mode is acti e
Steady Program error; error lockout (no keypress feedback)
Very rapid blink Memory erase is in progress (command 46)
“Pulsing” rapid blink Batch program of cards in progress (command 56); block
delete of users (command 58)
Bi-color LE
Steady red Lock is locked
Steady green Lock is energized (timed or latched)
Green Drop Out Auto-Unlock is Acti e
Quick double red/green flash Prox card read correctly
Alternating red/green Waiting for second PIN or “card and code” user
All LE 's Rapid red, yellow, green
sequencing Power on/reset
Sounder
(system)
Short beep (100 ms) e ery 2
seconds Audio Alert 2 is acti e
Sounder 1/2 sec on, 1/2 sec off Audio Alert 1 is acti e
3 slow beeps (250ms), followed by
a double-beep with yellow LED on
during both double-beeps
Indicates self-test
Sounder (after
PIN) 3 rapid beeps PIN not found
Double Beep User Lockout Canceled
Pair of Double Beep User Lockout Acti ated
1 Long Beep Followed by 1 Short
Beep Access Denied – User Disabled
1 Long Beep Followed by 2 Short
Beeps Access Denied – Back Timezone
1 Long Beep Followed by 3 Short
Beeps Access Denied – User Locked Out
4 Quick Beeps First-In Auto-Unlock Acti ated
6 Quick Beeps Toggle Mode Acti ated
Page 8 of 32 ocument # 6105681, Rev 1.1, 2a
prox.pad Plus IR Access System Installer Guide
prox.pad Plus IR Component Overview
The following diagram illustrates all the various components of the pro .pad Plus IR. Please not the location of the IR (Infrared)
communication port on the lower right corner of the communication board in the rear housing.
ocument # 6105681, Rev 1.1, 2a Page 9 of 32
Figure 1: prox.pad Plus IR Component Overview
prox.pad Plus IR Access System Installer Guide
prox.pad Plus IR Control Board Overview
The diagram below illustrates the connectors on the pro .pad Plus IR main circuit board. The power connections are made on the
communication board discussed in the ne t section.
Page 10 of 32 ocument # 6105681, Rev 1.1, 2a
Figure 2: Identifying Pin Connectors (Main Control Board)
Note: If you are not using door contacts, you must twist the white
and orange wires together for the REX to work.
Table des matières
