Nav6plus User Guide

MAN 3008.00

Issue 2.0

ICS Electronics Limited.

Unit V, Rudford Industrial Estate

Ford, Arundel, West Sussex

BN18 0BD

United Kingdom

Tel: +44 (0)1903 731101

Fax: +44 (0)1903 731105

E-Mail: sales@icselectronics.co.uk

support@icselectronics.co.uk

Website: www.icselectronics.co.uk

The technical data, information and illustrations contained in this publication

were to the best of our knowledge correct at the time of going to print. We

reserve the right to change specifications, equipment, installation and

maintenance instructions without notice as part of our policy of continuous

product development and improvement. No part of this publication may be

reproduced, stored in a retrieval system or transmitted in any form, electronic

or otherwise without permission in writing from ICS Electronics Ltd. No liability

can be accepted for any inaccuracies or omissions in the publication, although

every care has been taken to make it as complete and accurate as possible.

Nav6 Plus Navtex System User Guide

Important Information

This equipment is not approved for use by SOLAS convention

vessels within the Global Maritime Distress and Safety System

(GMDSS)

It is intended for use by leisure craft and other non-SOLAS

vessels wishing to participate within GMDSS

Safety Warnings

Do not use the sensor as a grab-handle

This instrument is for use as an aid to sailors and should not

lead to a reduction in the level of good seamanship required at

all times

Reception of messages cannot always be guaranteed as this

depends on local radio propagation

The correct magnetic variation must be input at the navigation

instruments (e.g. GPS, electronic compass) for the accurate

display of COG, set, waypoint bearing and heading.

Nav6 Plus Navtex System User Guide

Contents

Quick Start......................................................................................5

Introduction.....................................................................................5

Nav6plus Features..........................................................................6

Advanced Operation..................................................................... 13

Navtex Mode ................................................................................ 13

Navigate Mode ............................................................................. 18

Setup Mode.................................................................................. 23

Alarm Operation............................................................................ 36

Printing Navtex And Navigation Log.............................................. 37

Output To A PC or Plotter............................................................. 38

Installation Of Sensor Unit ............................................................ 38

Installation Of Display Unit............................................................ 41

Testing The Nav6 After Installation................................................48

Maintenance and Trouble Shooting............................................... 48

Warranty....................................................................................... 50

Glossary ....................................................................................... 51

Packing List And Options.............................................................. 51

Specification................................................................................. 52

Appendix I: Navtex Station Database............................................ 54

Appendix II: Message Type Indicators........................................... 57

Appendix III: NMEA Sentences Supported.................................... 57

Appendix IV: Nav6 Menu Navigation............................................. 58

Appendix V: Nav6 Menu Structure ................................................ 59

Nav6 Plus Navtex System User Guide

Congratulations on purchasing this superb ICS Electronics Ltd

product. It is not only an excellent Navtex receiver, but a first class

instrument repeater. It may be the only display you will ever need at

your navigation position. We hope that it gives you many years of

reliable and trustworthy service. Please take the time to read this

manual carefully as it contains some essential information regarding

the operation and maintenance of the product and a useful

background to the Navtex system.

We recommend that you regularly visit the ICS website

www.icselectronics.co.uk for information on updates, the availability

of software enhancements, further options and support. The support

pages contain frequently asked questions about the Nav6 that you

may find useful. There is also a Navtex database providing a list of

operational Navtex stations and their details.

The IMO and various national coastguards also operate informative

websites that you may wish to visit; see

www.icselectronics.co.uk/links.

Nav6 Plus Navtex System User Guide

QUICK START

QUICK STARTQUICK START

QUICK START

You will find this product extremely easy to operate. Please don't be

intimidated by the comprehensive nature of this manual. In reality,

receiving your first NAVTEX messages just could not be simpler.

•Follow the installation guidelines

•Re-check the cable connections

•Apply power

•If you have not connected a GPS navigation receiver, make sure

that you set the date and time on the screen which will appear at

start up

•Wait for your first NAVTEX message.If you are within range of a

NAVTEX transmitter, you should not need to wait for more than

four hours.

•Refer to “Appendix IV : Nav6 Menu Navigation” for an overview

of the available operating modes & how to switch between them.

•Read the “Basic Operation” section to find out how to use some

of the commonly used features of this product

•If you then want to get the best from the system, read the rest of

the manual!

INTRODUCTION

INTRODUCTIONINTRODUCTION

INTRODUCTION

What Is NAVTEX?

What Is NAVTEX?What Is NAVTEX?

What Is NAVTEX?

NAVTEX is a worldwide system for the broadcast and automatic

reception of maritime safety information (MSI) in English by means

of a narrow-band direct-printing telegraphy. NAVTEX provides

shipping with navigational and meteorological warnings and urgent

information.

NAVTEX is a component of the IMO/IHO worldwide Navigational

Warning Service (WWNWS) as defined by IMO Assembly resolution

A.706(17). It is included within the Global Maritime Distress and

Safety System (GMDSS). Since 1 August 1993, NAVTEX receiving

capability has become mandatory equipment for certain vessels

under the provisions of the International Convention for the Safety of

Life at Sea (SOLAS).

NAVTEX broadcast information is available to all seafarers, free of

charge.

Nav6 Plus Navtex System User Guide

How Does Navtex Work?

How Does Navtex Work?How Does Navtex Work?

How Does Navtex Work?

NAVTEX transmissions are sent from stations situated worldwide.

The power of each transmission is regulated so as to avoid the

possibility of interference between transmitters. Each station is

allocated a 10-minute time slot every 4 hours so that many stations

can share the same frequency. Stations typically have a

transmission range of 250 – 300 Nm.

NAV6PLUS FEATURES

NAV6PLUS FEATURESNAV6PLUS FEATURES

NAV6PLUS FEATURES

Display Unit

Display UnitDisplay Unit

Display Unit

•The Display Unit uses a high resolution backlit LCD to display

NAVTEX messages in a choice of text sizes.

•The display unit contains a large non-volatile memory to store

NAVTEX messages, NAVTEX station database, all of the user

settings, filter options, LCD contrast and backlight levels. All

messages and settings are retained during power down.

•Several messages can be displayed at once (depending upon

the length of the message) and messages can be scrolled with a

single keypress.

•Messages can be filtered and sorted using a number of user

selectable criteria.

•The Nav6plus can act as an NMEA instrument repeater and is

capable of displaying data in a choice of formats.

•The Nav6plus can be connected to a printer or computer to print

NAVTEX messages and Navigation logs.

•Audible and visible alarms can be set up to indicate reception of

SAR and/or New Messages.

•A sleep mode allows long standby periods with minimum power

consumption, such as when the vessel is left in a marina with

main batteries being trickle charged from the shore.

Sensor Unit

Sensor UnitSensor Unit

Sensor Unit

•The Sensor Unit contains a short whip antenna and dual receiver

that can receive on both 490kHz and 518kHz simultaneously.

•Multiple sensors and displays can be connected together.

Nav6 Plus Navtex System User Guide

BASIC OPERATION

BASIC OPERATIONBASIC OPERATION

BASIC OPERATION

The Nav6plus is a flexible & powerful tool for receiving, storing &

viewing NAVTEX messages. In order to assist you in getting the best

from your Nav6plus, read this section which contains short cuts to

the most common NAVTEX operations. Read the rest of the manual

for a comprehensive guide to the Nav6plus.

First, find your way around the keypad and the display.

•Centre keys are a ‘navigation pad’ ( UP DOWN LEFT RIGHT ).

•Softkeys are situated on either side of the navigation pad. The

current function of each softkey is shown on the soft-key menu

area at the bottom of the display.

•The mode softkey switches between the three operating ‘modes’

(Navtex, Navigate & Setup).

•The view softkey switches between ‘views’ in each operating

‘mode’. If a ‘view’ has several ‘pages’ associated with it then

these are selected with the page softkey.

•Operate the keys in this order to get to the mode that you want:

MODE →VIEW →PAGE →FUNCTION

Hint : softkeys are context sensitive and cyclical in operation, several

button presses will return you to the start of the cycle.

softkeys

navigation pad

The Keypad

FUNCTION

Nav6 Plus Navtex System User Guide

The Display

At the bottom of the display is the softkey menu area:

The softkey menu area shows what each softkey does in the current

operating mode.

•The top line of each softkey menu box indicates the option that is

currently selected.

•The bottom line of each softkey menu box indicates the current

function of that softkey.

The example above shows the Nav6plus in Navtex Mode; the right

hand softkey selects the ‘mode’ & the current mode is ‘Navtex’.

At the top of the display is a status bar:

The status information is displayed as a series of icons. The

meaning of the icons is as follows:

Message ID for the message at the top of the display

An alarm is active

NMEA / GPS position data available

490 kHz reception available

518 kHz reception available

Receiving message now

Signal Carrier, but no message

Sensor communication fault

SAR message received

NEW message received

UTC Time

Current softkey function

Current option

Nav6 Plus Navtex System User Guide

Viewing & Scrolling Through Navtex Messages

To view Navtex messages you must first select the Navtex Mode.

Use the right hand softkey to change modes until ‘Navtex Mode’ is

visible in the right hand softkey menu box. You can now use the UP,

DOWN, LEFT & RIGHT keys to scroll through the displayed

messages. UP & DOWN scroll line by line, whereas LEFT & RIGHT

scroll message by message.

The messages currently displayed are a sub-set of all the messages

stored in memory. Whether you can see a particular message or not

depends upon the current station selection, message filter and age

limit settings (see following sections for details).

Message Storage

All received NAVTEX messages are stored in memory regardless of

whether you have them selected for viewing or not. The Nav6plus

has lots of memory so you will easily have enough storage for all

messages received in any 72 hour period. The messages displayed

are selected from the Nav6plus’ memory by applying the current

message filter preset & age limit settings. This enables you to

change your mind later about your message display options. This

means you will still be able to view messages that were received

previously, but were not selected for display at the time, by changing

the current message filter or age setting.

After using the Nav6plus for a while you may notice that if you

receive a particular message more than once there will only ever be

one copy in view. If a message has been received more than once

the Nav6plus will store only the best version. It even attempts to

repair corrupted messages using comparing copies of the same

message!

Filter Presets

The messages currently available for viewing on screen are selected

from the messages stored in memory by applying ‘filter presets’.

To see the current selected filter presets go to [Navtex Mode⇒

⇒⇒

⇒Filter

View]. You will notice that the left hand softkey is labelled ‘Preset’

and a number from 1 to 5 is visible. This is the currently selected

filter preset number for the this ‘filter page’. Each of the 4 filter pages

(518 Types, 518 Stns, 490 Types & 490 Stns) has its own 5 presets.

In any one of the filter pages press PRESET to change the preset

number. You will notice that the settings on the screen change with

Nav6 Plus Navtex System User Guide

filter preset number.

Select the preset that you require for the filter page that you are

viewing and then look at the presets for the other filter pages. Note

that the preset that is displayed is the one that is currently applied to

the message display.

Multiple presets can be used for switching quickly between different

sets of messages on the screen. For instance, if you want to show

just ‘navigational warnings from all stations in range’, you can use a

preset to do this.

Although the presets are pre-programmed, you can set them to any

filter setting you require.

Tip : Use preset 1 for normal operation and only use the other

presets if you want to switch between different sets of messages on

the display.

Station Selection

If you leave your Nav6plus receiving for 72 hours you will have

received many messages (subject to your current location) and

unless you filter out those stations that are not required for display,

you will be swamped with data. This can either be done

automatically using a GPS or by using manual filter settings. In either

case go to [Navtex Mode⇒

⇒⇒

⇒Filter View⇒

⇒⇒

⇒490 or 518 Stns Page]. You

will notice that each station can be set to one of three filter settings:

Setting Operation

On Messages from station always in view (see note 1)

Off Messages from station never in view

Auto Messages from station only viewed when nearest or in

range depending upon setting (see note 1)

note 1 : messages are only displayed if they also fall within the

ageing limit, error limit and message category filter settings.

An asterisk to the right of the station name indicates that the station

is selected with the current filter setting.

Autres manuels pour Nav6plus

Table des matières

Autres manuels ICS Récepteur

ICS

ICS Nav6 Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
