FIR-ULV600-DVRUserManual Page:1/56
FIR-ULV600-DVR
User Manual
Version 1.0
POS+DVR
December 2005
FIR-ULV600-DVRUserManual Page:2/56
Copyright Notice
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the
part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
Trademarks
FIR-ULV600-DVR is registered trademarks of ICP Electronics Inc.; IBM PC is a
registered trademark of International Business Machines Corporation. INTEL is a
registered trademark of INTEL Corporation. AMI is registered trademarks of
American Megatrends Inc. Other product names mentioned herein are used for
identification purposes only and may be trademarks and/or registered trademarks of
their respective companies.
Support
Any questions regarding the content of this manual or related issues can be e-mailed
FIR-ULV600-DVRUserManual Page:3/56
Table of Contents
Chapter1 Introduction...............................................................................................5
1.1 Specification ...............................................................................................5
1.2 Package Contents........................................................................................7
Chapter2 Installation.................................................................................................8
2.1 Block Diagram & Board Layout.................................................................8
2.1.1 Block Diagram.................................................................................8
2.1.2 Board Layout ...................................................................................9
2.1.3 Board Dimension...........................................................................10
2.2 Unpacking Precautions .............................................................................10
2.3 System Memory DRAM...........................................................................11
2.4 Clear CMOS Setup ...................................................................................11
2.5 TFT LCD Setting......................................................................................11
2.6 COM4 Voltage Selection ..........................................................................12
2.7 COM4 Mode Selection.............................................................................12
2.8 COM2 RI Function Setting.......................................................................12
2.9 COM1 RI Function Setting.......................................................................13
2.10 Keyboard Data & Clock by pass.............................................................13
2.11 COM5 & 6 RI (CN11 pin8 & 18) Function Setting................................13
Chapter3 Connection ..............................................................................................14
3.1 Compact Flash Storage Card Socket (CF1)..............................................14
3.2 Serial Port Connector (COM1, COM2, COM4, COM5 & COM6)..........15
3.3 Parallel Port Connector (LTP1).................................................................16
3.4 Primary IDE Connector (IDE1)................................................................17
3.5 VGA Connector (VGA1 & VGA2) ..........................................................18
3.6 CPU & system Fan Connector (J4 & J5)..................................................19
3.7 USB Connector (USB1 & USB2).............................................................19
3.8 LVDS Connector (LVDS1 & LVDS2)......................................................19
3.9 Box Header Connector (CN7) ..................................................................20
3.10 Keyboard/Mouse Connector (KB_MS1 & CN10) .................................21
3.11 Power Button (PS_ON1).........................................................................21
3.12 Power LED (LED1)................................................................................22
3.13 Power SW/LED Connector (CN4)..........................................................22
3.14 Digital I/O with RJ-11 Connector (CN2)................................................22
3.15 Power Connector (CN5 & CN8).............................................................23
3.16 LCD Back Light Connector (CN6 & CN9)............................................23
FIR-ULV600-DVRUserManual Page:4/56
3.17 Audio Connector.....................................................................................24
3.17.1 Speaker Out Phone Jack Connector (J6)......................................24
3.17.2 MIC In Phone Jack Connector (J7)..............................................24
3.17.3 Speaker Out Pin Header Connector (CN3)..................................24
Chapter4 BIOS Setup..............................................................................................25
4.1 Setup Menu...............................................................................................25
4.2 Setup Submenu: Main...............................................................................26
4.3 Setup Submenu: Advanced.......................................................................27
4.3.1 CPU Configuration ........................................................................28
4.3.2 IDE Configuration (Compatible Mode).........................................29
4.3.2.1 Primary IDE Master (if attached Hard Disk)......................30
4.3.3 Super IO Configuration..................................................................32
4.3.4 Hardware Health Configuration (Manual Mode) ..........................35
4.3.4.1 Hardware Health Configuration (Thermal Cruise Mode)...36
4.3.4.2 Hardware Health Configuration (Speed Cruise Mode) ......36
4.3.5 ACPI Configuration.......................................................................38
4.3.6 USB Configuration ........................................................................39
4.4 Setup submenu: Boot................................................................................40
4.4.1 Boot Settings Configuration ..........................................................41
4.4.2 Boot Device Priority......................................................................43
4.4.3 Hard Disk Drives ...........................................................................44
4.4.4 Removable Devices .......................................................................44
4.4.5 CD / DVD Drives...........................................................................45
4.5 Setup submenu: Security...........................................................................46
4.6 Setup submenu: Chipset............................................................................47
4.6.1 North Bridge Chipset Configuration..............................................48
4.6.2 South Bridge Chipset Configuration..............................................50
4.7 Setup submenu: Power..............................................................................51
4.8 Setup submenu: Exit.................................................................................52
Appendix A Address Mapping................................................................................54
A.1 I/O Address Map......................................................................................54
A.2 1st MB Memory Address Map.................................................................54
A.3 IRQ Mapping Chart .................................................................................55
A.4 DMA Channel Assignment ......................................................................55
Appendix B Digital I/O...........................................................................................56
FIR-ULV600-DVRUserManual Page:5/56
Chapter1 Introduction
1.1 Specification
1. Form Factor
Form
Dimension: W 188 x D 122 mm
2. Processor Compatibility
Processor
CPU Type: Intel Celeron-M Processors
Max. Speed: Celeron-M 600MHz
FSB: 400 MHz
Package: Micro-FCBGA
L2 Cache: 0KB
CPU Process: 90nm
3. Main Chipset
North Bridge
Controller Hub: i82852GM GMCH
FSB: 400 MHz
VGA:
Dual independent pipe support: Concurrent, Simultaneous
◆VGA port
◆LVDS panel support
Memory: DDR 200/266 MHz up to 1GB
Package: 732-pin Micro-FCBGA (37.5 x 37.5 mm)
Hub Interface (HI): 66 MHz (266-MB/s)
South Bridge
Controller Hub: i82801DB ICH4
PCI Compliant: PCI 2.2
Package: 421-pin BGA (31x31 mm)
PCI Bus: Supports up to six master devices on PCI
Other Feature:
◆6 USB 2.0 ports, 480MB/s
◆IDE up to ATA 100 mode
◆AC'97 2.3 CODEC support
FIR-ULV600-DVRUserManual Page:6/56
◆Power Management
◆LPC interface to SIO and Flash BIOS
◆ SMBus 2.0
Firmware Hub: 4Mb Flash
4. Additional Chipset
LAN
Chipset: Realtek RTL8100BL
IEEE Compliant: IEEE 802.3u 100Base-T and IEEE 802.3x Full Duplex Flow
Control
Audio
Codec: AC'97 2.3 CODECALC202A
Rear panel output: Line-out, MIC-in
Hardware Monitor
Chipset: LPC I/O W83627EHF for onboard alarm
Super I/O
Chipset: Winbond 83627EHF
Fan: CPU Fan / System Fan
Monitor Voltage: TBD
Serial I/O
Chipset: FINTEK F81216D
COM 3, 4, 5, 6
Power Management
ACPI Support: ACPI 1.0b and 2.0
APM Support: APM Rev 1.2 compliant power management
Others:
◆SMRAM space remapping to A0000h (128-kB)
◆Support extended SMRAM space above 256-MB, additional 1-MB TSEG
from top of memory, cacheable (cache ability controlled by CPU)
◆Support Suspend to System Memory, Suspend to Disk and Soft Off
◆Enhanced Intel Speed Step technology support
◆Optimized Clock Gating for 3D and Display Engines
◆ On-Die Thermal Sensor
Wakeup on LAN: TBD
Bootup Device
IDE device: Yes
Compact Flash: Yes
USB device: Yes
FIR-ULV600-DVRUserManual Page:7/56
ACPI 2.0
1.2 Package Contents
Before any installation, please check if the following materials are included in the
package:
zOne FIR-ULV600-DVR all-in-one single board computer
zOne compact disk for utility and drivers
If any of these items are missing or damaged, contact your distributor or sales
representative immediately.
Chapter2 Installation
This chapter gives instructions about how to set up the FIR-ULV600-DVR hardware,
including directions of setting jumpers and connecting peripherals, switches and
indicators. Before installation, please pay attention to the unpacking precautions on
the following page for safety.
2.1 Block Diagram & Board Layout
2.1.1 Block Diagram
Intel
Celeron M
Intel
852GM
Intel
ICH4
PC-104 PLUS LAN0
RTL 8100BL
Transformer
LAN
RJ45
DDR-SODIMM 0
200 / 266 MHz
DAC
LVDS
CRT PORT
LCD CONN
HDD
SUP I/O
W83627HF
LPT PORT
COM2 PORT
COM1 PORT
FAN CONN
BIOS
28F040T
LPC I/O
F81216D
LPC I/O
ITE8706 DIO
COM3 PORT
COM4 PORT
COM5 PORT
COM6 PORT
LPC
AC97 CODEC
AUDIO
CONN
AC97
USB PORT 0
USB PORT 1
USB PORT 2
USB PORT 3
USB PORT 4
USB PORT 5
USB 2.0
PCI BUS, 3.3V
RS232
RS232
RS232
RS232
FIR-ULV600-DVRUserManual Page:8/56
2.1.2 Board Layout
LVDS2
LVDS1
JP10 VGA2
VGA1
CN6
CN9
USB1 KB/MS
CN10
Button LED
CN4
J5
JP2
CN5
J4
CN8
Power
J7 J6
MIC SPK
USB2 COM4 COM2 COM1
CN2
DIO
CF
JP7
Power
DDR DIMM Socket
LAN
J3
CN1
IDE1
LPT1
COM5
COM6
JP6 JP5
CN7 JP8 JP9
COM3+USB
JP11 CN3
CN11
+
FIR-ULV600-DVRUserManual Page:9/56
2.1.3 Board Dimension
zFIR-ULV-600’s Dimensions (Unit: mm)
2.2 Unpacking Precautions
Some components of FIR-ULV600-DVR SBC are very sensitive to static electric
charges and can be damaged by a sudden rush of power. To protect it from unintended
damage, be sure to note these precautions:
1. Ground yourself to remove any static charge before touching the
FIR-ULV600-DVR SBC. You can do it by using a grounded wrist strap at all
times or by frequently touching any conducting materials that is connected to the
ground.
2. Handle FIR-ULV600-DVR SBC by its edges. Don’t touch IC chips, leads or
circuitry if not necessary.
3. Do not plug any connector or jumper while the power is on.
FIR-ULV600-DVRUserManual Page:10/56
