Find the ICOP PMX-090T-512-SV at our website: Click HERE

DM&P Vortex86MX+

Panel PC with 9”TFT LCD

Model:

PMX-090T-5A / PMX-090T-8A

PMX-090T-5A-512 / PMX-090T-8A-512

(Revision 1.0A)

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Revision

Date

Version

Description

2012/11/20

Version 1.0

Initial Release

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD

The information in this manual is subject to change without notice for

continuous improvement in the product. All rights are reserved. The manufacturer

assumes no responsibility for any inaccuracies that may be contained in this

document. And makes no commitment to update or to keep current the

information contained in this manual.

No part of this manual may be reproduced, copied, translated or transmitted,

in whole or in part, in any form or by any means without the prior written

permission of the ICOP Technology Inc.

Manual No. IUMPMX090-01 Ver.1.0A Nov, 2012

Trademarks Acknowledgment

Vortex86MXis the registered trademark of DMP Electronics Inc. Other

brand names or product names appearing in this document are the properties and

registered trademarks of their respective owners. All names mentioned herewith

are served for identification purpose only.

Safety Information

Read these Safety instructions carefully.

Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

Do not expose your Panel PC to rain or moisture, in order to prevent shock

and fire hazard.

Keep PMX-090T away from humidity.

Do not open the cabinet to avoid electrical shock. Refer to your nearest

dealer for qualified personnel servicing.

Never touch un-insulated terminals or wire unless your power adaptor is

disconnected.

Locate your Panel PC as close as possible to the socket outline for easy access

and to avoid force caused by entangling of your arms with surrounding cables

from the Panel PC.

USB connectors are not supplied with Limited Power Sources.

If the equipment is not used for a long time, disconnect it from the power

source to avoid damage by transient overvoltage.

DO NOT ATTEMPT TO OPEN OR TO DISASSEMBLE THE CHASSIS (ENCASING)OF THIS

PRODUCT.PLEASE CONTACT YOUR DEALER FOR SERVICING FROM QUALIFIED TECHNICIAN.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

iii

PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD

Table of Contents

1 General Information.............................................................................. 3

1.1 Product Description...................................................... 1

1.2 Product Specification ................................................... 2

1.3 Inspection standard for TFT-LCD Panel ........................ 4

1.4 Product Dimension....................................................... 7

1.5 Ordering Information ................................................... 8

1.6 Packing List ................................................................... 8

2System Installation ................................................................................ 9

2.1 CPU Board Outline........................................................ 9

2.2 Connector Summary................................................... 10

2.3 Connector Pin Assignments........................................11

2.4 External I/O Overview ................................................13

2.5 External I/O Pin Assignment.......................................14

2.6 System Mapping......................................................... 16

2.7 Watchdog Timer......................................................... 20

3Driver Installation ................................................................................ 21

3.1 PMX-090T Development Note ...................................22

3.2 BIOS Default setting ...................................................24

Warranty......................................................................................................... 25

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD

1.General Information

1.1 Product Description

PMX-090T is an ultra-compact platform for the present demanding

embedded and productive applications. It has new Vortex86MX+ SoC CPU which

consumes only minimum power requirement when running at 1GHz, and DDR2

memory provides faster data transfer rate. By using 9”TFT LCD, PMX-090T

becomes the perfect choice for a limited budget. In additional, the integrated

10/100M Ethernet port supplies the communication capability which makes

PMX-090T can be more widely used when running with Linux, Windows CE, and

Windows XP environment to become the perfect solution for system integration.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD

1.2 Product Specification

Table 1-1 Product Specification

CPU Board Specifications

CPU

DM&P Vortex86MX+ 1GHz

Cache

L1:16KB I-Cache, 16KB D-Cache

L2: 256KB Cache

BIOS

AMI BIOS

Memory

512MB/1GB DDR2 onboard

Watchdog Timer

Software programmable from

30.5u to 512 seconds x 2 sets

LAN

Integrated 10/100M Ethernet

Audio

HD Audio-Realtek ALC262 CODEC

Internal Drives

Compact Flash Type I / II slot

Micro SD slot

1GB or 2GB Flash Memory onboard (Optional)

I/O

RS-232/422/485 x 1

USB ports (Ver2.0) x 2

RJ-45 Port x 1

Mechanical & Environment

Power Requirement

Single Voltage +5VDC ( 5A )

Multi Voltage +8~+35VDC ( 8A )

Power Consumption

1.5A@5VDC

Operating

Temperature

0 ~ +50℃( 32 ~ +122℉)

Storage

Temperature

-10 ~ +60℃( 14 ~ +140℉)

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD

Operating Humidity

0% ~ 90% relative humidity, non-condensing

Dimensions

236.6 x 146 x 35mm (9.31 x 5.75 x 1.38 inches)

Weight

468g

Front Panel

Protection

IP 65

Certification

CE / FCC / VCCI / Vibration

LCD Specifications

Display Type

9” TFT LCD

Backlight Unit

LED

Display Resolution

1024(W) x 600(H)

Brightness (cd/m2)

300 nits

Contrast Ratio

500 : 1

Display Color

262, 144

Pixel Pitch (mm)

190.5 (H) x 189 (V)

Viewing Angle

Vertical 120o,

Horizontal 140o

Backlight Lifetime

25,000 hrs

Touchscreen

Type

Analog Resistive

Resolution

Continuous

Transmittance

80%

Controller

PS / 2 interface

Software Driver

DOS / Linux / WinCE / WinXP

Durability

1 million

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD

1.3 Inspection standard for TFT-LCD Panel

Table 1-2 Inspection Standard

DEFECT TYPE

LIMIT

Note

VISUAL

DEFECT

INTER

NAL

SPOT

φ＜0.15mm

Ignore

Note1

0.15mm≦φ≦0.5mm

N≦4

0.5mm＜φ

N=0

FIBER

0.03mm<W≦0.1mm, L≦

5mm

N≦3

Note1

1.0mm＜W, 1.5mm＜L

N=0

POLARIZER

BUBBLE

φ＜0.15mm

Ignore

Note1

0.15mm≦φ≦0.5mm

N≦2

0.5mm＜φ

N=0

Mura

It’ OK if mura is slight visible through 6%ND filter

ELECTRICAL

DEFECT

BRIGHT DOT

A Grade

B Grade

Area

Total

Area

Total

Note3

N≦0

N≦2

N≦3

N≦5

Note2

DARK DOT

N≦2

N≦3

N≦5

N≦8

TOTAL DOT

N≦4

N≦5

N≦6

N≦8

Note2

TWO ADJACENT DOT

N≦0

N≦1

pair

N≦1

pair

N≦1

pair

N≦1

pair

N≦1

pair

Note4

THREE OR MORE

ADJACENT DOT

NOT ALLOWED

LINE DEFECT

NOT ALLOWED

(1) One pixel consists of 3 sub-pixels, including R, G, and B dot.

(Sub-pixel = Dot)

(2) LITTLE BRIGHT DOT ACCEPTITABLE UNDER 6 % ND-Filter

(3) If require G0 grand (Total dot N≦0), please contact region sales.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD

[Note 1] W : Width[mm], L : Length[mm], N : Number, φ: Average Diameter.

1. White / Black Spot

2. Polarizer Bubble

Fig 1-1

Fig 1-2

[Note 2] Bright dot is defined through 6% transmission ND Filter as following.

Fig 1-3

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
