fr5000/fr6000 repeater

idas programming guide

(Includes Trunking)

8/19/2011 i

Table of Contents

What is Covered in this Guide................................................................................................................................1

Before You Start Programming...............................................................................................................................1

Applicable Models...................................................................................................................................................1

Programming Tones in Repeater Mode..................................................................................................................2

Repeater Programming...........................................................................................................................................4

Analog Repeating................................................................................................................................................4

Mixed Analog Repeating .....................................................................................................................................5

Mixed Digital Repeating.......................................................................................................................................6

Digital Repeating.................................................................................................................................................7

Trunking Repeater Programming........................................................................................................................8

Using the External I/O Settings...............................................................................................................................9

Program Settings ..................................................................................................................................................11

Memory CH Window..........................................................................................................................................11

Digital/Option Window.......................................................................................................................................11

Expert Window...................................................................................................................................................11

Appendix A: Temperature/Voltage Output Chart..................................................................................................12

Appendix B: Checking RSSI Levels......................................................................................................................13

8/19/2011 1

What is Covered in this Guide

This guide provides simplified step by step instructions for programming your FR5000/FR6000 repeater. The

programming information covers IDAS 6.25kHz digital programming, including IDAS trunking. It covers repeater

operation only, though the repeater can be used as a base station.

IDAS (Icom Digital Advanced System) is a digital and analog land mobile radio system, using the NXDN™

6.25kHz digital modulation and common air interface protocol.

Before You Start Programming

Check that you have the following:

CS-FR5000 cloning software, latest version

Latest firmware loaded in the Radios, Repeaters, and Trunking Controllers (if applicable)

Repeater power supply

Cloning cable OPC-1122/U

UC-FR5000 Trunking Controller Boards (for trunking applications)

Applicable Models

This Guide applies to the FR5000/FR6000 repeaters only.

Programming Tones in Repeater Mode

The FR5000/6000 uses standard analog CTCSS tones and DTCS tones. When in digital mode, the repeater

uses RAN codes. RAN Codes are digital equivalents to CTCSS tones. The codes are decimal, and range from

0 to 63. If you want squelch open to be able to receive all RANs, enter 0. This code allows all RAN codes to be

received and will retransmit using the code that is programmed for transmit in that channel.

When programming tones, the first step is programming tones in the Multiple Table. Here you can enter all

tones/codes: CTCSS, DTCS, and digital RAN codes. This table allows you to assign up to 16 tone sets to a

channel.

1. Navigate to the Multiple Table.

2. Enter the number of the table in the Table No. field that applies to that particular channel

(frequency set).

3. Enter Digital or Analog, then set the desired tones.

4. Navigate to the Memory CH window.

5. Enter the number of the Multiple Table in the Multi Table No. field that you want assigned to your

channel.

8/19/2011 3

Important: If no tones are entered in the Multiple Table field, the radio will respond as described in the

following examples.

Analog Channels

The repeater will receive carrier squelch and will transmit no tones. If there is a tone set in the TX C Tone field

(in the Memory CH), the repeater will transmit this tone.

Digital Channels

The repeater will receive any RAN code and retransmit that RX code.

Repeater Programming

Analog Repeating

A repeater set for analog receives and transmits on analog only. Program your radio with the following settings.

All frequencies need to be entered and the squelch level must be set before programming the following

settings.

Common Window

Field

Setting / Description

Others >Digital Function

Set to Enable, for future use of digital channels. Analog

operation is possible with this set to either Enable or Disable.

When enabled, the Digital window appears.

Hold Timer

Set to desired Hang Time of the repeater

Memory CH Window

Multiple Table Window

Field

Setting / Description

Table No.

Set to desired number. Can have as many as 16 tables. If you

have created more than 1 table, entering a number in this field

will bring up the matching table.

Type

Set to Analog.

Decode/Encode

Set to the desired CTCSS tone set. Repeater will operate on all

tone sets entered.

Field

Setting / Description

Operation Mode

Set to Repeat.

Frequency (MHz)

Enter the RX and TX frequencies.

Text

Enter the appropriate text for the channel name.

RF PWR

Set the desired power level. Choices are L1 (5W), L2 (25W),

and High (50W).

CH Type

Set to Analog.

CW ID

ON/OFF

Set to ON (the CW window contains the timers and ID).

TX C Tone

Set the CTCSS/DTCS tone here. It is active in repeater mode

only If Multiple Table is not enabled, tones apply to TX only;

RX is open squelch. The front hand mic uses this TX tone.

If RX and TX tones are required, use the Multi Table to set the

tones.

Multi Table No.

Set to the desired table number. It points to the tone settings in

the Multiple Table screen. The repeater will RX and TX for the

assigned channel using all the tone sets referenced in this

window. Note: if there is no value entered, the radio will RX on

any tone and transmit on the tone entered in the TX C. Tone

field.

8/19/2011 5

Mixed Analog Repeating

A repeater set for mixed analog is capable of receiving both digital and analog signals, and will re-transmit in

the format received. The front hand mic will transmit in Analog.

Program your radio with the following settings. All frequencies need to be entered and the squelch level must

be set before programming the following settings.

Common Window

Field

Setting / Description

Others

Digital Function

Set to Enable. When enabled, the Digital window appears.

Hold Timer

Set to desired repeater Hang Time.

Memory CH Window

Multiple Table Window

Field

Setting / Description

Table No.

Set to desired number. Can have as many as 16 tables. If you

have created more than 1 table, entering a number in this field

will bring up the matching table.

Type

Set to Analog or Digital.

Decode/Encode

Set to the desired CTCSS tone or RAN code set. Note: RAN

codes are decimal.

Field

Setting / Description

Operation Mode

Set to Repeat.

Frequency (MHz)

Enter RX and TX frequencies

Text

Enter appropriate text for the channel name.

RF PWR Set the desired power level. Choices are L1 (5W), L2 (25W),

and High (50W).

CH Type Set to Mixed-Ana. This allows receiving in analog and digital

and transmitting the same format as was received.

CW ID

ON/OFF

Set to ON (the CW window contains the timers and ID).

TX C Tone If the Multiple Table is not enabled, tones apply to TX only; RX

is open squelch. The front hand mic uses this TX tone.

If RX and TX tones are required, use the Multi Table to set the

tones.

Multi Table No.

Set to the desired number. It points to the tone/RAN settings in

the Multiple Table screen. The repeater will RX and TX for the

assigned channel using the tone/RAN sets referenced in this

window. Note: if there is no value entered, the radio will RX on

any tone and transmit on the tone entered in the TX C. Tone

field or, if set to Digital, will have no RAN for RX or TX.

TX RAN

No function in Mixed Analog Mode.

Mixed Digital Repeating

A repeater set for mixed digital is capable of receiving both digital and analog signals, and will transmit in the

format received. The front hand mic transmissions will be digital.

Program your radio with the following settings. All frequencies need to be entered and the squelch level must

be set before programming the following settings.

Common Window

Field

Setting / Description

Others

Digital Function

Set to Enable. When enabled, the Digital window appears.

Memory CH Window

Multiple Table Window

Field

Setting / Description

Table No.

Set to desired number. Can have as many as 16 tables. If you

have created more than 1 table, entering a number in this field

will bring up the matching table.

Type

Set to Analog or Digital.

Decode/Encode

Set to the desired CTCSS tone or RAN code set. Note: RAN

codes are decimal.

Field

Setting / Description

Operation Mode

Set to Repeat.

Frequency (MHz)

Enter RX and TX frequencies.

Text

Enter appropriate text for the channel name.

RF PWR Set the desired power level. Choices are L1 (5W), L2 (25W),

and High (50W).

CH Type

Set to Mixed-Digi. This allows receiving in analog and digital

and transmitting the same format as was received.

CW ID

ON/OFF

Set to ON (the CW window contains the timers and ID).

TX C Tone If the Multiple Table is not enabled, tones apply to TX only; RX

is open squelch. The front hand mic uses this TX tone.

If RX and TX tones are required, use the Multi Table to set the

tones.

Multi Table No.

Set to the desired number. It points to the tone/RAN settings in

the Multiple Table screen. The repeater will RX and TX for the

assigned channel using the tones/RAN’s referenced in this

window. Note: if there is no value entered, the radio will RX on

any tone and transmit on the tone entered in the TX C Tone or,

if set to Digital, will have no RAN for TX and RX.

TX RAN

Front mic functionality only. Repeater will TX this RAN from the

front mic.

8/19/2011 7

Digital Repeating

A repeater set for digital receives and transmits in digital only. Program your radio with the following settings. All

frequencies need to be entered and the squelch level must be set before programming the following settings.

Common Window

Field

Setting / Description

Others

Digital Function

Set to Enable. When enabled, the Digital window appears.

Hold Timer

Set to desired Hang Time of the repeater

Memory CH Window

Multiple Table Window

Field

Setting / Description

Table No.

Set to desired number. Can have as many as 16 tables. If you

have created more than 1 table, entering a number in this field

will bring up the matching table.

Type

Set to Analog or Digital.

Decode

Encode

Set to the desired RAN code set. Note: RAN codes are

decimal.

Field

Setting / Description

Operation Mode

Set to Repeat.

Frequency (MHz)

Enter RX and TX frequencies

Text

Enter appropriate text for the channel name.

RF PWR

Set the desired power level. Choices are L1 (5W), L2 (25W),

and High (50W).

CH Type

Set to Digital. This allows transmitting in digital and receiving in

digital.

CW ID >ON/OFF

Set to ON (the CW window contains the timers and ID).

Multi Table No.

Set to the desired number. It points to the RAN settings in the

Multiple Table screen. The repeater will RX and TX for the

assigned channel using the RAN codes referenced in this

window. Note: if OFF is selected, the repeater will RX and TX

any matching digital frequency regardless of the RAN codes.

TX RAN

Front hand mic uses this RAN for transmission.

Trunking Repeater Programming

The following procedure assumes that the squelch has been set.

1. Go to Memory CH and enter your frequencies if you have not already done so.

2. In the Operation Mode field select Full-Duplex.

3. Go to the Common folder and click Common. Set Digital Function to Enable.

4. Click Clone and write the file into the repeater.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Icom Répétiteur

Icom

Icom IC-RP1210 Manuel utilisateur

Icom

Icom ID-RP1 Manuel utilisateur

Icom

Icom IC-FR3000 Series Manuel d'utilisation et d'entretien

Icom

Icom IC-RP4520 Manuel utilisateur

Icom

Icom iC-FR5000 Manuel utilisateur

Icom

Icom IC-RP1620 Manuel utilisateur

Icom

Icom id- rp2 Manuel utilisateur

Icom

Icom IC-RP1520 Manuel utilisateur

Icom

Icom CY 6000 Manuel utilisateur

Icom

Icom UR-FR5000 Manuel utilisateur

Icom

Icom IC-FR6100 Manuel utilisateur

Icom

Icom UHF IC-FR6000 Instructions d'installation et d'utilisation

Icom

Icom D-STAR ID-31A; D-STAR ID-31E Manuel utilisateur

Icom

Icom X BAND 50 Manuel utilisateur

Icom

Icom iFR5000 Manuel utilisateur

Icom

Icom id- rp2000v Manuel utilisateur

Icom

Icom ID-RP2010V Manuel utilisateur

Icom

Icom IC-FR5300 Manuel utilisateur

Icom

Icom IC-FR6000-L Manuel utilisateur

Icom

Icom IC-FR4000 Series Manuel utilisateur

Icom

Icom iC-FR5000 Manuel utilisateur

Icom

Icom IC-RP1520 Manuel utilisateur

Icom

Icom F6000 Manuel utilisateur

Icom

Icom IC-FR5000 Series Manuel utilisateur

Manuels Répétiteur populaires d'autres marques

Gigaset

Gigaset 108 Manuel utilisateur

Ace TECHNOLOGY

Ace TECHNOLOGY USR-1900A Manuel utilisateur

Kenwood

Kenwood TKR-750-850 Manuel de la liste des pièces

Asus

Asus RP-AC51 Manuel utilisateur

Exibel

Exibel HRP0101 Manuel utilisateur

Kidde

Kidde Vega Manuel utilisateur

Telcosat

Telcosat RBB 850 Guide d'installation

York

York Universal LINC485 Manuel utilisateur

MIKOM

MIKOM MRx01B Power Series Manuel utilisateur

Simrad

Simrad RD 301 Manuel utilisateur

Tait

Tait TB7304 Manuel utilisateur

R-tron

R-tron RSN-CDMA-37-C Manuel utilisateur

Inventronics

Inventronics DALI REPEATER SO Manuel utilisateur

XFP

XFP 16 Manuel utilisateur

Andrew

Andrew MRx18 Manuel utilisateur

COMBA

COMBA RXA3748 Manuel utilisateur

ADRF

ADRF SDR-ICS-43 Manuel utilisateur

Teltonika

Teltonika WRP100 Manuel utilisateur
