Icom IC-R30 Guide de configuration

ADVANCED MANUAL

COMMUNICATIONS RECEIVER

iR30

11 SPECIFICATIONS

10 OPTIONS

9 UPDATING THE FIRMWARE

8 Bluetooth®OPERATION

7 OTHER FUNCTIONS

6 MENU SCREEN

5 GPS OPERATION

4 MEMORY OPERATION

RECORDING AND PLAYING BACK

2 microSD CARD

1 POWER SUPPLY

INTRODUCTION

Thank you for choosing this Icom product. This product is designed and built with Icom’s

state of the art technology and craftsmanship. With proper care, this product should

provide you with years of trouble-free operation.

■About the IC-R30 manuals

The following manuals are supplied for your IC-R30.

Basic manual (Supplied with the IC-R30)

Instructions for the basic operations, precautions.

Advanced manual (This manual)

Instructions for the advanced operations, as shown below.

• Battery operation*

• Using a microSD card*

• Recording the received audio*

• Memory operation*

• GPS operation*

• Menu screen*

• Other functions*

• Bluetooth®operation*

• Firmware updating

• Options*

• Specications

R*Only the basic instructions are described in the BASIC MANUAL.

Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated

(Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain,

Russia, Australia, New Zealand, and/or other countries.

NXDN is a trademark of Icom Incorporated and JVC KENWOOD Corporation.

dPMR is a trademarks of the dPMR MoU Association.

Adobe, Acrobat, and Reader are either registered trademarks or trademarks of Adobe

Systems Incorporated in the United States and/or other countries.

Microsoft and Windows are registered trademarks of Microsoft Corporation in the United

States and/or other countries.

The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG,

Inc. and any use of such marks by Icom inc. is under license.

Other trademarks and trade names are those of their respective owners.

Functions of Adobe®Acrobat®Reader®

The following functions and features can be used with AdobeAcrobat Reader.

•Keyword search

Click “Find” (Ctrl+F) or “Advanced Search” (Shift+Ctrl+F) in the Edit menu

to open the search screen.

This is convenient when searching for a particular word or phrase in this

manual.

* The menu screen may differ, depending on the Adobe Acrobat Reader version.

• Find screen

• Advanced search screen

Click to open the nd or search

screen or advanced search screen.

INTRODUCTION

iii

Functions of Adobe®Acrobat®Reader® (Continued)

• Printing out the desired pages.

Click “Print” in the File menu, and then select the paper size and page

numbers you want to print.

*The printing setup may differ, depending on the printer. Refer to your

printer’s instruction manual for details.

*Select "A5" size to print out the page in the original manual size.

• Read Out Loud feature.

The Read Out Loud feature reads aloud the text in this PDF.

Refer to the Adobe Acrobat Reader Help for the details.

(This feature may not be usable, depending on your PC environment

including the operating system.)

* The screen may differ, depending on the Adobe Acrobat Reader version.

INTRODUCTION

Entering and editing text

Character type Selectable characters and symbols

AB A to Z, 0 to 9, (space)

ab a to z, 0 to 9, (space)

12 0 to 9, (space)

!”# ! " # $ % & ’ ( ) * + , - . / : ; < = > ? @

[ \ ] ^ _ ` { | } ˜ (space)

Selects a character

Selects

a character

Selects

a character

Clears

the entry

Moves the cursor

to the left

Opens the Entry Mode Select window

Selects

a character*

Keaypad

*Only when the DIAL/VOL Switch function is ON.

Alphabet

(Upper case)

Alphabet

(Lower case)

Number

Sets the entry

To enter characters

• To insert a text, move the cursor to a place to enter, then push the keypad.

LYou can elect a character by rotating [DIAL], or pushing D-pad (Up) or D-pad (Down).

• When the character type is “AB” or “ab,” and while entering a character, push [QUICK] to

select upper case or lower case letters.

• To clear a character, push [CLEAR].

• To consecutively clear characters, continuously hold down [CLEAR].

INTRODUCTION

The usable characters are alphabets, numbers and symbols.

Moves the cursor

to the right

Entry Mode Select window

INTRODUCTION

Entering and editing text (Continued)

DUsable characters

The usable characters and symbols, and the maximum characters differ, depending on

the item. See the following list for details.

Category Item Character type Maximum

characters

Illegal

characters Ref.

Memory mode Memory name [AB] [ab] [12] [!”#] 16 –

p. ?-?

Bank name [AB] [ab] [12] [!”#] 16 –

Program scan Scan name [AB] [ab] [12] [!”#] 16 –

P-LINK Scan Link name [AB] [ab] [12] [!”#] 16 –

SD Card Save Setting [AB] [ab] [12] [!”#] 20 / : ; * < > p. ?-?

Export [AB] [ab] [12] [!”#] 20 / : ; * < > p. ?-?

GPS Memory Memory name [AB] [ab] [12] [!”#] 16 –p. ?-?

Group name [AB] [ab] [12] [!”#] 16 –p. ?-?

Bluetooth®Device name [AB] [ab] [12] 8 –p. ?-?

[AB]: A to Z, 0 to 9, (space)

[ab]: a to z, 0 to 9, (space)

[12]: 0 to 9, (space)

[!”#]: ! " # $ % & ’ ( ) * + , - . / : ; < = > ? @ [ \ ] ^ _ ` { | } ˜ (space)

Entering and editing text (Continued)

DHow to enter

Example: Entering “2m Call” as a Memory name of channel 00 in group 00.

1. Push [VFO/MR] to enter the Memory mode.

2. Push [MW].

3. Select “Manage Memory.”

(Rotate [DIAL] to select it, then push [ENTER].)

4. Select group “00.”

5. Select channel “00,” then push [QUICK].

6. Select “Edit”.

• The Edit screen is displayed.

7. Select “NAME.”

• The Memory name edit screen is displayed.

8. Push [QUICK] to select a character type.

9. Push [MHz] to select “2.”

LTo enter symbols, select [!”#].

10. Repeat steps 8 ~ 9 to enter a name.

11. After entering, push [ENT].

• Returns to the Edit screen and the entered name is displayed.

12. Push [QUICK], then select “<<Overwrite>>.”

• A conrmation dialog appears.

13. Select <YES>.

• A beep sounds, then returns to the Memory mode.

Group 00

Character type Number “2” “2m Call” is entered

Channel 00 “NAME” item

INTRODUCTION

vii

About the air ventilation holes

There are air ventilation holes on the receiver body and battery pack/case that adjust the

air pressure inside of the receiver.

LApplying a sticker over the ventilation hole blocks the air pressure adjustment, and may

decrease the audio output level.

LDamage to the ventilation sheet may reduce the water protection capability.

Here is an air

ventilation hole

under the sheet.

Here is an air

ventilation hole.

Here is an air

ventilation hole.

INTRODUCTION

Ventilation sheet

1-8

Section 1

POWER SUPPLY

■About the Battery Case ……………………………………… 1-2

DBattery life …………………………………………………… 1-2

DAbout the battery replacement …………………………… 1-2

DAbout the safety use of battery case……………………… 1-3

■Charging with a USB cable ………………………………… 1-4

1POWER SUPPLY

1-9

■About the Battery Case

zRemove the battery case, then install three AA (LR6) size alkaline batteries, as

described below.

DBattery life

The approximate battery life (operating time) is approximately 4 hours under the

following assumptions:

• Dualwatch function: ON

(A band: Receiving, B band: Stand-by, Power Save function: ON (Auto (Short))

LThe battery life may differ, depending on the operating style, or the installed alkaline

batteries.

LThe batteries may seem to have low capacity when used in low temperatures. Keep the

case warm in low temperature environments.

DAbout the battery replacement

When the alkaline batteries are almost exhausted, “LOW BATTERY” is displayed,

then the receiver is automatically turned OFF. Replace all batteries with new alkaline

batteries.

LWhen the BP-293 battery case is attached to the receiver, the battery icon cannot display

the battery capacity of the alkaline batteries. The battery icon stays as “

点滅

容量表示

充電表示

,” and it does

not reect with the true battery capacity.

Battery case

(Optional BP-293)

Install three AA (LR6)

size alkaline batteries

Be sure to observe

the correct polarity.
