Iceking BU100.E Manuel utilisateur

Installation And Operating Manual

Please read these instructions carefully before attempting to install or use this appliance.

It is advisable to keep these instructions in a safe place for future reference.

Rated Built Under Larder Fridge

BU100.E

Iceking: Henry John House, Northway Industrial Estate, Northway Lane, Ashchurch, Tewkesbury, Gloucestershire,

GL20 8JH. T: 01527 888133 E: [email protected] W: www.ice-king.co.uk

Registered Office Address:

Henry John House, Northway

Industrial Estate, Northway

Lane, Ashchurch, Tewkesbury,

Gloucestershire, GL20 8JH

Introduction

Thank you for choosing this Iceking appliance. It has been

designed to give years of trouble-free use provided it is installed

and maintained correctly.

Please read these instructions carefully before installing or using your

appliance. It is advisable to keep your purchase and installation receipts

with these instructions in a safe place for future reference. Included is some

important safety information in addition to guidelines and

recommendations that will enable you to take full advantage of all the

functions available.

This quality appliance has been tested and certified to meet all applicable

UK electrical and safety standards.

This appliance must be installed and connected in accordance

with current regulations by a qualified electrician.

After unpacking the appliance ensure that there is no visible damage. If the

appliance has been damaged during transit, do not use it, contact your

retailer immediately.

Contents

………………………………………. 3-4

………………………………………. 4

………………………………………. 5

………………………………………. 6

………………………………………. 7

………………………………………. 8-9

………………………………………. 10 -16

………………………………………. 17

………………………………………. 18 -21

………………………………………. 21

………………………………………. 22

………………………………………. 23

………………………………………. 24 -25

………………………………………. 26

………………………………………. 27

Safety Instructions

Electrical Safety

Transportation & Handling

Installing & Switching on your Appliance

Before Switching On

Product Overview

Unit & Spare Parts

Usage

Temperature Selection

Installation

Fitting the Plinth

Door Reversal

Replacing the Light

Energy Saving Advice

Maintenance & Cleaning

Internal Cleaning

External Cleaning

When the appliance is not in Use

Trouble Shooting

Connection to the Mains Supply

Technical Spec

Guarantee & Contact Details ………………………………………. 28-29

Safety Instructions

Important note: Please read this booklet before installing and switching on this

appliance. The manufacturer assumes no responsibility for incorrect installation

and usage as described in this booklet.

•This model uses natural refrigerant gas as part of its cooling system. This

gas is known as R600a (Isobutene) and is environmentally friendly but can be

combustible. Care should therefore be taken when handling or transporting the

product to ensure that none of the refrigeration circuit components are

damaged,

•Do not obstruct ventilation openings in the appliance

•The appliance must not be placed or rested on its power cord.

•Do not use mechanical devices or other artificial means to accelerate the

defrosting process, such as a heater or a hair dryer.

•Do not use electrical appliances in the refrigerator compartment of the

appliance.

•If this appliance is to replace an old refrigerator with a lock, the lock must be

removed as a safety measure before storing it or disposing of it.This is to

protect children from locking themselves inside the appliance.

•Old refrigerators and freezers contain insulation gases and refrigerant, they

must be disposed of properly. Contact your local authority or your dealer if

you have any questions. Please ensure that you do not damage the scrapunit

prior to being picked-up by the relevant waste disposal service.

•Do not use adaptors or extension leads when connecting the appliance to the

electrical power supply

•Do not plug in damaged plugs

•Do not pull, twist or damage the power cable.

•Do not plug-in or un-plug the appliance with wet hands to prevent electrical

shock.

•This appliance can be used by childrenaged from 8 years and above and

persons with reduced physical, sensoryor mental capabilitiesor lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. Children should not play with the appliance.

•This appliance is designed to be used by adults, do not allow childrento play

with the appliance or letthem hang over the door.

•Do not place explosive or flammable material in your appliance for your own

safety.

•Bottles containing a high percentage of alcohol must be sealedwell and placed

vertically in the refrigerator.

•Do not cover the body or the top of the appliance

•Fix down the accessories in the appliance during transportation to prevent

damage to them.

Electrical Safety

THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET

•Before switching on, make sure that the voltage of your electricity supply is the

same as that indicated on the rating plate. This product is designed to operate

on 220 –240V AC; 50Hz. Connection to any other power source may damage

the unit.

•This product may be fitted with a non re-wireable plug. If it is necessary to

change the fuse in the plug, the fuse cover must be refitted. If the fuse cover

becomes lost or damaged, the plug must not be used until a suitable

replacement is obtained.

•If the plug has to be changed because it is not suitable for your socket, or

becomes damaged in any way, it should be cut off and an appropriate plug

fitted following the wiring instructions. This should be carried out by a qualified

electrician. The plug removed must be disposed of safely, as insertion into a 13

Amp socket is likely to cause an electrical hazard.

Transportation and Handling

For safe lifting, tilt the appliance backwards by no more than 45 degrees, hold the

base and rear corners of cabinet. Lift the refrigerator carefully. Never use the door

handles for lifting. To move the refrigerator on a flat level surface, tilt it slightly

backwards and push backwards.

This unit is heavy and could cause injury –ensure there are adequate people

present to move the appliance.

Installing and Switching on Your Appliance

•Operating voltage for your appliance is 220-240Vat 50Hz.

•Before plugging in the power supply, ensure that the voltage on the rating label

corresponds to the working voltage of your electrical system in your home.

•Insert the plug into an efficient Ground (Earth) connection. If the socket hasno

Ground (Earth) contact or the plug does not match, we suggestyou call an authorised

electrician for assistance.

•Place your appliance in an area that is not exposed to direct sunlight.

•Your appliance should be placed at least 10cm away from stoves, ovens and other

heating cores.

•This appliance should never be used outdoors or left in the rain.

•When your appliance is placed nextto achest freezer or freezer, there should be at

least 10cms between them to prevent humidityon the outer surface.

•The appliance must be used in the vertical position and on a flat surface.

•To level the appliance, use the adjustable feet on the appliance.

•Do not place your appliance on a carpeted surface as this will prevent adequate

ventilation.

•Keep ventilation openings in the appliance enclosure or in the built in structure clear of

obstruction

•This appliance should only be placed on a flat, firm surface.

•It is recommended the appliance is installed by a qualified kitchen fitter or joiner.

•Choose a dry and well-ventilated space.

•The appliance should be positioned so that the plug is easily accessible.

Before SwitchingOn

•Before using your appliance, add a teaspoon of bicarbonate of soda to warm

water and with a damp cloth wipe down all parts of the new appliance, then

repeat the process with a clean damp cloth and dry. (ensure the appliance is

not connected to the power when performing this task).

•Remove all transport tapes and foam protection pieces . Clean the interior with

a cloth dampened in lukewarm soap and water. Wipe with clean water and

wipe dry.

•There may be an odour when you first switch on the appliance, it will disappear

when the appliance starts to cool.

•When the appliance has been positioned, adjust the feet to ensure the unit is

stable. This is essential to ensure quiet running and proper door opening

/closing.

•Connect to the electrical socket but do not switch the power to the refrigerator

on for at least 3 hours. The coolant within the product needs time to settle after

it has been transported and put in to position, failure to do this will affect the

cooling performance of your appliance.

•Once the appliance has settled locate the thermostat dial on the product and

set to “5" and switch on the power. The compressor will begin to work. Close

the door.

•We recommend that the door is not opened for a minimum of 4 hours to allow

the appliance to reach the standard operating temperature.

•You may hear faint gurgling or bubbling sounds when the refrigerant is pumped

to the cooling system and through the coils or tubing at the rear of the

appliance. When the compressor is in operation you may hear a slight whirring

sound or pulsating noise. The thermostat controls the operation of the

compressor, and you may hear a slight click as it cycles in and out (this is

normal).

•To save energy, you should minimize the frequency and duration of door

opening.

Unit Parts & Spare Parts

Before installation, check that all parts detailed in the product overview are

present.

Product Overview

1. Light & thermostat

2. Adjustable shelves

3. Drainage hole

4. Non-adjustable shelf

5. Crispers (under shelf)

6. Adjustable feet

7. Door racks

8. 1 x egg tray & drainage hole plug

9. Installation accessories

The temperature in the appliance is controlled by the temperature control dial

or thermostat located inside the fridge. Rotate the control dial up or down to

regulate the temperature inside the fridge.

On the temperature control, 0 is the off setting, 1 is the warmest setting and 6 is

the coldest setting.

Depending on the ambient temperature of the room the appliance is situated in,

you may need to adjust the temperature control dial; in a room with a high

ambient temperature the temperature control dial may need to be adjusted to a

colder setting (moved towards setting 6) or in a room with a low ambient

temperature the temperature control dial may need to be adjusted to a warmer

setting (moved towards setting 4 ).

Setting 6 should be used as a rapid cool/freeze setting and should only be set 2

hours before a large amount of food is placed in the fridge. The temperature

control should be put back to setting 5 after the food has been placed in the

fridge, if this is not done the temperature in the fridge compartment could fall

below 0ºC as the compressor will run continuously.

Once the temperature control has been set, close the door and plug in the

appliance. We recommend that the door is not opened for a minimum of 4

hours to allow the appliance to reach the standard operating temperature.

Allow to stand for a minimum of 3 hours before plugging in to the mains

Usage

Allow to stand for a minimum of 3 hours before plugging in to the mains

Note: The standard operating temperature for the fridge compartment should

be between 0ºC and 4ºC.

Note: The temperature of the freshly stored food and how often the door is

opened affects the temperature in the refrigerator compartment. If

required, change the temperature setting.

Usage

Table des matières

Autres manuels Iceking Réfrigérateur

Iceking

Iceking RL550W.E Manuel utilisateur

Iceking

Iceking RL104AP Manuel utilisateur

Iceking

Iceking RL114W.E Manuel utilisateur

Iceking

Iceking RHL550WE Manuel utilisateur

Iceking

Iceking ZZ245WE Manuel utilisateur

Iceking

Iceking RL254W.E Manuel utilisateur

Iceking

Iceking RK113WE Manuel utilisateur

Iceking

Iceking TK50W.E Manuel utilisateur

Iceking

Iceking RL111WL Manuel utilisateur

Iceking

Iceking IK20569SE Manuel utilisateur

Iceking

Iceking IK5558WE Manuel utilisateur

Iceking

Iceking TF41W.E Manuel utilisateur

Iceking

Iceking ZL253WE Manuel utilisateur

Iceking

Iceking RL6150W.E Manuel utilisateur

Iceking

Iceking ICE-RZ110W.E Manuel utilisateur

Iceking

Iceking RL340WE Manuel utilisateur

Iceking

Iceking RK554W.E Manuel utilisateur

Iceking

Iceking TT47WE Manuel utilisateur

Iceking

Iceking RK104WE Manuel utilisateur

Iceking

Iceking RL253AP2 Manuel utilisateur

Iceking

Iceking FF218WE Manuel utilisateur

Iceking

Iceking IKBU201AP Manuel utilisateur

Iceking

Iceking RL252AP Manuel utilisateur

Iceking

Iceking BI707FF.E Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
