Icegame ROUND-UP Mode d’emploi

OWNERS AND SERVICE MANUAL

INNOVATIVE CONCEPTS IN ENTERTAINMENT INC.

10123 MAIN STREET, CLARENCE, NY 14031

SERVICE: 1-716-759-0360

FAX: 1-716-759-0884

E-MAIL: serv[email protected]

WEBSITE: www.icegame.com

ICE - ROUND CRANE MODELS

INTRODUCTION………………………………..……...PAGE 3

•GAME FEATURES

•GAME PLAY

SET-UP / TESTING / MAINTENANCE…………...…..PAGE 4

•SAFETY PRECAUTIONS

•GAME SET-UP

•ASSEMBLY

•TESTING

•CLEANING

PROGRAMMING……………………………..………...PAGE 5 & 6

•OPTION MODES

•ERROR CODES

QUICK TROUBLESHOOTING…………………..……PAGE 7 & 8

•PROBLEMS AND SOLUTIONS

PARTS LISTINGS………………………………..……..PAGE 9 & 10

SCHEMATICS………………………………………......PAGE 11 - 15

WIRING DIAGRAMS……………………...……..….....PAGE 16 - 36

WARRANTY INFORMATION…….…………….……..PAGE 37 & 38

TABLE OF CONTENTS

ICEDOC RC9001

REVISION D 12-04-02

INTRODUCTION

GAME FEATURES

The new ROUND CRANE by I.C.E. was de-

signed with the operator in mind. Reliability, low

maintenance, available custom cabinetry, and

all metal exterior construction are some of the

most important design features to be added to

the newest member of our crane family.

To keep things easy for the operator, all of our

best features have been carried over from our

other designs. Things such as an all-metal exte-

rior, powdered epoxy paint, tempered glass win-

dows, and full-featured programming are stan-

dards you’ve come to expect from I.C.E. prod-

ucts.

The ROUND CRANE uses state of the art elec-

tronics with a new drive circuit for all motors. In

our new design, even direct short circuits can’t

damage the motor or coil drivers. The protection

is built into the drivers themselves! Another ad-

vantage is that the new board incorporates

modular driver circuits so the same main board

can be used on multiple products.

This crane has been made to give you a crane

that is competitive with other smaller cranes of

similar size, but it has been engineered to leave

the competition behind. The ROUND CRANE

has been designed to easily go through a 36"

door without disassembly, and it is made to be a

great centerpiece type of game. Great for Mall

and arcade type locations.

We hope you thoroughly enjoy your ownership

experience with your new ROUND CRANE. If

you have any questions or comments, please

contact our service department at: (716) 759-

0360

GAME PLAY

As coins are inserted into the ROUND CRANE

a coin in sound will be heard. When sufficient

coins have been inserted, the game sound

starts, the claw clicks closed and re-opens,

which signals the start of the game. The crane

will position its self in the middle of the “play

field” and remain there, with the cranes sound

theme playing until the player is ready.

When the player has moved the joystick or

pressed the buttons, to move the crane, the

timer on the right display will begin to count

down. The player will position the crane above

the prize and they are attempting to win and

press the drop button to lower the claw.

If the nudging option is on, then the player will

have the ability to keep “nudging” the claw down

each time the button is pressed to hone in on

the chosen prize. If the nudging option is off,

then the player will have only one chance to

drop the claw.

When the claw is fully dropped it will close and

retract to its upper most position. The crane will

then automatically position its self over the prize

chute at the rear of the cabinet. The claw will

open, releasing the prize (if grabbed) into the

prize chamber. The player can now remove the

prize from the chamber through the prize door

located in the front of the game. The game is

now in its home position and is ready for the

next player in line.

SET-UP / TESTING / MAINTENANCE

SAFETY PRECAUTIONS

IMPORTANT: FAILURE TO FOLLOW THESE DI-

RECTIONS CLOSELY COULD CAUSE SERIOUS

DAMAGE TO YOUR GAME.

WARNING: WHEN INSTALLING THIS GAME, A 3

PRONG GROUNDED RECEPTACLE MUST BE

USED. FAILURE TO DO SO COULD RESULT IN

SERIOUS INJURY TO YOURSELF OR OTHERS.

FAILURE TO USE A GROUNDED RECEPTACLE

COULD ALSO CAUSE IMPROPER GAME OPERA-

TION, OR DAMAGE TO THE ELECTRONICS.

DO NOT DEFEAT OR REMOVE THE GROUNDING

PRONG ON THE POWER CORD FOR THE SAME

REASONS AS GIVEN ABOVE. USING AN IM-

PROPERLY GROUNDED GAME COULD VOID

YOUR WARRANTY.

GAME SET-UP

BEFORE PLUGGING THE GAME IN, OR TURNING

IT ON, BE SURE THE GAME HAS BEEN SET TO

THE PROPER VOLTAGE. YOUR GAME SHOULD

COME PRE-SET FROM THE FACTORY CORRECT

VOLTAGE, HOWEVER IT IS A GOOD IDEA TO

CHECK THE A.C. WALL RECEPTACLE VOLTAGE

BEFORE PLUGGING THE GAME IN.

ASSEMBLY INSTRUCTIONS

1. Carefully unbox the game from its packaging.

2. Using the supplied keys, unlock the front

door of the cabinet.

3. Cut all tie wraps holding the wagon assembly

and crane in place.

4. Plug the game into a three prong grounded

receptacle. NOTE: The appliance must be

positioned such that the plug is accessible

during use.

5. The game is now ready for start up.

TESTING

After the initial setup, it is time to test your game for

proper operation.

1. Locate the game in its permanent location.

2. Be sure the game has been properly plugged

into a 3 prong grounded outlet, and that the

receptacle is in good working order.

3. If using an extension cord, be sure it is a 3

prong grounded type of at least 16Ga.

4. Verify that the game is set up for the proper

voltage, and turn the power to the game on.

5. The game will run through a test mode at

every startup. See test mode explanation in

the programming section for details.

6. Insert coins/bills into the machine at least ten

times into the coin mech/bill acceptor to as-

sure proper operation

7. Check the credit and prize counters for

proper operation.

8. Check game volume during busy time at lo-

cation to set it at the proper level.

CLEANING

Regular cleaning of this game will keep it looking

new, and greatly enhance its appeal.

Clean the windows of your ROUND CRANE with a

standard window cleaner such as Windex®

Clean the cabinet sides with a good cleaner such as

“Fantastic” or “409” and a soft rag. A mild soapy so-

lution can be used. You may use a furniture polish

when finished to protect the game and make it look

more attractive,

NOTE: DO NOT USE ALCOHOL, THINNERS OF

ANY KIND, OR PINBALL PLAY FIELD CLEANERS

ON ANY OF THE CABINET SURFACES ESPE-

CIALLY THE DECALS.

IF YOU HAVE ANY QUESTIONS OR COMMENTS

REGARDING INSTALLATION OR PROPER FUNC-

TION OF YOUR GAME, PLEASE CALL OUR SER-

VICE DEPARTMENT AT

1-716-759-0360

MODE DESCRIPTION MIN / MAX / DEF MEANING

(Credit Display) (Timer Display)

BASIC PROGRAMMING

0 Game Type 0, 1, 0 0—Left, Right, Forward, Backward, Nudge

1—Left, Right, Forward, Backward, Drop

1 Game Mode 0, 1, 0 0—Normal Play

1—Play till you win

2 Time 10, 60, 20 10—60 Seconds (Inc. every 1 second)

3 Coin 0, 9, 2 0—Free Play

1—9 Coins required for a single credit

4 Bill 0, 9, 4 0—Off

1—9 Number of coins each bill is worth

5 Counter Type 0, 1, 0 0—Credit counter

1—Coin counter

6 Attract 1, 30, 20 1—30 Minutes between attract modes

7 Attract Type 1, 2, 2 1—Motion only

2—Audio and motion

8 Manual Strength 40, 99, 75 40—99 Claw strength Inc. by 1 (99= MAX)

ADVANCED PROGRAMMING

9 Auto Skill Leveling Strength 0, 99, 0 0—Auto off

60—99 Claw strength in auto (99 = MAX)

10 Right Time 0, 9, 5 0—40 Number of 1/4 sec. time intervals right

11 Forward Time 0, 40, 5 0—40 Number of 1/4 sec. time intervals forward

12 Plush Cost 1, 20, 4 Coins per piece of plush

13 Payout 20, 50, 33 20—50 Desired payout percentage

14 Tickets to Play 0, 99, 0 0—99 tickets to be paid just to play game

15 Tickets if Lose 0, 99, 0 0—99 tickets to be paid if you do not win plush

16 Factory Default 0, 1, 0 0—Normal

1—Restore factory defaults upon next startup

17 Center On / Off 0, 1, 0 0—Center option off

1—Center option on

18 Snap On / Off 0, 1, 1 0—Snap option off

1—Snap option on

19 Credit Discounting 0, 5, 0 # of Consecutive credits inserted for 1 free game

20 Up / Down Motor Test DIAG. Right display changes: 0 – 1 Up switch is made

0 – 2 Down switch is made

0 – 3 Both switches are made

21 Left / Right Motor Test DIAG. Right display changes: 0 – 1 Left switch is made

22 Front / Back Motor Test DIAG. Right display changes: 0 – 1 Back switch is made

0 – 2 Front switch is made

PROGRAMMING

Error Codes

# Problem

1 E² (Memory)

2 Prize Sensor

3 Up Sensor

4 Down Sensor

5 Left

6 NOT USED

7 Right

8 Back

9 Front

10 Counter Disconnect

11 Out Of Range (High)

12 Out Of Range (Low)

QUICK TROUBLESHOOTING

PROBLEM PROBABLE CAUSE SOLUTION

THE DECIMALS ON THE 4

DISPLAYS ARE LIT UP

NO GAME POWER

GAME WILL NOT TAKE MONEY

OR GIVE CREDITS CORRECTLY

DISPLAYS DO NOT WORK

CRANE OR WAGON DOES NOT

MOVE

CRANE KEEPS TRYING TO

MOVE IN TO THE HOME

POSITION

CLAW WILL NOT CLOSE

CLAW STAYS CLOSED

AUTO PERCENTAGING IS NOT

FUNCTIONING

CLAW GOES DOWN AND THEN

UP BUT DOES NOT CLOSE

CLAW COMES UP AND ABOUT

15 SEC. PASSES BEFORE

CRANE MOVES TO THE HOME

POSITION

CRANE OR WAGON WHEELS

SLIP

THIS IS IN FACT NOT A PROBLEM BUT A WAY

OF LETTING THE OPERATOR KNOW THAT

THERE WAS A PROBLEM DURING THE START

UP MODE

ON-OFF SWITCH ON THE GAME IS TURNED OFF

BLOWN A.C. POWER FUSE

GAME NOT PLUGGED OR CORD DAMAGED

BAD TRANSFORMER

TRANSFORMER HARNESS NOT CONNECTED

BAD POWER MODULE

BAD COIN SWITCH

COIN DISCOUNTING SET WRONG

COINS PER CREDIT SETTING INCORRECT

BAD COIN MECHANISM

LOOSE OR DAMAGED HARNESSING

BAD MAIN P.C. BOARD

BAD 12V FUSE

BAD DISPLAY P.C. BOARD

BAD MAIN P.C. BOARD

LOOSE OR DAMAGED DISPLAY HARNESSING

BAD MOTOR

LOOSE OR DAMAGED HARNESSING

BAD SWITCH ON BUTTON OR JOYSTICK

BAD HARNESSING TO BUTTONS OR JOYSTICK

BLOWN FUSE TO MOTORS ON MAIN P.C.B.

BROKEN DRIVE BELT

BAD LIMIT SWITCH(S)

LIMIT SWITCH NOT ALIGNED WITH ACTUATOR

BLOWN FUSE TO CLAW ON MAIN P.C. BOARD

BAD COIL

LOOSE OR DAMAGED HARNESSING

CLAW HAS MECHANICALLY JAMMED

BAD DRIVE TRANSISTOR ON MAIN P.C.B.

CLAW HAS MECHANICALLY LOCKED

PROGRAMMING IS NOT CORRECTLY SET

BAD PRIZE SENSOR

LOOSE OR DAMAGED SENSOR HARNESS

CLAW SLIDER SET IMPROPERLY

DOWN SWITCH BAD

LOOSE OR DAMAGED HARNESS TO DOWN

SWITCH

UP SWITCH BAD

LOOSE OR DAMAGED HARNESS TO UP SWITCH

LOOSE SET SCREWS IN WHEELS

LOOSE SET SCREWS IN DRIVE COUPLER

RAILS NEED TO BE SCUFFED

OPEN THE FRONT DOOR AND THE

ERROR CODES ARE SHOWN ON THE

DISPLAYS. TO ADVANCE THROUGH

THE ERROR CODES, PRESS THE

FIRE BUTTON

TURN POWER ON

REPLACE WITH PROPER FUSE

CHECK POWER CORD

CHECK FOR PROPER VOLTAGES

CHECK HARNESS

REPLACE POWER MODULE

CHECK W/METER AND REPLACE

CHECK PROGRAMMABLE SETTING

ADJUST OR REPLACE

CHECK W/METER - REPAIR

REPAIR OR REPLACE MAIN BOARD

REPLACE WITH PROPER FUSE

REPAIR OR REPLACE P.C. BOARD

CHECK W / METER AND REPAIR

REPLACE MOTOR

CHECK W / METER - REPAIR

REPLACE SWITCH

CHECK W / METER - REPAIR

REPLACE WITH PROPER FUSE

REPLACE BROKEN BELT

REPLACE SWITCH(S)

ALIGN SWITCH AND ACTUATOR

REPLACE WITH PROPER FUSE

REPLACE COIL

CHECK W / METER AND REPAIR

FIND JAM AND REPAIR

REPLACE TRANSISTOR

FIND JAM AND REPAIR

SET OPTIONS “9” AND “16”

REPLACE PRIZE SENSOR

CHECK W / METER AND REPAIR

ADJUST SLIDER

REPLACE DOWN SWITCH

CHECK W / METER AND REPLACE

REPLACE UP SWITCH

CHECK W / METER AND REPLACE

TIGHTEN SET SCREWS

SCUFF TOP OF RAILS WITH

SANDPAPER

QUICK TROUBLESHOOTING

1. A self-test will be performed each time the front door is “closed” or the game is powered up.

2. If the Wagon does not move smoothly through a full travel from SIDE to SIDE, check to see

that the motor driver board is working properly, and that the rotary motor itself is working.

3. If the Wagon does not move smoothly through a full travel from front to back, check to see

that the rod bushings are straight and not binding. Check for excessively loose drive belts or

one of them broken.

4. If the front door is having trouble closing fully, check to see that the front door harness is

routed properly. Also be sure the prize door is fully shut. If it is partially open it will not allow

the front door to open or close properly.

5. If the door will not lock properly or locks with difficulty, check to see if the lock rotates

smoothly. Next check that the lock rods are not binding on the lock cam or the lock rod

guides. Next check that all friction points have been lubricated with molly grease. Finally if

need be, file the lock rod guides such that the door closes and locks smoothly but be careful

not to file out too much, for this may cause the door not to pull tightly to the cabinet as it was

intended to do. Adjust the lock rod striker plates if necessary.

6. If the decimals light up on the displays after a self-test, an error has been locked. To advance

through the error codes press the drop button when in error detection mode.

7. If, at the beginning of the self-test mode, the claw does not drop, one or more of the following

may apply. The prize sensor is not working, or blocked. The string or string lever is mechani-

cally binding. The up or down switch is sticking or misaligned from its actuator.

8. If claw stays closed it is likely that the diode has blown and the transistor controlling the claw

has also blown. Shut off the game immediately and have a new diode, in coil assembly, and

transistor, on main board, installed.

9. If claw is jerky while being lowered, it is likely that the string has mechanically bound on the

spool. To fix the string binding enter programming mode and go to CLAW UP/DOWN MODE.

By moving the joystick to the left and right you are able to raise and lower the claw mecha-

nism. Move the crane over the prize chute and lower the claw mechanism all the way until it

starts to wind up backwards. Reverse the motor direction to raise the claw mechanism and

properly rewind the string on the spool. Exit the programming mode and the string should be

free of mechanical binding.

10. If the claw stays open First check for bad fuses on the main board, next check that there are

no wires dislodged from the connectors in the harness between the wagon and the crane, the

harness between the wagon and the main board, the crane assembly and the wagon assem-

bly. If the problem still exists and no fuses are blown or wires dislodged it is likely that the

transistor controlling the voltage to the claw has blown on the main board. Replace main

board and have the other main board repaired by electronics.

11. If the crane/wagon in the home position still tries to move left or back, check to see that the

actuators are both present. Check to see that the sensors are present. Next check to see

that the sensors and the actuators are both aligned. Then check to see that the sensor wires

are not dislodged from the connectors. Finally replace the sensor; it is likely to be bad.

PARTS LISTINGS

MECHANICAL PARTS

1030 Dollar Bill Validator Cover Plate

3004 Spacer, Long

3051 Wheel "O" Ring

5011 Spring

5014 Cash Box Lock

5101X Coin Mech Holder Assembly

BB3022 Wheel

BC1013-P801 Lock Cam

CG1052 Swivel Caster

CG1054 Wagon Roller Shaft

CG1061X Crane Assembly

CG1062 Crane motor Housing Cover

CG1066 Crane UP Spring

CG1070 Coil Housing

CG1073 Coil Slider

CG1075 Coil Plunger

CG1078A Small Claw

CG1078B Medium Claw

CG1078BX Medium Claw Assembly w / Solenoid

CG1078D Jumbo Claw

CG2039X Prize Sensor

CG3008A Micro Track Link

CG3008B Micro Track End Set

CG3019 Thumb Screw

CG3030 Wheel

CG3036 Coil / Claw Interconnect

CG3037 Claw Spider

CG4003 O-Ring Drive Band

CG4004 Spring

CG5014 "T" Handle Lock

CP1038-P801 Prize Door Hinge

RC1003-P700 Playfield Hinge

RC1012 Cash Box

RC1018-P100 Podium

RC1026-P100 Door Hinge

RC1022 Rotary Motor Coupler Assembly

RC1052 3" Swivel Caster

RC1061 Wheel Spacer

RC1062 Wheel Cap

RC3001AX Dome Assembly

RC3008A Micro Track Special Link ("S" bend)

RC3027 Window, Front

RC3028 Window, Side

RC3067 Prize Door

SR1053 Magnet

ELECTRONIC / ELECTRICAL

2033X Controller Board

2089X AC Rope Light Harness

2133CW White Chase Style Rope Light

2133U Rope Light "U" Channel

2134 Rope Light End Cap

2134A Chase light Power cord

8312 PLL Florescent Light Bulb

BC2032X Display, P.C. Board Assembly

BW2017 Light Bulb Retaining Clip

BW2018 Light Bulb Retainer

CG2008 Motor / Gearbox

CG2014 Joystick

CC2027 20 Ft. Power Cord, Computer Style

CG2012 Front / Back Sensor

CG2013 Left / Right Sensor

CG2039X Prize Sensor

CG2014 4 Way Joystick w / Push Button

CS2002X Transformer

CS2007X Power Module Assembly

FP2007 4" Round Speaker

HH1020 Actuator, Home Position

PP250X PLL Light Socket

RC2008 Rotational Motor and Gearbox Assy.

RC2029X Motor Driver Board

RC2034X Main P.C. Board

RC2035X Rotary Motor Driver Board

RC2036X Rotary Harness Adapter Board

RC2535X Strobe Light Assembly

MZ8284X Ballast, Work Horse 6

SUB CRANE ONLY

1017 L.E.D. Holder

RC2035X Strobe Light Assembly

RC3501X Yellow Sub Dome Assembly

RC3529X Porthole Side Panel Insert Assembly

RC3530 Diving Bell Claw Assembly

RC3530AX Diving Bell Top Assembly

RC3531AX Diving Bell Bottom Assembly

RC3540X Periscope Mount Assembly

RC3542X Left Large Periscope Assembly

RC3543X Right Large Periscope Assembly

RC3545X Small Periscope Assembly

PARTS LISTINGS

GRAPHICS

ROUND UP CRANE

RC7001 Prize Door Decal

RC7012 Control Panel Overlay

RC7027 Front Marquee Cabinet Decal

RC7028 Side Marquee Cabinet Decal

YELLOW SUBMARINE CRANE

RC7500 Cabinet Right Side Decal

RC7501 Prize Door Decal

RC7502 Cabinet Left Side Decal

RC7503 Window Rounds

RC7504 Rivet Bar, Right

RC7505 Rivet Bar, Left

RC7506 Diving Bell Top

RC7508 Cabinet Front

RC7509 Diving Bell Bottom

RC7512 Control Panel Overlay

RC7527 Front Marquee Cabinet Decal

RC7528 Side Marquee Cabinet Decal

RC7533 Bubbles, Small

RC7534 Bubbles, Small

RC7542 Green Rivets

RC7543 Yellow Rivets

RC7545 Red Rivets

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Icegame Machine de jeu d'arcade

Icegame

Icegame DODGEBALL Manuel utilisateur

Icegame

Icegame DODGEBALL ULTIMATE ARENA Manuel utilisateur

Icegame

Icegame Angry Birds Arcade Manuel utilisateur

Icegame

Icegame Harpoon Lagoon Mode d’emploi

Icegame

Icegame AF1000X Manuel utilisateur

Icegame

Icegame DB1200X Manuel utilisateur

Icegame

Icegame WORLD FOOTBALL PRO PS1000X Manuel utilisateur

Icegame

Icegame DODGEBALL Manuel utilisateur

Icegame

Icegame Bean Bag Toss Manuel utilisateur

Manuels Machine de jeu d'arcade populaires d'autres marques

Universal Space

Universal Space COCONUT BASH Manuel utilisateur

Bay-Tek

Bay-Tek EVOLVE Manuel utilisateur

Global VR

Global VR America's Army Instructions d'installation et d'utilisation

Atronic

Atronic Cashline Manuel utilisateur

Universal Space

Universal Space Checky Monkey Manuel utilisateur

Bay-Tek

Bay-Tek Skee Ball 1908 Alley Manuel utilisateur

Aristocrat Technologies

Aristocrat Technologies Mars X Upright Manuel utilisateur

Family Fun Companies

Family Fun Companies Reactor Guide de démarrage rapide

Universal Space

Universal Space FRUIT MANIA Extreme Manuel utilisateur

falgas

falgas CARRUSEL FIESTA Manuel utilisateur

Konami

Konami DanceDanceRevolution Manuel utilisateur

Bay-Tek

Bay-Tek quik drop Manuel utilisateur

Bandai Namco

Bandai Namco PAC-MAN BATTLE ROYALE CHOMPIONSHIP DELUXE Manuel utilisateur

Adrenaline

Adrenaline Flying Tickets Instructions d'installation et d'utilisation

Swinks

Swinks Stern Pinball Ghostbusters Manuel utilisateur

Innovative Concepts in Entertainment

Innovative Concepts in Entertainment MONOPOLY ROLL-N-GO Manuel utilisateur

jakar

jakar SPEED CARS Manuel utilisateur

Carmelli

Carmelli HAT TRICK NG1015H Manuel utilisateur
