Icecrypt T2300HD Manuel utilisateur
User Manual
Icecrypt T2300HD
Content ..............................................................................................................
Introduction ......................................................................................................
Quick Start Guide .............................................................................................
Basic Operations ..............................................................................................
Menu Information ..............................................................................................
Channel Menu ...................................................................................................
Picture Menu .....................................................................................................
Sound Menu ......................................................................................................
Time Menu .........................................................................................................
Option Menu ......................................................................................................
Lock Menu .........................................................................................................
Multimedia Player .............................................................................................
Introduction and Features
Unpacking, Safety information
Controlling the receiver, Front Panel information .............................................................................
Rear Panel connections, Connecting up your digital receiver ........................................................
Connecting to your Antenna, HDMI, SCART and Audio devices .....................................................
Remote Control ....................................................................................................................................
Switching on for the first time.............................................................................................................
Service search ......................................................................................................................................
Day to day use of your receiver ..........................................................................................................
Menu overview
Auto Tuning ..........................................................................................................................................
Manual Tuning ......................................................................................................................................
Programme Edit ...................................................................................................................................
Signal info, Software Update ..............................................................................................................
TV System, SCART Mode, Aspect Ratio, Resolution
Balance, SPDIF outout, SPDIF delay
Clock, On/Off timer, Sleep / Auto Sleep timer, Time Zone
Menu Time out and Menu Transparency
OSD, Audio, Subtitle Language. Hearing Impaired, PVR File System, Factory Default ................
Network configuration .........................................................................................................................
ECO Power, Antenna Power, Country, Software Update (USB) and System Information .............
System Lock, Set Password, Block Programmes, Parental Guidance
Your Media, Movies, Music ..................................................................................................................
Photos, Thumbnails, Files ...................................................................................................................
Setting Movie Preview Window. Setting Resume Play and Slide Show .........................................
Devices (USB), DTV Mode, supported media format information ...................................................
Audio, Music and Picture format information ...................................................................................
Personal Video Recording and Playback ...........................................................................................
Content:
2
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
24
25
26
26
27
28
29
30
31
15
Electronic Programme Guide ..........................................................................
MHEG-5 / Teletext .............................................................................................
Home Networking .............................................................................................
Network Based Applications (IP Button) ........................................................
EPG information, Programme reminder, Scheduling features
MHEG-5 Digital Text and conventional Teletext functions
UPnP, Network Media requirement, Digital Media Player .................................................................
Playing Media files: Movies, Photos, Music ......................................................................................
BBC iPlayer (UK only), Video browsing, Video profiles.
System overview, Red key ..................................................................................................................
Main menu, EPG, Video On Demand (VOD), Teletext .......................................................................
Youtube Leanback, Watching videos, Control Menu, Search Videos, Categories
Login to your account, Main Menu .....................................................................................................
Making Video calls, making Voice calls .............................................................................................
Stay in touch with Facebook on you receiver
Stay in touch with Twitter on your receiver
Surf the internet using the built-in browser
Free web mapping service application provided by Google
Photo sharing applications
Access your files on your Android device via Wi-Fi
Download and Play games on your receiver
HbbTV (Only available for certain models and markets) ..............................
YouTube (Only available for certain models and markets) ...........................
Skype (Only available for certain models and markets) ...............................
Facebook ...........................................................................................................
Twitter (Only available for certain models and markets) ..............................
Web browser .....................................................................................................
Google Maps .....................................................................................................
Flickr / Picasa ....................................................................................................
Samba File sharing ...........................................................................................
Games ................................................................................................................
Trouble Shooting ..............................................................................................
Technical Specifications ..................................................................................
Content
33
34
35
35
36
37
38
38
39
40
41
41
42
43
45
46
47
48
49
49
50
51
Introduction
The ICECRYPT T2300HD digital receiver is fully compliant with the international Digital
Video Broadcasting DVB-T and DVB-T2 standard. In order to receive these services, all
that is required is a conventional terrestrial aerial.
Features
The ICECRYPT T2300HD has the following features:
DVB-T/DVB-T2 compliant
MPEG-2 MP@ML, H.264(MPEG-4 Part 10) SD &HD transport stream
decoding
480i, 576i, 720p, 1080i, 1080p video resolution
MHEG-5 Interactive Services (Red Button)
Over 1500 TV, Radio and Data channel memory - subject to broadcast
On Screen Display with multi-language support
Favourite groups and Favourite channel selection
7-Day Electronic Programme Guide (EPG)
Automatic and Manual channel search
Versatile channel editing functions (Favourite, Move, Rename and Sort)
Picture in Graphics support (PiG)
32-bit colour On Screen Display (OSD)
Time set by GMT offset automatic and manual, Summer Time support
Subtitle support DVB EN300743 and EBU
Teletext support DVB ETS300472 by VBI and OSD
Automatic last channel memory
Logic Channel Number (LCN) support
Parental Lock
Automatic PAL/NTSC conversion
Multimedia playback with
USB updates.
MP3, WMA, OGG, JPEG, BMP, PNG, MPG, TS,
TRP, MP4 etc.
Lock/Delete/Rename,Preview playback, Browse record files information
Full control for multimedia playback: Play/Pause/Stop/FF/FR/Prev/Next
FAT16/FAT32/FAT12/NTFS Hard Disk support
Web Browser, Google Maps, Facebook, HbbTV, Home Networking,
Picasa, Samba and other OTT Functions.
(Please note OTT Functions may vary depending on market.)
Multi-language support
Unpacking
Please check that you have received the following items with the digital receiver.
Remote control unit
Two batteries for the remote control(AAA 1.5V)
One HDMI cable
A copy of this User Manual
Note: Accessories may vary according to your local area.
Safety precautions
Please read carefully the following safety precautions.
This unit is designed to operate between 90 and 250 volts. Please consult your local
installer if you are unsure of your local mains supply voltage before installation.
The mains adapter should be readily accessible so it can be easily unplugged when
necessary.
Note: This digital receiver is designed for indoor use only.
Expose the digital receiver to any liquids or install the unit in high humidity locations
such as bathrooms etc.
Remember to provide adequate ventilation w
allowing a minimum of 10cm of space surrounding the unit. Avoid placing the unit on
top of another device such as DVD player etc.
hen installing the unit in a cabinet, by
Place the digital receiver on a firm and level surface.
Place the digital receiver close to any heat sources or in direct sunlight.
Cover the unit as it will impair the cooling of the unit.
Protect the power cord from being damanged. If the cord is damaged, do not use the
digital receiver and get the cord replaced by a qualified service technician.
Open the digital receiver casing under any circumstances, or the warranty will be
void. Refer all repairs to a qualified service technician.
Do Not:
Connect or disconnecting anything to the unit whilst the unit is powered, apart from
USB accessories.
Do:
Disconnect the unit from mains power supply when the unit is to be left unused for
long periods of time.
Disconnect the unit from mains power and from the aerial when a thunderstorm is
expected.
Use any solvents or spray cleaner to clean the unit..
Use only a lightly damp cloth to clean the unit.
Quick Start Guide
When not in use, please keep the unit in stand-by mode in order to allow
event times to function normally.
NOTE
Front panel
Controlling the digital receiver
You can operate the ICECRYPT T2300HD digital receiver with the remote control or
via the buttons on the front panel.
Quick Start Guide
CH+/CH- to change to previous or next channel sequentially
IR Sensor for receiving remote control signals. Point the remote control
handset here.
Front panel 4-digit LED displays the current time in standby mode and
current channel number when in use
Standby mode RED LED indicator
USB port for USB device such as a memory stick (behind the dust cover).
button switches the digital receiver between standby mode and
active mode.
Rear panel connections
The T2300 HD has the following connections on the back:
Connect the terrestrial aerial to this socket
Terrestrial signal loop output socket: Connect other digital
receiver products to this socket.
Digital audio output socket for the audio-video receiver
Local area network (connect to your router)
USB device socket
Audio and video output socket for the high definition
television set
Audio and video output socket for the older television set
12V DC power inlet socket
Connecting up your digital receiver
For power connection, always follow the LIFO rule: Last in First out!
Always disconnect the unit from the mains power socket before connecting or
disconnecting anything else (apart from USB hot plug devices)
PLEASE NOTE: This receiver has an Eco Low Power Saving function (under 1 Watt in
Standby). When this is turned ON the RF loop out will not be active and will not pass a TV
signal when the unit is in Standby. If you require the RF loop out to be active and pass a TV
signal while in Standby mode please keep the Eco Low Power Save function set to OFF.
This digital receiver can be used with most television sets on the market, except perhaps
the very old types without AV inputs of any kind. In most cases the digital receiver will work
with most televisions and other devices by using the correct kind of cable (HDMI, SCART to
SCART, SCART to RCA cables etc.).
Where possible, use HDMI connections for best results. However, if you are unsure the
type of cable you require for you TV set or AV devices, please contact your dealer.
Quick Start Guide
Connecting to the antenna
First, connect the digital receiver to the
terrestrial antenna so that it can receive
digital television broadcasts.
Connect the antenna cable to the ANT IN
connector. If you have another digital
receiver, you may connect it to the LOOP
connector using an RF lead.
NOTE
LOOP is used as an antenna output for use with other devices such as TV’s,
VCR, or devices requiring an antenna signal.
To use the HDMI output
If you have a high definition television set,
you should use an HDMI cable for best
results. Plug one end of the cable into the
HDMI socket on the digital receiver, and plug
the other end into the matching socket on
your television.
For best results with a standard definition
television set, you should use a SCART
cable. Plug one end of the cable into the TV
socket on the digital receiver, and plug the
other end into the SCART socket on your
television.
To use the SCART output
You can not view high definition video via the SCART output.
NOTE
To make the audio connection
To enjoy Dolby Digital audio, your television
or A/V receiver must be able to decode
Dolby Digital audio, and you need to obtain
an optical S/PDIF cable. Plug one end of the
cable into the optical S/PDIF socket on the
digital receiver, and plug the other end into
the optical S/PDIF socket on your AV
receiver.
Quick Start Guide
12
3
9
12
16
4
10
19
17
8
11
15
13
13
14
14
18
5
7
6
2220
23
26
24
27
28 29
21
25
Function
Key
Standby/ON
Selects TV or Radio mode
0~9
MENU
EXIT
OK/LIST
Direct channel entry
Displays the on-screen menu
Return to the previous menu or
exit from main menu
TV/RADIO
Displays the favourite group list
FAV
Selects the highlighted item in the
menu screen or when entering
a value in any input mode.
Displays the channel list.
Move cursor up or down in menu
Move cursor right or left in menu
Displays the EPG
(Electronic Programme Guide)
EPG
Subtitles
TXT Teletext
PR+,PR-
Back to previous channel
SUB
Change the aspect ratio
Volume up / down
IP
Change the HD format
Change channels up/down
Optional OTT functions on
selected models
MEDIA Start the Media Player
WIDE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Mute
Display the Audio window.
AUDIO
Displays the current channel
information
INFO
AD
Audio Description ON/OFF
Remote control
Play
RECORD
Stop
Optional record functions on
selected models
24
25
26
27
28
29
PAUSE
When USB is not connected, press to
TV picture, press again to release.freeze
When USB is connected, press to
live TV (time-shift function)pause
Previous and next
Press to fast forward or fast backward
Quick Start Guide
Switching on for the first time
First insert batteries provided into the remote control. Take care when opening the
battery compartment and insert the batteries observing the polarity, which is
marked on the base of the battery compartment.
Ensure that your television set is switched on and on the correct video channel so
that you will be able to see the on-screen display from the digital receiver.
Once you have checked that you have connected your digital receiver correctly,
you can then plug in the mains power.
Press the button on the top left corner on the remote control. In a few
moments, you should see an on-screen menu and you should see the channel
indicator lit on the front panel of the receiver.
If you do not see anything on your TV, try pressing the V Format button on the
remote control. If after several tries you still get no picture, check that the television
is set to the correct input.
When you see the on-screen menu, you can start searching for available television
and radio services.
CAUTION
If the digital receiver no longer responds properly to the remote control
commands, first check that the IR sensor is not obstructed. Otherwise the
batteries in the remote may be flat. Replace only with 1.5 V AAA size batteries.
Do not mix different types of batteries, or new with old batteries.
Do not use rechargeable batteries.
Never recharge the old batteries.
Observe the polarities indicated inside the battery compartment.
Replace exhausted batteries immediately.
If you are not using the remote control for a long period of time, remove the
batteries. The manufacturer accepts no liability for the damage resulting
from leaking batteries.
Please dispose of used batteries in an environmentally sound manner.
Quick Start Guide
Table des matières
