Setup
Located inside the coin door are the coin and ticket meters, volume up and down
buttons, service button, and test button. You can lower or raise the volume by
pressing the UP and DOWN VOLUME buttons or set the volume through settings.
To test play your game without adding to the coin meter, press the SERVICE but-
ton. To enter programming options, press the TEST button.
To navigate through the menus, press volume up and down to move to different
options and press test to select that option.
000155 000041
Coin Tickets
Volume
Up
Service
Volume
Down
Test
Touch Screen - Calibration and Cleaning
When you have installed your game on location it is a good idea to entering pro-
gramming and adjust the calibration. Doing so will ensure reliable operation at
that location. If at anytime you upgrade the software to a newer version you
should also enter programming and perform a calibration.
When cleaning your touch-screen monitor it is important to never use a ammonia
based cleaner. Any non-ammonia based glass cleaner can be used to clean the
screen. Always spray the glass cleaner on the cloth or towel and then clean the
touch-screen.
4
Setup - Programming
The settings of your new game are crucial to the earnings and repeat play by your
customers. So how do you find the optimal settings for your location? Begin by
looking around your game room to find comparable games. The 3 main factors in
finding a comparable game are:
Cost of Game (purchase price)
Average Play Time
Game Type (video skill, play value redemption, quick coin, merchandiser, etc).
Once you have narrowed down your game room and have found comparable
games, review your current settings on these games. Then refer to the game
manual to determine how to change the settings if necessary.
How the game rewards the player:
The number of tickets given in the bonus prize is determined by the cost to play
the game and which type of bonus you have selected. The types of bonuses are:
Small = cost to play in cents
Medium = Twice the cost to play in cents
Large = Three times the cost to play in cents
The number is then rounded down to the next multiple of 5.
For example for a quarter game it will have 25 for the small bonus, 50 for the me-
dium bonus, and 75 for the large bonus values while a dollar game will have 100
for the small bonus, 200 for the medium bonus, and 300 for the large bonus val-
ues. If the cost of the game was .22 cents then the software would pay out 20 for
the small bonus, 40 for the medium bonus, and 65 for the large bonus values as it
would round down the values to the next multiple of 5.
5
Setup - Programming
Software version BUB_v01.00.09_STD
Main Menu
Operation Adjustments
Game Adjustments Default Options
Invert Touch Input Off On/Off
This option should only be enabled from the factory.
Use Bonus Bar On Off/On
This allows the bonus to be used or not.
Bonus Payout Amount Small Small/Medium/Large
This determines how large the bonus of tickets to give.
Ticket Adjustments
Minimum Tickets 1 0 or 1
This option gives a ticket to the player for just playing.
Ticket Value (in cents) .01 0 - 100
Credit Value (in cents) .25 0 - 100
Coin Settings
Free play Off On/Off
Currency Type Dollar Country or Coins
Currency Unit Value .25
Coin 1 Value .25
Coin 2 Value .25
Coin 3 Value/DBV Pulse .25
Maximum Credits $500
Player Cost/Payout
Cost to Play .25
Target Payout Percentage 40% 25 - 50
Volume
Game Volume 8 1-32
Attract Volume 6 1-32
Attract Sounds occasionally off/always/occasionally
6
Setup - Programming
Software version BUB_v01.00.09_STD
Main Menu
General Audits
Game Audits
Games played
Average game time
Ticket Audits
Total tickets dispensed
Average tickets per play
Current payout percentage
Total tickets (500 games)
Average tickets (500 games)
Payout percentage (500 games)
Tickets owed
System Audits
Playtime Shows the time people take to play a game.
Up time How long the game has been running.
Watch dogs This shows how many times your game has
Been reset by the watchdog board. Many
watch dogs might indicate a defective PC.
Exceptions See above.
Bad traps See above.
Coin Audits
Total Coin 1 How many coins has been inserted.
Total Coin 2 How many coins has been inserted.
Total Coin 3 (DBV) How many coins/DBs has been
inserted.
Lifetime coin count Total count of coins
Service credits
7
Setup - Programming
Software version BUB_v01.00.09_STD
Main Menu
Reset Menu
Reset game audits
Reset credits
Reset tickets
Reset coin counters
Reset adjustments
Factory reset
System Tests
Version list
Switch test This will allow you to test all switches.
Screen tests This test displays images to check the
monitor for proper operation.
Sound test This test plays sound samples.
File test This test checks the hard drive’s file system.
Coin meter test This test will advance the meter once.
Ticket dispenser test This test will dispense one ticket.
Dipswitch settings This test shows you settings on the I/O
board.
Watchdog test This test resets your computer testing the
built in watch dog pcb in the computer.
Screen Calibration
Depending on the touch screen used the instructions for doing your
screen calibration will be different. Follow the onscreen instructions to
calibrate your touch screen.
8
Monitor Assembly Replacement
The monitor assembly (monitor + touch screen) is attached to the front cover. You
will need to remove the 6 Allen screws circled in red below to remove the front
cover. The cover will slide as shown below. Disconnect the power, touch screen
USB cable and VGA signal wire before completely removing the front panel.
Once removed, lay the front cover on its front and remove the 9 nuts that hold the
monitor assembly. The monitor assembly can now be removed.
