ic audio
Status 09/2014
User manual
… to make people listen
MT-WCP-6
Wall control panel
for MT-AMP 1000
ic audio
MT-WCP-6
ic audio GmbH
Boehringerstraße 14a; D-68307 Mannheim; Germany
Fon: + 49(0) 621 / 77096-0; Fax: + 49(0) 621 / 77096-26
E-Mail: [email protected]; www.ic-audio.com
EN
2
Images
IMPORTANT
Before installing or operating this product, please always read this manual carefully.
WARNING:
To prevent the risk of fire or electric shock, never expose this product to rain or humidity.
ic audio GmbH
Boehringerstraße 14a; D-68307 Mannheim; Germany
Fon: + 49(0) 621 / 77096-0; Fax: + 49(0) 621 / 77096-26
E-Mail: [email protected]; www.ic-audio.com
EN
3
Table of content:
Images 2
1. Introduction 4
2. Features 4
3. Front panel 4
4. Rear panel 6
5. Installation 6
6. Technical specifications 7
ic audio
MT-WCP-6
1. Introduction
MT-WCP-6 is a modern designed wall panel.
MT-WCP-6 can be linked with MT-AMP 1000.
It can remote control the zone, music input and control the volume of MT-AMP 1000.
Connect external microphone for paging and external music source for MT-AMP 1000.
RJ45 terminal for easy installation of the system.
2. Features
MT-WCP-6 can control the zone, source and Aux 1~3 signal input of MT-AMP 1000.
Remote volume control can adjust the output signal level of MT-AMP 1000.
LINE IN socket for external music signal input.
Balanced microphone input to give announcement through wall control panel.
LINE IN and microphone signal can be mixed, use the trimmer to adjust the signal level.
The wall panel is available only when the BGM select of the MT-AMP 1000 is set at “Remote” position.
ic audio GmbH
Boehringerstraße 14a; D-68307 Mannheim; Germany
Fon: + 49(0) 621 / 77096-0; Fax: + 49(0) 621 / 77096-26
E-Mail: [email protected]; www.ic-audio.com
EN
4
ic audio
MT-WCP-6
3. Front panel
1
2
6
3
7
5
4
ic audio GmbH
Boehringerstraße 14a; D-68307 Mannheim; Germany
Fon: + 49(0) 621 / 77096-0; Fax: + 49(0) 621 / 77096-26
E-Mail: [email protected]; www.ic-audio.com
EN
5
ic audio
1. All/Zone 1~6 select switch & LED.
※All” switch can activate Zone 1~6 of MT-AMP 1000 and the relative Zone LED will light up.
Zone 1~6 switch can select each zone individually.
When the zone is selected, the relative LED will light up.
Press again to disable the Zone output.
2. Source/Aux 1~3 select switch & LED
Once the BGM signal selection of MT-AMP 1000 is set at “Remote” position, the wall panel can take over
BGM of MT-AMP 1000.
※Source” is to select signal from music source module of MT-AMP 1000.
※Aux 1~3” is to select signal from Aux 1~3
The LED will light up when the signal is selected.
3. LINE IN
耳3.5 LINE IN socket can input external music signal.
Line in signal will mix with MIC Input.
The priority is the same as BGM of MT-AMP 1000.
4. MIC Input
Balanced MIC Input can give speech to MT-AMP 1000 through MT-WCP-6 .
The priority is lower than MIC 1~6 but same priority as Source/Aux 1~3 of MT-AMP 1000.
5. Mix level adjust VR
The Line In and MIC signal will mix together.
The mixed signal level can be adjusted by “Mix Level” trimmer.
6. Remote Master VR
Remote Master VR can adjust the MT-AMP 1000 Master volume level.
When BGM is set at “Remote”, it can take over the Master volume control of MT-AMP 1000.
7. Activate Switch
Push Switch to switch on the wall panel, the activate LED will light up.
The wall panel will able to control MT-AMP 1000.
Push again to switch off wall panel, the activate LED will light off.
The LED will flash in 200mS periodically when there is other higher priority signal is operating.
The LED will flash in 1 Sec periodically if the BGM of MT-AMP 1000 is not set at “Remote” position.
MT-WCP-6
ic audio GmbH
Boehringerstraße 14a; D-68307 Mannheim; Germany
Fon: + 49(0) 621 / 77096-0; Fax: + 49(0) 621 / 77096-26
E-Mail: [email protected]; www.ic-audio.com
EN
6
ic audio
4. Rear panel
1. Data Socket
RJ45 data socket for connection between MT-AMP 1000 and MT-WCP-6.
MT-WCP-6
1. Unpack package
Open the package box and take out the unit.
Please check the accessories:
4 screws and manual
2. Insert the RJ45 cable to the RJ45 terminal
5. Installation
RJ45 cableRJ45 terminal
3. Fix the panel with the 4 screws to the compartment box on the wall.
4. Press the key to check the function and communication with MT-AMP 1000.
ic audio GmbH
Boehringerstraße 14a; D-68307 Mannheim; Germany
Fon: + 49(0) 621 / 77096-0; Fax: + 49(0) 621 / 77096-26
E-Mail: [email protected]; www.ic-audio.com
EN
7
ic audio
MT-WCP-6
6. Technical specifications:
MIC input XLR, 2mV/600Ω balanced
MIC Frequency Response 100~15KHz
MIC THD < 1%
Line In input φ3.5 stereo input, 10KΩ, 200mV, unbalanced
Line In frequency response 60-18KHz
Line In THD < 1%
Output Level 1 V rms.
Control key
All Tact switch x 1 Z1~Z6
Tact switch x 6 Source/AUX
1/AUX2/AUX3 select Tact switch x 1
Volume control Remote Master Rotary VR x 1 Mix
level Rotary VR x 1
Activate switch Push switch x 1
Indicator
All/ Zone Green x 7
Source/AUX1/AUX2/AUX3 Green x 4
Activate Blue x 1
Output RJ45 x 1
Operating temperature -10 45
Mounting 4 screws
ic audio
… to make people listen
ic audio GmbH
Boehringerstraße 14a
D-68307 Mannheim
Germany
Fon: + 49(0) 621 / 77096-0
Fax: + 49(0) 621 / 77096-26
www.ic-audio.com
E-Mail: [email protected]
ic audio
Status 09/2014
… to make people listen
MT-WCP-6
Fernsteuereinheit
für MT-AMP 1000
Bedienungsanleitung
ic audio
MT-WCP-6
ic audio GmbH
Boehringerstraße 14a; D-68307 Mannheim; Germany
Fon: + 49(0) 621 / 77096-0; Fax: + 49(0) 621 / 77096-26
E-Mail: [email protected]; www.ic-audio.com
DT
2
Produktbilder
WICHTIG
Vor der Installation und Bedienung dieses Produkts, bitte immer die Gebrauchsanleitung
sorgfältig lesen.
Um das Risiko eines Brandes oder eines Kurzschlusses zu minimieren, das Gerät bitte immer
vor Feuchtigkeit schützen.
