IBM UPS3000 LV Manuel utilisateur

IBM eServer System x and BladeCenter

IBM UPS3000

2700 Watt/3000 VA UPS

IBM System x – UPS3000 Training

2October 2007

System x Options Program

Increase system reliability. Always include power

protection and distributed power

UPS and PDU are designed and tested for

compatibility to ensure out-of-box usability

Available from System x Options group

IBM System x – UPS3000 Training

3October 2007

UPS Market Overview

Technology Trends

Move to rackable products is

speeding up

Trend toward dense packaging to

optimize computing power per square

foot

Power continuity and protection

growing in importance to the running

of business

The clean, reliable, power needs of

today's complex computing is

growing faster than the power grid

can support

Market Environment

UPSs need to be competitively

priced and positioned- they are

becoming standard options with

server rack sales.

Customers are willing to pay for

rack density

Worldwide customers demanding

IBM branded products to increase

success rate

IBM System x – UPS3000 Training

4October 2007

Understanding Power Terms

• Wattage - a measurement of real power (bucket)

• Amps - measurement of the rate of current flow (flow)

• Voltage - definition of the capacity (pipe)

• Formulas: Amps = Watts/Voltage

VA = Volts*Amps

PF = W/VA

So if server draws 500W how many Amps will it draw

at 110V and at 220V?

5.4A at 110V and 2.3A at 220V

• Most countries in EMEA run at 220-240V (World Trade)

• If you see 32A or 63A this show it is for World Trade

• If you see 30A or 60A this is an indication its for North America

style

x306

BladeCenter

220V

110V

IBM System x – UPS3000 Training

5October 2007

Single-phase vs. Three-Phase

C19/20 C13/14

Single Phase Three Phase

Signal Single electrical signal between two wires Three electrical signals between three wires

Output Single phase Three phase

Application

Typically used within a facility, often at point of

use, including:

Servers

Rack PDUs 15 to 60A

Racks

Small Computer Room

Typically used for power coming into a facility,

including:

Data Centers

Rack PDU 32 & 60A 3P

Larger Computer Rooms

High-end Servers

PDU Types NEMA, Rack, Front End, High Density, Enterprise,

PDU+ Front End, High Density, Enterprise, PDU+

IBM System x – UPS3000 Training

6October 2007

Volt-Amps and Watts:

Apparent Power and Real Power

Real Power

Apparent Power

VOLTAGE TIME

16.67ms.

CURRENT

The Power Factor is the Phase Difference between V and A

UPS needs to be able to provide both the kVA and the kW required by the load-

output p.f. indicates the multiplier from kVAs to kWs

Higher Output p.f. allows the UPS to be used with modern server loads without

having to upgrade to a larger kVA size

VA x PF = W

KVA x PF = KW

. . . The true output

power of a UPS is

measured in watts

While UPSs are

generally measured

in VA . . .

IBM System x – UPS3000 Training

7October 2007

What is a UPS?

“An uninterruptible power supply [or system] is defined as a

back-up power system used to ensure uninterrupted power for

various electronic devices.”1

Uninterrupted power may be achieved in the following ways:

• Provides back-up power when utility power fails

• Either long enough for critical equipment to shut down sequentially, ensuring

no data is lost, or

• Long enough to operate required loads before a generator comes on-line

• Provides clean and regulated power to electronic devices

New UPS3000 shown in rackmount and tower configuration.

1. Frost and Sullivan 2004 World UPS Markets Report

IBM System x – UPS3000 Training

8October 2007

Why a UPS?

Cost of Downtime

•The power grid typically provides only about 99.9% reliability

•In other words, almost 9 hours of downtime per year!

•The total cost to the US of power interruptions is $80B annually1

•Momentary interruptions were responsible for 2/3 of this cost- thus, it is the length

of the downtime, not length of the interruption, that determines the cost

Electrical downtime is a source of substantial cost to our customers-

Accordingly, a UPS is an extremely cost-effective investment

$80B Annual Cost of Electrical

Downtime to US Business Sectors Avg. Cost of 1-Hr Outage for Select

Industrial Equipment and Processes

Present

Absent

However, the average cost

per outage per industrial

customer is 3-4 times

higher than for the average

commercial customer

Industrial

Sector

$20.0B Commercial

Sector

$57.0B

Residential Sector $1.5B

IBM System x – UPS3000 Training

9October 2007

Things to consider when choosing power backup

1. How critical is the load?

Different UPS technologies offer different protection

2. Power requirement in both Watt and VA?

As many of today’s servers use power factor corrected supplies, it is

important to look at both Watt and VA power needs to avoid over sizing.

3. How much backup time is needed?

4. What are your future power requirement?

5. Will you need hardwired installation?

6. What are your space requirements?

7. Determine heat dissipation

8. Do you want to monitor or control your system remotely?

IBM System x – UPS3000 Training

10 October 2007

Executive Summary

Market Positioning

An easy to install, highly dense Uninterruptible Power Supply. Designed to protect

your valuable system and it’s data from unexpected utility power failures and

irregularities.

Key Product Messages

2U design to fit into today’s standard 19’ racks. Line cords now ordered as a

separate option. Additional battery modules available to extend run times.

Features & Functions

•A high density uninterruptible power solution for your rack based environment.

•Additional battery modules available to extend run time.

•Remotely managed w/ alert messaging.

•Both Low and High Voltage Models.

•Available with nine C13 outlets (high voltage)

•Available with seven NEMA outlets (low voltage)

Competitive Advantages

Maximum power protection and control in a 2U space saving design

Announce date: April 25, 2006 GA Date: shipping
