Quick Install Guide IBM
IBM Power®System S822LC (8335-GTB) Quick Install Guide
Read all precautions and instructions before you start working on the system and its parts.
Use normal electrostatic discharge (ESD) procedures when working on the system and parts. IBM
recommends wearing gloves and an ESD wrist strap to avoid possible damage to the equipment.
The information about the 8335-GTB system is available online in the IBM Knowledge Center.
https://ibm.biz/QR8335-GCB
8335-GTB parts
Use this information to find the field-replaceable unit (FRU) part number.
After you identify the part number of the part that you want to order, go to Advanced Part Exchange
Warranty Service. Registration is required. If you are not able to identify the part number, go to
Contacting IBM®service and support.
Rack final assembly
Table 1. Rack final assembly part numbers
Index number Part number
Units per
assembly Description
1 45W8836 1 Fixed rail kit - contains left and right fixed rails and
attaching screws
2 00E4260 1 Slide rail kit - contains left and right slide rails and
attaching screws
3 74Y9063 1 Cable management arm assembly
4 45W8836 1 Fixed rail kit - contains left and right fixed rails and
attaching screws
5 00E4260 1 Slide rail kit - contains left and right slide rails and
attaching screws
6 1 Electronic Industries Association (EIA) bracket (right side)
7 00E4688 1 Bezel
8 1 EIA bracket (left side)
Figure 1. Rack final assembly
2
System parts (air-cooled and water-cooled systems)
Table 2. System parts (air-cooled and water-cooled systems)
Index number Part number
Units per
assembly Description
1 1 Top access cover assembly
2 2 - 3 PCI adapters. Use the feature type of the adapter to find the
FRU number in PCIe adapters for the 8335-GTB.
3 46K5109 1 - 2 PCI filler
4 00E4574 1 Baseboard management controller (BMC) card
5 1 Power riser air baffle
6 01AF370 2 Power supply
7 00E4705 1 Power riser without time-of-day battery slot
Figure 2. System parts (air-cooled and water-cooled systems)
3
Table 2. System parts (air-cooled and water-cooled systems) (continued)
Index number Part number
Units per
assembly Description
8 00E4704 1 Power riser with time-of-day battery slot
Note: The power riser part number does not include the
time-of-day battery. The time-of-day battery is a CR2450N
lithium battery.
9 1 Time-of-day battery
10 00E4482 1 Disk and fan signal cable
11 00E4481 1 Fan power cable
12 00E4550 1 Front USB cable with connector
13 00E5189 1 Power switch and power switch cable
14 2 Screw
15 00E4252 2 Drive filler
00LY266 2 1 TB disk drive
00LY418 2 2 TB disk drive
00LY409 2 480 GB solid-state drive
00LY411 2 960 GB solid-state drive
00LY423 2 1.9 TB solid-state SATA drive
00LY438 2 3.84 TB solid-state drive
16 00E4256 4 Fan
17 00E4251 8 Memory riser filler
00E4498 8 Memory riser
78P4618 32 4 GB, 1600 MHz DDR4 RDIMM
78P4620 32 8 GB, 1600 MHz DDR4 RDIMM
78P4621 32 16 GB, 1600 MHz DDR4 RDIMM
78P4622 32 32 GB, 1600 MHz DDR4 RDIMM
4
Additional system parts (air-cooled system)
Table 3. Additional system parts (air-cooled system)
Index number Part number Units per assembly Description
18 2 Graphics processing unit (GPU) air baffles
19 01EM024 2 Rear GPU kit (includes GPU card, air baffle, heat sink,
and thermal interface material (TIM))
20 01EM025 2 Front GPU kit (includes GPU card, air baffle, heat sink,
and TIM)
21 00E4570 1 System backplane kit (includes module removal tool,
4mm hex key, magnetic screwdriver, air pump, and lid
removal tool)
Figure 3. Additional system parts (air-cooled system)
5
Table 3. Additional system parts (air-cooled system) (continued)
Index number Part number Units per assembly Description
22 00E5185 2 8 core 3.259 GHz system processor module kit (includes
system processor module, processor tray, 4mm hex driver,
module replacement tool, and air pump)
00E5187 2 10 core 2.860 GHz system processor module kit (includes
system processor module, processor tray, 4mm hex driver,
module replacement tool, and air pump)
23 01AF286 2 System processor heat sink kit (includes heat sink and
TIM)
24 01AF286 2 System processor heat sink kit (includes heat sink and
TIM)
25 00E5128 1 Disk drive and fan card
26 00E4476 1 Screw kit
Note: The screw kit includes 12 screws for the disk drive
and fan card and 16 screws for the system backplane.
27 1 Middle support for the system backplane
6
Additional system parts (water-cooled system)
Table 4. Additional system parts (water-cooled system)
Index number Part number Units per assembly Description
21 00E4570 1 System backplane kit (includes module removal tool, 4
mm hex key, magnetic screwdriver, air pump, and lid
removal tool)
Note: When replacing the system backplane kit in a
water-cooled 8335-GTB, you also need the System
processor TIM replacement kit (01EM029) and the
water-cooled system backplane kit (01EM030) . The
water-cooled system backplane kit (01EM030) is not
needed if you already have it.
Figure 4. Additional system parts (water-cooled system)
7
Table 4. Additional system parts (water-cooled system) (continued)
Index number Part number Units per assembly Description
22 00E5185 2 8 core 3.259 GHz system processor module kit (includes
system processor module, processor tray, 4mm hex driver,
module replacement tool, and air pump)
00E5187 2 10 core 2.860 GHz system processor module kit (includes
system processor module, processor tray, 4mm hex driver,
module replacement tool, and air pump)
23 00E5128 1 Disk drive and fan card
24 00E4476 1 Screw kit
Note: The screw kit includes 12 screws for the disk drive
and fan card and 16 screws for the system backplane.
25 1 Middle support for the system backplane
26 01EM027 Water-cooled GPU kit (includes spreader assembly, GPU
card, air baffle, heat sink, and TIM)
27 01AF969 1 Cold plate assembly (includes cold plates, tweezers, and
TIMs)
Miscellaneous parts
Table 5. Miscellaneous system parts
Description Part number Units per assembly
System processor TIM replacement
kit (includes TIM removal tool,
tweezers, and TIM)
01EM029 1
Water-cooled system backplane kit
(includes cold plate and module
tray)
01EM030 1
Rear ports
8
Table 6. Port descriptions
Identifier Description
1 Video Graphics Array (VGA). Text based capability is
only supported at this time.
2 Intelligent Platform Management Interface (IPMI) serial
3 Ethernet. Use the left Ethernet port for the BMC/IPMI
interface (as eth0). Use the right Ethernet port for any
direct OS usage (as eth1).
4 USB 3.0
Installing and removing IBM Power System S822LC
(8335-GTB) parts
Figure 5. Rear view of the system with ports displayed
9
Figure 6. Removing a power supply from the system
Figure 7. Removing the cover
Figure 8. Disk drive lock detail Figure 9. Removing a fan from the system
10
