IBM Power System LC922 Manuel utilisateur

IBM Power System LC922 (9006-22P)

Quick Install Guide

IBM

This 2020-01-22 edition applies to IBM® Power Systems servers that contain the POWER9™ processor and to all

associated models.

© Copyright International Business Machines Corporation 2018, 2019.

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with

IBM Corp.

IBM Power® System LC922 (9006-22P) Quick Install

Guide

The IBM Knowledge Center is available online from: http://www.ibm.com/support/knowledgecenter/

POWER9/p9hdx/9006_22p_landing.htm.

• Read all precautions and instructions before you start working on key parts.

• Use normal electrostatic discharge (ESD) procedures when working on the system and parts. IBM

recommends wearing gloves and an anti-static wrist strap to avoid possible damage to the equipment.

© Copyright IBM Corp. 2018, 2019 1

2 IBM Power System LC922 (9006-22P) Quick Install Guide

9006-22P parts

Figure 1. Rack nal assembly

© Copyright IBM Corp. 2018, 2019 3

Figure 2. System parts

4 IBM Power System LC922 (9006-22P) Quick Install Guide

Rear ports

Figure 3. Rear ports

Table 1. Input and output ports

Identier Description

1 USB 2.0 used for keyboard and mouse.

Certain USB drives might be too wide to t properly

into the USB ports on the rear of the system. Test

the t of your USB drive before proceeding.

2 Ethernet Intelligent Platform Management

Interface (IPMI)

3 Serial IPMI

4 Video Graphics Array (VGA) used for monitor. Only

the 1024 x 768 at 60 Hz VGA setting is supported.

Only up to a 3-meter cable is supported. Only text-

based capability is supported.

© Copyright IBM Corp. 2018, 2019 5

6 IBM Power System LC922 (9006-22P) Quick Install Guide

Installing and Removing

Figure 4. Removing a power supply from the system

Figure 5. Releasing and opening the cover

Figure 6. Removing a front drive Figure 7. Removing the 3.5-inch drive from the tray

© Copyright IBM Corp. 2018, 2019 7

Figure 8. Removing a DOM

Figure 9. Removing a rear drive

Figure 10. Opening the rear drive tray

Figure 11. Disconnecting the drive signal cables the

drive power cables

8 IBM Power System LC922 (9006-22P) Quick Install Guide
