Ibanez AEQ-TTS Guide de configuration rapide

Preamp Information

AEQ-TTS

ENGLISH

AEQ-TTS

Basic Controls

Tuner Functions

Displays the note that is closest to that of the sound that was input. Tighten or loosen the string until the desired

note is displayed. Pay attention not to overtighten a string, as it may break. When in tune, a display like (g.1) below

is shown. If the tuning is at, the meter moves toward the right as in (g.2), and if the tuning is sharp, the meter

moves toward the left as in (g.3). Check whether the desired note is displayed, and adjust the tuning so that the

meter comes to the center.

Adjusts the overall volume of the Pre-Amp.

VOLUME

AEQ-TTS

Pressing this button switches the tuner ON or OFF. The tuner will automatically switch OFF when 5 minutes have

passed after switching it ON.

※Sound will not output from the output jack while the tuner is ON.

TUNER ON/OFF SWITCH

NOTE INDICATOR & TUNING GUIDE METER

Turn to the right to increase the treble frequencies for a bright, shimmery sound, or turn to the left to increase the

bass frequencies to produce a thicker, more booming sound. In the center position, the EQ is not effected making

for a natural sound.

SHAPE

ﬁg.1 ﬁg.2 ﬁg.3

ENGLISH

ﬁg.4 ﬁg.5

NOTE

The battery used with the Pre-Amp needs to be replaced regularly. The battery needs to be replaced in situations

such as the following:

※The included battery is for conﬁrming proper operation of the Pre-Amp at the factory, and may have a short lifespan.

※Discard of used batteries in accordance with local laws and regulations.

※The specifications and appearance of this product are subject to change without notification for the purpose of

improvement.

Also, be sure to remove the plug from the output jack when not using a guitar in order to prevent unnecessary

damage to the battery.

• Deterioration in sound quality or reduction in volume

• No response to tuning even when the tuner is ON

• Display does not illuminate even when the tuner is ON

• A low battery warning is displayed

ENGLISH

When the battery charge starts running low, the battery charge display changes as shown, from (g.4) to (g.5). The

Pre-Amp may not work properly if the battery charge is low, so replace the battery as soon as you can.

BATTERY INDICATOR
