I-jet

●Introduction

●Working with I-jet

●Technical specifications

Introduction

These topics are covered:

●The I-jet in-circuit debugging probe

●Requirements

●Supported core families

●Target connections

AFE1_AFE2-1:1

Introduction

IAR Debug Probes User Guide

I-jet®, I-jet Trace, and I-scope™

THE I-JET IN-CIRCUIT DEBUGGING PROBE

I-jet connects to the target board via a JTAG, SWD, or cJTAG connection, and to the

host computer via the USB port.

I-jet communicates using USB 2.0. (USB 1.0 is also supported but not recommended.)

The I-jet in-circuit debugging probe is also referred to as a debug probe, debug adapter,

or JTAG in-circuit emulator by different tool vendors.

C-SPY debugger

C-SPY driver

USB connection

I-jet

JTAG, SWD

or cJTAG

AFE1_AFE2-1:1

I-jet

I-jet streams the program counter, variables, and power measurement data to the host

computer to provide a view into program execution in real time. Besides the typical

JTAG debugging, I-jet is capable of providing power to the target board and measuring

it with sufficient accuracy to provide a power profile during program execution in real

time. This feature is referred to as power debugging.

For debugging Cortex devices, I-jet also supports the SWO (Serial Wire Output) feature,

which can be used for tracing the program execution and tracking variables at predefined

points in your code.

The I-jet in-circuit debugging probe has full support for on-chip trace—ETB

(Embedded Trace Buffer), MTB (Micro Trace Buffer), and TMC (Trace Memory

Controller).

REQUIREMENTS

I-jet needs to be controlled by the IAR C-SPY® Debugger which comes with the IAR

Embedded Workbench® IDE.

SUPPORTED CORE FAMILIES

These cores are currently supported:

●Arm7

●Arm9

●Arm11

●Cortex-M

●Cortex-R

●Cortex-A

TARGET CONNECTIONS

These interfaces are supported:

●MIPI-20 (part number SHF-110-01-L-D): JTAG, cJTAG, SWD, SWO, ETM

●MIPI-10 (part number SHF-105-01-L-D): JTAG, cJTAG, SWD, SWO

●ARM-20 (part number HTST-110-01-L-DV): JTAG, cJTAG, SWD, SWO

I-jet comes with a MIPI-20 connector on the front panel, with MIPI-20 and MIPI-10

cables, and a legacy ARM-20 adapter.

All other available I-jet adapters are also compatible with I-jet Trace.

AFE1_AFE2-1:1

Working with I-jet

IAR Debug Probes User Guide

I-jet®, I-jet Trace, and I-scope™

Working with I-jet

These tasks are covered:

●Setup and installation

●Connecting the target system

●Updating the probe firmware

For information about debugging using I-jet, see the C-SPY® Debugging Guide for

Arm.

SETUP AND INSTALLATION

Software

Before you can use I-jet, you need to install IAR Embedded Workbench for Arm. For

information, see the Installation and Licensing Quick Reference Guide and the

Licensing Guide.

Probe setup

I-jet does not require any special driver software installation. Normally, all drivers for

I-jet are automatically installed as part of the IAR Embedded Workbench installation.

If you need to install the USB driver manually, navigate to \Program Files

\IAR Systems\Embedded Workbench x.x\arm\drivers\jet\USB\32-bit or

64-bit (depending on your system). Start the dpinst.exe application. This will

install the USB driver.

For information about using multiple I-jet probes on the same host computer, see the

C-SPY® Debugging Guide for Arm.

CONNECTING THE TARGET SYSTEM

Power-up your I-jet probe

1Connect I-jet to the target board using the cable that matches the target board connector

(MIPI-20 or MIPI-10). If a standard JTAG connector is used, you must first plug the

ADA-MIPI20-ARM20 adapter into the JTAG connector.

2Connect I-jet to the host computer using the USB micro cable.

Note: No harm is done if the above order is reversed.

To prevent damage, the target GND and the USB host GND must be at the same level.

When hot-plugging, make sure that the PC and the target board power supply are

connected to the same grounded wall outlet or a common grounded desktop power strip.

AFE1_AFE2-1:1

I-jet

Power up your evaluation board

If you have an evaluation board that is prepared for it, you can power the board via I-jet

through pin 19 on the standard ARM-20 connector, or pin 11/13 on the small MIPI-20

connector. Target power of up to 420 mA can be supplied from I-jet with overload

protection. Most of the IAR Systems KickStart Kits contain an evaluation board that can

be powered this way. Make sure that the power jumper found on most of these boards

matches your setup.

Note: The target board will get power via I-jet once you choose the Download and

Debug or Debug without Downloading command, but not before.

Note: The only way to use the power debugging feature is to power up your evaluation

board via I-jet.

UPDATING THE PROBE FIRMWARE

I-jet and I-jet Trace are designed so that firmware updates are not necessary unless new

features added to IAR Embedded Workbench for Arm require extra hardware support.

When a new version of IAR Embedded Workbench for Arm is released and a new

feature that requires new firmware is used, C-SPY displays a message in the DebugLog

window asking you to update the firmware.

Note: Support for new MCU devices is managed by software updates in IAR Embedded

Workbench for Arm, and has nothing to do with I-jet or I-jet Trace firmware.

For more information about firmware versions, see the release notes.

To update the probe firmware:

1In IAR Embedded Workbench, choose I-jet>EmuDiag to display the About to

Connect to an Emulator dialog box.

Select Connect to an EmulatorAutomatically and click Next.

AFE1_AFE2-1:1

Working with I-jet

IAR Debug Probes User Guide

I-jet®, I-jet Trace, and I-scope™

2In the EmuDiag dialog box, click Update Firmware.

Autres manuels pour I-jet

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels IAR SYSTEMS Accessoires informatiques

IAR SYSTEMS

IAR SYSTEMS I-jet Manuel utilisateur

Manuels Accessoires informatiques populaires d'autres marques

Motorola

Motorola ATRIX Manuel utilisateur

HP USB Media Docking Station Manuel utilisateur

Cherry

Cherry B.UNLIMITED 3.0 Manuel utilisateur

Logitech

Logitech IO2 Manuel utilisateur

ARM

ARM DSTREAM-ST Manuel utilisateur

Bartec

Bartec TC 7 Series Manuel utilisateur

Philips

Philips SPC3540 Manuel utilisateur

Logitech

Logitech mk220 Manuel utilisateur

SilverStone

SilverStone LC02 Manuel utilisateur

Flexispot

Flexispot ML2B Manuel utilisateur

Hamlet

Hamlet UNIVERSAL COVER 101 KBT2 Manuel utilisateur

Adam Equipment

Adam Equipment RS-485 Manuel utilisateur

Vivo

Vivo MOUNT-KB05-4DW Manuel utilisateur

Kvaser

Kvaser Memorator Professional Manuel utilisateur

DRC

DRC D-Imaging Manuel utilisateur

Sven

Sven Base 305 сombo Manuel utilisateur

Hama

Hama 108310 Manuel utilisateur

SpeechWare

SpeechWare FlexyMike FMK03 Manuel utilisateur
