I-Tech IT6721 Manuel utilisateur

Digital Control Power Supply

IT6721

User ’s Manual

ITECH

Access www.itechate.com for more products information

Safety Regulations

To avoid electrical shock, do not open the cabinet. Refer servicing

to qualified personnel only.

To avoid injuries, always disconnect power, discharge circuits,

and remove external voltage sources before touching components.

KEEP AWAY FROM LIVE CIRCUITS.

We cannot accept responsibility for any direct or indirect financial

damage or loss of profit that might occur when using the power

supply.

The instrument chassis and cover must be connected to an

electrical ground.

WARNING

We certify that this product met its published specifications at

time of shipment from the factory.

Certification

Notice The information contained in this document is subject to change

without notice.

Warranty

This hardware product is warranted against defects in material and

workmanship for a period of ONE year from date of delivery. IT6721

power supply for use with a hardware product and when properly

installed on that hardware product, are warranted not to fail to

execute their programming instructions due to defects in material

and workmanship for a period of 90 days from date of delivery.

During the warranty period our company will either repair or replace

products which prove to be defective. Our company does not

warranty that the operation for the software firmware or hardware

shall be uninterrupted or error free. For warranty service, with the

exception of warranty options, this product must be returned to a

service facility designated by our company. Customer shall prepay

shipping charges by (and shall pay all duty and taxes) for products

returned to our place for warranty service. Our company shall pay

for return of products to Customer.

Limitation of Warranty

The foregoing warranty shall not apply to defects resulting from improper

or inadequate maintenance by the customer, customer-supplied software or

interfacing, unauthorized

modification or misuse, operation outside of the environmental

specifications for the product, or improper site preparation and

maintenance.

Compliance Statements

Disposal of Old Electrical & Electronic Equipment (Applicable in the

European Union and other European countries with separate collection

systems)

The ITECH product you have purchased is subject to Directive

2002/96/EC of the European Parliament and the Council of the

European Union on waste electrical and electronic equipment

(WEEE) and, in jurisdictions adopting that Directive, is marked

as being put on the market after August 13, 2005, and should not

be disposed of as unsorted municipal waste. Please utilize your

local WEEE collection facilities in the disposition of this product

and otherwise observe all applicable requirements.

Safety Symbols

Connect it to safety earth ground using the wire recommended in

the user’s manual.

High voltage danger

The symbol on an instrument indicates that the user should refer

to the operating

instructions located in the manual.

About IT6721

With widest voltage and current range, IT6721 digital DC power

supplies are applied in many fields.

With max power 180W and adjustable output in 60V/8A, auto control

the voltage/current slew rate, the power rate three times rapid than

other similar products, a unit can replace three models (60V*3A/

30V*6A/ 20V*8A), reduce your repeat investment.

IT6721 output curve

When you set the output voltage as 60V,

because the max power of IT6721 is 180W,

so the max output current is 180W/60V=3A.

When you change the output voltage to 30V,

the output current is 180W/30V=6A.

Calculate according to above means: when

the output voltage is 20V, the output current

should be 9A, but because the rating max

current of IT6721 is 8A, so the final output

current value is 8A.

Example:

02468

Power

100%

Function

Fully digital control

High resolution 10mV/1mA in Full range

Low ripple and noise

Software calibration

Bright and easy to read display (VFD)

Constant current and constant voltage output

Selectable remote control keypads

High reliability OVP/OCP/OTP protection

Output on/off control

Best performance /price ratio

Storage for 4*100 preset voltage and current output

Panel Layout

Voltage / Current Selector + Memory D Button

Output +

Output –

Ground

Rotary Encoder

Main Power ON/OFF

Output ON/OFF Button

Voltage Value

Current Value

Step A + Memory A

Step C + Memory C

Step B + Memory B

Step D + Memory D

Output OFF Indicator

Shift Indicator

Keyboard Lock Indicator

Memory mode Indicator

OVP Indicator

OCP Indicator

CV mode Indicator

CC mode Indicator

Voltage setup Indicator

Left arrow + Memory A Button Right arrow + Memory B Button

Enter + Memory C Button

Shift Button

Setup Display (Shift)

Function Setup (Shift)

Keyboard (Shift)

Memory save (Shift)

Air flow input

IT6721 60V/8A/180W

Auto Range DC Power Supply

Quick Start

IT6721 60V/8A/180W

Auto Range DC Power Supply CV CC

OVP OCP

OFF Shift

Lock Prog

ITECH

ABCD

Confirm whether the power supply has been destroyed in transportation, if there is

any flaw, please contact the vender.

Confirm whether the AC input voltage of IT6721 comply with the standards of your

country or region.

Note: If switching input voltage, operate through the back panel switch

(110V/220V).

Check out

Press to light up the voltage setup

indicator B. It means IT6721 is in

voltage set mode, shown as fig 1.

Preset voltage

Press to light up the voltage

setup indicator . Now the voltage

will rise/decline 1V once you rotary

the knob . Set the voltage to 12V.

Step indicator B

After the check of the above matters,

power on by pressing

Setting the voltage

Setting the current

Press to light up the current setup

indicator A. IT6721 is in current set

mode, shown as fig 2.

DV/A

Press to adjust the setup

indicator to . Now the current will

rise/decline 1V once you rotary the

knob . Set the current to 4A.

IT6721 60V/8A/180W

Auto Range DC Power Supply CV CC

OVP OCP

OFF Shift

Lock Prog

ITECH

ABCD

Preset current indicator

Step indicator A

Enable output

IT6721 60V/8A/180W

Auto Range DC Power Supply CV CC

OVP OCP

OFF Shift

Lock Prog

ITECH

ABCD

Output off indicator

Press to enable the IT6721 output.

Voltage and current settings will be wink

for three seconds，and after that , the

display value of numerical display will

change from the set value to actual

measured voltage and current value.

On/OffOn/Off

Power off lights will be turned off which

means the power is in output state.

Press again, you will shut power

supply’s output.

Step value for Cursor Position

Cursor position Step voltage Step current

------

0.1V

0.01V

0.1A

0.01A

0.001A

The power supply usually displays the actual voltage and current values.

When you want to check the preset voltage and current values, the unit will

display automatically settings, press twice, the settings will be

displayed for three seconds.

Check the set voltage and current value

Key lock function

OVP function

OCP function

This function can prevent error operation by unauthorized person.

Press , after the was lit on, press ,

will be lit on, which means all keys on the panel except

and . Repeat above operation, key lock function will be

disabled.

IT6721 60V/8A/180W

Auto Range DC Power Supply CV CC

OVP OCP

OFF Shift

Lock Prog

ITECH

ABCD

Press , and press for

three seconds, now the panel

displays OVP, shown as fig 4.

ShiftShift

DV/A

Use and to set OVP

value.

OVP voltage value

IT6721 60V/8A/180W

Auto Range DC Power Supply CV CC

OVP OCP

OFF Shift

Lock Prog

ITECH

ABCD

OCP current value

Press to enter into OCP

setting interface after setting OVP

value, use and to

set the OCP value.

If the OVP and OCP settings are lower

than the actual voltage/current value,

the output of power supply will be

turned off. The default settings of

IT6721 are OVP=61V, OCP=5.1A.

NOTE

Key sound (BEEP)

Press to enter the BEEP setting

Interface after finished the OCP setting,

select the ON/OFF state with the knob .

ON indicates there is key sound,

OFF means no.

IT6721 60V/8A/180W

Auto Range DC Power Supply CV CC

OVP OCP

OFF Shift

Lock Prog

ITECH

ABCD

Power address (ADD)

IT6721 60V/8A/180W

Auto Range DC Power Supply CV CC

OVP OCP

OFF Shift

Lock Prog

ITECH

ABCD

Press to enter the ADD setting

interface after finishing the BEEP

setting, select the and

to enter store address setting. ADD

range: 0~30，press to confirm。

Store group setting (GRP)

IT6721 60V/8A/180W

Auto Range DC Power Supply CV CC

OVP OCP

OFF Shift

Lock Prog

ITECH

ABCD

Press to enter the GRP interface

after setting the key sound, use

and to select store group.

Press to confirm the chosen group

and end the setup mode. IT6721 allows

customers to store 100 groups with

A/B/C/D four set value for

every group.

Store operation

In the normal working mode, set the voltage/current value to be stored.

Press and , now the Cursor will wink together. Press

any key in to save it.

ShiftShift

ABCD

DV/A

Recall operation

Press and , the indicator will be lit on, which means that

IT6721working in the shortcuts mode. Press any key in ,

recall the preset voltage/current value which has been stored.

ShiftShift

Prog

DV/A

When the power supply is on recall operation, that means all you can recall the

parameters from the store group. Press any key of to

recall the stored parameter.

When the power supply is on recall operation are disabled,

they only can be used with key. Press , and press to exit recall

function.

DV/A

ShiftShift

Faulty disposal

3: Check whether the indicators are lit on, if so, please reset

according to the mentioned OVP/OCP/OCP means.

If the outputs is disabled:

1: Check whether voltage and current settings are zero, if so, reset voltage

and current value.

2: Check whether the indicator is lit on, if so, press to enable the

outputs. OFF

OVP OCP

If the keypad is disabled, check whether the indicator is lit on, if

so, unlock the keypads as the above means. Lock

On/OffOn/Off

6: Specifications

Output Rating Voltage

Current

Specifications IT6721

Load Regulation Voltage

Current

Line Regulation Voltage

Current

0~60V

<0.01%+5mV

<0.01%+5mA

<0.01%+5mV

<0.1%+5mA

0~8A

Specs

Power 180W

Programming Accuracy Voltage

Current <0.05%+10mV

<0.3%+5mA

Read back Accuracy Voltage

Current

Ripple Current

Voltage

<0.05%+10mV

<0.3%+5mA

<5mV rms

<8mA rms

Dimension 88*175*282(mm)

W*H*D

Weight Net <3.5Kg

Table des matières

Autres manuels I-Tech Alimentation

I-Tech

I-Tech IT7622 Manuel utilisateur

I-Tech

I-Tech IT6412 Manuel utilisateur

I-Tech

I-Tech IT6000D Series Manuel utilisateur

I-Tech

I-Tech IT6900 Series Manuel utilisateur

I-Tech

I-Tech IT6512D Manuel utilisateur

I-Tech

I-Tech IT6800A Series Manuel utilisateur

I-Tech

I-Tech IT-M3900D Series Manuel utilisateur

I-Tech

I-Tech IT6724 Manuel utilisateur

I-Tech

I-Tech IT6000B Series Manuel utilisateur

I-Tech

I-Tech IT6700 Series Manuel utilisateur

I-Tech

I-Tech IT7900P Series Manuel utilisateur

I-Tech

I-Tech IT6122 Manuel utilisateur

I-Tech

I-Tech IT-M3900D Series Manuel utilisateur

I-Tech

I-Tech IT8722 Manuel utilisateur

I-Tech

I-Tech IT7900 Series Manuel utilisateur

I-Tech

I-Tech IT6000C Series Manuel utilisateur

I-Tech

I-Tech IT8300 Series Manuel utilisateur

I-Tech

I-Tech IT6000C Series Manuel utilisateur

I-Tech

I-Tech IT7300 Series Manuel utilisateur

I-Tech

I-Tech IT6400 Series Manuel utilisateur

I-Tech

I-Tech IT6800 Series Mode d'emploi

I-Tech

I-Tech IT6400 Series Manuel utilisateur

I-Tech

I-Tech IT6900 Series Manuel utilisateur

I-Tech

I-Tech IT-M3400 Series Manuel utilisateur

Manuels Alimentation populaires d'autres marques

Monacor

Monacor PS-12CCD Manuel utilisateur

VOLTIMA

VOLTIMA MagicBox 15 Manuel utilisateur

Agilent Technologies

Agilent Technologies 6032A Manuel utilisateur

Miller

Miller Auto Deltaweld 452 Manuel utilisateur

BCP

BCP PUOUBK Feuille d'instructions

HC 2210 Manuel utilisateur

Puls

Puls CT5.241 Manuel utilisateur

OCZ

OCZ ZX1250W Manuel utilisateur

iseg

iseg ECH 238 Manuel utilisateur

Power

Power XXL A Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 6631B Manuel utilisateur

Renogy

Renogy PHOENIX 300 Manuel utilisateur

HP 6200B Manuel de service

Epson

Epson Stylus Scan 2500 Manuel d'utilisation

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manuel utilisateur

Puls

Puls MiniLine ML50.100 Manuel utilisateur

Puls

Puls AS-Interface SLA4.100 Manuel utilisateur

Kenwood

Kenwood PS-60 Manuel utilisateur
