1FEATURES OF YOUR HYUNDAI

122

Ionosphere

B750A02L

AM reception

Mountains

Buildings

Unobstructed

area

FM radio station

B750A03L

Ionosphere

FM reception

B750A01L

Obstructed area Iron bridges

FM broadcasts are transmitted at high

frequencies and do not bend to follow

the earth's surface. Because of this,

FM broadcasts generally begin to fade

at short distances from the station.

Also, FM signals are easily affected by

buildings, mountains, or other obstruc-

tions. These can result in certain lis-

tening conditions which might lead you

to believe a problem exists with your

radio. The following conditions are

normal and do not indicate radio trouble:

AM broadcasts can be received at

greater distances than FM broadcasts.

This is because AM radio waves are

transmitted at low frequencies. These

long, low frequency radio waves can

follow the curvature of the earth rather

than travelling straight out into the

atmosphere. In addition, they curve

around obstructions so that they can

provide better signal coverage.

B750A02A-AAT

How Car Audio Works

AM and FM radio signals are broadcast

from transmitter towers located around

your city. They are intercepted by the

radio antenna on your car. This signal is

then received by the radio and sent to

your car speakers.

When a strong radio signal has reached

your vehicle, the precise engineering

of your audio system ensures the best

possible quality reproduction. Howev-

er, in some cases the signal coming to

your vehicle may not be strong and

clear. This can be due to factors such

as the distance from the radio station,

closeness of other strong radio sta-

tions or the presence of buildings,

bridges or other large obstructions in

the area.

STEREO SOUND SYSTEM

FEATURES OF YOUR HYUNDAI

123

B750B03Y-GAT

Using a cellular phone or a two-

way radio

When a cellular phone is used inside

the vehicle, noise may be produced

from the audio equipment. This does

not mean that something is wrong with

the audio equipment. In such a case,

use the cellular phone at a place as far

as possible from the audio equipment.

CAUTION:

When using a communication sys-

tem such a cellular phone or a radio

set inside the vehicle, a separate

external antenna must be fitted.

When a cellular phone or a radio set

is used with an internal antenna

alone, it may interfere with the

vehicle's electrical system and ad-

versely affect safe operation of the

vehicle.

B750A04L B750A05L

o Station Swapping - As a FM signal

weakens, another more powerful

signal near the same frequency may

begin to play. This is because your

radio is designed to lock onto the

clearest signal. If this occurs, select

another station with a stronger sig-

nal.

o Multi-Path Cancellation - Radio sig-

nals being received from several

directions can cause distortion or

fluttering. This can be caused by a

direct and reflected signal from the

same station, or by signals from two

stations with close frequencies. If

this occurs, select another station

until the condition has passed.

o Fading - As your car moves away

from the radio station, the signal will

weaken and sound will begin to

fade. When this occurs, we suggest

that you select another stronger sta-

tion.

o Flutter/Static - Weak FM signals or

large obstructions between the

transmitter and your radio can dis-

turb the signal causing static or flut-

tering noises to occur. Reducing the

treble level may lessen this effect

until the disturbance clears.

1FEATURES OF YOUR HYUNDAI

124

!WARNING:

Don't use a cellular phone when

you are driving. This could result in

loss of control, and an accident

that may cause death, serious in-

jury, or property damage. You must

stop at a safe place to use a cellular

phone.

1FEATURES OF YOUR HYUNDAI

140

M445A01NF

M455A01NF-GAT

STEREO RADIO OPERATION (M455) (If Installed)

1. POWER ON-OFF, VOLUME Control Knob

2. Adjustment Mode

Select (A.MODE) Button

3. BAND Selector

4. Best Station Memory (BSM) Button

5. EQUALIZER (EQ)

Button

6. SEEK Select Button

7. TUNE (Manual)

Select Knob

8. PRESET STATION Select Buttons

FEATURES OF YOUR HYUNDAI

141

M455B01NF-GAT

1. POWER ON-OFF Control Knob

o The radio unit may be operated

when the ignition key is in the "ACC"

or "ON" position. Press the button to

switch the power on. The display

shows the radio frequency in the

radio mode, the tape direction indi-

cator in the tape mode or CD/MP3

track in either the CD/MP3 mode.

To switch the power off, press the

button again.

o Push the FM/AM, TAPE or CD/MP3

to turn on that function without push-

ing Power ON-OFF control knob.

VOLUME Control

Rotate the knob clockwise to increase

the volume and turn the knob counter-

clockwise to reduce the volume.

2. Adjustment Mode Select

(A.MODE) Button

Pressing the A.MODE button changes

the BASS, MIDDLE, TREBLE, FADER

and BALANCE mode.

The mode selected is shown on the

display.

After selecting the each mode, rotate

the volume control knob clockwise or

counterclockwise.

BASS Control

To increase the bass, rotate the knob

clockwise, while to decrease the bass,

rotate the knob counterclockwise.

MID Control

To increase the MID, rotate the knob

clockwise, while to decrease the MID,

rotate the knob counterclockwise.

TREBLE Control

Turn to the left or right for the desired

treble tone.

FAD (Fader Control)

Turn the control knob clockwise to

emphasize rear speaker sound (front

speaker sound will be attenuated).

When the control knob is turned coun-

terclockwise, front speaker sound will

be emphasized (rear speaker sound

will be attenuated).

BALANCE Control

Rotate the knob clockwise to empha-

size right speaker sound. (Left speaker

sound will be attenuated) When the

control knob is turned counter clock-

wise, left speaker sound will be em-

phasized (Right speaker sound will be

attenuated).

3. BAND Selector

Pressing the band selector FMˆAM

changes the AM, FM1 and FM2 bands.

The mode selected is shown on the

display.

4. Best Station Memory (BSM)

Button

When the BSM button is pressed the

six channels from the highest field

intensity are selected next and stored

in memory. The stations selected are

stored in the sequence frequency from

the first preset key.

1FEATURES OF YOUR HYUNDAI

142

5. EQUALIZER (EQ) Button

Press the EQ button to select the

CLASSIC, POPS, ROCK, JAZZ and

DEFEAT MODE for the desired tone

quality. Each press of the button

changes the display as follows;

8. PRESET STATION Select

Buttons

Six (6) stations for AM, FM1 and FM2

respectively can be preset in the elec-

tronic memory circuit.

HOW TO PRESET STATIONS

Six AM and twelve FM stations may be

programmed into the memory of the

radio. Then, by simply pressing the

band select button and/or one of the

six station select buttons, you may

recall any of these stations instantly.

To program the stations, follow these

steps:

o Press band selector to set the band

for AM, FM and FM2.

o Select the desired station to be

stored by seek or manual tuning.

o Determine the preset station select

button you wish to use to access

that station.

o Press the station select button for

more than two seconds. Beep sound

will be heard while depressing the

button. You should then release the

button, and proceed to program the

next desired station. A total of 18

stations can be programmed by se-

lecting one AM and two FM station

per button.

o When completed, any preset sta-

tion may be recalled by selecting

AM, FM1 or FM2 band and the

appropriate station button.

6. SEEK Select Button

(Automatic Channel Selection)

Press the SEEK select button. When

the ( ) side is pressed, the unit will

automatically tune to the next higher

frequency and when the ( ) side is

pressed, it will automatically tune to

the next lower frequency.

7. TUNE (Manual) Select Knob

Rotate the knob clockwise to increase

the frequency and turn the knob coun-

terclockwise to reduce the frequency.

CLASSIC →POPS →ROCK →JAZZ →DEFEAT

CAUTION:

o Do not place beverages close to

the audio system. The playback

mechanism may be damaged if

you spill them.

o Do not impact on the audio sys-

tem, or the playback mechanism

could be damaged.

FEATURES OF YOUR HYUNDAI

143

M445C01NF

M455C01NF-GAT

CASSETTE TAPE PLAYER OPERATION (M455) (If Installed)

1. TAPE PROGRAM

Button

2. TAPE EJECT Button

3. AUTO MUSIC Select Button

4. FF/REW Button

5. REPEAT Button

6. DOLBY Button

7. EQUALIZER (EQ)

Button

1FEATURES OF YOUR HYUNDAI

144

M455D01NF-GAT

1. TAPE PROGRAM Button

o This allows you to play the reverse

side of the tape by merely depress-

ing the program button. An arrow

will appear in the display to show

tape direction.

o Push the TAPE button to turn on

that function without pushing power

ONˆOFF control knob.

2. TAPE EJECT Button

o When the button is pressed with

a cassette loaded, the cassette will

eject.

o When the button is pressed

during FF/REW mode, the cassette

will eject.

3. AUTO MUSIC Select Button

Press the button to find the starting

point of each song in a prerecorded

music tape. The quiet space between

songs (must have at least 4 sec. gap)

can be accepted by the AUTO MUSIC

Select button.

o Pressing the button will play

the beginning of the next music

segment.

o Pressing the button will start

replay at the beginning of the music

just listened to.

4. FF/REW Button

o Fast forward tape winding starts

when the FF button is pressed dur-

ing PLAY or REW mode.

o Tape PLAY starts when the FF but-

ton is pressed again during FF mode.

o Tape rewinding starts when the

REW button is pressed during PLAY

or FF mode.

o Tape PLAY starts when the REW

button pressed again during REW

mode.

5. REPEAT Button

o To repeat the track you are cur-

rently listening to, press the RPT

button. To cancel, press again.

o If you do not release RPT operation

when the track ends, it will automati-

cally be replayed.

This process will be continued until

you push the button again.

6. DOLBY Button

If you get background noise during

tape PLAY, you can reduce this con-

siderably by merely pressing the

DOLBY button. If you want to cancel

the DOLBY feature, press the button

again.

7. EQUALIZER (EQ) Button

Press the EQ button to select the

CLASSIC, POPS, ROCK, JAZZ and

DEFEAT MODE for the desired tone

quality. Each press of the button

changes the display as follows;

CLASSIC →POPS →ROCK →JAZZ →DEFEAT

FEATURES OF YOUR HYUNDAI

145

NOTE:

o To assure proper operation of

the unit, keep the vehicle interior

temperature within a normal

range by using the vehicle's air

conditioning or heating system.

o When replacing the fuse, replace

it with a fuse having the correct

capacity.

o The preset station frequencies

are all erased when the car bat-

tery is disconnected. Therefore,

all data will have to be set again

if this should occur.

o Do not add any oil to the rotating

parts. Keep magnets, screwdriv-

ers and other metallic objects

away from the tape mechanism

and head.

o This equipment is designed to

be used only in a 12 volt DC

battery system with negative

ground.

o This unit is made of precision

parts. Do not attempt to disas-

semble or adjust any parts.

o When driving your vehicle, be sure

to keep the volume of the unit set

low enough to allow you to hear

sounds coming from the outside.

o Do not expose this equipment (in-

cluding the speakers and tape) to

water or excessive moisture.

CAUTION:

o Do not insert anything like coins

into the player slot as damage to

the unit may occur.

o Do not place beverages close to

the audio system. The playback

mechanism may be damaged if

you spill them.

o Do not impact on the audio sys-

tem, or the playback mechanism

could be damaged.

1FEATURES OF YOUR HYUNDAI

146

9. CD EJECT Button

M455E01NF-GAT

COMPACT DISC PLAYER OPERATION (M455) (If Installed)

- Compatiable with MP3/WMA/AAC/WAVE

M445E01NF

1. AUDIO/MP3 CD

Select Button

2. TRACK UP/DOWN

4. REPEAT (RPT) Button

5. RANDOM (RDM) Button

6. BOOKMARK (MARK) Button

8. EQUALIZER (EQ)

Button

10. SCAN

11. FILE SEARCH Knob

7. SCROLL

3. FF/REW Button

Table des matières

Autres manuels Hyundai Récepteur de voiture

Hyundai

Hyundai H-CDM8023 Manuel utilisateur

Hyundai

Hyundai CMRX 4807 SU Manuel utilisateur

Hyundai

Hyundai 2011 EQUUS Manuel utilisateur

Hyundai

Hyundai HM-3764RH Manuel utilisateur

Hyundai

Hyundai H-CDM8056 Manuel utilisateur

Hyundai

Hyundai H- CDM8053 Manuel utilisateur

Hyundai

Hyundai CMRX 4802 SU Manuel utilisateur

Hyundai

Hyundai MP3-02 Manuel utilisateur

Hyundai

Hyundai Multimedia DVD/CD/MP3 Receiver H-CMD4015 Manuel utilisateur

Hyundai

Hyundai FMT 263 Manuel utilisateur

Hyundai

Hyundai CRMD 7222 SU Manuel utilisateur

Hyundai

Hyundai MP3.O4H Manuel utilisateur

Hyundai

Hyundai H-CMD4018 Manuel utilisateur

Hyundai

Hyundai H-CMD2003 Manuel utilisateur

Hyundai

Hyundai H-CCR8103F Manuel utilisateur

Hyundai

Hyundai H- CDM8060 Manuel utilisateur

Hyundai

Hyundai CRM1002 Manuel utilisateur

Hyundai

Hyundai H-CDM8042 Manuel utilisateur

Hyundai

Hyundai H-CDM8092 Manuel utilisateur

Hyundai

Hyundai AC610HGMG Manuel utilisateur

Hyundai

Hyundai H-CMD4009 Manuel utilisateur

Hyundai

Hyundai ADC40F2AN Manuel utilisateur

Hyundai

Hyundai H-CMD4028 Manuel utilisateur

Hyundai

Hyundai MP3.36T Manuel utilisateur

Manuels Récepteur de voiture populaires d'autres marques

Motorola

Motorola VWA63 Manuel utilisateur

Nextar

Nextar D3201 Manuel utilisateur

Alpine

Alpine CDE-163BT Manuel utilisateur

Pioneer

Pioneer DEH-P645R Manuel utilisateur

Axxera

Axxera XDMA7600 Mode d'emploi

XM OnyX Manuel utilisateur

Sound Storm

Sound Storm STM93R Manuel utilisateur

Soundstream

Soundstream VIR-5000 Manuel utilisateur

Avson

Avson MKT Platform Manuel utilisateur

Sony

Sony MEX-1HD - Audio Library System Manuel utilisateur

Pioneer

Pioneer DVH-P500UB Manuel utilisateur

JVC

JVC KD-AHD69 Manuel utilisateur

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuel utilisateur

Sony

Sony CDX-4160 - Cd Receiver Manuel utilisateur

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuel utilisateur

VDO

VDO CD 2253 Manuel utilisateur

Volvo

Volvo 13 84 580 Manuel utilisateur

ZENEC

ZENEC ZE-160DVD Manuel utilisateur
