HyperX Cloud Alpha S Manuel utilisateur

User Manual

HyperX Cloud Alpha S™ Headset

Find the language and latest documentation for your headset here.

HyperX Cloud Alpha S Headset Installation Guide

Simplied Chinese .....简体中文说明书

Traditional Chinese ....繁體中文說明

............For instructions in English

. . . . . . . . . . . . . . . . . . Para instrucciones en Español

.........Für Anleitungen in Deutsch

. . . . . . . . . . . . . . . . . . Pour des instructions en Français

. . . . . . . . . . . . . . . . . . Per le istruzioni in Italiano

............Por as instruções em Português

. . . . . . . . . . . . . . . . . . Instrukcje w jezyku Polskim

. . . . . . . . . . . . . . . . . . Для инструкции на Pусском

. . . . . . . . . . . . . . . . . . Turkce talimatlar icin

. . . . . . . . . . . . . . . . . .日本語マニュアル用

. . . . . . . . . . . . . . . . . .한국어 안내

. . . . . . . . . . . . . . . . . . คำ�แนะนำ�ภ�ษ�ไทย

. . . . . . . . . . . . . . . . . . Để xem hướng dẫn bằng tiếng Việt

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 1 of 15

HyperX Cloud Alpha STM

Part Numbers

HX-HSCAS-BL/WW

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 2 of 15

TABLE OF CONTENTS

Overview .................................................................................................................................... 3!

Specifications ............................................................................................................................ 4!

Usage .......................................................................................................................................... 5!

Bass Adjustment ..................................................................................................................................................... 5!

USB Audio Control Mixer ....................................................................................................................................... 6!

Mic mute / mic monitoring button .......................................................................................................................... 6!

Headset volume buttons ....................................................................................................................................... 6!

7.1 surround sound button .................................................................................................................................... 7!

Game/Chat balance buttons ................................................................................................................................. 7!

Using with PC ............................................................................................................................ 8!

Connecting Headset to PC ..................................................................................................................................... 8!

Windows Setup ....................................................................................................................................................... 9!

Discord Setup ........................................................................................................................................................ 13!

Using with Console & Mobile ................................................................................................. 14!

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 3 of 15

Overview

A. Bass adjustment sliders

B. Detachable microphone

C. 3.5mm cable (4-pole)

D. USB audio control mixer

E. Mic mute / mic monitoring button

F. 7.1 surround sound button

G. Headphone volume buttons

H. Game Balance button

I. Chat Balance button

J. Cloth ear cushions

K. Travel bag

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 4 of 15

Specifications

Headphone

Driver: Custom dynamic, 50mm with neodymium magnets

Type: Circumaural, Closed back

Frequency response: 13Hz – 27kHz

Impedance: 65 Ω

Sound pressure level: 99dBSPL/mW at 1kHz

T.H.D.: ≤ 1%

Weight: 310g

Weight with mic: 321g

Cable length: Detachable headset cable (1m)

Connection type: Detachable headset cable - 3.5mm plug (4 pole)

Microphone

Element: Electret condenser microphone

Polar pattern: Bi-directional, Noise-cancelling

Frequency response: 50Hz – 18kHz

Sensitivity: -38dBV (0dB=1V/Pa at 1kHz)

USB Audio Control Mixer

Controls: Headset volume buttons, Game/Chat balance buttons, 7.1 surround sound button, mic mute /

mic monitoring button

Weight: 57g

Cable length: 2m

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 5 of 15

Usage

Bass Adjustment

Move the bass adjustment sliders up or down to change the amount of bass in the headset.

Move the sliders up for more bass. Move the sliders down for less bass.

More Bass

Less Bass

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 6 of 15

USB Audio Control Mixer

Mic mute / mic monitoring button

Press the mic mute / mic monitoring button to toggle mic mute on or off.

• LED On – Mic muted

• LED Off – Mic active

Hold the button for 3 seconds to toggle mic monitoring on or off.

Headset volume buttons

Press the volume +/- buttons to adjust headset master volume up or down.

Volume +

Volume -

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 7 of 15

7.1 surround sound button

Press the 7.1 surround sound button to toggle 7.1 surround on or off.

• LED On – Enabled

• LED Off – Disabled

Game/Chat balance buttons

Press the game/chat balance buttons to adjust mix between game audio and chat audio.

The game/chat balance functionality operates independently from the overall headset audio volume.

Game balance

Chat balance

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 8 of 15

Using with PC

Connecting Headset to PC

1. Connect the headset into the USB audio control mixer with the 3.5mm 4-pole cable.

2. Connect the USB audio control mixer into the PC’s USB port.

Document No. 480HX-HSCAS.A01

HyperX Cloud Alpha S™

Page 9 of 15

Windows Setup

1. Right click speaker icon in system tray, then select Open Sound settings.

2. In Sound settings window, select Sound Control Panel.
