Hygiena Dualo 32 Feuille d'instructions

Product Instructions

Dualo 32®

Product No. MCH230008

Product Instructions:

Revision A, September 2023

Dualo 32®

Product No.: MCH230008

MCH230008 - Dualo 32®

TABLE OF CONTENTS

This manual will teach you what you need to know to start running your Dualo 32®instrument.

It describes everything from connecting your instrument to the network to data analysis for your

qPCR experiments.

Contents include

1. SETUP

Learn how to install your Dualo 32 - from setting it up on your workbench,

to configuring the instrument and installing the software.

2. TIPS

Learn some useful tips for using your instrument.

3. EXPERIMENT

Learn the basics of setting up an experiment on your Dualo 32.

4. ANALYSIS

Learn how to easily analyze your results.

5. EXPORT

Learn how to export your data for use with other software.

6. MAINTENANCE

Learn how to look after your Dualo 32.

7. TROUBLESHOOTING

If you ever have a problem with your instrument, learn how to troubleshoot it here.

8. WARRANTY AND DISCLAIMER OF LIABILITY

9. SUPPLEMENTARY INFORMATION

TABLE OF CONTENTS

MCH230008 - Dualo 32®

1. SETUP

Installing your Dualo 32

You should have the following items in the Dualo 32 flight case:

1. Dualo 32 qPCR Instrument

2. Power Supply Unit and Mains Cable

3. Ethernet Cable

4. USB Drive

Please keep the flight case and outer box the Dualo 32 came in, in case you need to protect

your Dualo 32 during storage or shipment in future.

Lid

The lid ensures that tubes are seated correctly in the wells, provides optical isolation, includes

a heated lid to reduce condensation, and prevents dust falling into empty wells.

USB Port

Insert the USB drive here to run an experiment from the USB drive.

Lid

USB Port

SETUP

MCH230008 - Dualo 32®

Display LEDs

The Dualo 32 uses display LEDs to help you understand what the instrument is doing.

Here is a summary of these display LEDs.

Blue Initializing

Green Idle

Red Lid open - please close the lid

Yellow Tubes loaded

Blue Running, low temperature

Pink Running, medium temperature

Red Running, high temperature

Cyan Experiment complete

Red-Flashing Fault detected

Dualo 32 Connections

The Dualo 32 has three connections. One in the front and two in back as shown below:

This is to connect your Dualo 32 to the

provided power supply unit.

This is for connecting your Dualo 32 to

your LAN or computer.

Ethernet PortPower

Ethernet Port

Power

SETUP

MCH230008 - Dualo 32®

Powering on your Dualo 32

Place the Dualo 32 on your lab bench and then connect AC power to the power supply unit.

After a few seconds, your instrument will turn on. The display LEDs will light up blue and then

turn green if a lid is closed or red if not. Your Dualo 32 is ready to run. The Dualo 32 uses a

3-pin IEC mains connector. If you are not using a grounded supply, then you must provide an

additional ground connection.

Connecting your Dualo 32

to a Network, PC or Laptop

Connect one end of the Ethernet cable to the instrument and the other end to a LAN port, or

directly to your computer. Once your Dualo 32 is connected to a LAN, you can connect to your

instrument via Wi Fi if your network supports it.

Dualo 32 Connection Modes

USB

1. Direct network connection

3. USB drive connection

2. Local area network connection

LAN

SETUP

MCH230008 - Dualo 32®

Dualo 32 Heated Lid

The Dualo 32 heated lid will get hot. Please do not touch it. The heated lid will be preheated to

105 ºC if user activity is detected. This enables your run to start as soon as possible. After

5 minutes of inactivity, the heated lid will be turned off to conserve energy.

Installing your Dualo 32 Software

WINDOWS (MAC OS X also available)

Double-click on the Dualo 32-Windows-Installer and follow the on-screen instructions to install

your Dualo 32 software on Windows.

HEATED LID

DO NOT TOUCH

SETUP

MCH230008 - Dualo 32®

Configuring your Dualo 32

Please select Configuration

Please select Dualo 32

To add your new Dualo 32, select the Add button.

You will now be presented with a list of available instruments.

SETUP

MCH230008 - Dualo 32®

Double-click on the instrument

you wish to connect to, or press

Select with the instrument

selected. The instrument will

now be added to the list of

Registered Instruments for

use in the software.

SETUP

MCH230008 - Dualo 32®

2. TIPS

Here are some great tips to keep in mind while running the Dualo 32 instrument.

1. Lid gets warm

2. Do not leave the lid open

3. Spin the tubes

4. Remove all bubbles

5. Keep the lab clean

6. Keep the instrument clean

7. PC settings

Lid gets warm

The Dualo 32 lid can get warm during operation. This is completely normal.

Do not leave the lid open

If the lid is open dust may fall into the wells and affect the performance of the instrument.

Spin the tubes

This will ensure all well contents are at the bottom of the wells and will improve performance.

TIPS
