ILLUSTRATED PARTS LIST

MFG. ID NO. 96051007800

CUSTOMER CATALOG NO. CTH 224T

PRODUCT NO. 960 51 00-78

581 92 86-26 Rev. 6

MAX

_90N MAX

_150N

NOTE: All component dimensions given in U.S. inches

1 inch = 25.4 mm

wheel_art_1-tex

WHEELS AND TIRES

KEY PART

NO. NO. DESCRIPTION

1 532 05 91-92 Cap Valve Tire

2 532 06 51-39 Stem Valve

3 532 13 83-36 Rim Front

4 532 05 99-04 Tube Front (Service Item Only)

5 532 10 62-22 Tire Front 15 x 6.0-6

6 532 12 49-57 Fitting Grease (Front Wheel Only)

7 532 12 49-59 Bearing Flange (Front Wheel Only)

8 532 17 50-39 Cap Axle Blk 1 50 x 1 00

9 532 42 05-31 Tire R 18 x 9.5-8

10 532 12 49-26 Tube Rear (Service Item Only)

11 532 13 83-37 Rim Asm 8" Rear

- - 532 14 43-34 Sealant, Tire (10 oz. Tube)

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

DECALS

KEY PART

NO. NO. DESCRIPTION

1 532 44 55-03 Decal, Warning

2 532 19 68-41 Decal, Warning Eng. Sym.

3 581 62 73-01 Decal, Hood

4 581 51 72-01 Decal, Replacement

6 532 18 04-32 Decal, 100 DBA

7 532 44 02-47 Decal, Lower Dash

8 532 44 71-60 Decal, Side Panel

9 532 43 26-41 Decal, Warn CRD Bagger Elec Dump

10 532 40 11-46 Decal, Warning Ser/Fire

11 532 18 21-66 Decal, Cut finger

14 532 15 97-36 Decal, Chassis Hot Muffler

21 532 44 11-89 Decal, Belt

- - 532 44 46-19 Decal, Bypass

- - 532 44 54-93 Decal, Warning Combined

- - 532 44 51-02 Decal, Battery Door

- - 532 44 14-09 Pad Footrest LH

- - 532 44 14-10 Pad Footrest RH

- - 581 59 26-40 Manual Operator's (Euro)

- - 581 59 26-50 Manual Operator's (Scan)

- - 581 59 26-20 Manual Operator's (E-Bloc)

- - 581 59 26-30 Manual Operator's (Baltic)

KEY PART

NO. NO. DESCRIPTION

314

21 6

14 47

FUSE

STARTER

SOLENOID

BATTERY

REVERSE SWITCH (NOT IN REVERSE)

SEAT SWITCH (NOT OCCUPIED)

FULL BAG

IGNITION

UNIT

HOUR

METER

CHASSIS HARNESS

CONNECTOR (C1)

(MATING SIDE)

DASH HARNESS

CONNECTOR (C1)

(MATING SIDE)

FUEL

LINE

FUEL SHUT-OFF

SOLENOID

(IF SO EQUIPPED)

SPARK

PLUGS GAP

(2 PLUGS ON

TWIN CYL. ENGINES)

(OPTIONAL)

NON-REMOVABLE

CONNECTIONS

REMOVABLE

CONNECTIONS

WIRING INSULATED CLIPS

NOTE: IF WIRING INSULATED

CLIPS WERE REMOVED FOR

SERVICING OF UNIT, THEY

SHOULD BE RE-INSTALLED TO

PROPERLY SECURE YOUR

WIRING.

SCH25

IGNITION SWITCH

CIRCUITPOSITION

OFF

B+A1

RUN/OVERRIDE

B+S+A1START

M+G+A1

B+A1RUN

“MAKE”

L+A2

PTO SWITCH

(DISENGAGED)

BLACK

BLACK /WHITE

BLUE

BLUE BLACK

GREEN

BLACK

YELLOW

BLK/WHT

BLACK

BLK/WHT

DER

WHITE

GRAY

BLACK

YELLOW

POWER OUTLET

(OPTIONAL)

12V

BLACK

BLUE

BLACK

BROWN

HEADLIGHTS

LIGHT SWITCH

ORANGE

CLUTCH/BRAKE

(PEDAL UP)

WHITE

GREEN

BLUE RED

BAG PRESENT SWITCH

(BAG ATTACHED)

SHORTING CONNECTOR

BAG FULL SWITCH

(NOT FULL)

BUZZER

BLACK

BLUE BLACK

BROWN

DER RED

654

123

456

ELECTRIC CLUTCH

BLACKRED

REGULATOR STATOR

28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)

CHARGING SYSTEM OUTPUT

9-16AMPDC@3600 RPM

BLUE

RED

BLACK

ELECTRIC DUMP

SWITCH

ELECTRIC DUMP

SWITCH CONNECTOR

BLACK

ELECTRIC DUMP

ACTUATOR

FUSE

CHARGE

INDICATOR

(OPTIONAL)

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

SCHEMATIC

79 21

TC10S

With Service Minder Option

4646

108

107

102

105

With Charge Indicator Option

142

143

(+) (-)

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

ELECTRICAL

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

ELECTRICAL

KEY PART

NO. NO. DESCRIPTION

1 532 43 71-57 Battery

2 532 44 09-23 Screw Hex Hd Cap M6 x 1.12MM

16 532 17 61-38 Switch Interlock Push-In

21 532 40 02-52 Harness Light w/4152J

22 532 00 41-52 Bulb Light

25 532 44 13-82 Cable Starter

26 532 17 51-58 Fuse

27 873 51 04-00 Nut Keps Hex 1/4-20 unc

28 532 44 13-83 Cable, Ground

29 532 40 15-45 Switch, Seat

30 532 19 33-50 Switch, Ign

33 532 41 19-35 Key/Chain

34 532 11 07-12 Switch Light/Reset

40 581 68 64-01 Harness Ign. Dash/Lift

43 532 19 25-07 Solenoid

46 532 40 17-63 Gauge Serviceminder Hrmtr

50 532 17 46-51 Switch PTO

55 817 06 05-12 Screw Thdrol 5/16-18 x 3/4 TYTT

71 581 68 64-02 Harness Ignition Chassis/Lift

75 532 44 45-34 Switch Bag Dump

79 532 17 52-42 Socket Asm. Bulb

83 532 43 67-74 Nut Square M6 x 1.8.5 x 11MM

99 817 72 04-08 Screw 1/4-20 x 1/2

102 532 44 12-62 Harness Jumper

105 532 40 75-68 Switch Reverse

107 532 18 03-79 Switch Full Bagger

108 532 42 10-62 Switch Snapmount

142 532 44 80-57 Harness Jumper CTEK

NOTE: All component dimensions given in U.S. inches

1 inch = 25.4 mm

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

CHASSIS AND ENCLOSURES

183

236

236 34

343

235

213

218

282

162

287

162

284

283

199

194

198

chassis-TexCrd-Gen2_TEX GT HUSQ II_9_r1

177

175

130

151

176

345

344

176

182

195

176

178

202

203

208 15

207

205

206

297

191

130

234

137

150

350

335

350

336

214

204

229

180

159

152

228

194

339

338

347

189

217

319

309

130

340

368

308

342

189

159

366

367

189

130 342

349

159

334

118

119

118

119

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

CHASSIS AND ENCLOSURES

KEY PART

NO. NO. DESCRIPTION

3 532 43 97-52 Applique

5 532 43 74-84 Dash

14 532 44 11-77 Hood

15 532 43 97-33 Lens LH

18 532 43 77-62 Grille

25 532 44 33-85 Lens RH

34 580 91 09-01 Plate Engine

36 817 06 05-12 Screw 5/16-18 x 3/4

37 532 44 14-19 Fender

52 873 68 05-00 Nut Lock 5/16-18

62 872 11 06-08 Bolt RdHd Sqnk 3/8-16 x 1 Gr. 5

68 817 49 05-08 Screw Thdrol 5/16-18 x 1/2

118 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.

119 873 68 06-00 Nut Crownlock 3/8-16 unc

130 532 41 63-58 Screw #10 x 0.750

137 532 40 75-90 Bumper Dash

150 532 43 97-74 Air Duct

151 532 43 66-70 Bracket Pivot

152 532 43 98-70 Shield Browning

159 817 00 06-12 Screw Hexwsh Thrd 3/8-16 x 3/4

162 532 14 24-32 Screw

175 532 19 63-04 Crossmember

176 532 40 07-76 Screw 10-24 x 5/8

177 532 19 52-27 Bushing Steering

178 532 19 97-82 Cargo Asm. Net

180 583 90 27-01 Chassis

182 532 43 89-67 Dash Lower

183 874 52 05-20 Bolt 5/16-18 x 1-1/4

189 817 00 05-12 Screw 5/16-18 x 3/4

191 532 43 74-55 Insert Reflective RH

194 873 90 05-00 Nut Lock Hex Flange 5/16-18

195 532 40 41-37 Plug Hole Dash Lower

198 532 44 15-52 Indicator Deck Lift

199 532 41 87-39 Plate Deck Lift

202 532 43 97-28 Vent Side Hood RH

203 532 43 97-27 Vent Side Hood LH

204 532 44 06-65 Vent Top Hood

205 532 43 97-30 Skirt Hood Side RH

206 532 43 97-29 Trim Side LH

NOTE: All component dimensions given in U.S. inches

1 inch = 25.4 mm

207 532 43 97-34 Bezel RH

208 532 43 97-35 Bezel LH

213 874 76 05-12 Bolt 5/16-18 x 3/4

214 532 19 91-45 Clip Retainer Tinner

217 532 40 91-67 Rod Pivot

218 532 19 63-95 X-Piece Hood Stop

228 532 19 51-61 Stud Fastner

229 532 44 14-63 Lid Ext

234 532 40 47-42 Bumper Hood

235 532 40 61-29 Spacer Fender

236 873 93 05-00 Nut Lock 5/16-18 unc

282 532 41 41-10 Clip Retainer

283 532 44 72-12 Console Deck Lift LH

284 532 44 73-17 Console Shft RH

287 817 60 04-06 Screw 1/4-20 x 3/8

297 532 43 74-56 Insert Reflective LH

308 532 17 18-77 Bolt 5/16-18 unc x 3/4

309 581 32 89-02 Backplate

319 581 31 39-05 Lever Bag Presence

334 532 44 25-37 Bracket Engine

335 532 44 82-04 Cover RH Lower Close Out

336 532 44 53-09 Cover LH Lower Close Out

338 532 43 66-40 Bolt Shoulder

339 532 18 03-79 Lever Bagger Full

340 581 32 90-01 Door Battery

342 532 43 59-38 Supprt Fender

343 532 44 07-49 Clip

344 532 43 89-70 Control EZ Mulch

345 532 44 06-39 Knob

347 532 44 28-87 Hitch Tow

349 532 43 66-06 Bracket Support

350 532 44 51-43 Clip X-Mas Tree

366 581 31 46-02 Bracket RH Front Bagger

367 581 31 45-02 Bracket LH Front Bagger

368 581 42 48-01 Full Lever Bagger

- - 532 43 18-82 Kit Guard Brush

KEY PART

NO. NO. DESCRIPTION

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

DRIVE

351

116

103

161

125

205

183

205

183

185

159

125

355

339

125

339

226

227

116

184 221

drive-TexCrd-Gen2_K46_pedal_6_r3

315

143 280

335

362

364

195

143

186

189

314

359 335

363

352

342

359

197

196

160

208

210

214

211

125

215

166

211

222

163

188

159

160

167

203

125

209

213

221

160

206

207

116

38 175

360

279

360

311 312

140

313

309 143

NOTE: All component dimensions given in U.S. inches

1 inch = 25.4 mm

1 – – – – – – Transaxle, TUFFTORQ K46DF

(446488) (Order parts from trans-

axle manufacturer.)

2 532 12 35-83 Key Square

6 532 12 40-28 Bushing Snap

17 532 43 62-27 Spring Brake K46

26 532 19 96-79 Spring Return Cruise

27 817 49 05-28 ScrewHexwshThd5/16-18x1-3/4

29 532 44 27-95 Rod, Brake

30 819 13 16-16 Washer

33 812 00 00-01 Ring E

35 583 86 45-01 Rod, Brake, Park

37 532 18 89-67 Washer Harden .793 x 1.063 x 060

38 532 16 96-13 Nyliner Bushing

42 532 12 48-74 Cover, Foot Pedal

49 872 11 06-14 Bolt Rdhd 3/8-16 unc x 3/4 Gr. 5

50 532 19 43-27 Idler Flat

51 873 90 06-00 Lock Nut 3/8-16

52 532 19 43-26 Idler V-Groove

56 532 44 27-81 V-Belt, Drive

61 532 44 51-51 Pulley Transaxle K46

64 532 19 78-65 Shaft Asm. Pedal Brake Control

73 874 49 05-44 Bolt Flanged

90 532 44 36-05 Keeper Belt Clutching

92 874 76 05-20 Bolt Fin Hex 5/16-18 unc x 1.25

99 532 44 39-47 Rod Spring Bypass

103 873 35 05-00 Nut Hex Jam 5/16-18

116 873 90 05-00 Nut Lock Hex Flange 5/16-18

125 817 00 05-12 Screw 5/16-18 x 3/4

140 810 04 04-00 Washer Lock Hvy Helical 1/4

143 817 49 05-08 Screw 5/16-18 x 1/2

159 876 02 04-12 Pin Cotter 1/8 x 3/4

160 532 16 94-84 Retainer Clip

161 532 10 57-09 Spring, Return, Clutch

163 532 44 27-93 Rod Control

166 532 42 91-64 Nut Push

167 532 40 52-57 Latch Brake Parking

175 532 42 93-59 Shaft Asm Crosshift Rear Crd

183 532 13 70-57 Spacer Axle

184 532 44 14-55 Handle Parking Brake

185 872 11 06-22 Bolt 3/8-16 unc x 2-3/4 G5

186 532 19 43-21 Spacer Retainer

188 532 19 43-23 Link Clutch

KEY PART

NO. NO. DESCRIPTION

KEY PART

NO. NO. DESCRIPTION

189 532 43 36-11 Bellcrank Ground Drive

195 580 45 69-01 Bracket Rod Brake CRD Tex

196 817 00 06-16 Screw 3/8-16 x 1 Smgml Tap/R Blk

197 532 19 58-04 Link Clutch Anti-Rotation

203 819 11 11-16 Washer 11/32 x 11/16 x 16 Ga.

205 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.

206 532 44 85-96 Bracket Mount Latch Cruise

207 532 19 78-68 Latch Control Cruise

208 532 19 78-69 Gear Sector Control Cruise

209 532 19 95-92 Rod Control Cruise

210 532 40 09-80 Rocker Asm. Pedal Control

211 532 12 01-83 Bearing Nylon

213 532 40 31-19 Knob Control Cruise

214 532 42 12-63 Pedal Forward

215 532 41 94-82 Pedal Reverse

221 532 40 31-87 Retainer Spring Clip Handle

222 879 21 20-10 Washer 21/32 x 1-1/4 10 Ga.

226 532 40 15-64 Bracket Strap Torque

227 817 49 05-12 Screw

279 532 44 42-83 Link Shift

280 819 11 10-12 Washer 11/32 x 5/8 x 12 Ga.

309 532 16 55-81 Plate Fstnr Cross Shf

311 532 16 98-45 Washer Nylon

312 532 16 56-14 Hub Tapered

313 874 78 04-16 Bolt Hex Fin 1/4-20 unc x 1 Gd5

314 532 44 47-13 Keeper Belt

315 817 58 05-20 Screw Thdrol 5/16-18 x 4.25

335 532 19 95-34 Pulley V-Idler

339 532 43 68-67 Strap Torque K46 CRD Tex

342 532 18 26-82 Keeper Belt 2.5" STL V-Idlr CRD

351 532 43 69-98 Bracket 97 CRD Deck Sway

352 532 43 56-45 Bracket Idler CRD Tex

355 532 43 56-69 Bracket

359 817 49 06-10 Screw Thdrol 3/8-16 x 5/8

360 532 44 47-14 Nut 5/16-24 UNF

362 532 43 68-12 Idler Flat

363 532 44 27-80 Spacer 343 x 63 x .62

364 532 44 30-32 Bracket Idler CRD Tex

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

DRIVE

SPARK ARRESTER KIT

engine-tex_Kawa-2cyl_19

137

TRACTOR - MODEL NO. CTH 224T (96051007800), PRODUCT NO. 960 51 00-78

ENGINE

Autres manuels pour CTH 224T

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Husqvarna Tondeuse à gazon

Husqvarna

Husqvarna HD800BBC Manuel utilisateur

Husqvarna

Husqvarna WG3213P/968999114 Manuel utilisateur

Husqvarna

Husqvarna L 421P Manuel utilisateur

Husqvarna

Husqvarna 968999189/ ZTH6123KOLA Manuel utilisateur

Husqvarna

Husqvarna 968999214 Manuel de référence

Husqvarna

Husqvarna LZ5227, LZ6130 Manuel utilisateur

Husqvarna

Husqvarna iZ4217TSKAA/9689999254 Manuel utilisateur

Husqvarna

Husqvarna CTH 204T Manuel utilisateur

Husqvarna

Husqvarna AUTOMOWER 305/308 Manuel utilisateur

Husqvarna

Husqvarna AUTOMOWER 310 Manuel utilisateur

Husqvarna

Husqvarna Z142 Manuel utilisateur

Husqvarna

Husqvarna LC 142i Manuel utilisateur

Husqvarna

Husqvarna 124C Manuel utilisateur

Husqvarna

Husqvarna 532 42 20-50_R1 Manuel utilisateur

Husqvarna

Husqvarna LT100 Manuel utilisateur

Husqvarna

Husqvarna 96045000502 Manuel utilisateur

Husqvarna

Husqvarna W520i Manuel utilisateur

Husqvarna

Husqvarna 917.374463 Manuel utilisateur

Husqvarna

Husqvarna 96795370100 Manuel utilisateur

Husqvarna

Husqvarna CTH2642TRE Manuel utilisateur

Husqvarna

Husqvarna LC 153 Manuel utilisateur

Husqvarna

Husqvarna RZ4621 Manuel utilisateur

Husqvarna

Husqvarna CT126 Manuel utilisateur

Husqvarna

Husqvarna 961210037 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur

Stihl

Stihl RMA 443 PV Manuel utilisateur
