Installation and Operation Manual

For Hunter Ceiling Fans

44203-01 05/30/2007

44204-01 05/30/2007

44204-01 5/30/2007

CONGRATULATIONS!

Your new Hunter ceiling fan is an ad-

dition to your home or ofce that will

provide comfort and performance

for many years. This manual gives

you complete instructions for install-

ing and operating your fan.

We are proud of our work. We ap-

preciate the opportunity to supply

you with the best ceiling fan avail-

able anywhere in the world.

Before installing your fan, record

the following information for your

records and warranty assistance.

Please refer to the carton and the

Hunter nameplate (located on top

outside fan motor housing) for the

proper information.

05/30/2007

Model Name ________________

Catalog No. _________________

Serial No.___________________

Date Purchased______________

Where Purchased ____________

___________________________

Attach Your Receipt

or a Copy of

Your Receipt Here

44204-01 05/30/2007

CONTENTS

Important Information ......................................................................................................................................... 5

Step 1 - Getting Ready....................................................................................................................................... 6

Step 2 - Assembling the Fan ............................................................................................................................. 7

Step 3 - Hanging the Fan ................................................................................................................................... 8

Step 4 - Wiring the Fan....................................................................................................................................... 9

Step 5 - Installing the Canopy ...........................................................................................................................11

Step 6 - Assembling Fan Blades ...................................................................................................................... 12

Step 7 - Completing Your Installation ............................................................................................................... 13

Operating Your Hunter Fan............................................................................................................................... 15

Cleaning and Maintenance............................................................................................................................... 16

Troubleshooting................................................................................................................................................ 17

44204-01 5/30/2007

IMPORTANT INFORMATION

not lock the circuit break-

ers in the off position, se-

curely fasten a prominent

warning device, such as a

tag, to the service panel.

• All wiring must be in accor-

dance with national and lo-

cal electrical codes. If you

are unfamiliar with wiring,

you should use a qualified

electrician.

• To reduce the risk of per-

sonal injury, do not bend

the blade attachment sys-

tem when installing, bal-

ancing, or cleaning the

fan. Never insert foreign

objects between rotating

fan blades.

• The fan blades cannot be

placed lower than 2,3m

from the floor.

DO YOU NEED HELP?

To install a ceiling fan, be sure you

can do the following:

• Locate ceiling joist or other

suitable support in ceiling.

• Identify and connect electrical

wires.

• Lift 16 kg.

If you need help installing the fan,

your Hunter fan dealer can direct

you to a licensed installer or elec-

trician.

WARNINGS

• To avoid possible electri-

cal shock, before installing

your fan, disconnect the

power by turning off the

circuit breakers to the out-

let box and associated wall

switch location. If you can-

CAUTIONS

• Read entire booklet care-

fully before beginning in-

stallation and save these

instructions.

• To reduce the risk of per-

sonal injury, attach the

fan directly to the support

structure of the building

according to these instruc-

tions, and use only the

hardware supplied.

44204-01 05/30/2007

GATHERING THE TOOLS

You need the following tools to in-

stall the fan:

• Standard screwdriver

• Phillips-head screwdriver

• Wrench or pliers

PREPARING THE FAN SITE

Reliable operation, efciency, and

maximum energy savings depend

upon proper placement and attach-

ment of the fan. This fan should be

installed on a previously installed

J-Hook or U-Hook.

STEP 1 - GETTING READY

CHECKING YOUR FAN PARTS

Carefully unpack your fan parts to

avoid damage. Check for shipping

damage. If one of the fan blades

is damaged, return all blades for

replacement.

Hint: If installing more than one fan,

keep the fan blades in sets, as

shipped.

Standard Mounting (Figure 1) hangs

from the ceiling by a connector

pipe (included), for ceilings 2.3 m

or higher. For ceilings higher than

2.3 m.

Figure 1 - Standard Mounting

44204-01 5/30/2007

STEP 2 - ASSEMBLING THE FAN

1. Feed the wires and the steel ca-

ble support from the fan through

the canopy and the pipe.

2. Screw pipe into fan assembly until

tight. IMPORTANT! Tighten pipe

setscrew as shown in Figure 2.

CAUTION

• The pipe adapter has a spe-

cial coating on the threads.

Do not remove this coat-

ing; the coating prevents

the pipe from unscrewing.

Once assembled, do not

remove the pipe.

WARNING

• Failure to complete the

steps above properly could

result in the fan falling.

Figure 2 - Assembling The Fan

Pipe Setscrew

44204-01 05/30/2007

STEP 3 - HANGING THE FAN

Hang fan from the previously in-

stalled J-Hook or U-Hook.

SECURING FAN TO SECOND-

ARY SUPPORT

1. Find the looped end of the braid-

ed cable and insert it through the

ceiling plate and one of the holes

in the outlet box into the ceiling.

2. Access the support brace in the

ceiling. You may not be able to

do this from below the ceiling

depending on your installation

site.

3. Drive a #10 x 38 mm (1-1/2")

wood screw and washer into the

side of the brace that holds the

outlet box. Leave 3 mm (1/8")

of space between the support

brace and the washer. Figure 3a - Installing the Wood Screw

into the Brace

Figure 3b - Hooking the Cable

Figure 3c - Tightening the Loop

4. Wrap the braided cable around

the support brace once creating

a complete circle.

5. Hook the looped end of the cable

over the wood screw so that the

braided cable lies between the

washer and the support brace.

See Figure 3b.

6. Tighten the loop and secure the

screw and washer all the way

down to the support brace. See

Figure 3c.

7. Coil up the excess cable. Return

44204-01 5/30/2007

STEP 4 - WIRING THE FAN

WARNING

• To avoid possible electrical

shock, before wiring fan,

disconnect power by turn-

ing off the circuit break-

ers both to the outlet box

and to its associated wall

switch location. If you can-

not lock the circuit break-

ers in the off position, se-

curely fasten a prominent

warning device, such as a

tag, to the service panel.

• All wiring must be in accor-

dance with national and lo-

cal electrical codes. If you

are unfamiliar with wiring,

you should use a qualified

WARNING

To reduce the risk of re, elec-

trical shock, or motor damage,

do not lift or carry the fan by

Disconnect the power by turning

off the circuit breakers to the outlet

box and associated wall switch

location.

CONNECTING FAN TO ELEC-

TRICAL SOURCE

Use Figure 4 for reference in mak-

ing the following electrical connec-

tions.

1. Connect the supply mains with a

wire nut.

2. Connect the earth wire and the

CAUTION

Be sure no bare wire or wire

strands are visible after mak-

ing connections.

green/yellow ground wire from

the hanger.

3. Connect the blue neutral wire to

the blue wire from the fan.

4. Connect the brown line wire to

the brown wire from the fan.

Note: Unless there is a sepa-

rate line for the light kit, connect

the black/white wire and brown

wire from the motor housing to

the brown wire from the ceil-

ing.

44204-01 05/30/2007

FIGURE 4 - WIRING DIAGRAM

Earth

Power�

Wires�

In �

Ceiling Blue

Brown

Blue

Black/White

2Connections:�

�

Brown

(Optional Line)�

Wall Switch Wire For �

Separate Control of Light Kit

Green/Yellow�

Wire from Hanger

3 Wires �

From Fan

(Note: Wall switch �

must be acceptable �

as a general-use�

switch.)

Connect Blk/Wht Wire from fan�

to Wall Switch Wire for separate�

control of light, or�

Connect Blk/Wht Wire from fan�

to Ceiling Brown Wire if there �

is no separate Wall Switch Wire�

for the light kit.
