Valid for H3SA
HD-PGDE-0127-A1
Huddly USB Adapter
Product and Compliance
Information
Contents
Safety and Caution Information 3
Temperature 3
Modify 3
User Instructions 3
Installation 3
Power 4
Input 4
Output 4
Recycling 4
Regulatory Compliance Information 5
European Union 5
EMC Directive conformance statement 5
Recycling of waste electronic equipment 5
United States of America and Canada 6
FCC compliance statement 6
Industry Canada statement 6
Australia and New Zealand 7
Korea 7
Taiwan 8
Point of Contact 9
Support 9
EULA 9
Privacy policy 9
Further information 9
3
Safety and Caution
Information
Temperature
This device is intended for use in ambient temperatures between 0 °C and
35 °C (32 °F and 95 °F). Avoid using or storing next to heat sources, in
direct sunlight, or outside the intended temperature ranges.
Modify
Modication to thermal solution, device components or enclosure shall
violate regulatory compliance requirements and may induce safety hazards.
User Instructions
The USB Adapter is made to easily connect an Ethernet device to a host
computer using USB-C. The USB Adapter can also provide 37-57V DC
power to a connected Ethernet device. The USB Adapter can be powered
with AC adapter and USB C 5V DC.
Installation
Connect the Ethernet device and the USB Adapter using minimum a Cat5e
rated Ethernet cable. Further connect the USB Adapter to a USB host and
also connect the external power adapter to USB Adapter that included in
the package.
The status LED will light up after the unit has booted. The LED will be red
until the unit is ready to stream video from a connected network camera.
When streaming is ready, the LED will turn white.
A wall mount bracket with double sided tape is included. To install the
bracket, remove the tape liner and place the bracket in a suitable position,
not higher than 2m, and on a clean smooth surface.
4
Attach the USB Adapter to the wall mount bracket and ensure that the unit
is properly locked in position around the mounting plate. Magnetic surfaces
can generally be used to mount the USB Adapter. Optionally, place the
Adapter directly on any horizontal surface.
The wall bracket is designed to hold the Huddly USB Adapter only. It should
not be used as support for any additional weight.
Power
Input
Minimum requirements:
USB Vbus 5V >0.5A
The USB Adapter will enable Power over Ethernet functionality when
the following input requirements are met.
USB host 5V 3A, and
external DC adapter 5V 4A
Use only the included Cincon TRE25R050-35G02 VI or CUI SMM30-5-
RV-C AC/DC adapter. Other AC/DC adapters are not supported.
Output
Voltage range: 48V DC Maximum current: 0.35A
Recycling
At the end of life for this product, local rules and regulations shall be
followed. This product is ment to be recycled, and if applicable and/or
possible, should be handed in to a collection point for recycling purposes.
5
Regulatory Compliance
Information
European Union
EMC Directive conformance statement
This product, a Class A product, has been tested and found
to comply with the limits for Class A equipment in accordance
with European directives and harmonised standards. The
limits for Class A equipment were derived for mainly non-
residential environments to provide reasonable protection
against interference with licensed communication equipment.
Notice: In a domestic environment this product may cause radio interference,
in which case the user may be required to take adequate measures to
correct the interference.
Recycling of waste electronic equipment
In the European Union, this symbol indicates that this product
must not be disposed of with household waste. It is your
responsibility to hand it over to a designated collection point
for the recycling of waste electronic equipment. For more
information, please contact your local waste collection center
or the point of purchase of this product.
6
United States of America and Canada
This product carries the cNus safety mark in accordance with
the requirements of the applicable standards for Canada and
the United States of America.
FCC compliance statement
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
1.
this device may not cause harmful interference, and
2.
this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Changes or modications to the equipment not expressly approved by the
party responsible for compliance could void the user’s authority to operate
the equipment.
Industry Canada statement
This Class A digital apparatus complies with CAN ICES-3 (A)/NMB-3(A).
Operation is subject to the following two conditions:
1. this device may not cause interference, and
2.
this device must accept any interference, including interference that
may cause undesired operation of the device.
7
Australia and New Zealand
This product, a Class A product, carries the Regulatory
Compliance Mark (RCM) in accordance with the requirements
of the applicable Australian and New Zealand standards.
In a domestic environment this product may cause radio
interference, in which case the user may be required to take
adequate measures to correct the interference.
Korea
이 제품은 주로 비주거 환경에서 사용되는 Class A
장치입니다. 가정 환경에서 클래스 A 장치는 무선
간섭을 일으킬 수 있으며, 이 경우 사용자는 간섭을
수정하기 위해 적절한 조치를 취해야 할 수 있습니다.
This product is a Class A device to be used mainly in a non-
residential environment. In a domestic environment, class A devices may
cause radio interference, in which case the user may be required to take
adequate measures to correct the interference.
8
Taiwan
限制物質含量存在的聲明
Declaration of the presence of Restricted Substance Content
設備名稱
Equipment
Name:
USB Adapter
型號名稱
Model
Designation:
H3SA
限用物質及其化學符號
Restricted substances and its chemical symbols
帶領
Lead
汞
Mercury
鎘
Cadium
六價鉻
Hexavalent
chromium
多溴聯苯
Polybrominated
Biphenyls
多溴聯苯醚
Polybrominated
diphenyl ethers
單元 / Unit (Pb) (Hg) (Cd) (Cr+6) (PBB) (PBDE)
盒子
Box ○ ○ ○ ○ ○ ○
主組件
Main
Assembly ○ ○ ○ ○ ○ ○
其他各種零件
Various
Other Parts ○ ○ ○ ○ ○ ○
注 1 / Note 1: “超過 0.1 wt %” 和 “超過 0.01 wt %” 表示限用物質的百分比含量超過了規定的參考
值。 / “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicates that the percentage content of
the restricted substance exceeds the dened reference value.
注 2 / Note 2: ○” 表示限制物質的百分比含量不超過規定的參考值。 / “○” indicates that the
percentage content of the restricted substance does NOT exceed the dened reference value.
注 3 / Note 3: “–” 表示受限物質的出現屬於豁免範圍。/“−” indicates that the occurrence of the
restricted substance falls under an exemption.
Huddly 同意按照《商檢法》第 49 條的規定與 BSMI 合作，如果需要核實和
BSMI 要求，將在 28 個工作日內提供正確的相關文件。Huddly 還確保上述聲
明 - “限制物質含量存在的聲明” - 已通過測試和其他質量控制措施得到證
實。
Huddly agree to cooperate with BSMI as Article 49 of the Commodity
Inspection Act stipulates, and will provide the correct and relevant documents,
if needed for verication and on BSMIs request, and within 28 working
days. Huddly also ensure that the declaration above – “Declaration of the
presence of Restricted Substance Content” – have been substantiated by
means of testing and other quality control measures.
9
Point of Contact
Huddly AS,
Attn: Compliance
Haakon VIIs gate 5
NO-0161 Oslo,
Norway
Support
For more information visit:
https://support.huddly.com
EULA
By using this product, you agree that your use of this product is subject to
our End User Licence Agreement terms available at:
https://www.huddly.com/eula/
Privacy policy
Our privacy policy is available at:
https://www.huddly.com/privacy-policy/
Further information
You can nd further compliance information at:
https://www.huddly.com/compliance/usbAdapter/
