HuddleCamHD SimplTrack Lite Manuel utilisateur
HuddleCamHD SimplTrack Lite
User Manual
Model No. HC20X-SIMPLTRACKLITE
V1.0
(English)
Please check huddlecamhd.com for the most up to date version of this document.
2
Table of Contents
Preface .......................................................... 3
Precautions ................................................. 3
Warning .................................................... 3
Warranty ................................................... 4
Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FCC Statement .............................................. 4
Connection Guide .................................................. 5
Dimensional Drawings (mm) .......................................... 6
Features .................................................... 7
Technical Specications ............................................. 8
NDI®|HX with NDI® 4 Connection ..................................... 10
Tracking Software .................................................. 11
Device Management Interface ................................... 11
Conguring the Camera ............................................. 12
Tracking Software .................................................. 15
Main View Interface ........................................... 15
Controlling the Camera ........................................ 16
Tracking Settings ............................................. 16
Preset Zones ................................................ 16
Video Recording & Screenshot ....................................... 18
RS232 Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Serial Communication Control......................................... 21
HuddleCamHD VISCA Command List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
On Screen Display Menu ............................................ 27
Network Connection ................................................ 30
Using the Upgrade Tool ........................................ 31
Maintenance and Troubleshooting ..................................... 36
Unqualied Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Troubleshooting .............................................. 36
3
Preface
Thank you for using the HD Professional Video Conferencing Camera. This manual introduces the
function, installation, and operation of the HD camera. Prior to installation and usage, please read the
manual thoroughly.
Precautions
This product can only be used in the specied conditions in order to avoid any damage to the unit
itself.
• Don’t subject the camera to rain or moisture.
• Don’t remove the cover. Removal of the cover may result in an electric shock. In addition to void-
• Never operate outside of the specied operating temperature range, humidity, or with any other
power supply than the one originally provided with the unit.
• Please use a soft dry cloth to clean the unit. If the unit is very dirty, clean it with diluted neutral
detergent; do not use any type of solvents, which may damage the surface.
Warning
• Electrical Safety
Installation an operation must be in accordance with national and local electric safety
standards. Do not use any power supply other than the one originally supplied with this
camera.
• Polarity of Power Supply
The power supply output for this product is 12V DC with a maximum current supply of
2A. Polarity of the power supply plug is critical and is as follows:
• Handling
ŜAvoid any stress, vibration, or moisture during transportation, storage, installation,
and operation. o Do not lift or move the camera by grasping the camera head. Do
not turn the camera head by hand. Doing so may result in mechanical damage.
ŜDo not expose the camera to any corrosive solid, liquid, or gas to avoid damage to
the cover which is made of a plastic material.
ŜEnsure that there are no obstacles in the pan or tilt ranges of the camera lens.
ŜNever power the camera on before installation is complete.
• Do not dismantle the camera – HuddleCamHD is not responsible for any unauthorized modi-
cation or dismantling
4
Warranty
HuddleCamHD includes a limited parts & labor warranty for all HuddleCamHD manufactured
cameras. The warranty is valid only if HuddleCamHD receives proper notice of such defects during
the warranty period. HuddleCamHD, at its option, will repair or replace products that prove to be
defective. HuddleCamHD manufacturers its hardware products from parts and components that are
new or equivalent to new in accordance with industry standard practices.
Supplied Accessories
When you unpack your camera, check that all the supplied
accessories are
included:
• Camera 1
• AC Power Supply 1
• S-232C Cable 1
• IR Remote Controller 1
• Quick Start Guide 1
• AAA Batteries 2
FCC Statement
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radiofrequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
FCC Caution: Any changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment. Operation is subject to the
following two conditions: This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
• Warning - This is a class A product. In a domestic environment, this product may cause
radio interference in which case the user may be required to take adequate measures.
• Remote Control Battery Safety Information - Store batteries in a cool and dry place.
Do not throw away used batteries in the trash. Properly dispose of used batteries through
specially approved disposal methods. Remove the batteries if they are not in use for long
periods of time. Battery leakage and corrosion can damage the remote control. Do not use
old batteries with new batteries. Do not mix and use dierent types of batteries: alkaline,
standard (carbon-zinc) or rechargeable (nickel-cadmium). Do not dispose of batteries in a
re. Do not attempt to short-circuit the battery terminals.
Copyright Notice
The entire contents of this manual / guide, whose copyright belongs to HuddleCamHD, may not be
cloned, copied, or translated in any way without the explicit permission of the company. The product
specications referred to in this document are for reference only and as such are subject to updating
at any time without prior notice.
©2021 | HuddleCamHD | All Rights Reserved
5
Connection Guide
1. USB 2.0 USB 2.0 type B female connection
2. HDMI HDMI ver. 1.4 connection
3. Line In 3.5mm audio connection
4. Network RJ45 port for NDI®|HX & network streaming / control 5. SDI 3G-SDI connection
5. RS-232 In 8-pin mini din connection for joystick controller
6. RS-232 Out 8-pin mini din connection for daisy chaining
7. DC12V DC 12V power connection
6
Dimensional Drawings (mm)
211 mm
139 mm
211 mm
7
• Image Sensor
• 1/2.8”, 2.14 million eective pixels, HD CMOS sensor.
• High quality telephoto lens supporting 20X optical zoom and optional 12X digital zoom.
• Full HD 1920x1080p resolution up to 60 frames per second.
• 2D & 3D noise reduction with our latest “low noise CMOS sensor”.
• Wide angle 59.5° horizontal eld of view.
• Dynamic Range Control (DRC) for higher image quality and detail across simultaneous-
ly well-lit and shadowed scenes.
• High SNR (signal to noise ratio) of the CMOS sensor (≥55dB), combined with 2D & 3D
noise reduction algorithms, eectively reduces noise, even under low illuminated condi-
tions.
• Video Outputs
• Simultaneous NDI®|HX using NDI® 4 / IP network streaming, USB 2.0, 3G-SDI, &
HDMI 1.4 o USB 2.0 Full HD video output up to 1080p 30 frames per second.
• 3G-SDI Full HD video output up to 1080p 60 frames per second.
• HDMI 1.4 Full HD video output up to 1080p 60 frames per second.
• RTSP, RTMP, & RTMPS streaming using H.264 or MJPEG.
• Line level audio embeds over NDI®|HX / network stream. Uses AAC audio encoding for
better sound quality and lower bandwidth usage.
• Control and Settings
• Automatic tracking of active participant.
• NDI®|HX control through NDI® approved platforms that oer control
• HuddleCamHD VISCA & VISCA over IP
• IR Remote Control
• RS-232 VISCA & Pelco-D control
• Installation
• Standard 1/4-20 female thread for camera mounting
• 12V DC 2.5A Power Supply
• PoE+ 802.3af
• Warranty
• 3-year warranty
Features
• All-in-One Solution - The SimplTrack Lite does not require a dedicated computer to oper-
ate. This simplies deployment and provides a more seamless less-complicated solution
you can rely on for the long term. No need to manage dedicated auto-tracking software,
this camera can be tuned to your room and set to operate trouble-free and independent
from additional hardware.
• Dedicated Management Software - The SimplTrack Lite features dedicated camera man-
agement software that can be controlled from any Windows computer on the network. You
don’t need a dedicated computer to run the system You can use any Windows PC running
the Management Software to remotely manage the cameras when necessary.
8
Technical Specications
Model HC20X-SIMPLTRACKLITE
Type HuddleCamHD SimplTrack Lite HD 1080p Color Video Camera
Camera
Video System 1080p-60/50/30/25, 1080i-60/50, 720p-60/50
Sensor 1/2.8” CMOS, 2.14 megapixel
Lens 20X
Digital Zoom 12X Digital Zoom
Shutter 1/1 ~ 1/10000
White Balance Auto, ATW, OnePush, Indoor, Outdoor, Manual, Sodium Lamp, Fluo
Lamp
Backlight Compensation Supported
Digital Noise Reduction 2D & 3D Digital Noise Reduction
Video S/N ≥55dB
Horizontal Field of View 2.9° ~ 59.5°
Vertical Field of View 2° ~ 36°
Horizontal Rotation Range ±170°
Vertical Rotation Range -30° ~ +90°
Pan Speed Range 0.2° ~ 100°/s
Tilt Speed Range 0.2° ~ 60°/s
Image Flip / Mirror Supported
Image Freeze Not supported
PoE+ Supports PoE+ (802.3af)
Face Detection Not supported
Local Storage Not supported
Number of Presets 64
Preset Accuracy 0.1°
Input / Output Interface
HD Output 1 x RJ45 NDI®|HX using NDI® 4 / IP Network 10/100M Ethernet
port
1 x USB 2.0, Type B Female
1 x HDMI version 1.4
1 x 3G-SDI: BNC type, 800mVp-p, 75Ω, Along to SMPTE 424M
standard
Network Interface 1 x RJ45: 10/100M Adaptive Ethernet ports
Audio Interface 1 x 3.5 audio interface, Line in (NDI®|HX & IP Network stream
only) (Unbalanced stereo)
Communication Interface 1 x RS-232 In: 8-pin mini DIN, Max Distance 30m, Protocol: VISCA/
Pelco-D
1 x RS-232 Out: 8-pin mini DIN, Max Distance 30m, Protocol: VIS-
CA daisy chaining only
9
IR 4 x IR addresses, Max Distance 9m (30ft)
Power Jack JEITA type (DC IN 12V)
IP Video Features
Video Compression H.264 / H.265
Video Stream Two (2) IP video output streams available
First Stream Resolutions 1080p / 720p / 704x480(D1) / 320x240(QVGA) –
60/50/30/25
Second Stream Resolutions 704x480(D1) / 320x240(QVGA) – 60/50/30/25
Video Bit Rate 0Kbps ~ 16383 Kbps
Bit Rate Type Constant or Variable bit rate
Frame Rate 50Hz: 1 ~ 50 FPS, 60Hz: 1 ~ 60 FPS
Audio Compression AAC
Audio Bit Rate 16Kbps, 32Kbps, 48Kbps
Supported Protocols TCP/IP, HTTP, RTSP, RTMP, DHCP, Multicast,
NDI®|HX etc.
Generic Specications
Input Voltage DC 12V / PoE+ (802.3at)(optional)
Current Consumption <15W
Operating Temperature 32°F ~ 104° (0°C ~ +40°C)
Storage Temperature -4°F ~ 140° (-20°C ~ +60°C)
Humidity Range 10% RH ~ 90% RH
Size in. (W x D x H) 8.31” x 5.47” x 8.19” | 211mm x 139mm x 208mm
Camera Weight 2.43lbs | 1.1kg
10
NDI®|HX with NDI® 4 Connection
The NDI®|HX connection allows you to connect and control your camera through any NDI
compatible hardware or software on your Local Area Network. Once your camera is setup on a LAN,
you can utilize the NDI®|HX connection.
Three Easy Steps:
1. Download and install the latest NDI®|HX Tools.
2. Select your camera within the NDI®|HX compatible device.
3. 3. Select your camera. The NDI feed will utilize the camera’s device friendly name.
NewTek®, NDI®, NDI® 4 & NDI®|HX are all registered trademarks by NewTek®.
Please note that your NDI License key is non-transferrable.
Autres manuels pour SimplTrack Lite
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels HuddleCamHD Caméra IP
HuddleCamHD
HuddleCamHD 3X Gen2 Manuel utilisateur
HuddleCamHD
HuddleCamHD HuddleCamHD 18x Manuel utilisateur
HuddleCamHD
HuddleCamHD 3X Manuel
HuddleCamHD
HuddleCamHD SimplTrack Lite Manuel utilisateur
HuddleCamHD
HuddleCamHD HuddleCam-HD 12x Manuel utilisateur
HuddleCamHD
HuddleCamHD SimplTrack 2 Instructions d'utilisation et d'entretien
HuddleCamHD
HuddleCamHD HD Color Video Camera Manuel utilisateur
HuddleCamHD
HuddleCamHD conference camera Manuel utilisateur
HuddleCamHD
HuddleCamHD 10XA Manuel utilisateur
HuddleCamHD
HuddleCamHD HuddleCamHD 10X 720p Manuel utilisateur
