Huawei IDEOS S7 Slim Manuel utilisateur

Ideos Tablet S7

Quick Start

Contents

Packing list.......................................................... 1

Locking and unlocking the screen ......................6

Getting to know your Tablet ................................ 1

7.1

To lock the screen...................................................6

Installation........................................................... 2

7.2

To unlock the screen...............................................6

Setting date and time ..........................................6

3.1

To remove the back cover...................................... 2

Installing or removing the microSD card.............7

3.2

To install the SIM card............................................ 3

For more help....................................................7

3.3

To install the battery ............................................... 3

Warnings and Precautions ................................8

3.4

To install the back cover......................................... 3

Turning the Tablet on or off ................................. 4

4.1

To turn the Tablet on .............................................. 4

4.2

PIN protection ........................................................ 4

4.3

To turn the Tablet off............................................... 4

Charging the battery ........................................... 5

Using the touchscreen ........................................ 5

1 Packing list 2 Getting to know your Tablet

The product package contains the following items.

S7 Tablet

1 S7 Tablet

2 Stylus 1 Ambient light sensor

3 Battery

Home

key2

4 Power adapter

key3

5 USB cable

Back

key4

6 Quick start 5 LCD screen

6 microSD card slot

If the items in the product package are not consistent with

hose in the packing list, contact the vendor. The figures and

operation descriptions in this guide are provided only for

reference, see the actual product for details.

7 Dock interface

8 Microphone

End

key9

10 Power interface

11 Micro USB interface

3 Installation

OFN

(Optical Finger Navigation) key12

Call

key13

3.1 To remove the back cover

14 Speaker

15 LED indicator To remove the back cover, refer to the following figure and steps.

16 Camera lens

Power

key17 1. Unfold the bracket.

18 Bracket 2. Open and remove the back cover.

19 Stylus jack

20 Camera lens

To prevent injury, properly place the back cover after you

emove the back cover because it may have sharp edges and

angles.

Volume Up/Down

key21

22 Speaker

23 Headset jack

3.2 To install the SIM card

Before installing or removing the SIM card, power off the

Tablet.

Insert your SIM card into the SIM card slot as shown in the following

figure until the SIM card is completely in position.

3.4 To install the back cover

To install the back cover, refer to the following figure and steps.

3.3 To install the battery

1. Install the back cover.

To install the battery, refer to the following figure.

2. Fold the bracket.

4 Turning the Tablet on or off 4.2 PIN protection

If your SIM card is preset with a PIN, the Tablet prompts you to enter

the PIN.

4.1 To turn the Tablet on

The PIN may have been provided by your service provider with

your SIM card. If you lost it, consult your service provider.

Before you turn the Tablet on, ensure that the SIM card has been

correctly installed and that the battery is correctly installed or the

Tablet has been properly connected to the power supply.

4.3 To turn the Tablet off

To turn the Tablet on, press and hold the

Power

key for about two

seconds. 1. Press and hold

Power

key to open the

Tablet options

menu.

2. Touch

Power off

3. Touch

to assure you want to turn your Tablet off in the dialog

that opens.

5 Charging the battery 6 Using the touchscreen

Before charging the battery, ensure that the battery is properly

installed on your Tablet.

By using your finger, you can manipulate target items such as

applications and controls, and enjoy the touchscreen at your

fingertips. The Tablet supports the following actions.

To charge the battery, you can connect the Tablet to the power supply

through the power adapter, as shown in the following figure.

Action Description

Touch Simply touch items on the screen, such as

applications and controls. For example, you can

type letters and symbols using the onscreen

keyboard.

Touch

and hold

Touch and hold an item on the screen until an

action occurs. For example, you can usually touch

and hold the screen to open the context menu of

the active item.

Drag Touch and hold an item, and then move your finger

on the screen until you reach the target position.

For example, you can drag a shortcut to the trash to

delete it.

Flick Flick your finger vertically or horizontally across the

screen. For example, you can flick up and down to

manipulate a scroll bar and flick left and right to

switch between pictures.

7 Locking and unlocking the screen 8 Setting date and time

By default, the Tablet automatically uses the network provided date,

time zone, and time.

7.1 To lock the screen

When the time provided by the network is automatically used,

you cannot set the date, time, and time zone by yourself.

When the Tablet is on, press the

Power

key to turn off and lock the

screen.

When the Tablet remains idle for a time period that you have set, the

screen will automatically lock.

To manually set date and time, do as the following steps.

1. Open the

Settings

list.

To save your battery or prevent accidental taps when not in use,

or when you want to wipe smudges off your touchscreen, turn

off and lock the screen.

2. Touch

Date & time

3. Touch

Automatic

to make it unchecked.

4. Touch

Set date

. Then touch the plus button or the minus button to

adjust the date, month, and year, or touch the text field of date,

month, and year to enter them. Touch

Set

when finished.

7.2 To unlock the screen

When the screen is off, you can press the

Power

key to turn on it,

and then unlock the screen through the following steps. 5. Touch

Select time zone

, then select the time zone in the list.

Scroll down the list to view more time zones.

1. If you have not set up a screen unlock pattern, press the

key to unlock the screen, or follow the instructions displayed on

the screen and flick upwards to unlock the screen.

6. Touch

Set time

. Then touch the plus button or minus button to

adjust the hour and minute, or touch the text field of hour and

minute to enter them. Touch

Set

when finished.

2. If you have set up a screen unlock pattern, the Tablet prompts

you to draw the pattern on the screen to unlock it.

9 Installing or removing the microSD

card

10 For more help

For more help, you can open the user guide on the device on the

Applications screen. You can also press the

key when you are

on the Home screen, and touch

Settings

About tablet

User

Guide

Insert your microSD card into the microSD card slot as shown in the

following figure until the microSD card clicks into position.

To remove the microSD card, slightly push the card further into

he slot, and wait for it to ejects out for about 2 mm, and then

remove it.
