Huawei Y511-U00 Guide d'installation
HUAWEI TECHNOLOGIES CO., LTD.
www.huawei.com
Huawei Confidential
Security Level:
Y511-U030 Product
training courses V1.0
——Regional delivery and service products
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Course objectives:
Understand the product specification information, grasp the product
upgrades, capture operation and basic functions of the application
Product Line ：XX
Product Categories：XX
Product Model：XX
Author：XX
The basic product information training course
This page explained to customers to delete.。
Note: blue font can be modified.
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Course Catalog
Note: blue font can be modified. Please modify the content determination and dark red
1Y511-U10/U251/U30 Products Introduction
2Y511-U10/U251/U30 Products commonly used
functions operating instructions
3 Y511-U10/U251/U30 Products upgrade Guide
4Y511-U10/U251/U30 Products FAQ
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Y511-U10/U251/U30 Procuts brief Introduction
Y511-U00 is a WCDMA dual mode digital mobile phone operating
system, Android 4.2, MTK 6572 dual core 1.3GHz platform,
4.5 inch FWVGA screen, capacitive touchscreen, 300W camera, high
speed USB port, support the gravity sensing, distance, light
induction. Support for Bluetooth, WIFI, GPS function
Y511-U10/U251/U30 Products Introduction
Note: blue font can be modified.
Y511
appearance
of the product
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Page 5
Y511-U10/U251/U30 Products Introduction
Y511-U10/U251/U30
Products indicators, external expansion
interface description
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Y511U Technical specifications of hardware products
Y511U Products Introduction
Note: blue font can be modified. The font size is 14 characters, the font used Chinese
fine black.
The project according to the characteristics of the product to add, the
battery capacity and the standby time must be added.
Item description.
Phone Size 132.8*67.4*10.5
Phone weight; About 160g (Including battery)
Antenna Built-in antenna
SIM interface Standard 6 PIN SIM interface
USB interface Mini USB interface, Maintenance and supply for Telephones
Power interface Power interface Mini USB interface
Power adapter AC input：100V ~ 240V DC output ：5v---1A
LCM 4.5 inch、FWVGA、TN、1600 Million color、380cd/m2(typ)
Working
Environment;
Working temperature：－10℃～＋55℃
Storage temperature：－40℃～＋70℃
Operating humidity：5％～95％RH
XX •XX
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Y511U Products Introduction
Note: blue font can be modified. The font size is 14 characters, the font used Chinese fine black.
The project according to the characteristics of the
product to add,
Item description.
Technical Standard; WCDMA / GSM /DCS
Work Frequency Band
U10/U30:UMTS:900/2100
GSM/EDGE:850/900/1800/1900
U251:UMTS:850/1900/2100
GSM/EDGE:850/900/1800/1900
Maximum Transmit
Power GSM900:890-915MHz;GSM1800:1710-1785MHz WCDMA: 1940 –1955 MHz
Receiving
Sensitivity GSM900:935-960MHz；GSM1800:1805-1880MHz；WCDMA: 2130 –2145 MHz
XX
•XX
Y511U Technical specifications of hardware products
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Y511U Software products
Y511U Products Introduction
Item description.
Voice
service
Provide basic voice service (FR/EFR/AMR (NB-AMR), but WB-AMR does not
support); call a recently dialed; by dialing phone book; speed dial dial;
IP; emergency call; handset and handsfree; support 6 Volume in call control;
SMS
Support short message transceiver;
The telephone memory: the Outbox, inbox and drafts of shared memory space,
up to 1000 messages, support length letter (supports up to 670 Chinese
characters);
USIM card memory card capacity: up;
Support short message sending function, each up to 200 members;
Support sending short message by communication;
Address
Telephone: memory can store up to depend on internal storage residual
capacity; SIM card memory card capacity: whether in memory; telephone number
length: up to 100 numbers; the memory of the SIM number length: the limit
up;
Recorded on the telephone and mail list (U) copy SIM Kaka, support more than
one group, the number of open
Date service
2Supported by a data interface connected with a PC machine to realize data
service, support packet switched data services on GPRS: 70.4kbps/236.8kbps
(uplink / downlink packet data service), support for TD HSDPA: 384kbps/2.8M
(uplink / downlink); drivers installed automatically;
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Y511U Products commonly used functions operating instructions
1、WLAN
Click on the main menu settings menu in settings, select WLAN
to enter the WLAN settings
HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential
35pt
32pt
) :18pt
Open WLAN, automatic scanning AP, select a AP password, a
successful connection. Open the browser to browse webpage
through WLAN network.
Y511U Products commonly used functions operating instructions
