Huawei U7515 Manuel utilisateur
Notice
Copyright © Huawei Technologies Co., Ltd. 2009. All rights reserved.
Trademarks and Permissions
, HUAWEI and are trademarks or registered trademarks of Huawei
Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are
the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION
TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR
ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOOD-
WILL OR ANTICIPATED SAVINGS.
Introduction
Packing List . . . . . . . . . . . . . . P1
SIM Card and Memory Card . P1
Charging the Battery . . . . . . . P2
Appearance of Your Phone . . P4
Home Screen . . . . . . . . . . . . P6
Using the Touch Screen . . . . P7
Calibrating the Touch Screen P7
Dragging and Flicking . . . . . . P8
Accessing the Widget Bar . . . P9
Security Settings . . . . . . . . . . P9
Text Input
On-screen Keypad Mode . . P11
T9®Input Method . . . . . . . . P12
Traditional Input Method . . . P12
Call Service
Making a Call . . . . . . . . . . . P13
Answering or Rejecting a Call P14
Other Call Functions . . . . . . P14
Messaging
Sending a Message . . . . . . P15
Sending an Email . . . . . . . . P15
Viewing an Email . . . . . . . . . P16
Email Settings . . . . . . . . . . P16
Contacts
Adding a Contact . . . . . . . . . P17
Searching for a Contact . . . P17
Entertainment
Playing Music or Video . . . . P18
Using Camera or Video Camera .
P18
Using FM Radio (Optional) . P19
Accessing the Internet . . . . . P20
Managing files . . . . . . . . . . . P20
Connectivity
Using PC Options . . . . . . . . P21
Connecting to Other Bluetooth
Devices . . . . . . . . . . . . . . . . P22
Important Informations
Ambient Temperature . . . . . P23
FCC Statement . . . . . . . . . . P23
Certification Information (SAR) . .
P23
Contents
Introduction
1
1 Introduction
All the images in this guide are provided only for your reference. The actual
appearance and display depends on the phone that has been delivered.
Packing List
Your phone package box contains the following:
• One mobile phone
• One Li-ion battery
• One travel charger
• One USB data cablev
• One User Guide
• One Headset
SIM Card and Memory Card
Insert your SIM card before using your phone. Remove the SIM card and
the battery only after powering off your phone.
Your phone supports a memory card (microSD) with a capacity of up to 8
GB.
2
Introduction
The following figures show the installation of the SIM card and memory
card.
Charging the Battery
1. Connect the USB interface of the USB cable to the travel charger.
2. Plug in the travel charger to a power socket.
1 Remove the battery cover. 2 Inert the SIM card.
3 (Optional) Insert the memory card. 4 Insert the battery.
Introduction
3
3. Connect the mini USB interface of the USB cable to the charger
connector of your phone. When the battery is being charged, the
charging indicator blinks continuously.
4. When the charging indicator stops blinking, it indicates that the battery
is full.Disconnect the charger connector from the power socket.
5. Disconnect the USB cable from the phone.
2
3
1
4
Introduction
Appearance of Your Phone
1 Earpiece 2 Touch screen 3 Microphone
4 Send key 5 OK key 6 End key
7 Scroll key 8 Camera key 9 Shortcut key
10 Volume
Up/Down
Key
11 Internal
camera
(Optional)
12 Battery cover
1
2
3
45
6
7
11
12
13
14
15 16
8
9
10
Introduction
5
13 Speaker 14 Main camera 15 Charger
connector /
Cable
connector /
Headset jack
16 Power Key
Send Key • Make or answer a call.
• Access the Calls screen in standby mode.
OK Key Confirm a selection.
End Key • End an ongoing call or reject an incoming call.
• Return to the standby mode.
Camera
Key
Activate the camera in standby mode when the
screen is unlocked.
Shortcut
key
Activate the corresponding application in standby
mode when the screen is unlocked.
Power Key • Press and hold it to power on or power off the
phone.
• Press it to lock or unlock the touch screen.
6
Introduction
Home Screen
The phone is currently
in the HSDPA
network.
The phone is currently in
the GSM network.
The phone is currently
in the WCDMA
network.
You are using the
Roaming Service.
Call in progress. Alarm clock is enabled.
Bluetooth is enabled. Bluetooth connection is
being set up with another
device.
Icon bar
Tap it to access Widget Bar
Tap it to access the browser
Desktop
Tap it to access Contacts
Tap it to access the dialer
Tap it to access main menu
Introduction
7
Using the Touch Screen
You can select an item or enter text by tapping the touch screen.
NOTE:
• Tap the icon accurately to select an item.
• Tap gently to protect your touch screen.
• When the screen is locked, press the power key to unlock the touch
screen.
• When the screen is locked, press the send key, the OK key or the end
key to wake up the screen, and then unlock the screen by pressing
and holding the icon according to the instructions on screen.
Calibrating the Touch Screen
When operating the phone, if the phone cannot respond to your operation
correctly, calibrate the screen as follows.
You have new text
messages.
You have new multimedia
messages.
You have new Emails. The headset is
connected.
Memory card is
inserted.
Indicates power level of
the battery.
8
Introduction
1. Select Settings> Touch settings> Calibration to access the screen
for calibration.
2. Calibrate the screen by tapping the center of calibration frame
displayed on the screen according to the instructions.
NOTE: During the calibration, tap the center of calibration frame accu-
rately to ensure that the phone can respond to your tapping and text entry
correctly after the calibration.
Dragging and Flicking
On the following screens, you can perform certain operations conveniently
through dragging on the touch screen.
• On the standby screen, tap and drag the profile to change the position
of the selected item.
• On the standby screen, tap and drag the widgets to change the posi-
tion of the selected item.
• In the menu list, drag up or down to scroll. Then tap a submenu to
select it.
• When viewing pictures, flick right or left to switch a picture to the next
or previous one.
