HTC One (E8) Manuel utilisateur

HTC One (E8)

User guide

HTC Confidential 20140625

For Certification Only

Conventions used in this guide

In this user guide, we use the following symbols to indicate useful and important

information:

This is a note. A note often gives additional information, such as what happens

when you choose to do or not to do a certain action. A note also provides

information that may only be applicable to some situations.

This is a tip. A tip gives you an alternative way to do a particular step or procedure,

or lets you know of an option that you may find helpful.

This indicates important information that you need in order to accomplish a certain

task or to get a feature to work properly.

This provides safety precaution information, that is, information that you need to be

careful about to prevent potential problems.

7 Conventions used in this guide

HTC Confidential 20140625

For Certification Only

Important note on recoverable data

Files and other data that have been deleted, cleared, removed, or erased from

your device may still be recoverable by third-party data recovery software.

Even a factory reset may not permanently erase all data from your phone,

including personal information.

8 Important note on recoverable data

Important RF Notice

This device was tested for compliance with the applicable FCC and Industry

Canada specific absorption rate (SAR) limits for radio frequency (RF)

exposure during typical body-worn operations. To ensure that RF exposure

levels remain at or below the tested levels, use a belt-clip, holster, or similar

accessory that maintains a minimum separation distance of 1.0 cm between

your body and the device, with either the front or back of the device facing

towards your body. Such accessories should not contain any metallic

components. Body-worn accessories that do not meet these specifications

may not ensure compliance with applicable SAR limits and their use should be

avoided.

HTC Confidential 20140625

For Certification Only

Unboxing

HTC One (E8)

1. USB connector

2. 3.5mm headset jack

3. Dual speakers

4. VOLUME

5. microSD™card tray with eject

hole

6. Proximity sensor

7. Front camera

8. Notification LED

9. POWER

10. nano SIM card tray with eject hole

If you want to use a case, please don’t cover and block the proximity sensor.

Purchase a case designed for HTC One (E8).

9 Unboxing

HTC Confidential 20140625

For Certification Only

Back panel

1. LED flash

2. Camera

10 Unboxing

HTC Confidential 20140625

For Certification Only

nano SIM card

HTC One (E8) uses a nano SIM card.

You need a provisioned nano SIM card to connect to the mobile_operator 4G/LTE™

network and to support roaming on compatible GSM networks. The nano SIM card is

preinstalled on HTC One (E8). If you need to remove or replace the card, refer to the

following instructions.

Use a standard nano SIM card only. Inserting a modified card that is thicker than the

standard nano SIM card may cause the card to not fit properly or damage the card

slot.

Inserting a nano SIM card

1. Hold the phone face up.

2. Insert the tip of the tray eject tool (or a small bent paperclip) into the tray eject

hole next to the nano SIM card slot.

3. Push the tip all the way into the hole until the card tray ejects.

4. Pull the card tray out.

5. Place the nano SIM card (contacts facing down) into the tray.

6. Insert the card tray back into the slot.

11 Unboxing

HTC Confidential 20140625

For Certification Only

Removing a nano SIM card

Make sure to switch off HTC One (E8) before removing the card.

1. Hold the phone face up and the top panel facing you.

2. Insert the tip of the tray eject tool (or a small bent paperclip) into the tray eject

hole next to the nano SIM card slot.

3. Push the tip all the way into the hole until the card tray ejects.

4. Pull the card tray out, and remove the nano SIM card.

5. Make sure that you insert the empty card tray back into the slot.

Storage card

Use a storage card to store your photos, videos, and music. When you need to free up

phone storage space, you can also move certain apps to the storage card, if the apps

support this feature.

The storage card is optional and sold separately.

§Moving apps to the storage card doesn't back up the apps. If you do a factory

reset, your phone loses the apps. You'll need to reinstall them.

§When you remove the storage card and insert it in another phone, the apps on the

storage card won't be installed automatically to the other phone. You'll need to

reinstall them.

12 Unboxing

HTC Confidential 20140625

For Certification Only

Inserting the microSD card

1. Hold the phone face up.

2. Insert the tip of the tray eject tool (or a small bent paperclip) into the tray eject

hole next to the microSD card slot.

3. Push the tip all the way into the hole until the microSD card tray ejects.

4. Pull the microSD card tray out, and place the microSD card (contacts facing

down) into the tray.

5. Insert the microSD card tray back into the slot.

Unmounting the storage card

When you need to remove the storage card while HTC One (E8) is on, unmount the

storage card first to prevent corrupting or damaging the files in the storage card.

1. Go to Settings, and then tap Storage.

2. Tap Unmount SD card.

13 Unboxing

HTC Confidential 20140625

For Certification Only

Removing the microSD card

Make sure to unmount your microSD card before removing it.

1. Hold the phone face up and the top panel facing you.

2. Insert the tip of the tray eject tool (or a small bent paperclip) into the tray eject

hole next to the microSD card slot.

3. Push the tip all the way into the hole until the microSD card tray ejects.

4. Pull the microSD card tray out, and remove the microSD card.

After removing the microSD card, make sure that you insert the empty microSD card

tray back into the slot.

14 Unboxing

HTC Confidential 20140625

For Certification Only

Charging the battery

Before you turn on and start using HTC One (E8), it is recommended that you charge

the battery.

Use only the adapter and the USB cable that came with HTC One (E8) to charge

the battery. When the battery power is too low, make sure to use the power

adapter to charge, not the USB cable connection with your computer.

1. Insert the small end of the USB cable into the USB connector.

2. Insert the other end of the USB cable into the power adapter.

3. Plug in the power adapter to an electrical outlet to start charging the battery.

§As a safety precaution, the battery may stop charging to avoid overheating.

§When you're using the Internet and charging the battery, HTC One (E8) may

become warmer. This is normal.

§To conserve energy, unplug the power adapter from the electrical outlet after you

finish charging.

Switching the power on or off

Switching the power on

Press the POWER button until HTC One (E8) vibrates.

When you turn on HTC One (E8) for the first time, you’ll need to set it up.

Switching the power off

1. If the display is off, press the POWER button to turn it back on. If you've set up

a lock screen, you need to unlock it.

2. Press and hold the POWER button for a few seconds.

3. Tap Power off on the options menu.

15 Unboxing

HTC Confidential 20140625

For Certification Only
