Smart Phone

Quick Start Guide

1. What’s in the Box?

Battery

Getting Started CD

Phone

AC Adapter

USB Cable

Headset User Manual and

Quick Start Guide

Pouch

2. Your Phone at a Glance

1. Speaker

Listen to a phone call.

Display Screen

3. Left SOFT KEY

Press to perform the command shown in

the label above the button.

4. TALK

Press to dial a phone number, answer a call,

switch to another call, or put a call on hold.

Hold to activate/deactivate loudspeaker

mode

5. LED Indicators

The top LED indicators (green/red/amber)

notify you of the battery and network

status of your phone respectively, while

the bottom indicators (blue/green) notify

you of Bluetooth and Wi-Fi connectivity

status. For more information about LED

Indicators, see the

table at the end of this

section.

6. NAVIGATION

CONTROL/

ENTER

Use to scroll left, right, up, or down. Press

the center to use as the ENTER button.

Right

SOFT KEY

Press to perform the command shown in

the label above the button.

8. END

Press to end a call, or press and hold to

lock the phone.

9. HOME

Press to go to the Home Screen.

10. QWERTY Keyboard

This is similar to a standard keyboard

on a PC.

11.

Key

Press to let you type symbols

(characters in blue) and enter numbers

in text fields.

12.

Key

Press to type a single capital letter.

Press the FN key and this key to type

in all caps.

13. Microphone

Speak into the microphone when

receiving or making a phone call or

voice recording.

14.

Key

Press to open the Symbol table. Press

FN key then this key to open the

Camera program.

15.

Key

Press to open Internet Explorer

Mobile.

16.

Key

Press to open the Messaging program.

17. BACK

Press to go to the previous screen, or

backspace over characters.

1413

18. POWER

Press to turn on and off the

phone. Or press and quickly

release the Power button to

display the Quick List.

19. Camera Lens

20. Self-Portrait

Mirror

Turn the back side of your

device to face yourself so that

your image reflects on the

mirror when taking self-portrait

shots.

21. Back Cover

Remove to insert battery, SIM

card and Micro SD card.

22. Speakers

Listen to audio media or a

phone call.

23. JOGGR

Depending on the selected

JOGGR function, scroll up or

down to adjust the volume

when using the phone or to go

through the items on-screen.

Click

Start

Settings

JOGGR

to set what function the JOGGR

will be used for. Clear the

Enable JOGGR

box to disable

the JOGGR.

24.

Sync Connector/

Earphone Jack

Use for synchronizing data

or recharging the battery.

Pry open the rubber cover

(from the left) to connect the

earphone to listen to audio

media or use the phone’s

hands-free kit.

20 21 22

18 23

LED indicator lights

Various colors that might display in the two LED Indicators are summarized here.

Top LED Status

Solid green

Battery is fully charged.

Blank

Battery case is empty, no SIM card inserted or phone is off.

Solid amber

Battery is charging or the phone is using ActiveSync to synchronize with a PC.

Solid red

Battery is not installed or battery is over-discharged.

Flashing green

Connected to the network.

Flashing red

Battery very low (less than 10%)

Flashing amber

Battery temperature is hotter or colder than the functional limits of 0 to 48 degrees

Celsius (32 to 118 degrees Fahrenheit), and has stopped charging.

Amber/Green LED off

Battery fault. The “Battery Fault” indicator

(

Battery fault. The “Battery Fault” indicator

) is displayed. In this case, the flashing green LED can be recovered by

unplugging the AC adapter.

Dim

Disconnected from the network.

Bottom LED Status

Flashing blue

Bluetooth mode set to “On” or “Visible” mode.

Flashing green

Connected to Wi-Fi network.

3. Setting Up Your Phone

1 Install the SIM card

Open the cover and remove the battery

Hold the phone in one hand with the

keypad facing down in the palm of your

hand. With your other hand, press down on

the back cover and slide it open.

Remove the battery by lifting it up from

the bottom end.

Insert the SIM card

•

Insert the SIM card into the slot at the top-left corner with its gold-plated contacts facing

down. Push the SIM card all the way in until the SIM card locks into place.

•

To remove the SIM card, slightly lift up the end of the SIM card (the SIM card will pop out

a little) then slide the SIM card out of the slot.

Insert SIM card

Remove SIM card

2 Install the Micro SD card

You can install a Micro SD (Secure Digital) card in your phone to have an alternative storage place

for your images, video, music, and other phone data.

Remove the back cover of the phone.

Insert the Micro SD card into the slot with its

gold contacts facing down.

To remove, press the Micro SD card to pop it

out of the slot.

3 Install and charge the battery

New batteries are shipped partially charged. Before you can use your phone, you need to install

and charge the battery. To install the battery, remove the battery cover first, and then insert the

battery by aligning the exposed copper part of the battery pack with the protruding copper

conductor of the battery slot. Insert the top side of the battery first, then gently push the battery

into place, and replace the battery cover.

Some batteries perform best after several full charge/discharge cycles. You can charge the battery

in two ways:

•

Connect your phone directly to an electrical outlet using the AC adapter.

•

Connect your phone to the USB port on your PC using the USB cable.

4 Turn on your phone

Press and hold the POWER button on left side of the phone to turn on the phone.

5 Install ActiveSync

ActiveSync synchronizes information between your phone and your PC, keeping information

up to date in both devices. Before you connect your phone to your PC, you must install

ActiveSync on the PC. ActiveSync is already installed on your phone.

Insert the Getting Started CD into the CD drive of your PC.

Follow the instructions on the installation wizard screen to install ActiveSync.

Connect the USB cable to the phone and plug it into the USB port of your PC.

Turn on your phone. When the PC detects a USB connection, it starts the ActiveSync

Synchronization Setup Wizard. Follow the instructions on the screen and select the

items you want to synchronize.

6 Make your first phone call

Before you make a phone call, ensure that a SIM card is installed and the battery is sufficiently

charged.

•

To make a call, enter the phone number and press TALK

(

)

•

To end a call, press END

(

)

4. Setting Up an E-mail Account

Your phone can be set up to retrieve e-mails from Outlook e-mail, POP3 and IMAP4 accounts.

However, you need to set up your e-mail account with an Internet service provider (ISP) or an

account that you access using a VPN server connection (typically a work account) before you can

send and receive mail.

To set up a POP3/IMAP4 e-mail account

On the Home screen, click

Start

Messaging

and select

Outlook E-Mail

Click

Options

New Account

Your name

, enter your display name for e-mail messages.

E-mail address

, enter the e-mail address for this account.

Select

Attempt to obtain e-mail settings from the Internet

and click

Auto Setup will help you download necessary e-mail server settings. When completed,

click

Finish

To send an e-mail or SMS message

On the Home screen, click

Start

Messaging

Select an e-mail account or select Text Messages then click

Select

Click

New

Enter the e-mail address or phone number of one or more recipients, separating them

with a semicolon (;). To access addresses and phone numbers from Contacts, in

press ENTER and select a recipient from the list.

Enter your e-mail or message then click

Send
