HPE Ethernet 10Gb 2-port 561T Adapter
User Guide
Part Number: 728509-002
Published: May 2019
Edition: 2
Abstract
This document is for the person who installs, administers, and troubleshoots servers and
storage systems. Hewlett Packard Enterprise assumes you are qualified in the servicing of
computer equipment and trained in recognizing hazards in products with hazardous energy
levels.
© Copyright 2013, 2019 Hewlett Packard Enterprise Development LP
Notices
The information contained herein is subject to change without notice. The only warranties for Hewlett
Packard Enterprise products and services are set forth in the express warranty statements accompanying
such products and services. Nothing herein should be construed as constituting an additional warranty.
Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained
herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession,
use, or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer
Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government
under vendor's standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard
Enterprise website.
Acknowledgments
Intel®, Itanium®, Pentium®, Xeon®, Intel Inside®, and the Intel Inside logo are trademarks of Intel
Corporation in the U.S. and other countries.
Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated.
Java® and Oracle® are registered trademarks of Oracle and/or its affiliates.
UNIX® is a registered trademark of The Open Group.
Contents
Technician notes..................................................................................... 4
Warnings, cautions, and notes......................................................................................................4
Downloading files..........................................................................................................................5
Introduction............................................................................................. 6
Overview....................................................................................................................................... 6
UTP Cat 6 and Cat 6A cable use..................................................................................................6
LEDs............................................................................................................................................. 6
Installing an adapter............................................................................... 8
Installation overview......................................................................................................................8
Installing an adapter in a server....................................................................................................8
Installing a low-profile bracket.......................................................................................................9
Connecting the network cable.......................................................................................................9
Specifications........................................................................................10
UTP cable specifications.............................................................................................................10
General specifications.................................................................................................................10
Compliance................................................................................................................................. 11
Power and environmental specifications.....................................................................................12
Electrostatic discharge.........................................................................13
Preventing electrostatic discharge.............................................................................................. 13
Grounding methods to prevent electrostatic discharge...............................................................13
Websites................................................................................................ 14
Support and other resources...............................................................15
Accessing Hewlett Packard Enterprise Support......................................................................... 15
Accessing updates......................................................................................................................15
Customer self repair....................................................................................................................16
Remote support.......................................................................................................................... 16
Warranty information...................................................................................................................16
Regulatory information................................................................................................................17
Documentation feedback............................................................................................................ 17
Acronyms and abbreviations...............................................................18
3
Technician notes
Warnings, cautions, and notes
WARNING: Only authorized technicians trained by Hewlett Packard Enterprise should attempt to
repair this equipment. All troubleshooting and repair procedures are detailed to allow only
subassembly/module-level repair. Because of the complexity of the individual boards and
subassemblies, no one should attempt to make repairs at the component level or to make
modifications to any printed wiring board. Improper repairs can create a safety hazard.
WARNING: To reduce the risk of electric shock, personal injury, and damage to the equipment:
• Do not attempt to service any parts of the equipment other than those specified in the following
procedure. Any other activities may require that you shut down the server and remove the power
cord.
• Installation and maintenance of this product must be performed by individuals who are
knowledgeable about the procedures, precautions and hazards associated with the product.
WARNING: To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
This symbol indicates the presence of a hot surface or hot component. If this surface is
contacted, the potential for injury exists.
WARNING: To reduce the risk of injury from a hot component, allow the surface to cool
before touching.
CAUTION: To properly ventilate the system, you must provide at least 7.6 cm (3.0 in) of clearance
at the front and back of the server.
CAUTION: The server is designed to be electrically grounded (earthed). To ensure proper
operation, plug the AC power cord into a properly grounded AC outlet only.
NOTE: Any indications of component replacement or printed wiring board modifications might void any
warranty.
4 Technician notes
Downloading files
Procedure
1. Go to the Hewlett Packard Enterprise website.
2. Enter your user ID and password, and then click Sign in.
NOTE: If you do not have a user ID and password, click Create an account and follow the on-screen
instructions.
3. Enter the adapter name into the Products, software, drivers, documents... search field.
For example, enter HPE Ethernet 562T adapter.
Results with the potential match for the adapter you enter appear.
4. From the search results list, do one of the following:
• Click Drivers & Software for the desired adapter.
◦ Select the Operating environment for the product to download drivers and firmware as needed.
IMPORTANT: Filtering the results by Operating environment narrows down the list of
results that display. You can further filter the results by Software type and Driver
language.
• Click Documents for the desired adapter.
NOTE: You can further filter the results by Document type, Document details, Operating
environment, Language, and Relevance.
Technician notes 5
Introduction
Overview
The HPE Ethernet 10Gb 2-port 561T Adapter is a dual-port, 10GBASE-T stand-up NIC card for ML/DL/SL
ProLiant servers that uses the Intel X540 chipset. The adapter is available both built-to-order and
configure-to-order for Gen8 platforms. The Ethernet 10Gb 2-port 561T Adapter includes these advanced
server features:
• SR-IOV support for Windows, Linux, and VMware
The server must have ROM support for SR-IOV and the operating system must support SR-IOV to use
the feature.
• Sea of sensors for temperature monitoring of the device for optimized server power consumption
• Active Health Systems support for Gen8 devices using network-provided information
• Firmware upgrades without being taken offline (reboot to apply changes)
• Copper-based 1/10Gb compatibility for existing RJ-45 infrastructures
For more information about the Ethernet 10Gb 2-port 561T Adapter, see the Hewlett Packard Enterprise
website (http://www.hpe.com/info/proliantnics).
UTP Cat 6 and Cat 6A cable use
The Ethernet 10Gb 2-port 561T Adapter can use existing UTP Cat 6 (or better) cable. Hewlett Packard
Enterprise recommends Cat 6A cable for new installations. For troubleshooting and other information
about cabling, see "UTP cable specifications."
LEDs
The Ethernet 10Gb 2-port 561T Adapter has two ports with LEDs for Link (L) and Activity (A) for each
port. A standard-height bracket is shown in the following illustration with ports and LEDs.
6 Introduction
Item LED Description
1 Link Off
No link to the adapter is established. The adapter is
not receiving power or the cable connection is
faulty.
Amber: A link to the adapter is established at 1
Gb/s or 100 Mb/s. The adapter is receiving power
and the cable connection is good. 1
2 Activity Off: No network activity exists on the link.
Green: Network activity is on the link. The adapter
is sending or receiving network data at up to 10
Gb/s.
1 100Mb/s is not supported on HP-UX 11iv3
Introduction 7
Installing an adapter
Installation overview
This section describes installation precautions, how to install the adapter, and how to connect the network
cable.
WARNING: To reduce the risk of personal injury or damage to the equipment, consult the safety
information and user documentation provided with the server before attempting the installation.
Some servers contain high energy circuits, high current circuits, moving parts (such as fan blades),
or any combination of these hazards, that may be exposed if covers and access panels are
removed while the product is connected to a power source. These products are intended to be
serviced only by qualified personnel who have been trained to deal with these hazards. Do not
remove enclosures or attempt to bypass any interlocks designed to guard against these hazardous
conditions.
WARNING: Installation of this adapter should be performed by individuals who are both qualified in
the servicing of computer equipment, and trained in the hazards associated with products capable
of producing hazardous energy levels. This adapter is intended to be installed in Certified (UL or
CSA) ITE equipment having instructions for adding and removing user installed components such
as PCI, PCI-X, and PCI Express devices. Refer to the equipment instructions to verify that it is
suitable for user installed components and that it has the power capacity to support all of the
installed components.
NOTE: Before removing the cover of your server, refer to the HPE documentation for the proper methods
for installing a PCI Express card and avoiding electric shock hazards.
Installing an adapter in a server
For additional information on how to safely install a PCI Express card in the server, see the ProLiant
server documentation.
CAUTION: If the server is not PCI Hot Plug compliant, power it down and disconnect the power
cord from the power outlet before removing the server accesspanel. Failure to do so may damage
the adapter or server.
Procedure
1. Power down the server.
2. Remove the power cord and server access panel.
WARNING: To reduce the risk of personal injury from a hot component, allow the surface of the
option card to cool before touching it.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
3. Identify the PCIe expansion slot in which the adapter is to be installed. If a low-profile option slot is to
be used, install the low profile bracket onto the adapter.
4. Remove the expansion slot cover from the PCI Express slot.
8 Installing an adapter
5. Firmly seat the adapter in the PCI Express slot.
NOTE: For 1U type servers, you might need to replace the standard profile bracket with a low profile
bracket. See "Installing a low profile bracket."
6. Install the access panel, and then connect the power cord.
Installing a low-profile bracket
You might have to install a low-profile bracket to complete the product installation. The low-profile bracket
replaces the existing standard profile bracket shipped on the product.
To install a low-profile bracket:
Procedure
1. Remove the standard profile bracket, and then place the low-profile bracket over the connector.
2. Be careful not to damage the connector or bind the low-profile bracket to the connector.
Connecting the network cable
Procedure
1. To secure the cable, plug the cable connector into the RJ-45 port.
2. Ensure that the tab on the plug clicks into position indicating that it is properly seated. For more
information, see UTP cable specifications.
Installing an adapter 9
Specifications
UTP cable specifications
The Ethernet 10Gb 2-port 561T Adapter can deliver 10 gigabit Ethernet over an existing UTP Cat 6
copper cable, or better, according to the IEEE 802.3an specifications. Hewlett Packard Enterprise
recommends Cat 6A cable for new installations.
Cable distances:
• 10GBASE-T: 55m on Cat 6; 100m on Cat 6A
• 1000BASE-T: 100m on Cat 5e, Cat 6, or Cat 6A
To connect to the network, the Ethernet 10Gb 2-port 561T Adapter uses the following cable for
10GBASE-T transmission:
• Cat 6 (or better) UTP
• 22-26 AWG, 100 ohm at 1 MHz
• EIA/TIA 568-B.2-10b
General specifications
Specification Value
Controller Intel X540 chipset
Data rate 10 Gb/s per port, 20 Gb/s per port, full-duplex
PCI bus PCI Express 2.1, x8
Connectors Two 10GBASE-T (RJ-45)
Sea of sensors On chip temperature sensor
Dimensions (LxW) 15.5 cm x 6.4 cm (6.1 inches x 2.5 inches) without
bracket
10 Specifications
Table des matières
Autres manuels HPE Adaptateur
