8Installing Microsoft Windows Server

2003

This chapter is a supplement to the HP Server tc2120 Network Operating System

Installation Guide (HP part number312977-001) that came with your server and

provides instructions for installing Microsoft Windows Server 2003 (formerly

known as "Windows .NET").

High Level Process Flow

?? Perform Windows Server 2003 Server Installation.

?? Completing the Installation (HP drivers, Recovery Console).

?? Configure the System.

?? Configure the Network.

?? Additional HP accessories.

Prepare the Installation

Please refer to the Chapter 1 "Preparing your HP Server tc2120 for your NOS

installation" for our recommendations on server preparation.

Then gather the following material:

?? HP Server tc2120 Startup CD

?? Microsoft Windows Server 2003 CD-ROM.

?? Up to three blank, formatted 3.5-inch diskettes

?? Two or more clients for testing purpose (Optional)

NOTE Disable SCSI Support Before Using ATA RAID Controller if

present. Due to system resource limitations, the Promise

FastTrak100 TX2 IDE RAID controller is not compatible with

systems having SCSI capabilities. (The ATA and SCSI

functionality cannot operate simultaneously). You must

disable SCSI support in Setup before you can use the RAID

controller. To disable SCSI support, follow these steps:

1. Remove any installed SCSI HBA cards from the PCI slots.

Chapter 8InstallingMicrosoft Windows Server 2003

2. Install the ATA RAID controller into PCI slot 1 and connect the IDE drives.

3. Turn on the system.

4. Press F10 to enter Setup.

5. Select Bootfrom the menu.

6. Select Boot Device Priority.

7. Select SCSI Hard Drive and press Enter.

8. Select Promise Fast Track Raid Controller \HDD 0 and press Enter.

9. Press F6 to Save and Exit. Your system is now ready to use the ATA RAID

controller, but SCSI devices will not be functional.

10. On boot, pressCrtl-Fto enter the IDE RAID Configuration Utility and

configure the IDE array as usual. Please refer to the Fast Track 100

Reference guide off ofhttp://www.promise.com/ for additional information

on array configuration.

Section 1. Create the Drivers Diskettes

1. Insert a blank, formatted 3.5" diskette into a the floppy drive of a PC running

Microsoft Windows.

2. Insert your HP Startup CD into the PC's CD-ROM drive and follow the on-

screen instructions to create the appropriate Windows Server 2003 drivers

diskette.

NOTE If the Windows PC does not auto-start the Startup menu, start it

by opening Startup.htm found at the root level of the

Startup CD.

Section 2. Perform Windows Server 2003

Installation

1. Boot your new server from the Windows Server 2003 CD-ROM.

2. You will see a message that reads, "Setup is inspecting your

hardware configuration". The setup screen will be displayed.

3. The system will briefly show at the bottom of the display "Press F6 if

you need to install a third party SCSI or RAID

controller".

Chapter 8InstallingMicrosoft Windows Server 2003

NOTE Unfortunately, the Windows Server 2003 setup only gives you

a very short time to pressF6. If you missed it, you will need to

reboot your system and resume from step 1 above.

4. If you are installing to the Promise FastTrak100 TX2 IDE RAID card do the

following, if not skip to step 5:

a. Press Sto specify additional IDE adapters.

b. When prompted,insert the Promise IDE RAID driver diskette you created

from the tc2120 startup CD.

c. Press Enter to continue.

d. Select the Promise FastTrack100 TX2™ Controller adapter, and then

press Enter.

5. If you are installing the Adaptec SCSI RAID 2100S card do the following, if

not skip to step 6:

a. Press Sto specify additional adapters.

b. When prompted, insert the SCSI RAID driver diskette you created from

the tc2120 startup CD.

c. Press Enter to continue.

d. Select the Adaptec I2O RAID Host Adapters, and then pressEnter.

6. If you are installing to the Adaptec 29160 PCI card do the following, if not

skip to step 7:

a. Press Sto specify additional adapters.

b. When prompted, insert the AHA 29160 driver diskette you created from

the tc2120 startup CD.

c. Press Enter to continue.

d. Select the Adaptec Ultra160 Family PCI SCSI Controller, and then press

Enter.

7. Press Enter to continue at the "Windows Server 2003 Setup-Welcome to

Setup" Screen.

8. Press F8 to accept the licensing agreement.

9. At the drives partitioning screen, select the target drive. If you want to use

the entire drive to install Windows Server 2003 then pressEnter. Otherwise,

press Cto create a partition.

In this example we will create a 4GB partition.

Chapter 8InstallingMicrosoft Windows Server 2003

a. Press Cto create a partition.

b. At the "Create partition size" prompt, type 4096 and press Enter.

c. HP recommends that you create all the partitions needed for each hard

drive present on your system. Select unpartitioned space and pressC

again to create additional partitions.

10. Select the target drive to be used to install Windows Server 2003. Press

Enter.

11. Select "Format the partition using the NTFS file

system" and pressEnter.

12. The installer will format and copy files to the hard drive.

13. The system will reboot and launch the Windows Server 2003 graphical

interface. Be sure to remove any driver diskette before the system reboots.

14. You can now proceed through the customization of your installation using

the graphical interface.

NOTE The network settings may need to be customized to your

environment. Please refer to Microsoft Server 2003 manuals

should you need further details on the networking settings.

15. The "Installing Windows" screen starts with a progress bar. It may take up to

20 minutes to complete this section.

16. The wizard will then automatically start the "Finalizing installation" section

to complete the install. This step in the installation may take some time as

well.

NOTE There may be a period of time with no apparent activity at the

"Saving Settings" prompt. Please be patient.

17. After the installation is complete, the system will automatically reboot from

the hard drive.

18. Follow the on screen instructions to logon (pressCtrl-Alt-Del) as

Administrator.

19. The initial logon will automatically launch the "Manage Your Server" screen.

Close this window, as we will postpone the customization of your server

until completion of all the installation steps.

Chapter 8InstallingMicrosoft Windows Server 2003

NOTE You may open the "Manage Your Server" wizard at any point

in time by clicking Start | Programs | Administrative Tools |

Manage Your Server.

Section 3. Completing the Installation

PHASE 1–Install HP supported driver(s)

During the Windows Server 2003 installation, the OS may not install the most

current HP supported drivers.The following procedure will help you to

install/update the driver(s) using the HP Startup CD.

An Example of installing the Promise FastTrak100 TX2 IDE RAID driver

1. Insert the HP tc2120 Startup CD in your new server. If CD-ROM auto-start

is enabled, a menu will display. You may close this menu.

2. Open Start | Control Panel | System | Hardware | Device Manager.

3. Open the yellow question marked "Other Devices" tree and double-click

on the appropriate "RAID Controller" to display its menu.

4. From the "RAID Controller Properties" dialog box, click the

Driver tab then Update Driver to open the Update Device Driver Wizard.

Click Next.

5. At the prompt "What do you want the wizard to do?" select

"Install the software automatically", and clickNext.

6. Wait for the system to find the appropriate driver,and then click Next.

7. Click Finishonce the IDE RAID driver has been loaded.

8. Exit all open windows and restart your computer in order to properly

initialize the RAID adapter, if necessary.

9. After restarting Windows .NET, configure the IDE RAID Hard Drives. (See

Section 4, Phase 2 -Initialize Hard Disk Drive).

An example of installing the embedded Compaq NC7760 Gigabit Server Adapter

driver

1. Insert one blank, formatted 3.5" diskette into a workstation's floppy drive.

2. Insert the HP tc2120 Startup CD in your new server to create the Windows

Server 2003 drivers diskette for the embedded Compaq NC7760 Gigabit

Server adapter. If CD-ROM auto-start is enabled, a menu will display and

Chapter 8InstallingMicrosoft Windows Server 2003

follow the on-screen instructions to create the Windows Server 2003

embedded NIC drivers diskette.

3. After creating the drivers diskette, remove the HP tc2120 Startup CD.

4. Open Start | Control Panel | System | Hardware | Device Manager.

5. Open the "Network Adapters" tree and double click on the "BCM5703

Gigabit Ethernet Adapter" to display its menu.

6. From the "BCm5703 Gigabit Ethernet Properties" dialog box, click the

Driver tab then Update Driver to open the Update Device Driver Wizard.

Click Next.

7. Select to "Install from a list or specific location (advanced)." Click Next.

8. Select "Don't Search. I will choose the driver to install." Click Next.

9. Click on Have Disk.

10. Ensure A: is listed in the text box. Click OK.

11. Select Open to open the .inf file.

12. The Compaq NC7760 Gigabit Server Adapter should be detected, click Next.

NOTE If a message appears stating that this driver has not passed the

Windows logo-testing, click continue anyway.

PHASE 2–Install Windows Server 2003 Recovery Console

Please refer to Tip#2in the Troubleshooting section.

Section 4. Configure the System

PHASE1–Perform Hardware Status Check

In this section you will run the Windows Device Manager tool to identify any

issues with the installed devices or resource conflicts.

1. Open Start | Control Panel | System | Hardware | Device Manager.

2. Verify that no devices have either a yellow band (!) or question mark (?)

symbol next to it.

oYellow (!) means that there is a resource issue with the device.

oQuestion (?) means that the device is unknown.

Chapter 8InstallingMicrosoft Windows Server 2003

If (!) or (?) symbols are reported then double click on each of the devices

with (!) or (?). Use the "Device Status" message for troubleshooting. Or if a

printer is available, use the View, Printfrom the menu to get a report.

3. Verify if the installed drivers are digitally signed.

a. In the Device Manager, select the device (e.g. HP AHA-29160) that

you want to verify.

b. Right click Properties | Driver.

c. Locate the "Digital Signer:" If the driver of that device is not digitally

signed, it will be indicated by the signer. If the driver of the device is not

digitally signed we recommend that you check the HP Website

www.hp.comto install the latest driver package for that device.

4. Exit the Device manager, System Properties and Control Panel applications.

5. Check the Event viewer to make sure that there are no errors in the log.

Click on Start| All Programs | Administrative tools | Event viewer.

NOTE Windows Server 2003 Event Viewer may have recorded

network errors because your network is not configured yet.

Please disregard these errors.

6. Exit event viewer.

PHASE 2 -InitializeHardDiskDrive

NOTE There are two types of hard drive configurations: Dynamic and

Basic. You can select the appropriate type by right clicking on

the disk drive icon. Dynamic drives are used to create volumes,

which can contain more than one physical hard drive. Basic

drives are used to create primary or local partitioned drives.

To manage your different drives and partitions:

1. Click Start | All Programs | Administrative Tools | Computer

Management | Disk Management.

2. The "Write signature and Upgrade" wizard will start if you have new hard

drives with no signatures on them. Follow the on-screen instructions to create

this signature.

3. Click OKto proceed when notified you have a new hard disk to configure.

Chapter 8InstallingMicrosoft Windows Server 2003

4. Right-click to select available hard disk space and use the "New Partition

Wizard" to create and format the additional partitions, if desired.

5. Exit the "Computer Management" tool.

Section 5. Configure the Network

PHASE 1-- Configure Server IP Address

During the installation process the system was configured to use DHCP. If no

DHCP server is found on the network the system will auto-configure a random IP

address to start functioning. It is important that you configure the proper IP

address to be able to communicate with the clients:

1. Click Start | Control Panel | Network Connections | Local Area

Connection on your HP server.

NOTE If your HP server hosts several Network adapters, the window

will show one "Local Area Connection" icon for each Network

adapter present in the system. Identify the proper adapter by

browsing each one.

2. Click Internet Protocol (TCP/IP) | Properties | Use the following IP

address.

3. Enter an appropriate IP address.

4. Click the OKto continue, and thenOKagain to exit the "Local Area

Connection Properties" window.

PHASE 2-- AttachClientstoNetworkandTestNetworkLink

1. Create shares: create a folder on your HP server hard drive then share it (right

click Sharing).

2. Create users using the Windows Server 2003 Computer Management utility:

Start | Programs | Administrative Tools | Computer Management |

System tools | Local Users and Groups | Users.

3. Connect clients PC to the network your HP server operates on.

4. Open a command prompt window to verify the TCP/IP configuration and

enter the command:

ipconfig /all

5. To verify the server and clients can communicate properly:

Chapter 8InstallingMicrosoft Windows Server 2003

a. From one of the clients, open a command prompt and type:

ping computername

where computername is the server name you entered during the Windows

installation. You should get four replies from your new server. If there is

a link problem it must be fixed before going any further.

You may test the link further by doing a ping between two clients. At the

same command prompt, type:

ping other_client_IPaddress

Where other_client_Ipaddress is the IP address of another client

pc on this network.

You should get four replies from the second client.

b. Copy files back and forth from the clients to the server.

PHASE 3-- Domain Controller Setup

In order to promote your server to a domain controller, proceed with the

following:

1. Click Start | Administrative Tools | Manage Your Server to open the

"Manage Your Server" window.

2. Select "Add or remove a role".

3. Windows will advise you of preliminary steps to take before proceeding with

Server configuration.

4. Click Nextto continue.

5. From the "Server Role" menu select "Domain Controller (Active

Directory). Click "Next" to continue.

6. At the "Summary of Selections" screen, click "Next" to continue onto the

"Active Directory Installation Wizard". Click "Next" to begin.

7. Click Nextat the "Operating Systems Compatibility".

NOTE The following instructions correspond to the standard steps for

new domain creation. You may customize the options proposed

by Windows Server 2003 to match your networked

environment.

Chapter 8InstallingMicrosoft Windows Server 2003

8. Click Next at the "Domain Controller Type" screen to accept the default:

"Domain Controller for a new Domain".

9. Click Nextat the "Create a New Domain" screen to accept the default:

"Domain in a new forest".

10. If the current network does not contain a DNS server, choose "No, just install

and configure DNS on this computer", click Nextto continue.

11. At the text box for "Full DNS name for new domain:" type in the assigned

DNS name for your server (for example: mycompany.com).

12. Click Next. The system may take a few minutes before moving to the next

screen.

13. Click Nextat the "NetBIOS Domain Name" dialog box to accept the default

"Domain NetBIOS name:"

14. Click Nextto accept the "Database and Log Locations" default

directories.

15. Click Nextto accept the default "Shared System Volume".

16. Click Nextto accept the default permissions: "Permissions compatible only

with Windows 2000 or Windows Server 2003 operating systems".

17. Enter and confirm the Administrator password and click Next.

18. Review the "Summary" display and clickNext to continue.

19. The system will start configuring the active directory and DNS services, if

chosen. It will take a few minutes to complete.

20. If prompted, insert the Windows Server 2003 CD-ROM and clickOK to

continue.

21. Configuring active directory display shows again. Click Finishto close the

Wizard utility. This completes the active directory installation.

22. Click "Restart Now" to reboot the system. Remove the CD-ROM if

present.

23. At the login prompt, type in the password. Click the Options button and

verify that the "Log on to: HOST" appears on the dialog box. Click OK to

start the logon process.

24. "This Server is Now a Domain Controller" dialog box will

appear after the login, click Finishto close.

Autres manuels pour Tc2120 - Server - 256 MB RAM

Table des matières

Autres manuels HP Serveur

HP LC2000r - NetServer - 128 MB RAM Manuel utilisateur

HP ML530 - ProLiant - 128 MB RAM Instructions d'utilisation et de sécurité

HP LP 1000r Manuel utilisateur

HP ProLiant DL280 Manuel utilisateur

HP P4522A - Traffic Management Server Sa8220 Manuel utilisateur

HP ProLiant DL380 G3 Instructions d'utilisation

HP ProLiant DL360p G8 Instructions de montage

HP ProLiant BL460c Gen9 Manuel utilisateur

HP NetServer LH 6000 Manuel utilisateur

HP ProCurve 6120G/XG Mode d’emploi

HP Sa3110 - VPN Server Appliance Comment utiliser

HP ProLiant XL730f Gen9 Server Instructions d'utilisation

HP SimpliVity 380 Gen9 Manuel du produit

HP Integrity rx4610 Manuel utilisateur

HP t820 Manuel utilisateur

HP 4410t - Mobile Thin Client Manuel

HP HPE SimpliVity 380 Gen10 Manuel du produit

HP rp7440 Manuel utilisateur

HP ProLiant DL160se - G6 Server Manuel de référence

HP ProLiant DL385 Generation 2 (G2) Instructions d'utilisation

HP DL380 Generation 4 Manuel

HP 3020 Mode d’emploi

HP cc2300 Manuel utilisateur

HP ProLiant DL160 Gen8 Manuel

Manuels Serveur populaires d'autres marques

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

Milestone

Milestone Husky IVO 350T Manuel utilisateur

Planet

Planet NAS-7410 Manuel utilisateur

Lenovo

Lenovo ThinkSystem SR635 V3 Manuel utilisateur

Dell

Dell PowerEdge HS5610 Manuel
