SAP

Master Configurations

with

HP ProLiant

Servers

Heinrich Gschwandner

SAP Competence

Center Germany

January

2009

The information contained herein is subject to change without notice

Directory 1:

T-shirt

sizings

for

SAP ERP & SAP Business Suite

Subject Slide

Nr.

Directory 2 -

Preface

/ introduction 5 -

Definition of SAP ERP & SAP Business Suite 10 –

SAP ECC 6.0 & Customer

Relationship

Managemtent

/ CRM 2007 13 –

Service Specifications

& Categories

for

SAP ECC 6.0 & CRM 2007 15 –

SAP Business Intelligence

/ BI 7.0 17 –

SAP BI -Accelerator 19 –

SAP Process

Integration / PI 7.1 (before

XI / Exchange Information) 23 –

SAP Enterprise Portal / EP 7.0 25 –

SAP Supplier

Relationship

Management / SRM 5.0 27 –

SAP Supply

Chain Management / SCM ; Advanced

Planer & Optimizer

/ APO 4.1 29 –

Solution Manager 31

Directory Applications Technology Solutions

The information contained herein is subject to change without notice

Directory 2:

Server & StorageWorks

Hardware Technology

Subject Slide

Nr.

Introduction 33

Intel ProLiant

2 Processor

/Socket

Server (Quad

Core) 34

Intel ProLiant

4 Processor

/Socket

Server (Quad

Core) 35

Intel ProLiant

4 Processor

/Socket

Server (Six

Core) 36

AMD ProLiant

2 Prozessor / Socket

Server (Quad

Core) 37

AMD ProLiant

4 Prozessor / Socket

Server (Quad

Core) 38

AMD ProLiant

8 Prozessor / Socket

Server (Quad

Core) 39

StorageWorks

entry

level

–

MSA based 40

StorageWorks

Enterprise Solution (EVA 4400, 6100, 8100) 41 –

HP Storage & Backup Solutions for

business

continuity

& availability 43

Directory Applications Technology Solutions

The information contained herein is subject to change without notice

Directory 3:

HP SAP Landscapes / Solutions

Subject Slide

Nr.

Basic informations

to SAP landscapes 45

ERP cluster

scenario

with

EVA4400 46

ERP cluster

scenario

for

mirrored

data

centers

with

two

EVA8100 47

SAP business

suite with

blades & and EVA4400 48

Virtualized

SAP Landscapes 49

Directory Applications Technology Solutions

The information contained herein is subject to change without notice

Preface

For effective use of this slide set, we strongly recommend to read through the preface!

•

This slide set is primarily intended as a working tool for the SAP Competence Center; providing support for

our partners and customers.

•

Each of the SAP solutions presented is based on two certified HP

ProLiant

servers. These proposals are

intended to provide a general reference only; however, these proposals do not replace customer specific

sizing!

•

Mixing

the

different SAP applications

might

require

different server

& storage

configurations

as proposed

this

guide.

•

This is not a marketing document

to position different HP platforms with regard of SAP configurations –

it is a

tool for daily sales work.

•

For sizing requests

please

contact:

Hewlett-Packard GmbH

SAP Competence Center

Altrottstr. 31

D-69190 Walldorf

Germany

Phone: +49 (0) 170 783 35 25 or

+49 (0) 40 638 08 -

141

e-mail:

[email protected] – German Sizing Account

[email protected]

–EMEA Sizing Account

[email protected] –AMA Sizing Account

Directory Applications Technology Solutions

The information contained herein is subject to change without notice

SAPS

Availability

Proliant

Windows/Linux/Solaris*

IA64 Windows/Linux

IA64/HP-UX

250k

100k

+ RAS

Standard OS

Standard HA

+ SGeSAP

+ WLM

50k

DB Size

5TB

1 TB

20TB

*some

restrictions

apply,….

Preface: Platform

Guide for

SAP Solutions

Directory Applications Technology Solutions

The information contained herein is subject to change without notice

•

Server Design & Performance:

•

The term CPU is equivalent with socket or processors such as a two CPU Quad Core server contains 8 Cores.

•

For availability and performance reasons, HP recommends for SAP ProLiant

servers a minimum configuration of two

processors or sockets.

•

Depending on customer requirements in relation to data throughput (LAN; SAN); memory extension and scalability of

the server it might be advantageously to choose 4-socket servers as they provide more PCI-slots (data throughput) and

memory slots as 2-socket machines.

•

In smaller system landscapes, we offer more powerful server systems than required by SAPS. With Intel Xeon or AMD

Quad Core technology the systems offer huge CPU reserves.

•

Although one CPU might be able to cover system requirements of smaller systems (especially for non productive

environments), we recommend using two CPUs.

•

For clarification –

one 2.0 GHz Quad Core CPU costs about 250€

list price. Also bear in mind that two

CPUs improve server memory addressing and redundancy!

•

The sizes

of the test-

and quality assurance systems are related to the size of the given production system and serve

as a

general guide.

•

The database sizes are based on SAP CC experiences.

•

strongly

recommend

to get

in touch

with

our

StorageWorks

specialists

in our

SAP CC regarding

the

following

topics:

•

Selection

of appropriate

storage

array

SWD All-in-One, storage

blades, MSA, EVA or

even

XP, based

customer

requirements

•

Backup & restore

and availability

concepts

considering

recovery

point, recovery

time and general

availability

•

Consolidation

of backup

and the

various

associated

topics

tape

backup, virtual

tape

libraries, disk-assisted

backup, local

and remote

mirroring

including

cluster

integration

with

CLX or

MetroCluster

•

Value-added

tax (sales

tax) is

not

included

in the

prices (see separate excel worksheet) listed.

Preface

Directory Applications Technology Solutions

12/17/2008

The information contained herein is subject to change without notice

Preface: SAP System Landscapes –

Basics!

•

When running business critical processes on an SAP production system, you have to customize

and develop on a separate SAP system, called the development system. Upon completion of

a change, the change needs to be transferred to a

•

quality assurance system (also called test system), where the changes will be tested with

master data, ported from the production system. When it has been verified that the changes

function correctly, these changes will be ported from the development system to the production

system. Consequently, SAP recommends the implementation of at least three systems in every

SAP project.

•

On big systems, we recommend the additional installation of a lab system

for testing new

software versions and operational concepts. Another critical task handled by the lab system is to

verify if

backups from the production system can be restored, implying that the

database size needs to be the same as that on the production system.

•

If your production system

is deployed on a cluster, SAP strongly recommends

the

installation of a lab

system

which is also operated in a cluster.

•

HP recommends to provide high availability for production systems and to use a cluster generally

for 300 users and above.

Directory Applications Technology Solutions

12/17/2008

The information contained herein is subject to change without notice

Preface: Guideline for HP Services

IT availability

requirements

Business requirements

Proactive 24

Service

Critical

Service

Ensure

high

availability

Increased

effectiveness

Enhanced

support

services

Achievement

business

objectives

through

continual

improvement

of IT

service

quality

Mission Critical

Partnership

99,5 % 99,9 % 99,97 %

98,5 %

Reactive

Services

Emergency

support

Proactive

Services

Mission Critical

Services

20%

80%

Directory Applications Technology Solutions

12/17/2008

The information contained herein is subject to change without notice

SAP ERP –

the

components

•

SAP ERP Central Component

(current

Release ECC

6.0)

−

The

former

SAP R/3 will end in year

2012; the

Netweaver

based

up Bundle

ERP will offer

Service Oriented

Architecture. The

technical

replacement

of SAP R/3

Enterprise is

SAP ECC (Enterprise Central Componets).

•

SAP Business Intelligence

(SAP Netweaver)

•

SAP Enterprise Portal -

(SAP Netweaver)

•

SAP Process

Integration PI

before

(SAP Netweaver)

•

SAP Web Application

Server (SAP Netweaver)

•

SAP Supplier

Relationship

Management -

(only

self-service-procurement

scenario)

•

SAP Strategic

Enterprise Management

•

SAP E-Recruitment

(engine

for

extra listprice)

•

SAP Learning

Solution (engine

for

extra listprice)

•

SAP Financial Supply

Management (engine

for

extra listprice)

•

Employee Self-Services

/ Manager Self-Services

Not part of this solutionmap
