Microsoft Cluster Installation Documentation

for

HP NetServer LPr

with HP Rack Storage/12FC and HP Rack Storage/12

To assist you in installing your HP NetServer Microsoft Cluster, this file contains the documents

listed below in one pdf file.

•Installation Overview - This page provides an overview of the installation steps provided in

the Installation Guide.

•Configuration Guide - This guide provides configuration information specific to your cluster

configuration that you will need during installation of your cluster.

•HP NetServer Microsoft Cluster Installation Guide - This is the first of two documents used

to install the cluster. It covers the installation of all cluster supported HP NetServers and the

cluster software, and references the Shared Storage Supplement for installation and setup of the

shared storage.

•Shared Storage Supplement - This supplement is specific to the shared storage device you are

using and must be used with the installation guide. It provides instructions for installing and

setting up your shared storage devices.

22 February 2000

(See next page)

Version History

22 February 2000 Corrected typographical error in Configuration Guide. Under the heading "SPU"

the No. of CPUs was changed from "2-4" to "2."

8 February 2000 Initial release.

Installing a Cluster

“The Big Picture”

Gathering Hardware,

Software, etc. ➮

Gather:

Hardware

Software (Windows NT, NIC drivers, etc.)

IP Addresses, subnet mask, etc.

User names, password, and domain

Tools

What’s Needed

Setting Up Hardware ➮

Install components:

into NetServers (i.e., LAN adapters)

into Shared Storage (i.e., drives)

Configure NetServer and Shared Storage:

Cabling

Switches

Etc.

Setup and cable the cluster:

Stack as standalone or racked solution

Connect device cabling

NetServers

Shared Storage

Cluster

Installing Software ➮

NetServers:

Configure NetServer Hardware and BIOS

Install Windows NT

Install Service Pack

Shared Storage:

Create disk partitions

Assign Drive Letters

Format logical drives

Cluster:

Install MSCS

Reinstall Service Pack

Install HotFix (Service Pack 3 only)

NetServers

Shared Storage

Cluster

Testing ➮Run:

Hardware Verification and Labeling Utility

Cluster Installation Test (CIT)

Test the Cluster

The Overall Tasks

How to do it!

(See the referenced

part in the Installation

Guide)

What you will be

doing!

This page intentionally left blank.

HP NetServer LPr

with

HP Rack Storage/12FC & HP Rack Storage/12

Cluster Configuration Guide

22 February 2000

(see Versions at the end of this document)

Introduction

This document defines the supported HP NetServer LPr using the HP Rack Storage/12FC and Microsoft Cluster

Server and one or two HP Rack Storage/12s. This configuration minimizes single points of failure (SPOF),

provides maximum availability, and has been certified by Hewlett-Packard and Microsoft. This guide is

prescriptive; it describes the configuration supported by HP. Any deviance to this configuration can result in an

inoperative cluster or an operating cluster with degraded performance, hidden SPOFs, etc., and therefore will not

be supported by HP.

What’s Defined in a Racked Cluster

•Cluster

•SPUs

•Local and Shared Storage

•Intra-cluster and Client LANs

•Shared Storage Cabling

Cluster

Type of SPUs HP NetServer LPr

Each node must be the same model SPU, but may have different clock

speeds, main memory sizes, cache sizes, and number of CPUs (2, 3, or 4).

Number of nodes 2

Shared Storage HP Rack Storage/12FC with FCArray Cards (1-Simplex or 2-Duplex), HP

disks, and using a HP D8602A HBA in the server. See Shared Storage

below.

LANs:

Client LAN Any that is HP and Microsoft approved. See Client LAN below.

Intra-cluster

(Heartbeat) LAN HP D5013A/B with crossover cable. See Intra-cluster LAN below.

Power source Direct from power mains, power conditioner or uninterruptible power

supply (UPS) using any power conditioner or UPS.

System software:

Navigator version L.17.05 or later

Operating System Microsoft Windows NT Server 4.0, Enterprise Edition with Service Pack

SP5 or later

SPU

Model HP NetServer LPr

Clock speed 400, 450, 500, 550, 600, 650, 700 MHz. or higher

No. of CPUs 2

BIOS version 4.06.09 PR or later (400, 450 MHz with Rack Storage/12 D5989A)

4.06.14.PR or later (400, 450 MHz with Rack Storage/12 D5989B)

4.06.14.PR or later (500, 550 MHz with Rack Storage/12 D5989B)

4.06.29.PR or later (600, 650, 700 MHz with Rack Storage/12 D5989B)

CPU cache Any size

RAM 64 MB minimum. Must be HP.

Local storage See

Local Storage below.

I/O slots: P1 – Free or NetRAID Local StorageBus Adapter

P2 – Client LAN

P3 – Host Bus Adapter (Shared Storage)

P4 – Intra-cluster (Heartbeat) LANs

Storage

Local

Controller May use embedded SCSI controller, NetRAID-1, NetRAID-3, NetRAID-

3Si in PCI slot P1.

May not use NetRAID-1Si.

Cabinets (Physical drive

location) SPU internal drive bays or HP external drive cabinet (e.g., HP Rack

Storage/12), any number.

Disk drives (hot swap or

fixed) Must be HP.

SCSI bus Any HP cables that meet SCSI specifications and any SCSI bus speed.

SCSI Ids Any

Shared

HP Rack Storage/12FC (Required)

Host Bus Adapter

Model HP D8602A

No. of HBAs 1

Driver 1.12 or later

SPU I/O slot P3

RAID level 0, 1, 3, 5, or 0 & 1

Cabinet

RAID arrays Not more than 8 physical drives per logical array and not more than 8

LUNs are permitted per Rack Storage/12FC and Rack Storage/12

combination in a cluster.

No. of cabinets 1

FC Array Cards

Model D5990A

No. of cards/cabinet 1 - Simplex (Supplied with Rack Storage/12FC.)

2 - Duplex (Additional card required in the Rack Storage/12FC.)

Firmware 4.64-00 or later

Status SCSI ID 5 (fixed)

Disk SCSI IDs 0 – 3, 8 – 15 (fixed)

Disk drives: HP 9.1 GB Ultra SCSI Disk Module D6106A

HP 9.1 GB Ultra SCSI Disk Module D6107A

HP 18.2 GB Ultra SCSI Disk Module D6108A

HP 18.2 GB (10k rpm) Ultra SCSI Disk Module D7031A

HP 18.2 GB (7200 rpm) Low Profile Ultra SCSI Disk Module D7174A

HP 36.4 GB (10k rpm) Ultra SCSI Disk Module D8210A

Fibre-channel cables Optical (Server to Hub only):

50 meter D6980A

100 meter D6981A

Copper (Shared Storage to Hub and Server to Hub ):

3 meter D6978A

5 meter D6979A

10 meter D7080A

HP Rack Stoarge/12 (Optional)

Number of cabinets: 1 – 2

Status SCSI ID 5 (fixed)

Disk SCSI IDs 0 – 3, 8 – 15 (fixed)

Disk drives: Same as HP Rack Storage/12FC

Cables Any HP LVD SCSI cables from the following list:

1 meter D7131A

2.5 meter D6020A

5 meter D6982A

10 meter D6983A

Hub Only required for Duplex FCArray Card configuration.

Model HP D6976A 6-port fibre channel

Quantity 1

LANs

Intra-cluster (Heartbeat) LAN Client LAN

LAN connection HP D5954A crossover cable or

equivalent Any LAN

The intra-cluster LAN may only be

used for cluster node communication

via a crossover cable. It may not be

used for client communication.

NIC:

Model HP D5013A/B (10/100TX PCI) Any that is on both the HP Tested

Products List and the Microsoft

Hardware Compatibility List.

Driver 3.27.00.0001 or later Any driver

NOTE If the Client and Intra-

cluster LANs are the same model

the Client LAN must use the same

driver as the Intra-cluster LAN.

No. of NICs 1 1 minimum

SPU I\O slot P4 P2

Shared Storage Cabling

This part of the guide defines the allowable cabling configurations for clusters using the HP NetServer

LPr, one required HP Rack Storage/12FC and one or two optional HP Rack Storage/12s. Only these cabling

configurations and cables are supported.

HP Microsoft Cluster using HP Rack Storage/12FC and Rack Storage/12

without 6 Port Fibre Channel Hub (Simplex Operation)

HP Microsoft Cluster using HP Rack Storage/12FC and Rack Storage/12

and 6 Port Fibre Channel Hub (Duplex Operation)

Power Cabling to Separate Power Circuits

Versions

22 February 2000 Corrected typographical error. Under the SPU heading, changed the No.

of CPUs from "2-4" to "2."

8 February 2000 Initial release
