HP Stream x360 Manuel

HP Stream x360 Convertible PC

Maintenance and Service Guide

IMPORTANT! This document is intended for HP

authorized service providers only.

Development Company, L.P.

Bluetooth is a trademark owned by its

proprietor and used by Hewlett-Packard

Company under license. Atom, Celeron, and

Intel are trademarks of Intel Corporation in the

U.S. and other countries. Microsoft and

Windows are U.S. registered trademarks of the

Microsoft group of companies. SD Logo is a

trademark of its proprietor.

The information contained herein is subject to

change without notice. The only warranties for

HP products and services are set forth in

the express warranty statements

accompanying such products and services.

Nothing herein should be construed as

constituting an additional warranty. HP shall

not be liable for technical or editorial errors or

omissions contained herein.

First Edition: October 2014

Document Part Number: 793705-001

Product notice

This guide describes features that are common

to most models. Some features may not be

available on your computer.

Not all features are available on all editions of

Windows 8. This computer may require

upgraded and/or separately purchased

hardware, drivers, and/or software to take full

advantage of Windows 8 functionality. See

http://www.microsoft.com for details.

Software terms

By installing, copying, downloading, or

otherwise using any software product

preinstalled on this tablet, you agree to be

bound by the terms of the HP End User License

Agreement (EULA). If you do not accept these

license terms, your sole remedy is to return the

entire unused product (hardware and

software) within 14 days for a refund subject

to the refund policy of your place of purchase.

For any further information or to request a full

refund of the tablet, please contact your local

point of sale (the seller).

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not place

the device directly on your lap or obstruct the device air vents. Use the device only on a hard, flat surface. Do

not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or

rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft surface, such

as pillows or rugs or clothing, during operation. The device and the AC adapter comply with the user-

accessible surface temperature limits defined by the International Standard for Safety of Information

Technology Equipment (IEC 60950-1).

iii

iv Safety warning notice

Table of contents

1 Product description ....................................................................................................................................... 1

2 External component identification ................................................................................................................. 3

Right side ............................................................................................................................................................... 3

Left side ................................................................................................................................................................. 4

Display ................................................................................................................................................................... 6

Changing your notebook to an entertainment stand ......................................................................... 7

Changing your notebook to a tablet ................................................................................................... 7

Top ......................................................................................................................................................................... 8

TouchPad ............................................................................................................................................. 8

Speakers .............................................................................................................................................. 8

Lights ................................................................................................................................................... 9

Keys ................................................................................................................................................... 10

Service label and PCID label ................................................................................................................................ 11

Service label ...................................................................................................................................... 11

PCID label ........................................................................................................................................... 12

3 Illustrated parts catalog .............................................................................................................................. 13

Computer major components ............................................................................................................................. 13

Display assembly subcomponents ..................................................................................................................... 17

Mass storage devices .......................................................................................................................................... 19

Miscellaneous parts ............................................................................................................................................. 19

Sequential part number listing ........................................................................................................................... 19

4 Removal and replacement procedures preliminary requirements .................................................................... 22

Tools required ...................................................................................................................................................... 22

Service considerations ........................................................................................................................................ 22

Plastic parts ....................................................................................................................................... 22

Cables and connectors ...................................................................................................................... 23

Drive handling ................................................................................................................................... 23

Grounding guidelines ........................................................................................................................................... 24

Electrostatic discharge damage ....................................................................................................... 24

Packaging and transporting guidelines ......................................................................... 25

Workstation guidelines ................................................................................ 25

5 Removal and replacement procedures for Authorized Service Provider parts ................................................... 27

Component replacement procedures ................................................................................................................. 27

Bottom cover ..................................................................................................................................... 28

USB board .......................................................................................................................................... 32

WLAN module .................................................................................................................................... 33

WWAN module ................................................................................................................................... 35

Power button board .......................................................................................................................... 37

Speakers ............................................................................................................................................ 38

Battery ............................................................................................................................................... 40

TouchPad ........................................................................................................................................... 42

Power connector cable ...................................................................................................................... 43

System board .................................................................................................................................... 44

Display assembly .............................................................................................................................. 47

6 Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI) ................................................................... 55

Starting Setup Utility (BIOS) ................................................................................................................................ 55

Updating the BIOS ................................................................................................................................................ 55

Determining the BIOS version ........................................................................................................... 55

Downloading a BIOS update .............................................................................................................. 56

Using HP PC Hardware Diagnostics (UEFI) .......................................................................................................... 57

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device .................................................. 57

7 Specifications ............................................................................................................................................. 58

Computer specifications ...................................................................................................................................... 58

8 Backup and recovery .................................................................................................................................... 59

Backing up your information ............................................................................................................................... 59

Performing a system recovery ............................................................................................................................ 59

Recovery from external media ......................................................................................................... 59

Using Windows Refresh or Windows Reset ...................................................................................... 60

9 Power cord set requirements ........................................................................................................................ 61

Requirements for all countries ........................................................................................................................... 61

Requirements for specific countries and regions ............................................................................................... 62

10 Recycling .................................................................................................................................................. 64

Index ............................................................................................................................................................. 65

1 Product description

Category Description

Product Name HP Stream x360 Convertible PC

Processor Intel® Celeron® N2840 processor (up to 2.58 GHz, 2 MB L2, 1333 MHz, dual core)

Chipset Intel Atom™

Graphics Internal graphics:

Intel HD Graphics

Support for DX11

Support for HD playback, streaming, and recording @ 720p 30fps

Panel 11.6 in [29.5 cm] (1366×768), high-definition (HD), white light emitting diode (WLED), AntiGlare,

flat panel TouchScreen with MultiTouch enabled; 16:9 ultra-wide aspect ratio; typical brightness:

200 nits (cd/m

)

Supports low-voltage differential signaling (LVDS) (co-layout with eDP1.3+PSR)

Memory On-board system memory

Support for DDR3L-1333 MHz (DDR3L-1600 MHz downgrade to DDR3L-1333 MHz)

Supports up to 2 GB max on-board system memory (2048 MB (256 MB × 16 x 4pcs))

Optical drive Support for external 9.5 mm tray load, SATA, DVD+/-RW DL SuperMulti drive only

Audio and video Integrated HP TrueVision camera: HD (1280×720 by 30 frames per second), fixed (no tilt), with

activity light

Dual array Digital Microphones with appropriate software - beam forming, echo cancellation,

noise suppression

DTS Studio Sound

Dual Speakers support 25 mm x 14 mm speaker

Ethernet Integrated 10/100 network interface card (NIC)

Co-layout with Giga-LAN

Sensor Sensor Hub (Accelerometer + Gyroscope + e-Compass)

Wireless Compatible with Miracast-certified devices

Support Assistant GPS

Integrated wireless local area network (WLAN) options by way of wireless module; 1 antenna

Support for the following WLAN format:

●Broadcom BCM43142 802.11 b/g/n 1x1 Wi-Fi + Bluetooth® 4.0 HMC Combo Adapter

Integrated wireless wide area network (WWAN) options by way of wireless module; 2 antennas

Support for the following WWAN format:

●HP hs3110 HSPA+ Mobile Broadband Module

SIM card slot (user accessible)

Category Description

External media cards HP Multi-Format Digital Media Card Reader with push-push technology. Supports SD/SDHC/SDXC.

SIM slot

Ports ●AC adapter: HP Smart pin plug (4.5 mm barrel)

●Audio: one combo audio-out (headphone)/audio-in (microphone) jack, supports jack auto-

detection

●HDMI: v. 1.4a, supporting up to 1080p, 1920×1080 at 60 Hz

●RJ-45/Ethernet

●(1) USB 3.0

●(2) USB 2.0

●VGA (Dsub 15 pin) supporting 1920×1200 external resolution at 60 Hz, hot plug/unplug and

auto-detection for correct output to wide-aspect versus standard aspect video

Keyboard/pointing devices 97% size, textured, island-style keyboard (no numerical keypad)

Touchpad requirements:

HP Imagepad - Clickpad with image sensor

Taps enabled as default

Multitouch gestures enabled

Support for PS/2 and SMB interface

Support for Windows 8.1 Modern TouchPad Gestures

Power requirements 1 meter length power cord

AC adapter with localized cable plug support

Support for the following AC adapter:

●45 W HP Smart AC adapter (non-PFC, with 26.5 mm z-height adapter [non-slim]) (not for

India/People’s Republic of China)

Embedded 3 cell, 43 Wh, prismatic battery

Security Security cable lock slot

Operating system Preinstalled:

●Windows 8.1 (WIMBoot)

Serviceability End user replaceable parts:

●AC adapter

2 Chapter 1 Product description

2 External component identification

Right side

Component Description

(1) SIM slot (select models only) Supports a wireless subscriber identity module (SIM).

(2) Memory card reader Reads optional memory cards that store, manage, share, or

access information.

To insert a card, hold the card label-side up, with connectors

facing the slot, insert the card into the slot, and then push in on

the card until it is firmly seated.

To remove a card, press in on the card it until it pops out.

(3) USB 2.0 port Connects an optional USB device, such as a keyboard, mouse,

external drive, printer, scanner or USB hub.

(4) USB 3.0 port Connects an optional USB device, such as a keyboard, mouse,

external drive, printer, scanner or USB hub.

(5) HDMI port Connects an optional video or audio device, such as a high-

definition television, any compatible digital or audio component,

or a high-speed HDMI device.

(6) RJ-45 (network) jack/status lights Connects a network cable.

●White: The network is connected.

●Amber: Activity is occurring on the network.

(7) AC adapter/battery light ●On: The AC adapter is connected and the battery is

charged.

●Off: The computer is using battery power.

(8) Power connector Connects an AC adapter.

Right side 3

Left side

Component Description

(1) Security cable slot Attaches an optional security cable to the computer.

NOTE: The security cable is designed to act as a deterrent, but

it may not prevent the computer from being mishandled or

stolen.

(2) Power button ●When the computer is off, press the button to turn on the

computer.

●When the computer is on, press the button briefly to

initiate Sleep.

●When the computer is in the Sleep state, press the button

briefly to exit Sleep.

●When the computer is in Hibernation, press the button

briefly to exit Hibernation.

CAUTION: Pressing and holding down the power button will

result in the loss of unsaved information.

If the computer has stopped responding and Windows

shutdown procedures are ineffective, press and hold the power

button down for at least 5 seconds to turn off the computer.

To learn more about your power settings, see your power

options. From the Start screen, type power, select Power and

sleep settings, and then select Power and sleep from the list of

applications.

(3) Power light ●On: The computer is on.

●Blinking: The computer is in the Sleep state, a power-

saving state. The computer shuts off power to the display

and other unneeded components.

●Off: The computer is off or in Hibernation. Hibernation is a

power-saving state that uses the least amount of power.

(4) USB 2.0 port Connects an optional USB device, such as a keyboard, mouse,

external drive, printer, scanner or USB hub.

(5) Audio-out (headphone)/Audio-in (microphone)

jack

Connects optional powered stereo speakers, headphones,

earbuds, a headset, or a television audio cable. Also connects an

optional headset microphone. This jack does not support

optional microphone-only devices.

4 Chapter 2 External component identification

Autres manuels pour Stream x360

Table des matières

Autres manuels HP Ordinateur portable

HP Compaq Presario Manuel

HP ENVY TouchSmart m7 Manuel

HP OmniBook 5500 PC Manuel utilisateur

HP ProBook 635 Aero G7 Manuel

HP CQ45-323TX Manuel utilisateur

HP Compaq NX9600 Manuel

HP Pavilion m7-1000 Manuel

HP ProBook 430 Instructions d'utilisation

HP Pavilion g4-1100 Manuel utilisateur

HP Pavilion dv2-1200 - Entertainment Notebook... Manuel utilisateur

HP Compaq 6910p Instructions d'utilisation

HP Chromebook x360 14 Manuel

HP OmniBook 4100 Manuel utilisateur

HP COMPAQ NC4200 Manuel utilisateur

HP Pavilion dv4000 - notebook pc Guide de configuration rapide

HP Compaq Presario V2000 Series Instructions de montage

HP Compaq Presario Fiche technique

HP Dv2210us - Pavilion Entertainment - Turion 64 X2 1.6... Manuel utilisateur

HP 2530p - EliteBook - Core 2 Duo 2.13 GHz Manuel utilisateur

HP Pavilion Sleekbook 14-b000 Manuel

HP 6930p - EliteBook - Core 2 Duo 2.8 GHz Instructions d'utilisation

HP Presario CQ32-100 - Notebook PC Manuel

HP 6720t - mobile thin client Fiche d'information produit

HP OmniBook 2000 Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel

Lenovo

Lenovo THINKPAD X31 Manuel

Sony

Sony VGN-T240P VAIO Manuel utilisateur

Compaq

Compaq Armada E700 Series Manuel utilisateur

Fujitsu

Fujitsu Lifebook A6230 Manuel utilisateur
