HP Pavilion x360 Instructions de montage

EL-MF877-00 Page 1

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Product End-of-Life Disassembly Instructions

Product Category: Notebooks and Tablet PCs

Marketing Name / Model

[List multiple models if applicable.]

HP Pavilion x360 Converitble PC 15

Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions

for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU

directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).

1.0 Items Requiring Selective Treatment

1.1 Items listed below are classified as requiring selective treatment.

1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as

applicable.

Item Description

Notes

Quantity

of items

included

in product

Printed Circuit Boards (PCB) or Printed Circuit

Assemblies (PCA)

With a surface greater than 10 sq cm

PCB

Batteries

All types including standard alkaline and lithium

coin or button style batteries Battery pack

Mercury-containing components

For example, mercury in lamps, display backlights,

scanner lamps, switches, batteries N/A

Liquid Crystal Displays (LCD) with a surface

greater than 100 sq cm

Includes background illuminated displays with gas

discharge lamps LED

Cathode Ray Tubes (CRT)

N/A

Capacitors / condensers (Containing PCB/PCT)

N/A

Electrolytic Capacitors / Condensers measuring

greater than 2.5 cm in diameter or height

N/A

External electrical cables and cords

N/A

Gas Discharge Lamps

N/A

Plastics containing Brominated Flame Retardants

weighing > 25 grams (not including PCBs or PCAs

already listed as a separate item above)

N/A

Components and parts containing toner and ink,

including liquids, semi-liquids (gel/paste) and toner

Include the cartridges, print heads, tubes, vent

chambers, and service stations. N/A

Components and waste containing asbestos

N/A

EL-MF877-00 Page 2

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Components, parts and materials containing

refractory ceramic fibers

N/A

Components, parts and materials containing

radioactive substances

N/A

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components

and materials requiring selective treatment can be removed.

Tool Description

Tool Size (if

applicable)

Description #1Phillips screwdriver

Description #2

Description #3

Description #4

Description #5

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

1. Disassemble U-Case

2. Disassemble Battery and HDD

3. Disassemble MB and Speaker

4. Disassemble LCD Module

10.

3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items

contained in the product that require selective treatment (with descriptions and arrows identifying locations).

Step 1.

a. Loosen 12x screws from the bottom of system

b. Take U-Case Out

EL-MF877-00 Page 3

Template Revision B

PSG instructions for this template are available at EL-MF877-01

Step 2

a. Loosen 3x screws from Battery

b.Disconnect FFC Cable

c. Take battery out of L-Case

d. Take HDD out of L-Case

Step 3

a. Unplug Dc in Cable

b. Loosen 11x screws for MB and speaker

c. Disconnect FFC Cables

d. Take MB and speaker out of L-Case.

Step 4.

a. Take LCD Module out of Hinge Up

EL-MF877-00 Page 4

Template Revision B

PSG instructions for this template are available at EL-MF877-01
