his guide is for experienced HP Response Center

personnel, CEs, and reseller technicians. That is,

personnel that have already completed the HP Vectra

PC family training course, or equivalent, and have at

least six months of experience servicing the HP Vectra

PCs.

It is a self-paced training guide designed to train you to

install configure, and repair the OmniBook Notebook

PC. You can follow it without having any equipment

available.

Microsoft, MS, and MS-DOS are registered trademarks

and Windows is a trademark of Microsoft Corporation.

LapLink Remote Access is a trademark of Traveling

Software, Inc. System Soft is a registered trademark

and CardView, CardSoft, and CardID are trademarks of

SystemSoft Corporation.

HP OmniBook 600C/CT

Familiarization Guide

Thank you for purchasing this Factory Service

Manual CD/DVD from servicemanuals4u.com.

Please check out our eBay auctions for more great

deals on Factory Service Manuals:

servicemanuals4u

OmniBook Product Comparisons................................................ 3.........

OmniBook 600 Series: Product Features........................................ 7.........

Notebook Hardware Structure.................................................... 20.......

Battery Module (End User Replaceable)....................................... 20.......

Keyboard (Hewlett-Packard Authorized Service Providers Only).............. 20.......

Mouse Assembly (End User Replaceable)..................................... 21.......

Hard Disk Drive (End User Replaceable)....................................... 22.......

Removing the Motherboard (Exch PCA) 25

Small parts...................................................................... 26.......

Installing memory............................................................... 24.......

Troubleshooting and Repair...................................................... 25.......

OmniBook Product Comparisons

HP OmniBook 5000 HP OmniBook 4000 HP OmniBook 600

Size Closed •29.5 x 22.6 x 4.9 cm

(11.6 x 8.9 x 1.93 in)

29.5 x 22.6 x 4.9 cm

(11.6 x 8.9 x 1.93 in)

18.49 × 28.24 × 3.99

(7.28 × 11.12 × 1.57

in)

Weight •3.08-3.18 kg (6.8-7 lb)DSTN (C): 3.13 kg

(6.9 lb)

TFT (CT): 3.27 kg

(7.2 lb)

1.72 kg (3.8 lb)

Processor•75-, 90-, or 120-MHz

Intel Pentium®

processor

50-, 75-, or 100-MHz

Intel 486DX2 50- or 75-MHz Intel

486DX2 or 486DX4

Bus Architecture 32-bit PCI bus ISA bus ISA bus

Cache some models include:

256-KB external L2

cache

No L2 cache No L2 cache

Display •10.4-inch diagonal:

•VGA (C/CT): 640 x

480 x 65,536 colors

(DSTN or TFT)

•SVGA (CTS): 800 x

600 x 256 colors

(TFT)

•PCI local bus video;

1.5-MB video RAM

SVGA-out supports

VGA & SVGA monitors

(up to 1024 x 768 x

256 colors)

10.3-diagonal DSTN

(up to 256 colors) or

10.4-inch diagonal

TFT (up to 65,536

colors)

VGA: 640 x 480

Local bus video; 1-MB

display RAM

SVGA-out supports

VGA & SVGA monitors

(up to 1024 x 768 x

256 colors)

8.6-diagonal DSTN

(600C) or

9.5-inch diagonal TFT

(600CT)

640×480 backlit color

VGA displays

64K colors from a

262K color palette

VGA-out supports

VGA and SVGA

monitors (up to

1024×768×256 colors)

Accelerated local bus

video with 1-MB VRAM

HP OmniBook 5000 HP OmniBook 4000 HP OmniBook 600

Power •14.4Vdc

Rechargeable

Lithium-Ion or NiMH

battery

•Battery life

(approximate with one

battery): 2 to 3 hrs

•Battery recharges to

high level in 4 hrs

using AC adapter while

PC is on or off

•2-minute low-battery

warning

•AC adapter 100 to

240 Vac (50 to 60 Hz)

input; 12 Vdc, 3.3 A

output

•Instant-on maintains

computer in

ready-to-work state for

weeks on a full charge;

returns you to your

application or file

instantly

14.4 Vdc rechargeable

NiMH battery pack

Battery life

(approximate):

3-4 hrs on DSTN

DX2/50

2-3 hrs on TFT

DX4/100

AC adapter 100 to 240

Vac (50 to 60 Hz)

input; 21 Vdc,1.35 A

output

Suspend-resume

power management.

9.6 Vdc rechargeable

NiMH or Lithium Ion

battery

Battery life up to

3.0-3.5 hours.

Battery pack

recharges to high level

in less than 2 hours

using AC adapter

2-minute (or less)

low-battery warning

AC adapter 100 to 240

Vac (50 to 60 Hz)

input; 12 Vdc, 2.5 A

output

Instant-on maintains

computer in

ready-to-work state for

months on a charge.

Turn it on again, and

you’re instantly back

where you were.

Removable Modules •Floppy disk drive (can

be replaced with a

second battery for

double battery life)

•Hard disk drive

•RAM

•Battery

Floppy disk drive (can

be replaced with a

second battery for

double battery life)

Hard disk drive

RAM

Battery

Hard disk drive

•RAM

•Battery

Mass Storage •540-MB, 810-MB, or

1.2-GB hard disks 260-, 340-, 520-, or

810-MB hard disk

options

170, 260, or 340 MB

hard disk drive

170MB Hard drives are

no longer available

RAM 8- or 16-MB Models

•upgradable to 64 MB

•8-, 16-, or 32-MB

RAM cards

4-, 8-MB, or 16-MB

RAM models

upgradable to 32 MB

4-, 8-, 16- or 24-MB

RAM models

upgradable to 32MB

(CT) 12MB or 16MB

(C).

HP OmniBook 5000 HP OmniBook 4000 HP OmniBook 600

Audio •16-bit with Sound

Blaster and MIDI

support

•Stereo sound via two

built-in speakers

16-bit, Sound

Blaster-compatible

Stereo sound via two

built-in stereo speakers

Microsoft Windows

sound in CT.

Two built-in speakers

(not stereo sound)

The OmniBook 600C

does not have a built-in

sound board and only

one speaker

Input/Output •9-pin, 115,200 - b/s,

RS-232 port

•25-pin EPP and ECP

parallel port

•SVGA-out (up to 1024

x 768 x 256); VGA-out

(640 x 480 x 65,536

colors)

•115,200-baud,

bidirectional infrared

•Expansion bus

connector

•SCSI-2 port

•NTSC/PAL video-out

port

•Keyboard/mouse port

•Headphone/stereo-out

port

•Stereo-in and

microphone ports

•MIDI/joystick port

9-pin, 115,200 - b/s,

RS-232 port

25-pin EPP and ECP

parallel port

SVGA-out (up to 1024

x 768 x 256)

115,200 - baud,

bi-directional infrared

Expansion bus

connector

Keyboard/mouse port

Headphone/stereo-out

port

Microphone port

Stereo-in port

9-pin, 115,200 - b/s,

RS-232 port

25-pin bidirectional

parallel port

SVGA-out (up to 1024

× 768 × 256)

115,200 - baud,

bidirectional infrared

Enhanced port

replicator connector

Floppy drive port

HP OmniBook 5000 HP OmniBook 4000 HP OmniBook 600

Expandability •One Type III PCMCIA

slot (or use as two

Type II slots) with

3.3-V or 5-V support

ISA-based slots, and

parallel, serial,

SVGA-out (up to 1024

x 768 x 256),

keyboard, PS/2

mouse, MIDI/joystick,

audio, and SCSI-2

ports

One Type III PCMCIA

slot (or use as two

Type II slots)

Enhanced port

replicator with parallel,

two serial, SVGA-out

(up to 1024 x768),

keyboard, PS/2

mouse, and SCSI

ports; and PCMCIA

slot (concurrent Type II

and Type III)

One Type III PCMCIA

slot (or use as two

Type II slots)

External ultra-thin

floppy disk drive

(included with product)

Enhanced port

replicator with EPP

parallel, serial,

VGA-out (up to 1024 ×

768), keyboard, PS/2

or Microsoft®mouse,

and SCSI ports;

external floppy

connector; and

optional HP EtherTwist

LAN card slot

Pre-installed

Software •Microsoft Windows 95

Microsoft Windows for

Workgroups 3.11 *

•MS-DOS 6.22

•Plug and Play BIOS

•HP PIM

Microsoft Windows for

Workgroups 3.11

MS-DOS 6.2

Laplink Remote

Access

Easy connection to

your desktop PC,

network and desktop

printers; works via

cable or infrared.

Microsoft Windows

for Workgroups 3.11

MS-DOS 6.22

Upgrade easily to

Windows 95

User upgradable Plug

and Play BIOS in

EEPROM

LapLink Remote

Access

Appointment Book

HP Financial

Calculator

Phone Book

IrDA infrared printing

driver

Security Features •2-level password

protection

•PC ID (tattooing)

•Kensington lock slots

User password

Kensington lock slots

User password

Kensington lock slots

OmniBook 600 Series: Product Features

Description The smallest, lightest color notebook with desktop performance for the professional

on the go

Models This is a complete list of all the standard Omnibook models ever made available.

Factory special options are not included in this listing. All of these models are now

obsolete.

Product Description HP Part #

HP OmniBook 600C DX2/50MHz; 170MB Hard Drive F1065A

HP OmniBook 600C DX2/50MHz; 260MB Hard Drive F1110A

HP OmniBook 600C DX4/75MHz; 170MB Hard Drive F1066A

HP OmniBook 600C DX4 /75MHz; 260MB Hard Drive F1111A

HP OmniBook 600C DX4 /75MHz; 340MB Hard Drive F1113A

HP OmniBook 600CT* DX4 /75 MHz; 260MB Hard Drive F1114A

HP OmniBook 600CT* DX4 /75MHz; 340MB Hard Drive F1115A

* Indicates TFT display

(Note: All models have 8-MB RAM except the F1065A and F1110A with 4MB

RAM.

Accessories Description Part Number

4-MB RAM expansion card F1054A

8-MB RAM expansion card (replaces F1055A). F1055B

16-MB RAM expansion card F1123A

24-MB RAM expansion card F1124A

170-MB Hard Disk Drive F1068A

260-MB Hard Disk Drive F1069A

340-MB Hard Disk Drive F1070A

3.5 inch Floppy Drive Module F1059B

AC Adapter F1044B

NiMH Battery Pack Module F1058A

Power Clip (TM) External Battery Charger F1063B

Automobile Adapter F1064A

LiIon Battery Pack Module F1121A

Enhanced Port Replicator F1071A

Pop-up Mouse F1049A

OmniBook 600CT

improvements

over the

OmniBook 600C

Feature Benefit

9.5 inch Active Matrix Display Clearer, more vivid graphics

Windows Sound Media and presentation flexibility for

Windows applications

RAM expansion to 32-MB Handle more complex applications

Lithium-Ion battery Longer battery life and less weight than

NiMH

What comes in the

box OmniBook 600 mainframe

Battery pack

User documentation: manuals, support material, registration card

AC adapter (P//N: F1044B), localized power cord

Brochures for OmniBook accessories and Deskjet 340

External 3.5"Floppy Drive

Microprocessor Intel486 DX2 50-MHz

Intel486 DX4 75-MHz

Processor cache: 16K internal (L1)

Bus Architecture ISA, Video local Bus

The OmniBook 600 does not have DMA capability

Memory Main Memory ( on

mother board) DX2/50 MHz, Model 170 (F1065A)

All other models

4MB RAM

8MB

Memory Max Possible RAM 600C

Max Possible RAM 600CT

12/16MB

32MB

Type of memory boards HP Proprietary, 1 user-accessible slot on the front case.

Cycle time 70ns

Possible Memory

Configurations Motherboard RAM

Memory Memory Slot Total RAM

4MB -- 4MB

4MB 4MB 8MB

4MB 8MB 12MB

8MB -- 8MB

8MB 4MB 12MB

8MB 8MB 16MB

8MB 16MB (600CT only) 24MB

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Ordinateur portable

HP 2730p - EliteBook - Core 2 Duo 1.86 GHz Manuel utilisateur

HP Armada 7400 Mise à jour du firmware

HP Pavilion 11 x360 PC Manuel

HP Pavilion g4 Manuel

HP OmniBook XE Manuel utilisateur

HP Compaq tc4400 Manuel

HP Pavilion Media Center dv9341eu Manuel utilisateur

HP ENVY 14-j000 Manuel

HP Pavilion g4-2000 Manuel utilisateur

HP Pavilion g6-2000 Manuel utilisateur

HP Pavilion g7 Manuel

HP 15 Manuel

HP ProBook 470 G3 Manuel

HP Computer Manuel utilisateur

HP Compaq V3000 Series Instructions de montage

HP Presario CQ71-300 - Notebook PC Manuel utilisateur

HP Compaq Presario Fiche technique

HP EliteBook 845 G7 Manuel

HP mt31 Manuel

HP OMEN 17 Instructions de montage

HP CQ60 Series Manuel

HP Pavilion xt200 - Notebook PC Mode d’emploi

HP HP6830s Manuel utilisateur

HP Presario CQ42-100 - Notebook PC Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel

Lenovo

Lenovo THINKPAD X31 Manuel

Sony

Sony VGN-T240P VAIO Manuel utilisateur

Compaq

Compaq Armada E700 Series Manuel utilisateur

Fujitsu

Fujitsu Lifebook A6230 Manuel utilisateur
