HP Compaq NX7400 Manuel utilisateur

External Devices

Document Part Number: 410774-001

April 2006

This guide explains how to use optional external devices with the

computer.

External Devices ii

Contents

1 Using a USB device

Connecting a USB device . . . . . . . . . . . . . . . . . . . . . . . . 1–2

Stopping a USB device . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2

Required USB software . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3

USB legacy support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3

2 Using a 1394 device

Connecting a 1394 device . . . . . . . . . . . . . . . . . . . . . . . . 2–1

Stopping a 1394 device . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Required 1394 software . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

3 Using the docking connector

External Devices 1–1

Using a USB device

Universal Serial Bus (USB) is a hardware interface that can

be used to connect an optional external device, such as a USB

keyboard, mouse, drive, printer, scanner, or hub, to the computer

or to an optional docking device. A hub provides additional USB

ports for the system and can be connected to the computer or to

another hub.

The computer has 3 standard USB ports that support USB 2.0 and

USB 1.1 devices. An optional docking device provides additional

USB ports that can be used with the computer.

1–2 External Devices

Using a USB device

Connecting a USB device

ÄCAUTION: To prevent damage to the USB connectors, use minimal force

to connect a USB device.

To connect a USB device to the computer, connect the USB cable

for the device to the USB port on the computer. The operating

system will issue a sound to indicate that a device has been

detected.

✎The first time you connect a USB device, the “Found New

Hardware” message is displayed in the notification area, at the

far right of the taskbar.

Stopping a USB device

ÄCAUTION: To prevent loss of information or an unresponsive system, stop

a USB device before removing it.

To stop a USB device:

1. Double-click the Safely Remove Hardware icon in the

notification area, at the far right of the taskbar.

✎To display the Safely Remove Hardware icon, click the

Show Hidden Icons icon (<or <<) in the notification area.

2. Click the USB listing.

✎If the USB device is not listed, you do not have to stop the

device before you remove it.

3. Click Stop.

Using a USB device

External Devices 1–3

Required USB software

Some USB devices may require additional software, which is

usually included with the device. For more information about

device-specific software, refer to the manufacturer’s instructions

included with the device.

USB legacy support

USB legacy support (enabled by default) allows you to

■Use a keyboard, mouse, or hub connected to a USB port on

the computer during startup or in a non-Microsoft®

Windows®application or utility.

■Start or restart from an optional external MultiBay.

To enable or disable USB legacy support:

1. Open Computer Setup by turning on or restarting the

computer, and then pressing f10 while the “F10 = ROM Based

Setup” message is displayed in the lower-left corner of the

screen.

2. Use the arrow keys to select System Configuration > Device

Configurations.

3. Use the arrow keys to enable or disable USB legacy support.

4. To save your preferences and exit Computer Setup, use the

arrow keys to select File > Save changes and exit. Then

follow the instructions on the screen.

Your preferences go into effect when the computer restarts.

External Devices 2–1

Using a 1394 device

IEEE 1394 is a hardware interface that can be used to connect a

high-speed multimedia or data storage device to the computer.

Scanners, digital cameras, and digital camcorders often require

a 1394 connection.

The computer 1394 port, illustrated below, also supports IEEE

1394a devices.

Connecting a 1394 device

ÄCAUTION: To prevent damage to the 1394 port connectors, use

minimal force to connect a 1394 device.

To connect a 1394 device to the computer, connect the 1394

device cable to the 1394 port on the computer. The operating

system will issue a sound to indicate that a device has been

detected.

✎The first time you connect a 1394 device, the “Found New

Hardware” message is displayed in the notification area, at the

far right of the taskbar.

2–2 External Devices

Using a 1394 device

Stopping a 1394 device

ÄCAUTION: To prevent loss of information or an unresponsive system, stop

a 1394 device before removing it.

To stop a 1394 device:

1. Double-click the Safely Remove Hardware icon in the

notification area, at the far right of the taskbar.

✎To display the Safely Remove Hardware icon, click the

Show Hidden Icons icon (<or <<) in the notification area.

2. Click the 1394 listing.

3. Click Stop.

Required 1394 software

Some 1394 devices may require additional software, usually

included with the device. For more information about

device-specific software, refer to the manufacturer’s instructions

included with the device.

External Devices 3–1

Using the docking connector

The docking connector on the bottom of the computer allows you

to connect the computer to an optional docking device. An

optional docking device provides additional ports and connectors

that can be used with the computer.

Microsoft and Windows are U.S. registered trademarks of Microsoft

Corporation.

The information contained herein is subject to change without notice. The

only warranties for HP products and services are set forth in the express

warranty statements accompanying such products and services. Nothing

herein should be construed as constituting an additional warranty. HP shall

not be liable for technical or editorial errors or omissions contained herein.

External Devices

First Edition: April 2006

Document Part Number: 410774-001
