HP Armada e500 Series Document technique

Connector Pin Assignments B-1

appendix B

POWER CORD SET

REQUIREMENTS

3-Conductor Power Cord Set

The wide range input feature of the Armada E500 and V300 Series of

Personal Computers permits them to operate from any line voltage from

100 to 120 or 220 to 240 volts AC.

The power cord sets received with the computers meets the requirements

for use in the country where the equipment is purchased.

Power cord sets for use in other countries must meet the requirements of

the country where the computer is used. For more information on power

cord set requirements, contact a Compaq authorized reseller or service

provider.

General Requirements

The requirements listed below are applicable to all countries:

1. The length of the power cord set must be at least 5.00 feet (1.5 m) and

a maximum of 6.50 feet (2.0 m).

2. All power cord sets must be approved by an acceptable accredited

agency responsible for evaluation in the country where the power

cord set will be used.

3. The power cord set must have a minimum current capacity of 10A

and a nominal voltage rating of 125 or 250 volts AC, as required by

each country’s power system.

4. The appliance coupler must meet the mechanical configuration of an

EN 60 320/IEC 320 Standard Sheet C13 connector, for mating with

appliance inlet on the back of the computer.

B-2Connector Pin Assignments

Country-Specific Requirements

3-Conductor Power Cord Set Requirements—

By

Country

Country

Accredited Agency Applicable Note

Numbers

Australia EANSW 1

Austria OVE 1

Belgium CEBC 1

Canada CSA 2

Denmark DEMKO 1

Finland FIMKO 1

France UTE 1

Germany VDE 1

Italy IMQ 1

Japan JIS 3

The Netherlands KEMA 1

Norway NEMKO 1

Sweden SEMKO 1

Switzerland SEV 1

United Kingdom BSI 1

United States UL 2

Notes

1. The flexible cord must be <HAR> Type HO5VV-F, 3-conductor, 1.0

mm2conductor size. Power cord set fittings (appliance coupler and

wall plug) must bear the certification mark of the agency responsible

for evaluation in the country where it will be used.

2. The flexible cord must be Type SPT-3 or equivalent, No. 18 AWG, 3-

conductor. The wall plug must be a two-pole grounding type with a

NEMA 5-15P (15A, 125V) or NEMA 6-15P (15A, 250V) configuration.

3. The appliance coupler, flexible cord, and wall plug must bear a "T"

mark and registration number in accordance with the Japanese

Dentori Law. The flexible cord must be Type VCT or VCTF,

3-conductor, 0.75mm2conductor size. The wall plug must be a

two-pole grounding type with a Japanese Industrial Standard C8303

(15A,125V) configuration.
