HP OmniBook Plug-In Modules
User’s Guide
For other Service and User Manuals, go to www.ManualDepot.com
1-2
Notice
This manual and any examples contained herein are provided “as is” and are
subject to change without notice. Hewlett-Packard Company makes no warranty of
any kind with regard to this manual, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose. Hewlett-Packard
Co. shall not be liable for any errors or for incidental or consequential damages in
connection with the furnishing, performance, or use of this manual or the examples
herein.
Consumer transactions in Australia and the United Kingdom: The above disclaimers
and limitations shall not apply to Consumer transactions in Australia and the United
Kingdom and shall not affect the statutory rights of Consumers.
© Copyright Hewlett-Packard Company 1998. All rights reserved. Reproduction,
adaptation, or translation of this manual is prohibited without prior written
permission of Hewlett-Packard Company, except as allowed under the copyright
laws.
The programs that control these products are copyrighted and all rights are
reserved. Reproduction, adaptation, or translation of those programs without prior
written permission of Hewlett-Packard Co. is also prohibited.
Portions of the programs that control this product may also be copyrighted by
Microsoft Corporation, SystemSoft Corp., Crystal Semiconductor Corporation,
Phoenix Technologies, Ltd., and NeoMagic Corporation. See the individual
programs for additional copyright notices.
Microsoft, MS, MS-DOS, and Windows are registered trademarks of Microsoft
Corporation. Pentium and the Intel Inside logo are U.S. registered trademarks and
MMX is a U.S. trademark of Intel Corporation.
For warranty information, see the Support and Service booklet.
,I[PIXX4EGOEVH'SQTER]
1SFMPI'SQTYXMRK(MZMWMSR
4VYRIVMHKI%ZI
'YTIVXMRS'%97%
1-3
Contents
1. Using OmniBook Plug-In Modules.......................... 1-5
Replacing a Plug-In Accessory Module ....................... 1-7
To replace a plug-in module............................. 1-7
Using the Floppy Disk Drive ............................... 1-9
To connect the floppy disk drive externally .................. 1-9
To insert or eject a floppy disk ........................... 1-10
Using the CD-ROM Drive ................................. 1-11
To insert or remove a CD ............................... 1-11
To open the CD-ROM drive manually ...................... 1-12
Using the Zip Drive ..................................... 1-13
To install the Zip drive software .......................... 1-13
To insert or eject a Zip disk ............................. 1-14
To eject a Zip disk manually............................. 1-14
Using the DVD Drive .................................... 1-15
To insert or eject a DVD ................................ 1-15
To eject a DVD manually ............................... 1-16
Using the Second Battery ................................. 1-17
To handle and store the battery safely ...................... 1-17
To maintain and preserve battery life ...................... 1-18
2. Troubleshooting ....................................... 1-19
Solving Problems with Plug-In Accessories..................... 1-21
Floppy disk drive problems ............................. 1-21
CD-ROM drive problems ............................... 1-22
Zip drive problems ................................... 1-22
DVD Drive Problems .................................. 1-23
Battery problems .................................... 1-23
3. Specifications and Regulatory Information................... 1-25
Hardware Specifications and Safety ......................... 1-27
To use the CD-ROM and DVD drive safely ................... 1-27
Regulatory Information .................................. 1-28
U.S.A. ............................................ 1-28
Canada ........................................... 1-29
Japan ............................................ 1-29
Europe ........................................... 1-30
1-5
1
Using OmniBook Plug-In
Modules
1-6
Using OmniBook Plug-In Modules
The OmniBook Plug-in Modules User’s Guide describes OmniBook plug-in accessory
modules and shows you how to install and use them. For complete information
about operating the OmniBook, consult the OmniBook Reference Guide and the
online User’s Handbook.
This manual explains how to
♦ Replace a plug-in module in the OmniBook.
♦ Use the floppy disk drive.
♦ Use the CD-ROM drive.
♦ Use the Zip drive.
♦ Use the DVD drive.
♦ Use the second battery.
Using OmniBook Plug-In Modules
6ITPEGMRKE4PYK-R%GGIWWSV]1SHYPI
1-7
Replacing a Plug-In Accessory Module
-QTSVXERX Shut down the OmniBook before removing or inserting the plug-in module using the
Start menu, or press and hold the blue power button until the display shuts down.
This is not necessary if you are removing a second battery from the plug-in module
bay and inserting another battery.
To replace a plug-in module
1. From the Start menu, shut down Windows (this is not necessary if you are
removing a battery from the plug-in module bay and inserting another battery).
2. Slide the safety latch for the plug-in slot into its recess.
3. Slide and hold the release latch, then pull out the module, as shown.
Using OmniBook Plug-In Modules
6ITPEGMRKE4PYK-R%GGIWWSV]1SHYPI
1-8
4. Slide the plug-in module into the OmniBook until it clicks into place.
'%98-32 &IWYVIXLIWEJIX]PEXGLMWSTIR3XLIV[MWI]SYGSYPHHEQEKIXLIQSHYPISV]SYV
3QRM&SSO
5. Slide the safety latch back to its original position (in the direction of the arrow).
Using OmniBook Plug-In Modules
9WMRKXLI*PSTT](MWO(VMZI
1-9
Using the Floppy Disk Drive
You can install the floppy disk drive in the plug-in module bay or attach it externally
to the parallel port.
This section describes how to
♦ Connect the floppy disk drive externally.
♦ Insert or eject a floppy disk.
To connect the floppy disk drive externally
If you want to use the floppy disk drive while also using any other OmniBook plug-in
module, you can use the floppy cable (optional accessory F1380A) to connect the
floppy disk drive module to the OmniBook via the parallel port.
1. Connect the floppy cable to the floppy disk drive module and tighten the
knurled thumbscrews.
2. Connect the other end of the floppy disk drive cable to the OmniBook parallel
port, as shown below.
Using OmniBook Plug-In Modules
9WMRKXLI*PSTT](MWO(VMZI
1-10
To insert or eject a floppy disk
'%98-32 (SRSXMRWIVXSVVIQSZIEJPSTT]HMWO[LMPIXLI3QRM&SSOMWEGXMZIP]VIEHMRKSV
[VMXMRKHEXE3XLIV[MWI]SYGSYPHPSWIHEXESVXLI3QRM&SSOGSYPHWXST
VIWTSRHMRK
1. Hold the disk with its face up, then slide it into the floppy disk drive slot until it
clicks into place.
2. To remove the floppy disk, press the eject button on the front of the drive.
