HP StorageWorks FC1143 Instructions d'utilisation

Models

HP StorageWorks

FC2143 4Gb PCI-X 2.0

HBA

StorageWorks 4Gb, PCI-X-to-Fibre Channel Host Bus Adapter for Windows and

Linux. (Emulex LP1150)

AD167A

HP StorageWorks

FC2243 Dual Channel

4Gb PCI-X 2.0 HBA

StorageWorks Dual Channel 4Gb, PCI-X-to-Fibre Channel Host Bus Adapter for

Windows and Linux (Emulex LP11002)

AD168A

HP StorageWorks

FC1143 4Gb PCI-X 2.0

HBA

StorageWorks 4Gb, PCI-X-to-Fibre Channel Host Bus Adapter for Windows and

Linux (Qlogic QLA2460)

AB429A

HP StorageWorks

FC1243 Dual Channel

4Gb PCI-X 2.0 HBA

StorageWorks Dual Channel 4Gb, PCI-X-to-Fibre Channel Host Bus Adapter for

Windows and Linux (Qlogic QLA2462)

AE369A

Product Description

The 4Gb PCI-X Fibre Channel Host Bus Adapter Family consists of single and dual channel Host Bus Adapters (HBAs) with

an optical LC type connector. These HBAs are provided by Qlogic and Emulex and are qualified for ProLiant and Integrity

platforms configured with the Enterprise Virtual Array 3000, 4000, 5000, 6000 and 8000, MSA1000, MSA1500, and XP

array offerings.

For supported Fibre Channel SAN Switches, please consult the SAN Design Reference Guide at the following WEB

address:

http://h18006.www1.hp.com/products/storageworks/san/documentation.html

Key Features

4Gb/s Fibre Channel link speed support

PCI-X 2.0 mode 2, 266 MHz bus compatibility and extended high-availability support with ECC.

Compatible with PCI 33/66 (3.3V signaling) and PCI-X 66/100/133 MHz slots

Automatic speed negotiation with existing 1Gb/s and 2Gb/s Fibre Channel SANs

Superior performance capable of sustaining up to 100,000 I/Os per second per channel

4-Gbps FC increases aggregate throughput rate to 1.6GBps in full-duplex mode

Full fabric support with automatic topology and speed adaptation

Full support for both FC service Class 2 and 3

Support FC-Tape devices

RoHS compliance

HBAnyware from Emulex and Qlogic SANsurfer FC HBA Manager for centralized management and remote control of

distributed HBAs

Benefits At a Glance

Higher performance with lower price

Supports the Windows and Linux operating environments

Provides the flexibility and broad interoperability need for complex highly scalable SANs

Family Comparison Table

FC2143 FC2243 FC1143 FC1243

Number of channels

Single

Dual

Single

Dual

Port Speed

4 Gb 4 Gb 4 Gb 4 Gb

Slot type supported

PCI-X 2.0 to Fibre

Channel

PCI-X 2.0 to Fibre

Channel

PCI-X 2.0 to Fibre

Channel

PCI-X 2.0 to Fibre

Channel

QuickSpecs

HP StorageWorks 4Gb PCI-X 2.0 Host Bus Adapters

Overview

DA - 12481 U.S. QuickSpecs — Version 5 — 9/21/2007

Page 1

OS Supported

Microsoft Windows

2000

Microsoft Windows

2000

Microsoft Windows

2000

Microsoft Windows

2000

Microsoft Windows

Server 2003

Microsoft Windows

Server 2003

Microsoft Windows

Server 2003

Microsoft Windows

Server 2003

Microsoft Windows

Server 2003 64-Bit

Edition

Microsoft Windows

Server 2003 64-Bit

Edition

Microsoft Windows

Server 2003 for 64-bit

Extended Systems

Microsoft Windows

Server 2003 for 64-bit

Extended Systems

Microsoft Windows

Server 2003 for 64-bit

Extended Systems

Microsoft Windows

Server 2003 for 64-bit

Extended Systems

Red Hat Enterprise

Linux 3

(AMD64/EM64T)

Red Hat Enterprise

Linux 3

(AMD64/EM64T)

Red Hat Enterprise

Linux 3

(AMD64/EM64T)

Red Hat Enterprise

Linux 3

(AMD64/EM64T)

Red Hat Enterprise

Linux 3 (x86)

Red Hat Enterprise

Linux 3 (x86)

Red Hat Enterprise

Linux 3 (x86)

Red Hat Enterprise

Linux 3 (x86)

Red Hat Enterprise

Linux 4

(AMD64/EM64T)

Red Hat Enterprise

Linux 4

(AMD64/EM64T)

Red Hat Enterprise

Linux 4

(AMD64/EM64T)

Red Hat Enterprise

Linux 4

(AMD64/EM64T)

Red Hat Enterprise

Linux 4 (Itanium)

Red Hat Enterprise

Linux 4 (Itanium)

Red Hat Enterprise

Linux 4 (x86)

Red Hat Enterprise

Linux 4 (x86)

Red Hat Enterprise

Linux 4 (x86)

Red Hat Enterprise

Linux 4 (x86)

SUSE LINUX

Enterprise Server 8

SUSE LINUX

Enterprise Server 8

SUSE LINUX

Enterprise Server 8

SUSE LINUX

Enterprise Server 8

SUSE LINUX

Enterprise Server 8

(AMD64)

SUSE LINUX

Enterprise Server 8

(AMD64)

SUSE LINUX

Enterprise Server 8

(AMD64)

SUSE LINUX

Enterprise Server 8

(AMD64)

SUSE LINUX

Enterprise Server 9

(AMD64/EM64T)

SUSE LINUX

Enterprise Server 9

(AMD64/EM64T)

SUSE LINUX

Enterprise Server 9

(AMD64/EM64T)

SUSE LINUX

Enterprise Server 9

(AMD64/EM64T)

SUSE LINUX

Enterprise Server 9

(Itanium)

SUSE LINUX

Enterprise Server 9

(Itanium)

SUSE LINUX

Enterprise Server 9

(x86)

SUSE LINUX

Enterprise Server 9

(x86)

SUSE LINUX

Enterprise Server 9

(x86)

SUSE LINUX

Enterprise Server 9

(x86)

VMware

V2.5.4 and later

V3.0 and later

VMware

V2.5.4 and later

V3.0 and later

VMware

V2.5.4 and later

V3.0 and later

VMware

V2.5.4 and later

V3.0 and later

Servers Supported

HP ProLiant platforms

HP Integrity platforms

HP ProLiant platforms

HP Integrity platforms

HP ProLiant platforms

HP Integrity platforms

HP ProLiant platforms

Array Platforms

Supported

EVA3000,

EVA4x00,

EVA5000,

EVA6x00,

EVA8x00,

XP Disk Arrays,

MSA1000,

MSA1500

EVA3000,

EVA4x00,

EVA5000,

EVA6x00,

EVA8x00,

XP Disk Arrays,

MSA1000,

MSA1500

EVA3000,

EVA4x00,

EVA5000,

EVA6x00,

EVA8x00,

XP Disk Arrays,

MSA1000,

MSA1500

EVA3000,

EVA4x00,

EVA5000,

EVA6x00,

EVA8x00,

XP Disk Arrays,

MSA1000,

MSA1500

Environmental -

Operating

Temperature

32° to 131° F (0° to 55°

32° to 113° F (0° to 45°

QuickSpecs

HP StorageWorks 4Gb PCI-X 2.0 Host Bus Adapters

Overview

DA - 12481 U.S. QuickSpecs — Version 5 — 9/21/2007

Page 2

Environmental -

Storage Temperature

-20° to 158° F

(-4° to 70° C)

-20° to 158° F

(-4° to 70° C)

-40° to 158° F -40° to 158° F

Environmental -

Relative Humidity -

Operating

10% to 90% non-

condensing

10% to 90% non-

condensing

10% to 90% non-

condensing

10% to 90% non-

condensing

Product Dimensions

(HxW)

6.7 x 2.5 in (16.93 cm x

5.15 cm)

6.7 x 2.5 in (16.93 cm x

5.15 cm)

6.60 x 2.54 in

(167.64mm x 64.4 mm)

6.60 x 2.54 in

(167.64mm x 64.4 mm)

Media

Multi-mode Optic Multi-mode Optic Multi-mode Optic Multi-mode Optic

Connector

Short wave laser with

LC type connector

Short wave laser with

LC type connector

Short wave laser with

LC type connector

Short wave laser with

LC type connector

Brackets

Shipped with both ½

height and full-height

brackets

Shipped with both ½

height and full-height

brackets

Shipped with both ½

height and full-height

brackets

Shipped with both ½

height and full-height

brackets

For additional technical specifications go to

http://saw.cce.hp.com/km/saw/home.do

(HP employees and partners only)

Warranty

3-0-0 Three-year parts exchange warranty. Additional Warranty protection can be purchased.

HP Global Services provides a three-year, limited warranty, fully supported by a worldwide network of resellers and service

providers toll-free 7 x 24 hardware technical phone support for the duration of the warranty. In addition, available service

offerings include a full range of HP Care Pack packaged hardware and software services.

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

QuickSpecs

HP StorageWorks 4Gb PCI-X 2.0 Host Bus Adapters

Overview

DA - 12481 U.S. QuickSpecs — Version 5 — 9/21/2007

Page 3

Software Product

Services

Stand-alone telephone support

Rights to new license

Media and documentation updates

Hardware Product

Services

Installation services

On-site maintenance (includes warranty support)

Response time upgrades during the warranty period

Post-warranty coverage

RAID setup and performance consulting via statement of work

For additional hardware installation and maintenance information, please refer to the URL listed

below:

http://www.hp.com/hps/hardware/

Warranty Upgrade

Options

Response - Upgrade on-site response from next business day to same day 4 hours

Coverage - Extend hours of coverage from 9 hours x 5 days to 24 hours x 7 days

Duration - Select duration of coverage for a period of 1, 3, or 5 years

Additional Warranty protection and/or HP Installation packages can be purchased.

HP Care Pack

Information and

Installation Services

Sample part numbers:

3 year, uplift to 5 x 9, Next Day Response

FM-

XHW-36

3 year, uplift to 5 x 9, 4-hour Response

FM-

4HR-36

3 year, uplift to 7 x 24, 4-hour Response

FM-

724-36

Hardware Installation

FM-

INS-IN

** Represents a two-digit, product-specific code

HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific

duration and hours of coverage.

HP Care Pack is not available for less than the product's warranty duration.

HP Care Pack is available for sale anytime during the warranty period for most products, but the

commencement date will be the same as the Warranty Start Date (delivery date to end user

customer). Proof of purchase may be required.

HP Care Pack services are prepaid.

If ordering this HBA for a non-HP server, manually add package band 8D4 and Installation

HA113A1 band 527. If ordering this HBA as an add-on to an existing HP server, manually add

Installation HA113A1 band 527.

For additional HP Care Pack (hardware & software) information, as well as orderable part

numbers, please refer to the URL

http://www.hp.com/hps/carepack/

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for

details.

QuickSpecs

HP StorageWorks 4Gb PCI-X 2.0 Host Bus Adapters

Service and Support, HP Care Pack and Warranty Information

DA - 12481 U.S. QuickSpecs — Version 5 — 9/21/2007

Page 4

Windows is a registered trademark of the Microsoft Corporation.

Hewlett-Packard shall not be liable for technical or editorial errors or omissions contained herein. The information is

provided "as is" without warranty of any kind and is subject to change without notice. The warranties for HP products are set

forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as

constituting an additional warranty.

QuickSpecs

HP StorageWorks 4Gb PCI-X 2.0 Host Bus Adapters

Service and Support, HP Care Pack and Warranty Information

DA - 12481 U.S. QuickSpecs — Version 5 — 9/21/2007

Page 5

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Adaptateur hôte

HP FCA2214DC PCI-X Manuel utilisateur

HP Xw4550 - Workstation - 2 GB RAM Manuel utilisateur

HP Xw4600 - Workstation - 2 GB RAM Manuel utilisateur

HP SC44Ge Instructions d'utilisation

HP Tc2110 - Server - 128 MB RAM Manuel de l'opérateur

HP SC44Ge Manuel utilisateur

HP A8002A Instructions d'utilisation

HP H221 Manuel utilisateur

Manuels Adaptateur hôte populaires d'autres marques

Digital Equipment

Digital Equipment StorageWorks EK-KZPCM-UG Manuel utilisateur

ATTO Technology

ATTO Technology ExpressPCI UL4S Manuel utilisateur

Sun Microsystems

Sun Microsystems Sun StorEdge Manuel utilisateur

LSI

LSI LSI21320-R Manuel utilisateur

LSI

LSI Ultra160 Manuel utilisateur

ATTO Technology

ATTO Technology ATTO ExpressPCI FC 3321 Manuel utilisateur

Tekram Technology

Tekram Technology TR-824 Manuel utilisateur

ATTO Technology

ATTO Technology ATTO Celerity FC-81EN Manuel utilisateur

LSI

LSI S14037 Manuel utilisateur

Sonnet

Sonnet Tempo Ultra ATA66 Manuel utilisateur

Adaptec

Adaptec AHA-3940UW/OF Manuel utilisateur

HighPoint

HighPoint RocketRAID 600L Manuel utilisateur

Tekram Technology

Tekram Technology DC-820B Manuel utilisateur

HighPoint

HighPoint RocketRAID 174x Manuel utilisateur

Adaptec

Adaptec AHA-2944UW Manuel utilisateur

ATTO Technology

ATTO Technology ATTO Celerity FC-81EN Manuel utilisateur

ATTO Technology

ATTO Technology UL4D PCI Manuel utilisateur

IBM

IBM System Storage DS4000 Manuel utilisateur
