HP 4400 Enterprise Manuel utilisateur

HP 4400 Enterprise Virtual Array Installation

Guide

Abstract

This guide describes how to install the HP 4400 Enterprise Virtual Array (EVA4400) and is intended for users with knowledge

of storage area networks and basic operating system commands and utilities.

The EVA4400 is customer self installable. However, you may purchase installation service by an HP-authorized service provider

if preferred. For more information, contact HP technical support in North America at 1-800-474-6836. Outside North America,

call HP technical support at the nearest location. Telephone numbers for worldwide technical support are listed on the HP

website: http://www.hp.com/support.

To assist you in installing the EVA4400, videos of the procedures have been produced. Go to the Services Media Library

website: http://www.hp.com/go/sml and navigate to your product to view these videos.

HP Part Number: 5697-1146

Published: September 2011

Edition: 8

Confidential computer software. Valid license from HP required for possession, use, or copying. Consistent with FAR 12.211 and 12.212, Commercial

Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under

vendor's standard commercial license.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express

warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall

not be liable for technical or editorial errors or omissions contained herein.

WARRANTY STATEMENT: To obtain a copy of the warranty for this product, see the warranty information website:

http://www.hp.com/go/storagewarranty

Microsoft®, Windows®, Windows® XP, and Windows NT® are U.S. registered trademarks of Microsoft Corporation.

UNIX® is a registered trademark of The Open Group.

Printed in Puerto Rico

Contents

1 Review and confirm your plans.....................................................................5

Overview................................................................................................................................5

Prerequisites.............................................................................................................................5

Plan your storage configuration..................................................................................................5

System and performance expectations....................................................................................6

RAID levels.........................................................................................................................6

HP P6000 Command View implementation..................................................................................7

2 Prepare your site........................................................................................8

Overview................................................................................................................................8

Provide adequate structural support for the floor...........................................................................8

Provide adequate clearance space and ventilation........................................................................8

Provide adequate and redundant sources of power.......................................................................9

Remove product from packaging.................................................................................................9

3 Install components....................................................................................10

Overview..............................................................................................................................10

Rack installation best practices.................................................................................................10

Attach the brackets for a longer chassis.....................................................................................11

Converting the rails.................................................................................................................12

Attach the rails.......................................................................................................................12

Install the enclosures...............................................................................................................14

Installing the hard drives into the drive bays...............................................................................16

Installing SFPs........................................................................................................................17

4 Connect cables and power cords...............................................................18

Overview..............................................................................................................................18

Cabling best practices.............................................................................................................18

Connecting the Fibre Channel cables........................................................................................18

Connecting device port Fibre Channel cables to the EVA (rear view).........................................18

Connecting Fibre Channel cables to the EVA (front end)..........................................................19

Connecting cables to an HSV300-S controller enclosure (front end)..........................................19

Labeling cables using labeling kit........................................................................................19

Connecting the power cords....................................................................................................19

5 Turn on power..........................................................................................20

Power on the devices...............................................................................................................20

Verify the operating status of the EVA........................................................................................20

Verify the operating status of the disk enclosures.........................................................................21

Verify the operating status of the Fibre Channel switches and adapters..........................................22

Installing Fibre Channel drivers.................................................................................................22

Configuring the embedded switch in an HSV300-S controller.......................................................22

Verify the operating status of the servers....................................................................................24

6 Connecting to the management module......................................................25

Overview..............................................................................................................................25

Connecting to the management module.....................................................................................25

Connecting through a public network...................................................................................25

Connecting through a private network..................................................................................26

Accessing HP P6000 Command View on the management module...............................................27

Changing the default operating mode.......................................................................................27

Accessing the HP P6000 Control Panel through HP P6000 Command View...................................28

Contents 3

7 Configuring servers using HP P6000 SmartStart...........................................29

Configuring management servers using HP P6000 SmartStart.......................................................29

Configuring application servers for Windows using HP P6000 SmartStart......................................29

8 Using and monitoring your storage.............................................................30

Using your storage.................................................................................................................30

Firmware recovery .................................................................................................................30

HP Insight Remote Support software..........................................................................................30

9 Support and other resources......................................................................31

Contacting HP........................................................................................................................31

HP technical support..........................................................................................................31

Subscription service............................................................................................................31

Documentation feedback....................................................................................................31

Related information.................................................................................................................32

Documents........................................................................................................................32

HP websites......................................................................................................................32

Typographic conventions.........................................................................................................33

Customer self repair................................................................................................................33

Rack stability..........................................................................................................................34

Location of WWN and serial number........................................................................................34

A EVA4400 cabling diagrams......................................................................36

Connecting device port Fibre Channel cables to the EVA4400 (rear view)......................................36

Connecting Fibre Channel cables to the EVA4400 (front end).......................................................37

Connecting to the HSV300-S controller enclosure........................................................................39

4 Contents

1 Review and confirm your plans

Overview

Before installing the EVA, HP recommends that you:

•Develop an installation and configuration plan for your environment.

•Review all videos and documentation.

•Determine if the EVA will be fabric-attached (connected to Fibre Channel switch) or

direct-attached (connected to Fibre Channel adapter in server). The EVA4400 is factory

configured for fabric-attached. To change to direct-attached mode, see “Connecting to the

management module” (page 25).

NOTE: Models of the EVA4400 with an embedded switch (also known as the HSV300-S

controller) are configured in fabric-attach mode and must remain fabric-attached.

Prerequisites

Prerequisites for using this product include:

•A Fibre Channel switch installed in your environment

•An equipment cabinet suitable for 2U sized enclosures

•A management server running Windows for HP P6000 Command View software (server-based

management)

•A management module running HP P6000 Command View software (array-based management)

•A CD-ROM drive attached to either the management server or the server attached to the

management module

Plan your storage configuration

Proper planning of the system storage and its subsequent performance is critical to a successful

deployment of the EVA. Improper planning or implementation can result in wasted storage space,

degraded performance, or inability to expand the system to meet growing storage needs. Planning

considerations include:

•System and performance expectations

•Striping methods

•RAID levels

•Hard drive sizes and types

•Spare drives

•Array sizing (capacity)

NOTE: For the minimum supported configuration, and other configuration information, see the

QuickSpecs document at: http://www.hp.com/go/eva4400

Overview 5

System and performance expectations

To help determine the best way to configure your storage, rank the following three storage

characteristics in order of importance:

•Fault tolerance (high availability)

•I/O performance

•Storage efficiency

With your priorities established, you can determine which striping method and RAID level to use.

As highlighted in the following section, some configuration methods offer greater fault tolerance,

while other configuration methods offer better I/O performance or storage efficiency.

RAID levels

Vraid is the HP term for the implementation of RAID (Redundant Array of Independent Disks) storage.

Vraid is also referred to as redundancy in HP management software. Virtual disks with HP Vraid

use three key RAID methods: data striping, data mirroring, and parity error checking. Unlike

traditional RAID, all HP Vraid levels distribute data across all available physical disks.

Data striping improves speed by performing virtual disk I/O with an entire group of physical disks

at the same time. Mirroring provides data redundancy by storing data and a copy of the data.

Parity also provides data redundancy by storing data and the calculated parity for each stripe of

data. If a subset of the data on a physical disk becomes corrupt or the entire physical disk fails,

the data can be automatically recovered from redundancy so that data loss does not occur.

The EVA has four Vraid types: Vraid0, Vraid1, Vraid5, and Vraid6. Each Vraid type provides

unique I/O speed and has a different level of data redundancy, which directly effects the amount

of physical space used. Once a virtual disk is created, the Vraid type or level cannot be changed.

See Table 1 (page 6) for a comparison of the different RAID levels.

Table 1 Raid Level Comparison

RAID methodData redundancyBest practicesSummary

StripingNoneIMPORTANT: HP does not

recommend using Vraid0 for virtual

Vraid0 is optimized for I/O

speed and efficient use of

Vraid0

disks when high availability isphysical disk capacity, but

provides no data redundancy. required. Consider Vraid0 only for

noncritical storage. Vraid0 virtual

disks provide the best performance

for applications that use random I/O.

Striping and

mirroring

HighIn general, Vraid1 virtual disks

provide better performance

Vraid1 is optimized for data

redundancy and I/O speed,

Vraid1

characteristics over a wider range of

application workloads than Vraid5.

but uses the most physical disk

space.

IMPORTANT: Vraid1 uses

about 100% more physical

disk space than Vraid0.

Striping and

parity

MediumVraid5 virtual disks provide as good

or better performance than Vraid1

Vraid5 provides a balance of

data redundancy, I/O speed,

Vraid5

for applications that use sequentialand efficient use of physical

writes. Vraid5 has much lowerdisk space. Vraid5 uses about

random write performance in20% more physical disk space

than Vraid0. comparison to Vraid1, but has much

higher capacity efficiency.

Striping and

double parity

Very highPerformance characteristics of Vraid6

for random and sequential write

Vraid6 is similar to Vraid5, but

provides a higher level of

Vraid6

workloads will be slightly slower thanredundancy by storing two

Vraid5. Vraid6 provides the highestparity blocks per stripe instead

6 Review and confirm your plans

Table 1 Raid Level Comparison (continued)

RAID methodData redundancyBest practicesSummary

of one. Vraid6 uses 33% more

physical disk space than

Vraid0.

level of redundancy protection of all

the Vraid types.

NOTE: For best practice information, see the HP 4400 Enterprise Virtual Array configuration

best practices white paper available at:

http://h18006.www1.hp.com/storage/arraywhitepapers.html?jumpid=reg_R1002_USEN

HP P6000 Command View implementation

HP P6000 Command View can be implemented in two ways:

•Server-based management—HP P6000 Command View is installed on a management server

connected to the EVA, providing management of multiple HP EVA storage systems. All

components of the software suite (HP P6000 Command View, HP Command View EVAPerf,

HP Storage System Scripting Utility, SMI-S EVA) are installed. Server-based management is

applicable to all EVA models.

•Array-based management—Beginning with HP Command View EVA 8.1, the EVA4400 is

shipped with HP P6000 Command View pre-installed on the management module within the

controller enclosure. Only one component of the software suite (HP P6000 Command View)

is installed. Array-based management is applicable to the EVA4400 only.

HP P6000 Command View implementation 7

2 Prepare your site

Overview

Preparing your site means providing:

•Physical rack space for the equipment

•AC power for the EVA

•Proper ventilation and temperature conditions

•LAN or Fibre Channel cables to attach the EVA hardware to your network.

To ensure continuous, safe, and reliable operation of your equipment, place your system in an

approved environment.

Consider using the HP Enterprise Configurator (eCO) to help plan and configure racks and

rack-mountable devices. The eCO is available on the HP website:

http://h30099.www3.hp.com/configurator

Click Configure under Disk products.

Provide adequate structural support for the floor

Calculate the total weight of your equipment and verify that your site can support the weight.

Provide adequate clearance space and ventilation

Be sure to provide adequate clearance around the front and back of the racks. Provide at least

25 inches (63.5 cm) in the front of the rack to allow the doors to open fully and provide at least

30 inches (76.2 cm) in the rear of the rack to allow for servicing and airflow.

If there are unused spaces in your rack, attach blanking panels across those empty spaces to force

the airflow through the components instead of through the open spaces.

8 Prepare your site

Provide adequate and redundant sources of power

Make sure that you have two high-line power feeds installed near your computer. These two power

sources usually come from the same external power grid, but occasionally may originate from

different grids or even entirely different sources.

For protection against a power-source failure, obtain and include two uninterruptible power supplies

in your installation.

For power consumption specifications, see the QuickSpecs document at:

http://www.hp.com/go/eva4400

Remove product from packaging

1. Remove product from boxes.

2. Verify that contents match your expectations and site requirements.

•EVA4400 controller enclosure should contain:

One 2U controller enclosure with two HSV300 or HSV300–S controller modules,

two power supply modules, two fan modules, and two battery modules installed.

◦

◦Rack mounting hardware

◦Two 2.0 meter FC copper cables

◦Two power cords

◦Installation documentation

◦XCS controller software recovery CD

•Each FC disk shelf should contain:

◦One 2U M6412 disk enclosure, two power supply modules, two fan modules, and

two battery modules.

◦Rack mounting hardware kit

◦Two 0.41 meter FC copper cables

◦Two power cords

3. Inspect for damage.

If damage is present, contact your local HP representative.

Provide adequate and redundant sources of power 9

3 Install components

Overview

Component installation includes:

•Rail kits

•Controller and disk enclosures

•Disk drives

NOTE: If you have ordered the factory integrated product, skip this chapter and go to “Turn on

power” (page 20).

Rack installation best practices

In addition to industry-standard recommendations, consider the following:

•Locate the heaviest items, such as uninterruptable power supplies (UPS) and additional disk

enclosures near the bottom of the rack.

•To make cabling easy, install the disk enclosures below the controller enclosure.

•Install similar components next to each other in the rack. Because enclosures, switches, and

servers are of differing depths, if you have more than one of a device, mount those devices

adjacent to one another to accommodate working behind the rack.

WARNING! To reduce the risk of personal injury or damage to the equipment, be sure that:

•At least two people lift the storage system during removal or installation, if the weight, exceeds

22.7 kg (50 lb). If the system is being loaded into the rack above chest level, a third person

MUST assist with aligning the system with the rails while the other two people support the

weight of the system.

•The leveling jacks on the rack are extended to the floor.

•The full weight of the rack rests on the leveling jacks.

•The stabilizing feet are attached to the rack if it is a single-rack installation.

•The racks are coupled together in multiple-rack installations.

•Only one component in a rack is extended at a time. A rack may become unstable if more

than one component is extended.

•To prevent damage and to ease insertion of the device into the rack, support the weight of

the device and keep it level when sliding it into the rack.

Review Figure 1 (page 11) before installing the EVA components in the rack.

10 Install components

Table des matières

Autres manuels HP Système de disques

HP StorageWorks XP12000 Mode d'emploi

HP StorageWorks MSA 1000 Guide de démarrage rapide

HP StorageWorks Series Manuel utilisateur

HP XP20000/XP24000 Manuel utilisateur

HP StorageWorks XP12000 Mode d'emploi

HP StorageWorks MSA 1000 Manuel utilisateur

HP StorageWorks XP128 Manuel utilisateur

HP StorageWorks XP48 - Disk Array Manuel utilisateur

HP StorageWorks P2000 Mode d’emploi

HP StorageWorks 2000fc - G2 Modular Smart Array Manuel utilisateur

HP STORAGEWORKS XP24000 Manuel utilisateur

HP StorageWorks XP12000 Manuel utilisateur

HP STORAGEWORKS XP20000 Manuel utilisateur

HP Compaq Presario,Presario 4400 Instructions d'utilisation

HP A3550A - High Availability Disk Arrays Model 20 Storage... Manuel utilisateur

HP StorageWorks 2000sa Instructions d'utilisation

HP STORAGEWORKS XP24000 Manuel utilisateur

HP StorageWorks XP128 Manuel utilisateur

HP XP20000/XP24000 Manuel utilisateur

HP P2000 G3 Manuel utilisateur

HP XP20000/XP24000 Manuel utilisateur

HP StorageWorks XP128 Manuel utilisateur

HP StorageWorks XP1024 Guide rapide

HP StorageWorks XP512 - Disk Array Manuel utilisateur

Manuels Système de disques populaires d'autres marques

Fujitsu

Fujitsu ETERNUS DX60 S2 Manuel utilisateur

Accom

Accom WSD/2XTREME Manuel utilisateur

ATTO Technology

ATTO Technology Diamond Storage Array V-Class Manuel utilisateur

National Instruments

National Instruments RMX-8268 Manuel utilisateur

Overland Tandberg

Overland Tandberg SnapServer DX1 Manuel utilisateur

easyRAID

easyRAID Q08QA-2GR2 Manuel utilisateur

NEC

NEC NF2300-SR412E Manuel utilisateur

EMC

EMC iomega StorCenter px12-350r Manuel utilisateur

Infortrend

Infortrend EonStor A08U-C2411 Manuel utilisateur

SE Audiotechnik

SE Audiotechnik M-F3 Manuel utilisateur

Buffalo

Buffalo HD-QHU3R5 Manuel utilisateur

Addonics Technologies

Addonics Technologies Z4SN25NML Manuel utilisateur

G-Technology

G-Technology G-RAID2 Manuel utilisateur

Bosch

Bosch DVA-16K SCSI Manuel utilisateur

easyRAID

easyRAID ERQ12+U4R2 Instructions d'utilisation

easyRAID

easyRAID X6P U3R2 Manuel utilisateur

CRU

CRU DataPort 25 USB-to-Dual SATA Manuel utilisateur

Seagate

Seagate Lyve Mobile Array Manuel utilisateur
