LSI SAS RAID Host Bus Adapter

installation

Introduction

This document describes how to install an LSI 9212–4i Serial Attached SCSI (SAS) Redundant Array of

Independent Disks (RAID) Host Bus Adapter (HBA) in HP Z series Workstations. Procedures are included

for drives mounted in internal hard drive bays and external drive bays.

Kit contents

●LSI SAS 9212–4i RAID HBA (RAID controller card)

●SAS driver CD

●4x SATA cable extender (for HP Z620 Workstation only)

●Hard drive activity LED cable

●Warranty information

●Installation instructions (this document)

Before you begin

To view QuickSpecs and determine the compatibility of this product with your HP workstation, see

http://www.hp.com/go/productbulletin.



405023-007

Warnings and cautions

WARNING! Any surface or area of the equipment marked with this symbol indicates the

presence of a hot surface or hot component. If this surface is contacted, the potential for injury exists.

To reduce the risk of injury from a hot component, enable the surface to cool before touching.

WARNING! Any surface or area of the equipment marked with this symbol indicates the

presence of an electrical shock hazard. To reduce the risk of injury from electrical shock, do not open

any enclosed area marked with this symbol.

WARNING! To reduce the risk of electric shock or damage to your equipment:

— Do not disable the power cord grounding plug. The grounding plug is an important safety feature.

— Plug the power cord in a grounded (earthed) outlet that is easily accessible at all times.

— Disconnect power from the equipment by unplugging the power cord from the electrical outlet.

WARNING! To reduce the risk of serious injury, read the Safety & Comfort Guide. It describes

proper computer setup, posture, health, and work habits for computer users, and provides important

electrical and mechanical safety information. This guide is located at http://www.hp.com/ergo and on

the documentation CD (if one is included with the product).

WARNING! If a product is shipped in packaging marked with this symbol, , the product must

always be lifted by two persons to avoid personal injury due to product weight.

CAUTION: Static electricity can damage the electronic components of the computer. Before

beginning these procedures, be sure you discharge static electricity by briefly touching a grounded

metal object.

CAUTION: To prevent damage to the computer, observe the following Electrostatic Discharge (ESD)

precautions while performing the system parts removal and replacement procedures:

— Work on a static-free mat.

— Wear a static strap to ensure that any accumulated electrostatic charge is discharged from your

body to the ground.

— Create a common ground for the equipment you are working on by connecting the static-free mat,

static strap, and peripheral units to that piece of equipment.

NOTE: HP accessories are for use in HP computer products. They have been extensively tested for

reliability and are manufactured to high quality standards.

2 LSI SAS RAID Host Bus Adapter installation

Step 1—Preparing for component installation

NOTE: Computer models vary. All illustrations are examples only.

Download and install updates

1. Check for available system BIOS updates specified for your HP computer model and operating

system at http://www.hp.com/support.

2. Install the system BIOS updates, if available.

Accessing the internal components of the computer

1. If you need help preparing the computer for this installation, refer to the

●Removal and replacement procedures in the Maintenance and Service Guide for your

computer at http://www.hp.com/support/computer manuals, or

●Removal and Replacement videos for your computer at http://www.hp.com/go/sml.

2. Power down the computer, and then disconnect the power cord.

3. Power down all external devices, and then disconnect them from the computer.

4. Remove the side access panel.

Step 2—Installing the RAID controller card

1. If present, remove the card support to enable access to the expansion slots and system board

connectors.

2. Select an unused PCI Express (PCIe) x4, x8, or x16 expansion slot on the system board. The

9212-4i RAID controller card must be installed in a higher performance slot.

NOTE: To identify an available PCIe expansion slot, see the service label on the side access

panel.

3. Install the RAID controller card into the selected slot on the system board. Verify that the keyed

components of the card align with the slot.

Figure 1 Placing the RAID controller card in the expansion slot

Step 1—Preparing for component installation 3

Step 3—Configuring the cabling

The RAID controller card may be used to control hard drives located in the internal and external drive

bays.

The data cable connections for RAID controller cards differ between workstation models. To determine

the correct connection for your hard drives, identify the applicable HP workstation model and the

location of the hard drive being connected in the following table. To connect existing hard drives,

disconnect the existing data cables from the system board and choose the correct connection type.

The hard drive LED cable connection is similar for most HP workstation models.

Table 1 Data cable configuration guide

HP workstation

model

Location of hard drive Connection type Description

HP Z400 and Z420

Workstations

●Internal hard drive bay

●External drive bay

Connecting standard data

cables on page 7

Use the data cable provided with

the hard drive to connect the hard

drive to the RAID controller card.

For SAS drives, refer to specific

instructions on data cabling and

adapter types in Connecting

standard data cables

on page 7.

HP Z600 and Z620*

Workstations

●Internal hard drive bay Connecting pre-installed

data cables on page 5

The pre-installed data cables from

the internal hard drives are

disconnected from the system

board and connected to the

appropriate port connectors on the

RAID controller card in Connecting

pre-installed data cables

on page 5.

HP Z600 and Z620*

Workstations

●External drive bay Connecting standard data

cables on page 7

Use the data cable provided with

the hard drive to connect the hard

drive to the RAID controller card.

For SAS drives, refer to specific

instructions on data cabling and

adapter types in Connecting

standard data cables

on page 7.

IMPORTANT: * The HP Z620 Workstation requires use of the provided 4x SATA cable to extend the data cable length.

Attach the 4x SATA cable extender to the RAID controller card, then connect the internal hard drive bay data cables or the

external drive bay cable to the appropriate port on the other end of the 4x SATA cable.

4 LSI SAS RAID Host Bus Adapter installation

Connecting pre-installed data cables

HP Z600 and HP Z620 Workstations have internal hard drive bay data cables pre-installed on the

system board. For workstations with this cabling configuration, use the following procedure to connect

internal hard drives to the RAID controller card.

1. Locate and disconnect the hard drive cables from the system board.

Figure 2 Reconnecting the data cables to the RAID controller card (1 of 2)

Figure 2 Reconnecting the data cables to the RAID controller card (2 of 2)

Step 3—Configuring the cabling 5

2. Connect the data cables to the corresponding ports on the RAID controller card, as shown in

Figure 3 SAS/SATA data ports and hard drive LED connector on page 6. For the HP Z620

Workstation, refer to Table 1* instructions on the required use of the 4x SATA cable extender to

lengthen the data cabling.

Figure 3 SAS/SATA data ports and hard drive LED connector

3. Continue with Connecting the hard drive LED activity indicator on page 9.

Figure 4 RAID controller card and 4x SATA cable extender

6 LSI SAS RAID Host Bus Adapter installation

Connecting standard data cables

External hard drives installed in HP Z400 and HP Z420 Workstations do not have cabling preinstalled

on the system board. To connect the RAID controller card cabling for these configurations:

1. If connecting a SAS hard drive, ensure that there is a SAS-to-SATA adapter or SAS-to-SATA cable

(included with the HP workstation SAS hard drive kit) attached to the data connector on the SAS

hard drive. Figure 5Attaching the SAS-to-SATA adapter or SAS-to-SATA cable on page 7

shows examples of adapter types A and B.

Figure 5 Attaching the SAS-to-SATA adapter or SAS-to-SATA cable

2. For adapter types A and B, select the required data cable for the workstation from those shipped

with the hard drive.

Table 2 SAS-to-SATA adapter and data cable options

Adapter

type

Work-

station

Hard drive

bay use

Cabling with adapter installed

AHPZ400

HP Z420

HP Z600

HP Z620*

HP Z800

HP Z820

External drive

bays

Use straight connector to straight connector data cable. Plug the end of the

data cable into port 0 of the RAID controller card; and plug in opposite end

of the data cable into the adapter.

BHPZ400

HP Z420

Internal hard

drive bays

Plug in portion (2) of the SAS-to-SATA cable into the hard drive; plug in

portion (1) of the SAS-to-SATA cable into port 0 on the RAID controller card;

plug in portion (3) of the SAS-to-SATA cable into SATA power source from

the power supply, as shown in Figure 6Attaching the data cable

on page 8.

IMPORTANT: * For the HP Z620 Workstation: refer to Table 1 Data cable configuration guide on page 4 instructions

on the required use of the 4x SATA cable to extend the data cabling length.

Step 3—Configuring the cabling 7

Figure 6 Attaching the data cable

3. Attach any subsequent hard drives to ports 1 through 3 on the RAID controller card as shown in

Figure 3 SAS/SATA data ports and hard drive LED connector on page 6.

4. Continue with Connecting the hard drive LED activity indicator on page 9.

8 LSI SAS RAID Host Bus Adapter installation

Connecting the hard drive LED activity indicator

This section applies to all HP workstations previously listed.

Attach one end of the hard drive LED cable to the RAID controller card LED port (L) as shown in Figure

7RAID controller card with hard drive LED connector on page 9. The LSI SAS 9212-4i hard drive

LED cable is a 4-to-2 pin connector style. The RAID controller card connection is illustrated in Figure 7

RAID controller card with hard drive LED connector on page 9.

Figure 7 RAID controller card with hard drive LED connector

Attach the other end of the hard drive-LED cable to the hard drive LED activity connector on the system

board, as shown in Figure 8Attaching the hard drive LED cable on page 9. (An HP Z600 series

Workstation system board is shown for reference in Figure 8Attaching the hard drive LED cable

on page 9.)

NOTE: To locate the hard drive LED activity connector on the system board, see the service label

inside the workstation side access panel. Use the hard drive LED cable appropriate for the workstation.

Figure 8 Attaching the hard drive LED cable

Step 3—Configuring the cabling 9

Step 4—Reassembling the workstation

1. Reinstall the card support, if applicable.

2. Reinstall the side access panel.

3. Reconnect power to the workstation and all external devices.

4. Restore power to the workstation and all external devices.

Step 5—Loading and setting up driver software

For instructions on loading and setting up the drivers for use with your workstation, see the

manufacturer’s documentation shipped with the RAID controller card.

At the time of component installation, look for device firmware and driver updates, designated for your

workstation model and operating system. Obtain updates from http://www.hp.com/go/

workstationsupport.

Step 6—Configuring RAID devices

For detailed instruction on configuring RAID devices, see the service guide for your HP workstation

model at http://www.hp.com/support/workstation_manuals.

Additional information is available at http://www.hp.com/support/RAID_FAQs.

Japanese 日本語

This document is available in Japanese. See http://www.hp.com/support/workstation_manuals, then

select your workstation product and select Japanese from the drop down Manual Language

menu.

このドキュメントは日本語版が用意されています。http://www.hp.com/support/

workstation_manuals にアクセスし、ご使用のワークステーション製品を選択し、Manual Language

ドロップダウンメニューから Japanese を選択してください。

10 LSI SAS RAID Host Bus Adapter installation

Autres manuels pour Z420 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HP Ordinateur de bureau

HP TouchSmart IQ700 - Desktop PC Mode d’emploi

HP 9000 715/64 Manuel utilisateur

HP Workstation Z600 Manuel utilisateur

HP Vectra VL6 7 Manuel utilisateur

HP Z600 - Workstation - 6 GB RAM Guide de référence

HP 1028705233 Manuel utilisateur

HP BladeSystem Blade Enclosure Instructions de montage

HP Compaq SP700 Manuel utilisateur

HP Model 745i - Workstation Manuel utilisateur

HP Pavilion p7-1200 Manuel d'utilisation et d'entretien

HP 280 Pro G3 Instructions d'installation

HP 200 G1 Microtower Manuel utilisateur

HP Compaq dx2390 Instructions d'utilisation

HP Vectra XM 5/xxx - 3 Manuel utilisateur

HP Pavilion t490 Instructions d'installation

HP Compaq dc7700 DT Manuel d'installation et d'exploitation

HP Pavilion Slimline s7300 - Desktop PC Comment utiliser

HP dc7900 - Convertible Minitower PC Mode d’emploi

HP Agent-Desktop-Laptop Computer Manuel utilisateur

HP Vectra XU6 Manuel utilisateur

HP Z400 - Workstation Manuel utilisateur

HP Pavilion t200 - Desktop PC Instructions d'installation

HP dx2200 - Microtower PC Manuel utilisateur

HP Pavilion v400 - Desktop PC Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Dell

Dell Alienware Area-51 R4 Manuel utilisateur
