HP Xw9400 Instructions d'utilisation

HP recommends Windows Vista

Business

Monitor (sold separately)

1 PCI, 2 PCI-X slots, 2 PCI Express x8 slots

Standard Keyboard (USB or PS/2)

2 PCI Express x16 Graphics slots

Mouse (USB or PS/2)

Dual-Core AMD Opteron™ Processors 2200 series

Front IO: 2 USB 2.0, IEEE-1394 (standard), headphone and

microphone

10.

8 DIMM slots for DDR2 memory

5.25" external bay for optional diskette drive, optical drive or

additional 5.25"/3.5" device

11.

6 USB 2.0, 1 standard serial port, 1 IEEE 1394, 2 PS/2, 2 RJ-

45, SPDIF out, audio in/out, microphone

5 internal 3.5" bays, 3 external 5.25" bays 12.

1050 w 80+ power supply

QuickSpecs

HP xw9400 Workstation

Overview

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 1

Processors

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

Quad-Core AMD Opteron™ 2300 Series Processors with AMD64 and AMD Virtualization

Quad-Core AMD Opteron 2378/ 2.4 GHz, 512 KB L2 cache per

core, 6MB shared L3

Y Y

FZ810AA

Quad-Core AMD Opteron 2380/ 2.5 GHz, 512 KB L2 cache per

core, 6MB shared L3

Y Y

FZ811AA

Quad-Core AMD Opteron 2387/ 2.8 GHz, 512 KB L2 cache per

core, 6MB shared L3

Y Y

NH256AA

Quad-Core AMD Opteron 2389/ 2.9 GHz, 512 KB L2 cache per

core, 6MB shared L3

Y Y

NT236AA

Quad-Core AMD Opteron 2393SE/ 3.1 GHz, 512 KB L2 cache

per core, 6MB shared L3 (AVAILABLE JUNE 2009)

Y Y

Dual-Core AMD Opteron Processor 2200 Series

AMD Opteron Processor Model 2220 / 2.80 GHz, 1 MB L2

cache per core

Y Y

RC403AA

AMD Opteron Processor Model 2222 / 3.0 GHz, 1 MB L2 cache

per core

Y Y

RM697AA

6-Core AMD Opteron™ 2400 Series Processors with AMD64 and AMD Virtualization

AMD Opteron Processor Model 2427 2.2GHz with 2.4GHz

AMD HyperTransport™ bus 6 MB L3 cache

Y Y

NY129AA

AMD Opteron Processor Model 2431 2.4GHz with 2.4GHz

AMD HyperTransport™ bus 6 MB L3 cache

Y Y

NY130AA

AMD Opteron Processor Model 2435 2.6GHz with 2.4GHz

AMD HyperTransport™ bus 6 MB L3 cache

Y Y

NY131AA

Dual- and Quad-Core are new technologies designed to improve performance of multithreaded software

products and hardware-aware multitasking operating systems and may require appropriate operating

system software for full benefit. Not all customers or software applications will necessarily benefit from

use of this technology.

AMD's numbering is not a measurement of clock speed.

Actual bus clock rate is less for the 1 GHz AMD HyperTransport technology. Listed bus speed represents

the effective data transfer rate.

QuickSpecs

HP xw9400 Workstation

Supported Components

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 2

Memory

Configure To Order (CTO)

Support Notes

PC2-5300 (DDR2-667 MHz) Memory Configurations

HP 1GB (2x512) DDR2-667 ECC reg SingProc

HP 2GB (2x1GB) DDR2-667 ECC reg SingProc

HP 4GB (4x1GB) DDR2-667 ECC reg SingProc

HP 4GB (2x2GB) DDR2-667 ECC reg SingProc

HP 8GB (4x2GB) DDR2-667 ECC reg SingProc

HP 2GB (4x512MB) DDR2-667 ECC reg

HP 4GB (4x1GB) DDR2-667 ECC reg

HP 6GB (4x1GB+4x512) DDR2-667 ECC reg

HP 8GB (8x1GB) DDR2-667 ECC reg

HP 12GB (4x2+4x1) DDR2-667 ECC reg

HP 16GB (4x4GB) DDR2-667 ECC reg

HP 16GB (8x2GB) DDR2-667 ECC reg

HP 32GB (8x4GB) DDR2-667 ECC reg

PC2-4200 (DDR2-533 MHz) Memory Configurations

HP 64GB (8x8GB) DDR2-533 ECC reg

Sub-Section Description/Notes

: Dual Channel is only supported when the system is configured with DDR2

symmetric memory (i.e. 2 x 256).

After Market Options (AMO)

Option Kit Part Number

PC2-5300 (DDR2-667 MHz) Memory Modules

HP 512MB (1x512MB) DDR2-667 ECC Reg RAM

EV281AA

HP 1GB (1x1GB) DDR2-667 ECC Reg RAM

EV282AA

HP 2GB (1x2GB) DDR2-667 ECC Reg RAM

EV283AA

HP 4GB (1x4GB) DDR2-667 ECC Reg RAM

GY414AA

PC2-4200 (DDR2-533 MHz) Memory Modules

HP 8GB (1x8GB) DDR2-533 ECC Reg RAM

GT808AA

QuickSpecs

HP xw9400 Workstation

Supported Components

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 3

SAS Hard Drives

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP SAS (Serial Attached SCSI) Hard Drives for HP Workstations

146GB SAS 15K rpm 3Gb/s 3.5" HDD

Y Y

EA330AA

300GB SAS 15K rpm 3Gb/s 3.5" HDD

Y Y

EM174AA

450GB SAS 15K rpm 3Gb/s 3.5" HDD

Y Y

FM803AA

Sub-Section Description/Notes

: * NCQ (Native Command Queuing) not supported in Red Hat Enterprise

Linux

1 GB = 1 billion bytes. Actual formatted capacity is less. Up to 8 GB of hard drive (or system disk) is

reserved for system recovery software (XP and XP Pro). Up to 12 GB of system disk is reserved for system

recovery software (Vista).

SATA Hard Drives

SATA (Serial ATA) Hard Drives for HP Workstations

80GB SATA 7200 rpm 3Gb/s 3.5" HDD

Y Y

PY276AA

160GB SATA 7200 rpm 3Gb/s 3.5" HDD

Y Y

PV944A

250GB SATA 7200 rpm 3Gb/s 3.5" HDD (for HP xw-

Workstations)

Y Y

EA788AA

500GB SATA 7200 rpm 3Gb/s 3.5" HDD

Y Y

PV943A

1000GB (1TB) SATA 7200 rpm 3.0Gb/s 3.5" HDD

Y Y

GE262AA

80GB SATA 10K rpm SFF in 3.5" Frame HDD

Y Y

EM172AA

160GB SATA 10K rpm SFF in 3.5" Frame HDD

Y Y

EW222AA

300GB SATA 10K rpm SFF in 3.5" Frame HDD

Y Y

FM802AA

Sub-Section Description/Notes

: 1 GB = 1 billion bytes. Actual formatted capacity is less. Up to 8 GB of

hard drive (or system disk) is reserved for system recovery software (XP and XP Pro). Up to 12 GB of

system disk is reserved for system recovery software (Vista).

NOTE:

The RHEL3 U4 (x86) OS will operate correctly after some manual configuration steps. Please refer

to the Release Notes Chapter in

http://www.hp.com/support/linux_user_manual

QuickSpecs

HP xw9400 Workstation

Supported Components

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 4

Hard Drive Controllers

Factory

Configured

Option Kit

Part

Number

Support Notes

Integrated SATA 3.0 Gb/s Controller, RAID 0, 1, 10,

5 supported

Y Y

Integrated LSI SAS 1068E Controller with RAID 0

(IS), RAID 1(IM), RAID 10(IME) capability

Y Y

Factory integrated RAID on motherboard for SATA drives

RAID 0 Data Configuration -- Boot/OS Drive + 2

Drive Striped Array

Y Y

4th HD Drive

can't be 750 GB.

5th HD Drive

can't be 500 GB

RAID 0 Configuration - Striped Array

Y Y

750 GB HD Drive

not supported.

3rd HD Drive can

not be 500 GB.

RAID 1 Configuration - Mirrored Array

Y Y

2 HD Drives only

LSI MegaRAID® SAS 8888ELP Host Bus Adapter (HBA)

LSI 8888ELP 8-port SAS HW RAID Card

Y Y

GE258AA

LSI RAID Definitions

* IS: Striping of 2 or more HDDs into a single logical volume

**IM: Mirroring of 2 HDDs into a single logical volume

***IME: Mirroring of 3 or more HDDs into a single logical volume

NOTE:

Specific user-configured hardware SAS RAID configurations are supported on this Linux system.

Please visit

http://www.hp.com/support/linux_hardware_matrix

for details.

NOTE:

RAID 0, 1 requires 2 identical hard drives (speeds, capacity, interface); SATA RAID 0, 1 and SAS RAID 0, 1

available as options. Specific user-configured hardware SAS RAID configurations are supported on this Linux

system. Please visit

http://www.hp.com/support/linux_hardware_matrix

for details.

Hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID, provides

excellent functionality and performance. It is a good alternative to hardware-based RAID. Please visit

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

for RAID

capabilities with Linux.

QuickSpecs

HP xw9400 Workstation

Supported Components

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 5

PCI Express Graphics

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

Supported

Multi

Mixed

Professional 2D

NVIDIA Quadro NVS 290 256 MB PCIe Graphics

Card with 'DMS-59 to Dual DVI cable' included –

for Workstations

Y Y

GN502AA

See

support

note 1

NVIDIA Quadro NVS 295 256MB PCIe Graphics

Card

Y Y

FY943AA

NVIDIA Quadro NVS 450 512 MB PCIe Graphics

Card

Y Y

FH519AA

Entry 3D

NVIDIA Quadro FX 580 512MB PCIe Graphics Card

Y Y

FY945AA

Mid-range 3D

NVIDIA Quadro FX 1800 768MB PCIe Graphics

Card

Y Y

FY946AA

High-end 3D

NVIDIA Quadro FX 3800 1.0GB PCIe Graphics Card

Y Y

FY949AA

NVIDIA Quadro FX 4800 1.5GB PCIe Graphics Card

Y Y

FQ138AA

NVIDIA Quadro FX 5800 4GB PCIe Graphics Card

Y Y

FZ559AA

NOTE:

To run the accelerated graphics driver on RHEL3 U4, download the latest driver. Please refer to the

Release Notes Chapter in

http://www.hp.com/support/linux_user_manual

Support note 1:

May use two graphics cards USING 1050W Power Supply. Some graphics card may not be

supported in dual configurations with older, 800W power supply. Must use matching graphics cards and

order a second processor.

Multimedia and Audio

Devices

Factory

Configured

Option Kit

Part

Number

Support

Notes

HP Thin USB Powered Speakers

Y Y

KK912AA

Integrated High Definition audio with internal speaker

Y Y

HP Satellite Speakers

Y Y

ZD929AA

QuickSpecs

HP xw9400 Workstation

Supported Components

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 6

Optical and Removable

Storage

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

1.44 MB Diskette Drive (1 only)

Y Y

DY670A

HP 16X DVD+-RW SuperMulti SATA Drive

Y Y

EW269AA

1, 2

HP 16X DVD-ROM SATA Drive

Y Y

EW268AA

HP 16-In-1 Media Card Reader with PCI Card

Y Y

EM718AA

HP StorageWorks DAT 40 USB internal tape drive

Y Y

DW022A

HP StorageWorks DAT 72 USB internal tape drive

Y Y

DW026A

HP StorageWorks DAT 160 USB internal tape drive

Y Y

Q1580A

SUPPORT NOTE 1

: LightScribe creates a grayscale image similar to black and white photography.

LightScribe media required and sold separately. Double-layer discs can store more data than single layer

discs. However, double-layer discs burned with this drive may not be compatible with many existing

single-layer DVD drives and players.

SUPPORT NOTE 2

: Actual speeds may vary. Does not permit copying of commercially available DVD movies

or other copy-right protected materials. Intended for creation and storage of your original material and

other lawful uses. Note that DVD-RAM cannot read or write to 2.6 GB single sided/5.2 GB double sided -

version 1.0 media.

Networking and

Communications

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

Integrated dual NVIDIA 10/100/1000 LAN

Y Y

The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit

Ethernet, and does not connote actual operating speed of 1 Gb/sec. For high speed transmission,

connection to a Gigabit Ethernet server and network infrastructure is required.

Controller Cards

Factory

Configured

Option Kit

Part

Number

Support

Notes

HP FireWire 800 IEEE-1394b 3-Port PCI Card

Y Y

EA327AA

(1-port

1394a &

2-ports

1394b)

QuickSpecs

HP xw9400 Workstation

Supported Components

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 7

Input Devices

Factory

Configured

Option Kit

Part

Number

Support

Notes

HP PS/2 Optical Scroll Mouse

Y Y

EY703AA

HP USB Laser Mouse

Y Y

GW405AA

HP USB Optical 3-Button Mouse

Y Y

DY651A

HP USB 2-Button Optical Scroll Mouse

Y Y

DC172B

HP USB Optical 3-Button 2.9M OEM Mouse

Y Y

ET424AA

HP SpacePilot 3D USB Intelligent Controller

Y Y

EF390AA

HP USB Standard Keyboard

Y Y

DT528A

HP PS/2 Standard Keyboard

Y Y

DT527A

HP USB Smart Card Keyboard

Y Y

ED707AA

NOTE:

Mixing PS/2 and USB Keyboards and Mice are not supported with Linux OS.

Racking and Physical

Security

Factory

Configured

Option Kit

Part

Number

Support

Notes

HP xw8/9 PCI Hold Down Kit, Bulk 10 Pack

Y Y

EN764AA

HP Business PC Security Lock Kit

Y Y

PV606AA

Security Cable with Kensington Lock

Y Y

PC766A

HP xw8/9 Sliding Rail Rack Kit

Y Y

DY664A

Monitors

Factory

Configured

Option Kit

Part

Number

Support

Notes

HP LP3065 30-inch Widescreen LCD Monitor

Y Y

EZ320A4

HP LP2465 24-inch Widescreen LCD Monitor

Y Y

EF224A4

HP LP2065 20-inch LCD Monitor

Y Y

EF227A4

HP LP1965 19-inch LCD Monitor

Y Y

RA373AA

Other Hardware

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP Power Cord Kit

Y Y

DM293A

See Note

HP SAS Back Panel Connector Kit

Y Y

EM164AA

HP Internal USB Port Kit

Y Y

EM165AA

SUPPORT NOTE 1:

Use only Power Supply Cord supplied with the HP xw9400 workstation. This is a

specially rated power cord.

QuickSpecs

HP xw9400 Workstation

Supported Components

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 8

Software

Factory

Configured

Option Kit

Part

Number

Support

Notes

HP ProtectTools Security

Y Y

Microsoft Office 2007 Small Business Edition

Y Y

Microsoft Office 2007 Trial Edition

Y Y

HP Performance Tuning Framework

Y Y

PDF Complete

Y Y

HP Client Manager Software v6.2 (optional download)

Y Y

HP SkyRoom Software

Y Y

NG863AA

Available

9/22/09

Operating Systems

Support Notes

Genuine Windows Vista®

Business 64-bit

Certain Windows Vista product features require advanced or additional

hardware. See

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx

and

http://www.microsoft.com/windowsvista/getready/capable.mspx

for details.

Windows Vista Upgrade Advisor can help you determine which features of

Windows Vista will run on your computer. To download the tool, visit

http://www.windowsvista.com/upgradeadvisor

. (See para below which also

applies)

Genuine Windows Vista®

Business 32-bit

Certain Windows Vista product features require advanced or additional

hardware. See

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx

and

http://www.microsoft.com/windowsvista/getready/capable.mspx

for details.

Windows Vista Upgrade Advisor can help you determine which features of

Windows Vista will run on your computer. To download the tool, visit

http://www.windowsvista.com/upgradeadvisor

. (See para below which also

applies)

Genuine Windows Vista®

Business 64-bit with

downgrade to Windows®

XP Professional x64

custom installed

To qualify for this downgrade, an end user must be a business (including

governmental or educational institutions) and is expected to order at least 25

customer systems with the same custom image.

Genuine Windows Vista®

Business 32-bit with

downgrade to Windows®

XP Professional 32-bit

custom installed

To qualify for this downgrade, an end user must be a business (including

governmental or educational institutions) and is expected to order at least 25

customer systems with the same custom image.

Red Hat Enterprise Linux

WS 4 (32-bit/64-bit)

NOTE:

The RHEL3 U4 (x86) OS will operate correctly with most options after

some manual configuration steps. Please refer to the Release Notes Chapter

http://www.hp.com/support/linux_user_manual

HP Installer CD for Red Hat

Enterprise Linux WS 4

See

http://h20331.www2.hp.com/hpsub/cache/537200-0-0-225-121.html

QuickSpecs

HP xw9400 Workstation

Supported Components

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 9

System Board

Expansion Slots

2 PCI Express (PCIe) x16 75W+EXT75W (Graphics) slots

2 PCIe x16 (8,4,1) slots

Full-height PCI-X slots at 100 MHz, or 1 slot at 133 MHz, exclusive1 full-length PCI

Bays

Five 3.5 inch bays

Three 5.25 inch bays

Front I/O

4 ports: 2 USB 2.0, 1 headphone, 1 microphone, 1 IEEE 1394

Rear I/O

16 ports: 6 USB 2.0, 1 standard serial 9-pin port, 1 IEEE 1394, 1 PS/2 keyboard, 1 PS/2 mouse, 2 RJ-45 to

integrated Gigabit LAN, 1 Audio In, 1 Audio Line Out, 1 Mic In, S/PDIF OUT coax

USB Keyboard

Optional

USB Mouse

Optional

PS/2 Keyboard

PS/2 Mouse

Memory

Maximum Memory

Supports up to 64 GB of DDR2 SDRAM, in a configuration of 32 GB per processor (over 32 GB requires dual

CPUs and Quad Ranked DIMMS when supported).

NVIDIA Nforce Professional 3000 Series

DDR2 SDRAM ECC REGISTERED MEMORY

This chart does not represent all possible memory configurations. Each AMD Opteron processor has an

integrated memory controller that supports ECC Registered 667 MHz (PC2 5300P) DDR2 or ECC Registered

533 MHz (PC2 4200) DDR2 memory. Main memory is directly connected to the processor through the Direct

Connect Architecture. There are 8 DIMM slots in total, with 4 DIMM slots per processor, each processor

offering a memory bandwidth transfer rate up to 10.2 GB/s. Over 32 GB requires dual CPUs, and will require 8

GB DIMMS (when available)

Memory must be added in pairs. Match DIMM pairs by size and type. Use only HP tested and validated

memory

In a single processor configuration, install the first DIMM pair in socket set 1 (blue sockets), and the 2nd DIMM

pair in socket set 3 (black socket).

In a dual processor configuration, install the first DIMM pair in socket set 1 (blue sockets), the 2nd DIMM pair

in socket set 2 (blue sockets) and, if required, the 3rd pair in socket set 3 (black sockets) and the 4th pair in

socket set 4 (black sockets).

The memory sockets are laid out on the mainboard as below:

Memory configurations for the HP xw9400 Workstation:

QuickSpecs

HP xw9400 Workstation

System Technical Specifications

DA - 12594 Worldwide — Version 36 — September 1, 2010

Page 10

Autres manuels pour xw9400

Table des matières

Autres manuels HP Ordinateur de bureau

HP dc5100 - Microtower PC Guide de référence rapide

HP Pavilion w1100 - Desktop PC Manuel utilisateur

HP Pavilion p7-1200 Manuel d'utilisation et d'entretien

HP LSI MegaRAID SAS 9260-8i Manuel utilisateur

HP Xw4300 - Workstation - 2 GB RAM Instructions d'utilisation

HP Compaq dc5100 MT Manuel utilisateur

HP Workstation x4000 Manuel utilisateur

HP Pavilion t100 - Desktop PC Manuel d'utilisation et d'entretien

HP Pavilion a250 Instructions originales

HP Presario SR2000 - Desktop PC Manuel utilisateur

HP TouchSmart 9300 Elite Manuel utilisateur

HP Pavilion t100 - Desktop PC Manuel utilisateur

HP Workstation xw4100 Manuel

HP Compaq Presario Manuel utilisateur

HP Pavilion t468 Manuel utilisateur

HP TouchSmart 320-1100 Manuel utilisateur

HP Z1 G2 Manuel utilisateur

HP Compaq dx6050 MT Manuel d'utilisation et d'entretien

HP Compaq Presario CQ5000 PC Series Instructions d'installation

HP Pavilion 754 Instructions d'installation

HP HPTouchSmart610 Manuel utilisateur

HP Pavilion t100 - Desktop PC Manuel utilisateur

HP EliteDesk 705 G4 Manuel

HP Elite 7000 Microtower Instructions d'installation

Manuels Ordinateur de bureau populaires d'autres marques

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Dell

Dell Alienware Area-51 R4 Manuel utilisateur

HP xw9400 Instructions d'utilisation

Manuels Ordinateur de bureau populaires d'autres marques
