HP Xw6200 - Workstation - 2 GB RAM Instructions d'utilisation

Monitor (sold separately)

4 PCI, 1 PCI Express 8x prime slots

2004 Standard Keyboard

1 PCI Express x16 Graphics Bus

2-Button Scroll Mouse

6 USB 2.0, 1 standard serial port, 1 parallel port, 2 PS/2, 1 RJ-45,

audio in/out

Front IO: 2 USB 2.0, IEEE-1394 (requires optional PCI card to enable),

headphone and microphone

10.

Dual Intel® Xeon™ processors

3.5" external bay for optional diskette drive or other 3.5" device

11.

500 watt power supply

2 internal 3.5" bays, 2 external 5.25" bays

At A Glance

Choice of operating systems:

Microsoft Windows XP Professional

Red Hat Enterprise Linux Workstation 3

HP Linux Installer Kit (see

http://www.hp.com/workstations/software/linux/

for details)

Intel® Xeon™ processors with EM64T technology

Up to 8 GB of DDR-2 memory

PCI-Express I/O and graphics

Integrated Broadcom NetXtreme Gigabit ethernet

800 MHz processor front side bus support

Intel Hyper-Threading technology support

SATA and Ultra 320 SCSI drives

Digital AC97 integrated audio with internal speaker

Pre-loaded Manageability tools

Energy Star compliance with energy-saving features

Protected by HP Services, including a 3-3-3 standard warranty. Terms and conditions vary by country. Certain restrictions and exclusions

apply.

QuickSpecs

HP Workstation xw6200

Overview

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 1

Processor and Speed

–

One of the following

Intel Xeon Processor

with 800 MHz Front Side Bus, 1 MB L2 cache

2.8 GHz

3.0 GHz – available in Fall 2004

3.2 GHz

3.4 GHz

3.6 GHz

2nd Intel Xeon Processor

with 800 MHz Front Side Bus, 1 MB L2 cache

2.8 GHz

3.0 GHz – available in Fall 2004

3.2 GHz

3.4 GHz

3.6 GHz

Operating System

–

One of the following

Microsoft Windows XP Professional

Red Hat Enterprise Linux Workstation 3 32-bit version (Update 2 in 32- and 64-bit available as aftermarket option)

HP Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions)

1st Hard Disk Drive

–

One of the following

40 GB 7200 rpm Serial ATA drive (2 MB cache)

80 GB 7200 rpm Serial ATA drive (8 MB cache)

160 GB 7200 rpm Serial ATA drive (8 MB cache)

250 GB 7200 rpm Serial ATA drive (8 MB cache)

400 GB 7200 rpm Serial ATA drive (8 MB cache) – available in Winter 2004

36 GB 10K rpm Serial ATA drive (8 MB cache)

74 GB 10K rpm Serial ATA drive (8 MB cache)

73 GB 10K Ultra320 SCSI drive

300 GB 10K Ultra320 SCSI drive

36 GB 15K Ultra320 SCSI drive

73 GB 15K Ultra320 SCSI drive

146 GB 15K Ultra320 SCSI drive

2nd Hard Disk Drive

–

One of the following

2nd hard drive, 40 GB 7200 rpm Serial ATA drive (2 MB cache)

2nd hard drive, 80 GB 7200 rpm Serial ATA drive (8 MB cache)

2nd hard drive, 160 GB 7200 rpm Serial ATA drive (8 MB cache)

2nd hard drive, 250 GB 7200 rpm Serial ATA drive (8 MB cache)

2nd hard drive, 400 GB 7200 rpm Serial ATA drive (8 MB cache) – available in Winter 2004

2nd hard drive, 36 GB 10K rpm Serial ATA drive (8 MB cache)

2nd hard drive, 74 GB 10K rpm Serial ATA drive (8 MB cache)

2nd hard drive, 73 GB 10K Ultra320 SCSI drive

2nd hard drive, 300 GB 10K Ultra320 SCSI drive

2nd hard drive, 36 GB 15K Ultra320 SCSI drive

2nd hard drive, 73 GB 15K Ultra320 SCSI drive

2nd hard drive, 146 GB 15K Ultra320 SCSI drive

QuickSpecs

HP Workstation xw6200

Standard Features - Custom Components

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 2

3rd Hard Disk Drive

–

One of the following

3rd hard drive, 73 GB 10K Ultra320 SCSI drive

3rd hard drive, 300 GB 10K Ultra320 SCSI drive

3rd hard drive, 36 GB 15K Ultra320 SCSI drive

3rd hard drive, 73 GB 15K Ultra320 SCSI drive

3rd hard drive, 146 GB 15K Ultra320 SCSI drive

Drive controllers

Integrated serial ATA controller

Optional Ultra 320 SCSI controller (required if HDs are SCSI) – basic

Optional Ultra 320 SCSI controller (required if HDs are SCSI) – advanced, with RAID support and external connector

Memory

–

One of the following

256 MB DDR-2 PC2-3200 (400 MHz) ECC Registered (1 x 256 MB)

512 MB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 256 MB)

1 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 512 MB)

2 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 1 GB)

2 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 512 MB)

3 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 1 GB + 2 x 512 MB)

4 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 2 GB)

4 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 1 GB)

6 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 2 GB + 2 x 1 GB)

8 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 2 GB)

Removable Storage

1.44-MB Diskette Drive

48X CD-ROM Drive

48X/32X/48X CD-RW Drive

16X/40X DVD-ROM Drive

48X/32X/48X/16X Combo CD-RW/DVD-ROM Drive

8X DVD+R/RW Drive

2nd Removable Storage

48X/32X/48X CD-RW Drive

16X/40X DVD-ROM Drive

48X/32X/48X/16X Combo CD-RW/DVD-ROM Drive

8X DVD+R/RW Drive

Keyboard

–

One of the following

PS/2 Standard Keyboard

USB Standard Keyboard

Mouse

–

One of the following

PS/2 2-Button Scroll Mouse

PS/2 3-Button Mouse

USB 2-Button Optical Scroll Mouse

USB 3-Button Optical Mouse

Audio

Integrated Digital AC97 audio with internal speaker

Sound Blaster Audigy 2 ZS PCI

QuickSpecs

HP Workstation xw6200

Standard Features - Custom Components

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 3

NIC

Broadcom 5782 10/100/1000 (PCI)

Graphics

NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI – up to 2 of these two cards can be integrated in the factory)

NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)

NVIDIA Quadro NVS 280 PCI Express (64 MB, VGA & DVI)

NVIDIA Quadro FX 330 PCI Express (64 MB)

ATI FireGL V3100 PCI Express (128 MB)

NVIDIA Quadro FX 1300 PCI Express (128 MB)

ATI FireGL V5100 PCI Express (128 MB)

NVIDIA Quadro FX 3400 PCI Express (256 MB)

Miscellaneous

Solenoid lock and hood sensor

IEEE 1394 PCI Card

Software

Symantec Norton AntiVirus 2004 (optional)*

HP Performance Tuning Framework*

Altiris Recovery*

HP Client Manager Software v6.0*

* Not available with Linux Operating System

QuickSpecs

HP Workstation xw6200

Standard Features - Custom Components

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 4

Operating System (choice)

Microsoft Windows XP Professional*

OR Red Hat Enterprise Linux Workstation 3 Update 2 (32-bit only)

OR HP Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions on xw8200, xw6200, xw4200)

Form factor

Minitower

Color

Carbonite/Alloy metallic

System Board Form Factor

Non-standard ATX

Processor

Single or dual Intel Xeon processors (Nocona) with EM64T and Hyper-Threading Technology

CPU Bus Speed Supported

800 MHz FSB

Standard L2 Cache

1 MB L2 cache

Chipset

Intel E7525

Memory Expansion Slots

4 DIMM's

Memory Type Supported

DDR-2 (ECC registered)

Memory Speed Supported

DDR-2 Synch DRAM PC2-3200 (400 MHz) Registered ECC

Maximum Memory

8 GB (4 DIMMs slots, 2 GB DIMMs required to meet maximum configurations)

Network controller

Integrated Broadcom 5751 10/100/1000 for HP

Audio

Integrated AC'97 digital audio with S/PDif 6-channel pass-through, stereo microphone, and Yamaha XG Lite Softsynth

support

PCI slots

4 PCI slots (full-height)

1 PCI Express (x8 mechanically, x4 electrically)

1 PCI Express x16 graphics

AGP slot

none

Bays

Total Bays = 5

Internal Bays

Two 3.5 inch bays with acoustic dampening rail assemblies

External Bays

Two 5.25 inch full length 2003 mm maximum device depth (top bay is limited to 198 mm depth when optional

smart cover solenoid lock is installed). Bottom bay can be converted to an internal 3.5 inch 3rd Hard Drive bay

using optional bracket

One 3.5 inch bay for optional floppy drive

Parallel Port

Serial Port

Front I/O

2 USB 2.0, Headphone, Microphone, optional IEEE 1394

Rear I/O

6 USB 2.0, 1 standard serial port, 1 parallel port, PS/2 keyboard and mouse, 1 RJ-45 to integrated Gigabit LAN, Audio

In, Audio Out, Mic In

USB Keyboard

Optional

USB Mouse

Optional

PS/2 Keyboard

PS/2 Mouse

Chassis Dimensions

(H x W x D)

17.3 x 6.5 X 17.3 in (44.1 x 16.5 x 44.0 cm)

System weight

Standard config – 35 lb

Shipping weight

Varies by region

Temperature

Operating

40° to 95° F (5° to 35° C)

Non-operating

-40° to 140° F (-40° to 60° C)

Humidity

Operating

8% to 85%

Non-operating

8% to 90%

Maximum Altitude

(nonpressurized)

Operating

10,000 ft (3,000 m)

Non-operating

30,000 ft (9,100 m)

Power Supply

500W wide-ranging, active Power Factor Correction

Interfaces Supported

1 SATA interface (2 serial-ATA connectors), 1 EIDE interface (2 EIDE connectors) for optical drives, optional multi-

bay interface

Hard Drive Controller (PCI)

Supported

Ultra160 or Ultra320, or SATA RAID, or Ultra320 RAID

QuickSpecs

HP Workstation xw6200

Standard Features - Specs

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 5

Preinstalled Software

HP Client Manager Software v6.0*

Altiris Local Recovery*

Alert Standard Format specification*

Norton AntiVirus 2004 (optional preinstall)*

CD/DVD software dependent on optical drive choices

* Not available on Linux

QuickSpecs

HP Workstation xw6200

Standard Features - Specs

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 6

xw6200X/XD2.8/B80/

H1.0/280E/dF/s

Processor

Intel Xeon processor 2.80 GHz 1 MB/800 MHz FSB with EM64T

Microsoft Windows XP Professional

Cache Memory

1 MB L2

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

80 GB SATA/150 7200 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative

graphics card options should be ordered separately - they are listed below:

NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)

NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)

NVIDIA Quadro FX 330 PCI Express (64 MB)

ATI FireGL V3100 PCI Express (128 MB)

NVIDIA Quadro FX 1300 PCI Express (128 MB)

ATI FireGL V5100 PCI Express (128 MB) (available September 2004)

NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD2.8/B80/H1.0/280E/dF/s Country Code Key

N. America

PD896AW#ABA

Switzerland

(German/French)

PD896AW#AR8

Fr. Canadian

PD896AW#ABC

Switzerland

(Italian/English)

PD896AW#ACN

L. America

PD896AW#ABM

Dutch

PD896AW#ABH

Japan

(English)

PD896AW#ACF

Denmark

PD896AW#ACE

Japan

(Japanese)

PD896AW#ABJ

Asia/Pacific

(English)

PD896AW#AB4

PD896AW#ABU

Korea

PD896AW#AB1

Germany

PD896AW#ABD

China

PD896AW#AB2

France

PD896AW#ABF

Taiwan

PD896AW#AB0

Italy

PD896AW#ABZ

India

PD896AW#ACJ

Spain

PD896AW#ABE

Australia

PD896AW#ABG

Europe

PD896AW#AK6

Thailand

PD896AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 7

xw6200X/XD3.2/C74/

H1.0/280E/dF/s

Processor

Intel Xeon processor 3.20 GHz 1 MB/800 MHz FSB with EM64T

Microsoft Windows XP Professional

Cache Memory

1 MB L2

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

74 GB SATA/150 10,000 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative

graphics card options should be ordered separately - they are listed below:

NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)

NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)

NVIDIA Quadro FX 330 PCI Express (64 MB)

ATI FireGL V3100 PCI Express (128 MB)

NVIDIA Quadro FX 1300 PCI Express (128 MB)

ATI FireGL V5100 PCI Express (128 MB) (available September 2004)

NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.2/C74/H1.0/280E/dF/s Country Code Key

N. America

PM199AW#ABA

Switzerland

(German/French)

PM199AW#AR8

Fr. Canadian

PM199AW#ABC

Switzerland

(Italian/English)

PM199AW#ACN

L. America

PM199AW#ABM

Dutch

PM199AW#ABH

Japan

(English)

PM199AW#ACF

Denmark

PM199AW#ACE

Japan

(Japanese)

PM199AW#ABJ

Asia/Pacific

(English)

PM199AW#AB4

PM199AW#ABU

Korea

PM199AW#AB1

Germany

PM199AW#ABD

China

PM199AW#AB2

France

PM199AW#ABF

Taiwan

PM199AW#AB0

Italy

PM199AW#ABZ

India

PM199AW#ACJ

Spain

PM199AW#ABE

Australia

PM199AW#ABG

Europe

PM199AW#AK6

Thailand

PM199AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 8

xw6200X/XD3.2+/B80/

H1.0/280E/dF/s

Processor

Dual Intel Xeon processors 3.20 GHz 1 MB/800 MHz FSB with EM64T

Microsoft Windows XP Professional

Cache Memory

1 MB L2 per processor

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

80 GB SATA/150 7200 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative

graphics card options should be ordered separately - they are listed below:

NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)

NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)

NVIDIA Quadro FX 330 PCI Express (64 MB)

ATI FireGL V3100 PCI Express (128 MB)

NVIDIA Quadro FX 1300 PCI Express (128 MB)

ATI FireGL V5100 PCI Express (128 MB) (available September 2004)

NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.2+/B80/H1.0/280E/dF/s Country Code Key

N. America

PD898AW#ABA

Switzerland

(German/French)

PD898AW#AR8

Fr. Canadian

PD898AW#ABC

Switzerland

(Italian/English)

PD898AW#ACN

L. America

PD898AW#ABM

Dutch

PD898AW#ABH

Japan

(English)

PD898AW#ACF

Denmark

PD898AW#ACE

Japan

(Japanese)

PD898AW#ABJ

Asia/Pacific

(English)

PD898AW#AB4

PD898AW#ABU

Korea

PD898AW#AB1

Germany

PD898AW#ABD

China

PD898AW#AB2

France

PD898AW#ABF

Taiwan

PD898AW#AB0

Italy

PD898AW#ABZ

India

PD898AW#ACJ

Spain

PD898AW#ABE

Australia

PD898AW#ABG

Europe

PD898AW#AK6

Thailand

PD898AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 9

xw6200X/XD3.4/C74/

H1.0/280E/dF/s

Processor

Intel Xeon processor 3.40 GHz 1 MB/800 MHz FSB with EM64T

Microsoft Windows XP Professional

Cache Memory

1 MB L2

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

74 GB SATA/150 10,000 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative

graphics card options should be ordered separately - they are listed below:

NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)

NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)

NVIDIA Quadro FX 330 PCI Express (64 MB)

ATI FireGL V3100 PCI Express (128 MB)

NVIDIA Quadro FX 1300 PCI Express (128 MB)

ATI FireGL V5100 PCI Express (128 MB) (available September 2004)

NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.4/C74/H1.0/280E/dF/s Country Code Key

N. America

PM200AW#ABA

Switzerland

(German/French)

PM200AW#AR8

Fr. Canadian

PM200AW#ABC

Switzerland

(Italian/English)

PM200AW#ACN

L. America

PM200AW#ABM

Dutch

PM200AW#ABH

Japan

(English)

PM200AW#ACF

Denmark

PM200AW#ACE

Japan

(Japanese)

PM200AW#ABJ

Asia/Pacific

(English)

PM200AW#AB4

PM200AW#ABU

Korea

PM200AW#AB1

Germany

PM200AW#ABD

China

PM200AW#AB2

France

PM200AW#ABF

Taiwan

PM200AW#AB0

Italy

PM200AW#ABZ

India

PM200AW#ACJ

Spain

PM200AW#ABE

Australia

PM200AW#ABG

Europe

PM200AW#AK6

Thailand

PM200AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 10

Autres manuels pour Xw6200 - Workstation - 2 GB RAM

Table des matières

Autres manuels HP Ordinateur de bureau

HP Compaq CQ1569x LCD MONITOR Instructions de montage

HP Presario SR5500 - Desktop PC Manuel utilisateur

HP Compaq dc7100 DT Manuel d'utilisation et d'entretien

HP Vectra VL5 5 Manuel utilisateur

HP Z1 Manuel utilisateur

HP Envy TouchSmart 23 All-in-One Instructions d'installation

HP TV Manuel utilisateur

HP Vectra VL800 Manuel utilisateur

HP Omni 200-5300 - Desktop PC Manuel utilisateur

HP P Class 450/500/550/600/650/700/750 Manuel utilisateur

HP Xw4550 - Workstation - 2 GB RAM Manuel d'utilisation et d'entretien

HP Neoware e370 - Thin Client Manuel utilisateur

HP Presario All-in-One CQ1-1100 - Desktop PC Fiche technique

HP 100B - All-in-One PC Manuel d'utilisation

HP Z200 - Small Form Factor Workstation Manuel utilisateur

HP Compaq Presario Manuel utilisateur

HP Pavilion 364 Manuel utilisateur

HP Pro 3000 Series Instructions d'utilisation

HP Compaq Presario Manuel utilisateur

HP Pavilion x360 15 Manuel

HP TouchSmart IQ524 Manuel utilisateur

HP Pavilion t469 Manuel utilisateur

HP ProDesk 600 G1 Tower Guide de configuration

HP Compaq Presario Manuel

Manuels Ordinateur de bureau populaires d'autres marques

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Dell

Dell Alienware Area-51 R4 Manuel utilisateur
