HP TOUCHSMART 9100 Instructions d'utilisation

Touch-enabled 23-inch diagonal widescreen BrightView LCD

with tilt adjustment

Volume buttons

Bluetooth module (optional)

10.

Mute button

Dual wireless antennas

11.

HP TouchSmart button

Dual microphone array

12.

Memory card reader

Webcam

13.

IR Receiver and LED (select models only)

Power button and LED

14.

High-performance 2.0 speakers

Slot-load optical drive (optional)

15.

HP low-profile keyboard with numeric keypad

Drive activity LED

16.

HP optical mouse

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Overview

DA - 13434 North America — Version 8 — December 12, 2011

Page 1

DVI-D video out

10.

IR Emitter (Blaster) output (optional)

IEEE 1394 port

11.

(2) USB ports

(3) USB ports

12.

Line in

RJ-45 Gigabit Ethernet port

13.

Headphone jack

Digital audio out (SPDIF)

14.

Optional wireless keyboard/mouse receiver

Audio line out

15.

Kensington Lock slot

TV coax in (optional)

16.

Power connector

S-video input (optional)

17.

Adjustable tilt stand

Stereo audio in (optional)

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Overview

DA - 13434 North America — Version 8 — December 12, 2011

Page 2

At A Glance

Genuine Windows 7 Professional Edition

Touch-enabled 23-inch diagonal widescreen BrightView LCD with glass covering

Integrated all-in-one form factor

Intel® Core™ 2 Duo processor, NVIDIA MCP7A-J chipset, and NVIDIA integrated or discrete graphics

Integrated Gigabit Network Connection (10/100/1000 NIC)

Wireless connectivity:

Integrated 802.11 b/g/n draft 2.0 wireless LAN module

Bluetooth® 2.1

Integrated webcam, dual microphone array, and premium stereo speakers

Optional TV Tuner

Up to 8 GB of DDR3 SDRAM supported, dual channel memory support

Up to 500 GB hard drive, or 64 GB Solid State Drive

Slot-load Blu-ray Combo Drive (Blu-ray Reader/DVD Burner) or SuperMulti DVD Burner

6-in-1 Media Card Reader

HP TouchSmart software suite for instant access to calendar, internet, notes, and multimedia content

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Overview

DA - 13434 North America — Version 8 — December 12, 2011

Page 3

Processors

Intel Core 2 Duo Processor P7570 (2.26 GHz, 3 MB L2 cache, 1066 MHz FSB)*

Intel Core 2 Duo Processor T6570 (2.10 GHz, 2 MB L2 cache, 800 MHz FSB)*

* Intel's numbering is not a measurement of higher performance.

Operating System

Preinstalled

Genuine Windows 7 Professional Edition 64*

Genuine Windows 7 Professional Edition 32*

* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the

Windows 7 software and take full advantage of Windows 7 functionality.

See

http://www.microsoft.com/windows/windows-7/

for details.

Chipset

NVIDIA MCP7A-J chipset

Graphics

Integrated NVIDIA GeForce G200

Discrete NVIDIA GeForce GT230, 1 GB

Display

Touch-enabled 23-inch diagonal widescreen BrightView LCD with glass covering,

tilt adjustment between 10º and 40º from vertical

Resolution

1920 x 1080 resolution (16:9)

Contrast ratio

1000:1

Image brightness

300 nits typical

Vertical viewing angle

160 degrees

Horizontal viewing angle

160 degrees

Memory

Standard

PC3-10600 DDR3 non-ECC SDRAM (runs at 1333 MHz)

Two 200-pin SODIMM slots supporting dual channel memory

2 GB (1 GB x 2)

4 GB (2GB x 2)

8 GB (4GB x 2)

Dual-channel

Maximized dual-channel performance requires SODIMMs of the same size and

speed in both memory slots.

NOTE:

Full availability of 4 GB or more of memory requires a 64-bit operating system. With Windows 32-

bit operating systems, the amount of usable memory is dependent upon your configuration, so that above

3 GB all memory may not be available due to system resource requirements.

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Standard Features

DA - 13434 North America — Version 8 — December 12, 2011

Page 4

Communications

Realtek 8111DL Ethernet Connection

Integrated 10/100/1000 NIC*

802.11 PCIe Mini Wireless Module

Support for 802.11 b, g, and n

Up to 300 mbps data rate

Built-in dual antennas

Bluetooth Wireless Technology (optional)

Bluetooth Specification v2.1 compliant

Works with a wide range of Bluetooth devices

* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for

Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,

connection to a Gigabit Ethernet server and network infrastructure is required.

Keyboard

Standard HP USB

Keyboard

104 keys plus special keys for Mute, Volume Up, Volume Down. Separate

numeric keypad.

Cable length 51 in (130 cm)

Optional HP Wireless

Keyboard

104 keys plus special keys for Mute, Volume Up, Volume Down

Separate numeric keypad.

Operates at ~ 2.4 GHz and supports a working distance of up to 32 ft (10 m).

Pointing Device

Standard HP USB Optical

Scroll Mouse

Two buttons with scroll wheel acting as third button.

Cable length 69 in (175 cm)

Optional HP Wireless

Optical Scroll Mouse

Two buttons with scroll wheel acting as third button.

Operates at ~ 2.4 GHz and supports a working distance of up to 32 ft (10m).

Storage

Hard Drive

3.5-inch, 7200 rpm, 3.0 Gb/s SATA Hard Drive:

250 GB

500 GB

or 3.5-inch SATA Solid State Drive:

64 GB

Optical Drive

Slot-load Blu-ray Combo Drive

Read: 4x max BD-ROM, 8x max DVD-ROM, 24x max CD-ROM

Write: 8x max DVD±R, 4x max DVD±R DL, 4x max DVD±RW,

5x max DVD-RAM, 16x max CD-R, 10x max CD-RW

Slot-load SuperMulti DVD Burner

Read: 8x max DVD-ROM, 24x max CD-ROM

Write: 8x max DVD±R, 6x max DVD±R DL, 8x max DVD+RW,

6x max DVD-RW, 5x max DVD-RAM, 24x max CD-R,

24x max CD-RW

Option for no optical drive

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Standard Features

DA - 13434 North America — Version 8 — December 12, 2011

Page 5

Interfaces

6-in-1 Media Card Reader

Supports Secure Digital (SD, SDHC), MultiMediaCard,

Picture Card, Memory Stick, Memory Stick Pro

DVI-D Video out

One

IEEE 1394 port

One

USB 2.0

Five (2 front, 3 rear)

Line in

One

Audio headphone jack

One

Audio line out

One

Audio digital out (SPDIF)

One

Power connector

One

RJ-45/Ethernet

One

IR Emitter (Blaster) out

One (with TV tuner option only)

S-Video in

One (with TV tuner option only)

Stereo audio in

One (with TV tuner option only)

TV Coax connector

One (with TV tuner option only)

Audio/Visual

High Definition Audio support

Integrated high-performance 2.0 speakers

Integrated dual-microphone array

Volume control and mute buttons

Stereo headphone jack

Stereo line in

Stereo line out

Audio digital out (SPDIF)

Integrated VGA webcam

Up to 30 frames/sec

640x480 resolution

Designed for low light conditions

Optional TV Entertainment Experience (configurable)

Hybrid ATSC/NTSC, Clear QAM, Over the Air TV Tuner, HW encoded

Hybrid PAL/DVB-T, Over the Air TV Tuner, HW encoded

Hybrid PAL/DMB-T, Over the Air TV Tuner, HW encoded, Hong Kong/China

Dual channel ISDB-T/ISDB-S, Over the Air TV Tuner, HW encoded, Japan

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Standard Features

DA - 13434 North America — Version 8 — December 12, 2011

Page 6

Software

Preinstalled software

(varies by country)

HP Power Manager

HP TouchSmart Browser

HP TouchSmart Calendar

HP TouchSmart Canvas

HP TouchSmart Clock

HP TouchSmart DVD

HP TouchSmart Hulu

HP TouchSmart Live TV

HP TouchSmart Music

HP TouchSmart Video

HP Touch Smart Photo

HP TouchSmart Netflix

HP TouchSmart RSS Reader

HP TouchSmart Twitter

HP TouchSmart Weather

HP TouchSmart Webcam

HP Total Care Advisor

PDF Complete

McAfee Total Protection*

Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition

* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to

receive updates. First update included. Subscription required for updates thereafter.

HP Power Manager

Provides real-time reporting of how system settings impact the energy consumed by the PC and the

potential savings over time.

SMBIOS

System Management BIOS, previously known as DMI BIOS, is used to store system management

information.

Security

Kensington lock

Power Supply

Integrated graphics: external 120-watt power supply, 87% efficiency, active PFC

Discrete graphics: external 150-watt power supply, 87% efficiency, active PFC

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Standard Features

DA - 13434 North America — Version 8 — December 12, 2011

Page 7

Service and Support

On-site Warranty

Note 1:

One-year (1-1-1) limited warranty delivers one year of on-site, next business-

day

Note 2

service for parts and labor and includes free telephone support

Note 3

24 x 7. Global coverage

Note

ensures that any product purchased in one country and transferred to another non-restricted country will

remain fully covered under the original warranty and service offering. One-year onsite and labor are not

available in all countries. To choose the right level of service for your HP product, use the HP Care Pack

Services Lookup Tool at:

http://www.hp.com/go/lookuptool

. Additional HP Care Pack Services information

by product is available at:

http://www.hp.com/hps/carepack

NOTE 1

: Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other

warranty variations may be offered in your region.

NOTE 2:

On-site service may be provided pursuant to a service contract between HP and an authorized HP

third-party provider, and is not available in certain countries. Global service response times are based on

commercially reasonable best effort and may vary by country.

NOTE 3:

Technical telephone support applies only to HP-configured Compaq and third-party HP-qualified

hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Standard Features

DA - 13434 North America — Version 8 — December 12, 2011

Page 8

Memory

HP 1GB DDR3-1333 (PC3-10600) SODIMM

VH639AA

HP 2GB DDR3-1333 (PC3-10600) SODIMM

VH640AA

HP 4GB DDR3-1333 (PC3-10600) SODIMM

VH641AA

Graphics

HP DisplayPort To DVI-D Adapter

FH973AA

HP DisplayPort To VGA Adapter

AS615AA

HP DisplayPort Cable Kit

VN567AA

HP DisplayPort To HDMI Adapter

BP937AA

HP DisplayPort to Dual Link DVI Adapter

NR078AA

HP USB Graphics Adapter

NL571AA

Internal Storage

HP 250-GB SATA 3.0-Gb/s Hard Drive

PY278AA

HP 500-GB SATA 3.0-Gb/s Hard Drive

KW347AA

HP 1-TB SATA 3.0-Gb/s Hard Drive

VU353AA

HP 500GB SATA 6.0Gb/s Hard Drive

QK554AA

HP 1TB SATA 6.0Gb/s Hard Drive

QK555AA

64 GB Solid State Drive

VG679AA

Input Devices

HP USB 2-Button Optical Scroll Mouse

DC172B

HP USB 2-Button Laser Scroll Mouse

GW405AA

HP Mouse Pad

AT485AA

HP USB PS/2 Washable Scroll Mouse

BM866AA

HP USB Standard Keyboard

DT528A#ABA

HP USB Standard Keyboard with USB Ports

BT330AA#ABA

HP USB CCID Smartcard Keyboard

BV813AA#ABA

HP 2.4GHz Wireless Keyboard & Mouse

NB896AA#ABA

HP USB Mini Keyboard

AS601AA#ABA

HP USB PS2 Washable Keyboard

VF097AA#ABA

HP USB PS2 Washable Keyboard & Mouse

BU207AA#ABA

HP Slim Line 2.4GHz Wireless Keyboard & Mouse

BL549AA#ABA

Multimedia

HP Thin USB Powered Speakers

KK912AA

Security

Kensington Security Lock

PC766A

HP Keyed Cable Lock

BV411AA

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Options

DA - 13434 North America — Version 8 — December 12, 2011

Page 9

Miscellaneous

Belkin Promo 7-Outlet Surge Protector

AG290AA#ABA

Belkin Network Cable

AH122AA

Belkin Firewire (1394) Cable

AH123AA

Belkin Starter Kit: Surge Protector, Patch Cable, Printer Cable

RT174AA

Belkin USB to Serial Adapter

EM449AA

Vesa Wall Mount Adapter

VK554AA

QuickSpecs

HP TouchSmart 9100 All-in-One PC

Options

DA - 13434 North America — Version 8 — December 12, 2011

Page 10

Autres manuels pour TOUCHSMART 9100

Table des matières

Autres manuels HP Ordinateur de bureau

HP Pro 1000 Series Instructions d'installation

HP dx2355 - Microtower PC Guide de configuration

HP Workstation xw3100 Manuel d'utilisation et d'entretien

HP Compaq Presario Manuel utilisateur

HP s3600f - Pavilion - Slimline Manuel d'utilisation et d'entretien

HP Compaq Elite 8000 CMT Manuel utilisateur

HP Z200 - Small Form Factor Workstation Guide de référence

HP ProOne 400 G1 Manuel d'utilisation et d'entretien

HP Compaq Business PC dc7600 Series Instructions de montage

HP Compaq Pro 4300 Guide de configuration

HP Pavilion A6355 Manuel utilisateur

HP 300 Instructions d'utilisation et d'installation

HP Pavilion t134 Manuel utilisateur

HP TouchSmart IQ700 - Desktop PC Instructions d'installation

HP A524x - Pavilion - 512 MB RAM Manuel d'instructions

HP Visualize c100 Comment utiliser

HP A6300f - Pavilion - 2 GB RAM Fiche technique

HP A320m - Pavilion - 256 MB RAM Manuel utilisateur

HP Kayak XW 04xx Manuel utilisateur

HP Pavilion p6730f Manuel utilisateur

HP Spectre x2 Manuel

HP s7700n - Pavilion - Slimline Fiche technique

HP Xw4300 - Workstation - 2 GB RAM Manuel utilisateur

HP Xw9300 - Workstation - 1 GB RAM Manuel d'utilisation et d'entretien

Manuels Ordinateur de bureau populaires d'autres marques

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Dell

Dell Alienware Area-51 R4 Manuel utilisateur
