HP EliteOne 800 G1 All-in-One Business PC

FRONT

Dual microphone array (only on models with Webcam)

2.0 MP Webcam (optional)

Webcam Activity LED

23-inch IPS Full HD capable screen (with or without projected capacitive touch panel option)

Increase brightness

Decrease brightness

Mute microphone

Increase volume

High performance stereo speakers

10.

Reduce volume

11.

Mute speaker

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Overview

DA - 14652 North America — Version 13 — November 11, 2013

Page 1

HP EliteOne 800 G1 All-in-One Business PC

SIDE

Hard disc drive activity LED

HP SD media card reader (optional)

(2) USB 3.0 ports, including 1 fast charging port

Microphone/line in jack

Headphone/line out jack

Tray-load optical disc drive (optional)

Optical disc drive eject button

Optical disc drive activity LED

Power button

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Overview

DA - 14652 North America — Version 13 — November 11, 2013

Page 2

HP EliteOne 800 G1 All-in-One Business PC

REAR/PORTS (BEHIND SECURITY COVER)

Basic Stand

PS/2 mouse connector

Access panel latches

PS/2 keyboard connector

I/O security cover latch

10.

(2) USB 3.0 ports

Security Screw hole

11.

RJ-45 Gigabit Ethernet port

Security lock slot

12.

(2) USB 3.0 ports

Power connector

13.

DisplayPort connector

Serial port

14.

Stereo line out

* Can be configured with no stand, basic stand, or height adjustable/reclining stand

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Overview

DA - 14652 North America — Version 13 — November 11, 2013

Page 3

At A Glance

Windows 7 or Windows 8

UEFI BIOS developed and engineered by HP for better security, manageability and software image stability

Integrated All-in-One form factor

23-inch IPS (1920 x 1080) diagonal widescreen WLED backlit anti-glare LCD, with or without Projected Capacitive Touch Panel

option

Landscape or portrait display orientation - with height adjustable stand or VESA mount

Can be configured with no stand, basic stand, or height adjustable/reclining stand

Intel® Q87 chipset

Intel® 4th generation Core™ processors

Intel® vPro™ Technology available with select processors

Integrated Intel® HD Graphics

Optional MXM Discrete graphics

Integrated Intel® Gigabit Network Connection I217LM

Optional wireless connectivity:

Intel® Advanced-N 6205 WLAN - Intel® 802.11 a/b/g/n

Intel® Dual Band Wireless-N 7260 - Intel 802.11 a/b/g/n

WLAN and Bluetooth Combo Card - HP 802.11 a/b/g/n and Bluetooth® 4.0

WiDi support (with Intel® 6205 WLAN and Intel® HD Graphics)

Optional Near Field Communication (NFC)

Optional Integrated 2.0 MP Webcam & Dual Microphone Array

High performance integrated stereo speakers

DTS Studio Sound™

Up to 16 GB of DDR3 SDRAM, dual channel memory support, two SODIMM slots

Support for up to 3 storage drives (2 SATA, 1 mSATA) with RAID support

Up to 1TB SATA Hard Drive, up to 160GB Solid State Drive, 500 GB Self-Encrypting Drive, 256GB Self-Encrypting Solid State Drive,

and 1TB Solid State Hybrid Drive

Optional Intel® Smart Response Technology support with 32GB mSATA SSD Flash Cache Module

Optional slim Tray-load SuperMulti DVD Writer or DVD-ROMOptical Disc Drive

Optional SD Media Card Reader

Serial port

DisplayPort out

Integrated VESA 100 x 100 mounting holes

Lockable rear access panel with intrusion sensor

ENERGY STAR® qualified. EPEAT® registered where applicable/supported. See

www.epeat.net

for registration status by country.

CCC, CECP & SEPA Certified

Optimized for Microsoft Lync

TCO AiO and TCO Edge

Low Halogen

Arsenic Free

Protected by HP Services, including warranties up to 5-5-5 (terms and conditions vary by country; certain restrictions and

exclusions apply)

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Overview

DA - 14652 North America — Version 13 — November 11, 2013

Page 4

OPERATING SYSTEM

Preinstalled

Windows 8 Professional (64-bit)

Windows 8 (64-bit)

Windows 7 Ultimate (32-bit)** (LAR only)

Windows 7 Ultimate (64-bit)

Windows 7 Professional (32-bit)

Windows 7 Professional (64-bit)

Windows 7 Professional (32-bit) (available through downgrade rights from Windows 8 Pro)

***

Windows 7 Professional (64-bit) (available through downgrade rights from Windows 8 Pro)

***

Windows 7 Home Premium (32-bit)

(LAR only)

Windows 7 Home Premium (64-bit)

Windows 7 Home Basic (32-bit)

(LAR only)

FreeDOS 2.0

Novell SUSE Linux Enterprise Desktop 11

*Not all features are available in all editions of Windows 8. Systems may require upgraded and/or

separately purchased hardware, drivers and/or software to take full advantage of Windows 8

functionality. See

http://www.microsoft.com

**Not all features are available in all editions of Windows 7. This system may require upgraded and/or

separately purchased hardware to take full advantage of Windows® 7 functionality. See

http://www.microsoft.com/windows/windows-7/

for details.

***This system is preinstalled with Windows 7 Pro software and also comes with a license and media

for Windows 8 Pro software. You may only use one version of the Windows software at a time.

Switching between versions will require you to uninstall one version and install the other version. You

must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid

loss of your data.

PROCESSOR

Intel® 4th Generation Core™ i7 Processors

Intel® Core™ i7-4770S

Up to 3.9 GHz Max. Turbo Frequency (3.1 GHz base frequency), 8 MB cache, 4 cores, 8 threads

Intel® HD Graphics 4600

Supports DDR3 memory up to 1600 MT/s data rate

Supports Intel® vPro Technologies and Intel's® Stable Image Platform Program (SIPP)

Intel® 4th Generation Core™ i5 Processors

Intel® Core™ i5-4670S

Up to 3.8 GHz Max. Turbo Frequency (3.1 GHz base frequency), 6 MB cache, 4 cores, 4 threads

Intel® HD Graphics 4600

Supports DDR3 memory up to 1600 MT/s data rate

Supports Intel® vPro Technologies and Intel's® Stable Image Platform Program (SIPP)

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14652 North America — Version 13 — November 11, 2013

Page 5

Intel® Core™ i5-4570S

Up to 3.6 GHz Max. Turbo Frequency (2.9 GHz base frequency), 6 MB cache, 4 cores, 4 threads

Intel® HD Graphics 4600

Supports DDR3 memory up to 1600 MT/s data rate

Supports Intel® vPro Technologies and Intel's® Stable Image Platform Program (SIPP)

Intel® 4th Generation Core™ i3 Processors

Intel® Core™ i3-4340

3.6 GHz base frequency, 4 MB cache, 2 cores, 4 threads

Intel® HD Graphics 4600

Supports DDR3 memory up to 1600 MT/s data rate

Intel® Core™ i3-4330

3.5 GHz base frequency, 4 MB cache, 2 cores, 4 threads

Intel® HD Graphics 4600

Supports DDR3 memory up to 1600 MT/s data rate

Intel® Core™ i3-4130

3.4 GHz base frequency, 3 MB cache, 2 cores, 4 threads

Intel® HD Graphics 4600

Supports DDR3 memory up to 1600 MT/s data rate

Intel® 4th Generation Pentium™ Processors

Intel® Pentium™ G3430

3.3 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Supports DDR3 memory up to 1600 MT/s data rate

Intel® Pentium™ G3420

3.2 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Supports DDR3 memory up to 1600 MT/s data rate

Intel® Pentium™ G3220

3.0 GHz base frequency, 3 MB cache, 2 cores, 2 threads

Intel® HD Graphics

Supports DDR3 memory up to 1300 MT/s data rate

CHIPSET

Intel® 8 Series (Q87) Chipset

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14652 North America — Version 13 — November 11, 2013

Page 6

INTEL® VPRO TECHNOLOGY CAPABLE

Intel® Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units configured with select

processors, and a preinstalled Windows operating system. It provides advances in remote manageability, security, energy

efficient performance, and wireless connectivity. Intel® Active Management Technology 9.0 (iAMT) offers an advanced set of

remote management features and functionality which provides network administrators the latest and most effective tools to

remotely discover, heal, and protect networked client systems regardless of the system's health or power state. AMT 9.0 includes

the following advanced management functions:

Power Management (on, off, reset)

Hardware Inventory (includes BIOS and firmware revisions

Hardware Alerting

Agent Presence

System Defense Filters

SOL/IDER

Cisco NAC/SDN Support

ME Wake-on-LAN

DASH 1.1 compliance

IPv6 Support

Fast Call for Help - a client inside or outside the firewall may initiate a call for help via BIOS screen, periodic connections, or

alert triggered connection

Remote Scheduled Maintenance - pre-schedule when the PC connects to the IT or service provider console for maintenance.

Remote PCs can get required patches, be inventoried, etc by connecting to their IT console or Service Provider when it's

convenient

Remote Alerts - automatically alert IT or service provider if issues arise

Access Monitor - Provides oversight into Intel® AMT actions to support security requirements

PC Alarm Clock

Microsoft NAP Support

Host Base set-up and configuration

Management Engine (ME) firmware roll back

Wireless AMT functionality on Desktop (WoDT)

Enhanced KVM resolution

* Requires Intel® Advanced-N 6205 WLAN 802.11a/b/g/n PCIe Minicard Wireless Module

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14652 North America — Version 13 — November 11, 2013

Page 7

INTEL® STANDARD MANAGEABILITY

Includes DASH 1.0/1.1 compliance plus:

System Defense

Agent Presence

SOL/IDE Redirection

CISCO NAC/SDN support

ME Wake on LAN

Host Based Configuration

ME Firmware Rollback

IPv6 Support

DASH 1.0/1.1 compliance:

Boot Control

HW Inventory

SW Inventory

Power State Management

HW Alerting

SMBIOS

System Management BIOS, previously known as DMI BIOS, is used to store system management information.

GRAPHICS

Integrated

Intel® HD Graphics 4600

Graphics controller

Intel® Processor Graphics

DisplayPort

Multi-Stream support (supports up to 2 external displays)

Memory

Up to 1.8GB DDR3

Supported Graphics APIs

DX11.1, OpenGL 4.0, OpenCL 1.2, full 1080p Blu-Ray Disc

(H264) playback in hardware

Discrete (optional)

AMD® Radeon HD 7650A 2GB DDR3 MXM Graphics

Graphics controller

AMD® Radeon HD 7650A

DisplayPort

Multi-Stream support (supports up to 4 external displays at

1920x1080)

Core clock

600MHz max

Memory clock

800MHz max

Memory frame buffer

2GB, DDR3, 128-bit wide

Memory

2GB DDR3

Supported Graphics APIs

DX11, OpenGL 4.1, OpenCL 1.1, full 1080p Blu-Ray Disc (H264)

playback in hardware

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14652 North America — Version 13 — November 11, 2013

Page 8

Using the Integrated Graphics, two (2) external displays are supported via one of these methods:

Using the MXM Graphics, up to four (4) external displays are supported via one of these methods:

1) DisplayPort multi-stream monitors 'daisy-chained' together or

2) DisplayPort multi-stream hub - hub requires power through power cable provided. DisplayPort multi-stream hub

provides 4 DisplayPort ports, adapters are required for support of DVI, VGA or HDMI displays.

WIRELESS DISPLAY

WiDi support with Intel® Advanced-N 6205 WLAN or Dual Band Wireless-N 7260 (mini PCI Express) and Intel® HD graphics

Desktop system requirements for Intel® Wireless Display

System Component

Requirement

Processor

4th generation Intel® Core processor

Graphics

Intel® HD Graphics

Wireless

Intel Advanced-N 6205 WLAN

Software

Intel® My WiFi Technology and Intel® Wireless Display must be pre-installed and enabled.

OS*

Windows 7 32-bit/64-bit Home Premium, Ultimate, Professional; Windows 7 32-bit Home Basic

* Windows 8 supports Wireless Display natively

DISPLAY

Projected Capacitive Touch or Non-touch

23"diagonal IPS widescreen WLED backlit anti-glare LCD; With or without Projected Capacitive Touch Panel

option; Orientation

designed to operate in portrait or landscape

Display Panel

Type

IPS WLED Backlit LCD

Viewable image area (mm)

509.18 x 286.42

Touch Active Area (mm)

509.18 x 286.42

Screen opening (mm)

510.6 x 287.6

Native Resolution (HxV)

1920 x 1080

Aspect ratio

16:9

Pixel pitch (HxV)(mm)

0.256 x 0.256

Contrast ratio (typical)

1000:1

Brightness (typical)

Touch - 225nits (cd/m2)/ Non-Touch 250nits

(cd/m

)

Viewing angle (typical) (HxV)

179 ° x 179 °

Backlight lamp life (to half brightness)

30,000 hours minimum

Color support

Over 16 million colors

Color gamut (typical)

72%

Anti-glare

Yes

Default color temperature

Warm (6500K)

NOTE:

All performance specifications represent the typical specifications provided by HP's

component manufacturers; actual performance may vary either higher or lower.

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14652 North America — Version 13 — November 11, 2013

Page 9

Projected Capacitive Touch panel is not anti-glare

With Projected Capacitive Touch Panel

Without Projected Capacitive Touch Panel

Basic Stand:

Tilt Angle

-5° to +30°

Rotation

360° swivel

Height Adjustable /Reclining Stand:

Vertical Adjustment

Up to 110 mm

Recline Angle

Low position sliding height adjustment => -5°

to +60°

Tilt Angle

High position sliding height adjustment => -

5° to +30°

Rotation

360° swivel and portrait or landscape

orientation

WEBCAM & MIC

Optional integrated 2 MP webcam & dual microphone array; maximum resolution of 1920 x 1080

STORAGE

2.5" SATA Hard Drive

500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV

2.5" Solid State Drive

120 GB, SATA, Solid State Drive

128 GB, SATA, Solid State Drive

160 GB, SATA, Solid State Drive

2.5" Self-Encrypting Solid State Drive

128 GB, SATA, Self-Encrypting Solid State Drive

256 GB, SATA, Self-Encrypting Solid State Drive

2.5" Self-Encrypting Drive

500 GB, SATA, Self-Encrypting Drive

2.5" Solid State Hybrid Drive

500 GB, SATA, Solid State Hybrid Drive

1 TB SATA, Solid State Hybrid Drive

Optical Disc Drive

Slim Tray-load SATA DVD-ROM

Slim Tray-load SATA SuperMulti DVD Writer

No included Optical Disc Drive

QuickSpecs

HP EliteOne 800 G1 All-in-One Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 14652 North America — Version 13 — November 11, 2013

Page 10

Autres manuels pour EliteOne 800 G1

Table des matières

Autres manuels HP Ordinateur de bureau

HP 6305 SF Manuel utilisateur

HP P Elite SFF 600 G9 Instructions de montage

HP Pavilion t337k Manuel utilisateur

HP S5220F - Pavilion Slimline - Desktop PC Manuel

HP Pavilion t458d Manuel utilisateur

HP 8000f - Elite Ultra-slim Desktop PC Manuel d'utilisation et d'entretien

HP A1210n - Pavilion - 512 MB RAM Manuel utilisateur

HP Z600 - Workstation - 6 GB RAM Guide de référence

HP Pavilion a100 - Desktop PC Comment utiliser

HP Vectra VEi 8 Manuel du produit

HP Compaq 6000 Pro SFF Manuel utilisateur

HP Kayak XA Manuel utilisateur

HP Xw6400 - Workstation - 4 GB RAM Instructions d'utilisation

HP Computer Cards & Components / Motherboards Manuel utilisateur

HP Rp5700 - Point of Sale System Guide de configuration

HP Pavilion Media Center m7700 - Desktop PC Comment utiliser

HP Workstation xw8000 Manuel de la liste des pièces

HP Xw6200 - Workstation - 2 GB RAM Manuel d'utilisation et d'entretien

HP Pavilion t142 Manuel utilisateur

HP Z240 Small Form Factor Manuel

HP 3350 - Cisco NAC Appliance Mode d’emploi

HP Compaq Presario Fiche technique

HP Media Center m1100 - Desktop PC Manuel utilisateur

HP Cisco MDS 9020 - Fabric Switch Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Dell

Dell Alienware Area-51 R4 Manuel utilisateur
